Mercury V-200XRI (EFI) Outboard Motor Parts Diagram & Catalog – Free PDF Download

ACCUMULATOR

Below is the parts list for Mercury V-200XRI (EFI) ACCUMULATOR:

Position No.	Part Name	OEM Number	Supersedes
-	ACCUMULATOR	811290	811288
1	END FRAME ASSEMBLY (W/WIRES)	823059A1
2	ARMATURE ASSEMBLY	823061A1
3	PUMP ASSEMBLY	823062
4	SHELL/MAGNET ASSEMBLY	823063
5	BOLT KIT	10-823064
6	CONTROLLER	823065
7	SCREW KIT	10-823066
8	FILTER KIT	35-823067
9	RUBBER DAMPER	823068
10	RUBBER ISOLATOR	823070
11	GASKET, Reservoir	27-823071
12	SCREW KIT	10-823072
13	O-RING	25-823074
14	PLATE, Retaining	823075
15	HARNESS ASSEMBLY, Power	84-823077A1
16	COVER ASSEMBLY	823078A1
17	FILL PLUG	19-823080A1
18	HOUSING ASSEMBLY	823082
19	SCREW, (.375-16 x .250)	10-79953Q04
20	WASHER, Fiber	12-191833
21	FITTING Comment: SEE NOTE	22-823087
22	SHORT HIGH PRESSURE LINE Comment: SEE NOTE	32-823069
23	LONG HIGH PRESSURE LINE Comment: SEE NOTE	32-823073
24	SHORT LOW PRESSURE LINE	32-811524
25	LONG LOW PRESSURE LINE	32-811525

BOTTOM COWL

Below is the parts list for Mercury V-200XRI (EFI) BOTTOM COWL:

Position No.	Part Name	OEM Number	Supersedes
1	BOTTOM COWL ASSEMBLY (BLACK)(Without Decals) Comment: PORT	2197-9744A16
1	BOTTOM COWL ASSEMBLY , Gray (Without Decals) Comment: PORT	2197-9744A16
1	BOTTOM COWL ASSEMBLY (TRACKER)(Without Decals) Comment: PORT	2197-9744A16
2	BOTTOM COWL ASSEMBLY (BLACK)(Without Decals) Comment: STARBOARD	2197-9745A5
2	BOTTOM COWL ASSEMBLY (GRAY)(Without Decals) Comment: STARBOARD	2197-9745A6
2	BOTTOM COWL ASSEMBLY (TRACKER)(Without Decals) Comment: STARBOARD	2197-9745A7
3	SEAL KIT	18701A1
4	SCREW, (.250-20 x 1.320) (STARBOARD)	10-18699
5	CHECK VALVE ASSEMBLY, Drain	21-817519A1
6	FITTING	22-813613
7	HOSE, (57.00 Inches Bulk)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
8	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
10	SWITCH ASSEMBLY	87-8M0042301	87-896620, 87-856990, 87-850691, 87-18286A40
11	RETAINER	8M0032848	812443 1
12	T-FITTING	22-815914
13	HOSE, (24.500 Inches Bulk)	32-77653101
14	HANDLE ASSEMBLY (BLACK) Comment: PORT	19648A2
14	HANDLE ASSEMBLY (GRAY) Comment: PORT	19648A2
14	HANDLE ASSEMBLY (TRACKER) Comment: PORT	19648A7
15	HANDLE ASSEMBLY (BLACK) Comment: STARBOARD	19647A3
15	HANDLE ASSEMBLY (GRAY) Comment: STARBOARD	19647A3
15	HANDLE ASSEMBLY (TRACKER) Comment: STARBOARD	19647A7
16	NYLINER	23-65830
17	WAVE WASHER	13-99611
18	PAWL	19369
19	PAWL	19370
20	WASHER, (.281 x .734 x .063)	12-69057
21	LOCKWASHER, (.250) Stainless Steel	13-26992
22	SCREW, (.250-20 x .500) Stainless Steel	10-73286
23	CLAMP	54-19749
24	CLAMP	54-197481
25	SCREW, (#10-16 x 1.12)	10-92799
26	COVER ASSEMBLY (BLACK)	18872A1
26	COVER ASSEMBLY (GRAY)	18872A2
26	COVER ASSEMBLY (TRACKER)	18872A4
27	LOCKNUT	11-8136921
28	FRONT HANDLE	8130764
29	SCREW, (.250-20 x .875)	10-181921
30	BUSHING	23-19666
31	ROD	18727

Bleed System

Below is the parts list for Mercury V-200XRI (EFI) Bleed System:

Position No.	Part Name	OEM Number	Supersedes
1	TUBING, (20.00 Feet Bulk), Bleed	32-892024122	32-99130122
2	FITTING	22-59169003
3	CHECK VALVE, Press In (.8125 Long)	21-426982
4	CHECK VALVE, Press In (.6875 Long)	21-426233
5	FITTING, Elbow, Press In	22-822715
6	FITTING, Barbed	22-56759
7	CAP, Elbow (Yellow)	22-15026
8	TEE	22-18205
9	TUBING, (36.00 Inches Bulk)	32-9912688
10	FILTER	35-8M0207786

Bottom Cowl

Below is the parts list for Mercury V-200XRI (EFI) Bottom Cowl:

Position No.	Part Name	OEM Number	Supersedes
1	BOTTOM COWL ASSEMBLY, Black Comment: (Port)	2197-9744A16
1	BOTTOM COWL ASSEMBLY , Gray Comment: (Port)	2197-9744A16
1	BOTTOM COWL ASSEMBLY, Tracker Comment: (Port)	2197-9744A16
2	BOTTOM COWL ASSEMBLY, Black Comment: (Starboard)	2197-9745A5
2	BOTTOM COWL ASSEMBLY, Gray Comment: (Starboard)	2197-9745A6
2	BOTTOM COWL ASSEMBLY, Tracker Comment: (Starboard)	2197-9745A7
3	SEAL KIT, Bottom Cowls	18701A1
4	SCREW, (.250-20 x 1.320), Cowl Comment: (Starboard)	10-18699
5	CHECK VALVE ASSEMBLY, Drain	21-817519A1
6	FITTING, Tell Tale	22-813613
7	LINE, (57.00 Inches Bulk), Tell Tale	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
8	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
10	SWITCH ASSEMBLY	87-8M0042301	87-896620, 87-856990, 87-850691, 87-18286A40
11	RETAINER	8M0032848	812443 1
12	T-FITTING, Tell Tale	22-815914
13	HOSE, (24.500 Inches Bulk)	32-77653101
14	HANDLE ASSEMBLY, Black Comment: (Port)	19648A2
14	HANDLE ASSEMBLY, Gray Comment: (Port)	19648A2
14	HANDLE ASSEMBLY, Tracker Comment: (Port)	19648A7
15	HANDLE ASSEMBLY, Black Comment: (Starboard)	19647A3
15	HANDLE ASSEMBLY, Gray Comment: (Starboard)	19647A3
15	HANDLE ASSEMBLY, Tracker Comment: (Starboard)	19647A7
16	NYLINER	23-65830
17	WAVE WASHER	13-99611
18	PAWL Comment: (Starboard)	19369
19	PAWL Comment: (Port)	19370
20	WASHER, (.281 x .734 x .063)	12-69057
21	LOCKWASHER, (.250) Stainless Steel	13-26992
22	SCREW, (.250-20 x .500) Stainless Steel	10-73286
23	CLAMP, Upper	54-19749
24	CLAMP, Lower	54-197481
25	SCREW, (#10-16 x 1.12)	10-92799
26	COVER ASSEMBLY, Black	18872A1
26	COVER ASSEMBLY, Gray	18872A2
26	COVER ASSEMBLY, Tracker	18872A4
27	LOCKNUT	11-8136921
28	FRONT HANDLE	8130764
29	SCREW, (.250-20 x .875)	10-181921
30	BUSHING	23-19666
31	ROD	18727

CARBURETOR(WMH - 12A/12B/13/13B/14A/15/16)

Below is the parts list for Mercury V-200XRI (EFI) CARBURETOR(WMH - 12A/12B/13/13B/14A/15/16):

Position No.	Part Name	OEM Number	Supersedes
1	CARBURETOR, Top Comment: 135 - WMH-12A/B	3311-818650A28	3308-813682A 7, 3311-818650A16, 3308-9672A50, 3311-818650A13 135 - WMH-12A/B
1	CARBURETOR, Center Comment: 135 - WMH-12A/B	3311-818650A29	3308-813682A 8, 3311-818650A17, 3308-9672A51, 3311-818650A14 135 - WMH-12A/B
1	CARBURETOR, Bottom Comment: 135 - WMH-12A/B	3311-818650A55	3308-813682A 9, 3311-818650A30, 3311-818650A18, 3308-9672A52, 3311-818650A15 135 - WMH-12A/B
1	CARBURETOR, Top Comment: 150 - WMH-13/B	3311-818650A31	3311-818650A10, 3308-9672A19, 3308-9672A35 150 - WMH-13/B
1	CARBURETOR, Center Comment: 150 - WMH-13/B	3311-818650A32	3311-818650A11, 3308-9672A20, 3308-9672A36 150 - WMH-13/B
1	CARBURETOR, Bottom Comment: 150 - WMH-13/B	3311-818650A56	3311-818650A33, 3311-818650A12, 3308-9672A21, 3308-9672A37 150 - WMH-13/B
1	CARBURETOR, Top Comment: XR6/MAGNUM III - WMH-14A	3314-821684A1
1	CARBURETOR, Center Comment: XR6/MAGNUM III - WMH-14A	3314-821684A2
1	CARBURETOR, Bottom Comment: XR6/MAGNUM III - WMH-14A	3314-821684A3
1	CARBURETOR, Top Comment: 175 - WMH-15	3311-818650A37	3311-818650A 7 175 - WMH-15
1	CARBURETOR, Center Comment: 175 - WMH-15	3311-818650A38	3311-818650A 8 175 - WMH-15
1	CARBURETOR, Bottom Comment: 175 - WMH-15	3311-818650A58	3311-818650A39, 3311-818650A 9 175 - WMH-15
1	CARBURETOR, Top Comment: 200 - WMH-16	3311-818650A52	3311-818650A 4, 3311-818650A40 200 - WMH-16
1	CARBURETOR, Center Comment: 200 - WMH-16	3311-818650A53	3311-818650A 5, 3311-818650A41 200 - WMH-16
1	CARBURETOR, Bottom Comment: 200 - WMH-16	3311-818650A59	3311-818650A 6, 3311-818650A42 200 - WMH-16
2	CAP	810779
3	NOT SOLD SEPARATE, Idle Mixture Screw/Spring	NSS
4	PLUG, Retainer	1395-811803
5	GASKET	27-677511
6	JET, (.048) Comment: (135/150)	815633048
6	JET (.070 - 175)	815633070
6	JET, (.050) (XR6/MAGNUM III/200)	815633050
7	LEVER, Throttle (TOP/CENTER)	810721
7	LEVER, Throttle (BOTTOM)	810722
8	SPACER	1395-811284	23-810746
9	WASHER	12-810745
10	NUT	11-810744
11	NOT SOLD SEPARATE, Spring	NSS
12	JET, Main (.096) Comment: (150)	1399-6249
12	JET, (.086) Comment: (XR6/MAGNUM III)	1395-5815
12	JET, (.080) Comment: (175)	1395-6201
12	JET, Main (.090) Comment: (135/200)	1395-6247
13	JET, (.048) Comment: (135)	1395-6246
13	JET, (.046) Comment: (150)	1399-5317
13	JET, (.052) Comment: (XR6/MAGNUM III/175/200)	1395-6359
14	NOT SOLD SEPARATE, Gasket-Fuel Bowl	NSS
15	FLOAT ASSEMBLY	810738
16	NOT SOLD SEPARATE, Float Shaft	NSS
17	NOT SOLD SEPARATE, Screw-Float	NSS
18	VALVE SEAT KIT	1395-8116901
19	NOT SOLD SEPARATE, Gasket	NSS
20	BOWL, Fuel (TOP)	1395-811687
20	BOWL, Fuel (CENTER/BOTTOM)	1395-811688
21	PLUG	1395-811694	1395-9596 1
22	NOT SOLD SEPARATE, Gasket-Power/Progression Jet	NSS
23	JET, Main (.054) Comment: (XR6/MAGNUM III)	1399-5225
23	JET, Main (.062) Comment: (150)	1399-4217
23	JET, (.064) Comment: (135/175)	1399-4216
23	JET, Main Fuel (.066) Comment: (200)	1399-4215
24	POWER JET Comment: (135/150/200)	1395-811689
24	POWER JET Comment: (XR6/MAGNUM III)	1395-811807
24	POWER JET Comment: (175)	1395-811925
25	NOT SOLD SEPARATE, Screw-Fuel Bowl	NSS
26	TEE FITTING (TOP/CENTER)	1395-7900
27	ELBOW (BOTTOM)	1395-7901
-	GASKET KIT, Carburetor	8107492
-	REPAIR KIT, Carburetor	1395-8116912
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90

CARBURETOR(WMH-21/22/23/24/25/28)

Below is the parts list for Mercury V-200XRI (EFI) CARBURETOR(WMH-21/22/23/24/25/28):

Position No.	Part Name	OEM Number	Supersedes
1	CARBURETOR, Top Comment: 135 - WMH-28	3311-818650A28	3308-813682A 7, 3311-818650A16, 3308-9672A50, 3311-818650A13 135 - WMH-28
1	CARBURETOR, Center Comment: 135 - WMH-28	3311-818650A29	3308-813682A 8, 3311-818650A17, 3308-9672A51, 3311-818650A14 135 - WMH-28
1	CARBURETOR, Bottom Comment: 135 - WMH-28	3311-818650A55	3308-813682A 9, 3311-818650A30, 3311-818650A18, 3308-9672A52, 3311-818650A15 135 - WMH-28
1	CARBURETOR, Top Comment: 150 - WMH-23	3311-818650A31	3311-818650A10, 3308-9672A19, 3308-9672A35 150 - WMH-23
1	CARBURETOR, Center Comment: 150 - WMH-23	3311-818650A32	3311-818650A11, 3308-9672A20, 3308-9672A36 150 - WMH-23
1	CARBURETOR, Bottom Comment: 150 - WMH-23	3311-818650A56	3311-818650A33, 3311-818650A12, 3308-9672A21, 3308-9672A37 150 - WMH-23
1	CARBURETOR, Top Comment: XR6/MAGNUM III-WMH-25	3314-821684A1
1	CARBURETOR, Center Comment: XR6/MAGNUM III-WMH-25	3314-821684A2
1	CARBURETOR, Bottom Comment: XR6/MAGNUM III-WMH-25	3314-821684A3
1	CARBURETOR, Top Comment: 175 - WMH-22	3311-818650A37	3311-818650A 7 175 - WMH-22
1	CARBURETOR, Center Comment: 175 - WMH-22	3311-818650A38	3311-818650A 8 175 - WMH-22
1	CARBURETOR, Bottom Comment: 175 - WMH-22	3311-818650A58	3311-818650A39, 3311-818650A 9 175 - WMH-22
1	CARBURETOR, Top Comment: 200 - WMH-21	3311-818650A52	3311-818650A 4, 3311-818650A40 200 - WMH-21
1	CARBURETOR, Center Comment: 200 - WMH-21	3311-818650A53	3311-818650A 5, 3311-818650A41 200 - WMH-21
1	CARBURETOR, Bottom Comment: 200 - WMH-21	3311-818650A59	3311-818650A 6, 3311-818650A42 200 - WMH-21
2	CAP	810779
3	NOT SOLD SEPARATE, Idle Mixture Screw/Spring	NSS
5	GASKET	27-677511
6	JET, (.060) (.056 - 150/135 - WMH-24)	815633060
6	JET (.070 - 135 - WMH-28)	815633070
6	JET, .040 (175)	1399-7570
6	JET, (.050) (XR6/MAGNUMIII/200)	815633050
7	LEVER, Throttle (TOP/CENTER)	810721
7	LEVER, Throttle (BOTTOM)	810722
8	SPACER	1395-811284	23-810746
9	WASHER	12-810745
10	NUT	11-810744
11	NOT SOLD SEPARATE, Spring	NSS
12	JET, (.094) (.094 -150)	1395-8423
12	JET, (.086) (XR6/MAGNUM III)	1395-5815
12	JET, (.098) (175)	1395-7335
12	JET, Main (.090) (200/135 - WMH-24)	1395-6247
13	JET, Main (.060) (135 - WMH-24)	1395-6487
13	JET, Main (.056) (150/135 - WMH-28)	1399-5213
13	JET, (.048) (175)	1395-6246
13	JET, (.050) (XR6/MAGNUM III)	1395-6028
13	JET, (.046) (200)	1399-5317
14	NOT SOLD SEPARATE, Gasket-Fuel Bowl	NSS
15	FLOAT ASSEMBLY	810738
16	SHAFT	F10064
17	NOT SOLD SEPARATE, Screw-Float	NSS
18	VALVE SEAT KIT	1395-8116901
19	NOT SOLD SEPARATE, Gasket-Valve Seat	NSS
20	BOWL, Fuel (TOP)	1395-823623
20	BOWL, Fuel (CENTER/BOTTOM)	1395-823624
21	PLUG	1395-811694	1395-9596 1
22	NOT SOLD SEPARATE, Gasket-Power/Progression Jet	NSS
23	JET, Main (.060) (150/135 - WMH-24)	1395-6487
23	JET, Main (.062) (135 - WMH-28)	1399-4217
23	JET, Main (.054) (XR6/MAGNUM III)	1399-5225
23	JET, (.064) (175/200)	1399-4216
24	POWER JET (150/135 - WMH-24)	1395-823629
24	POWER JET (135 - WMH-28)	1395-808584
24	POWER JET (XR6/MAGNUM III)	1395-823625
24	POWER JET (175)	1395-823626
24	POWER JET (200)	1395-823627
25	NOT SOLD SEPARATE, Screw-Fuel Bowl	NSS
26	TEE FITTING (TOP/CENTER)	1395-7900
27	ELBOW (BOTTOM)	1395-7901
-	GASKET KIT, Carburetor	8107492
-	REPAIR KIT, Carburetor	1395-8116912
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90

CARBURETOR(WMH-30/31/32/33/34)

Below is the parts list for Mercury V-200XRI (EFI) CARBURETOR(WMH-30/31/32/33/34):

Position No.	Part Name	OEM Number	Supersedes
1	CARBURETOR, Top Comment: 135 - WMH-30	3311-818650A28	3308-813682A 7, 3311-818650A16, 3308-9672A50, 3311-818650A13 135 - WMH-30
1	CARBURETOR, Center Comment: 135 - WMH-30	3311-818650A29	3308-813682A 8, 3311-818650A17, 3308-9672A51, 3311-818650A14 135 - WMH-30
1	CARBURETOR, Bottom (30A) Comment: 135 - WMH-30	3311-818650A55	3308-813682A 9, 3311-818650A30, 3311-818650A18, 3308-9672A52, 3311-818650A15 135 - WMH-30
1	CARBURETOR, Top Comment: 150 - WMH-31	3311-818650A31	3311-818650A10, 3308-9672A19, 3308-9672A35 150 - WMH-31
1	CARBURETOR, Center Comment: 150 - WMH-31	3311-818650A32	3311-818650A11, 3308-9672A20, 3308-9672A36 150 - WMH-31
1	CARBURETOR, Bottom (31A) Comment: 150 - WMH-31	3311-818650A56	3311-818650A33, 3311-818650A12, 3308-9672A21, 3308-9672A37 150 - WMH-31
1	CARBURETOR, Top Comment: TRACKER/XR6/MAGNUM III-WMH-32	3311-818650A34
1	CARBURETOR, Center Comment: TRACKER/XR6/MAGNUM III-WMH-32	3311-818650A35
1	CARBURETOR, Bottom (32A) Comment: TRACKER/XR6/MAGNUM III-WMH-32	3311-818650A57	3311-818650A36 TRACKER/XR6/MAGNUM III-WMH-32
1	CARBURETOR, Top Comment: 175 - WMH-33	3311-818650A37	3311-818650A 7 175 - WMH-33
1	CARBURETOR, Center Comment: 175 - WMH-33	3311-818650A38	3311-818650A 8 175 - WMH-33
1	CARBURETOR, Bottom (33A) Comment: 175 - WMH-33	3311-818650A58	3311-818650A39, 3311-818650A 9 175 - WMH-33
1	CARBURETOR, Top Comment: 200 - WMH-34	3311-818650A52	3311-818650A 4, 3311-818650A40 200 - WMH-34
1	CARBURETOR, Center Comment: 200 - WMH-34	3311-818650A53	3311-818650A 5, 3311-818650A41 200 - WMH-34
1	CARBURETOR, Bottom (34A) Comment: 200 - WMH-34	3311-818650A59	3311-818650A 6, 3311-818650A42 200 - WMH-34
2	CAP	810779
3	NOT SOLD SEPARATE, Idle Mixture Screw/Spring	NSS
5	GASKET	27-677511
6	JET, (.060) (.056 - 135)	815633060
6	JET, .040 (XR6/MAGNUM III)	1399-7570
6	JET, (.050) (150/175/200)	815633050
7	LEVER, Throttle (TOP/CENTER)	810721
7	LEVER, Throttle (BOTTOM - WMH-SERIES)	810722
7	LEVER, Throttle (BOTTOM - WMH-A SERIES)	8107221
8	SPACER	1395-811284	23-810746
9	WASHER	12-810745
10	NUT	11-810744
11	NOT SOLD SEPARATE, Spring	NSS
12	JET, (.086) (150)	1395-5815
12	JET, Main (.090) (XR6/MAGNUM III)	1395-6247
12	JET, (.084) (135/175/200)	1399-3517
13	JET, Main (.054) (135)	1399-5225
13	JET, (.052) (150)	1395-6359
13	JET, (.048) (175)	1395-6246
13	JET, Main Fuel (.058) (XR6/MAGNUM III)	1395-7831
13	JET, (.046) (200)	1399-5317
14	NOT SOLD SEPARATE, Gasket-Fuel Bowl	NSS
15	FLOAT ASSEMBLY	810738
16	SHAFT	F10064
17	NOT SOLD SEPARATE, Screw-Float	NSS
18	VALVE SEAT KIT	1395-8116901
19	NOT SOLD SEPARATE, Gasket-Valve Seat	NSS
20	BOWL, Fuel (TOP)	1395-823623
20	BOWL, Fuel (CENTER/BOTTOM)	1395-823624
21	PLUG	1395-811694	1395-9596 1
22	NOT SOLD SEPARATE, Gasket-Power/Progression Jet	NSS
23	JET, Main Fuel (.066) (135)	1399-4215
23	JET, Main (.062) (150/XR6/MAGNUM III)	1399-4217
23	JET, (.064) (175)	1399-4216
23	JET, Main Fuel (.066) (200 - TOP)	1399-4215
23	JET, (.064) (200 - CENTER/BOTTOM)	1399-4216
24	POWER JET	1395-808584
25	SCREW AND WASHER, (#8-32 x .750)	1395-808612	1399-5132
26	TEE FITTING (TOP/CENTER)	1395-7900
27	ELBOW (BOTTOM)	1395-7901
-	GASKET KIT, Carburetor	8107492
-	REPAIR KIT, Carburetor	1395-8116912
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90

CHOKE PLATE AND THROTTLE LEVERS

Below is the parts list for Mercury V-200XRI (EFI) CHOKE PLATE AND THROTTLE LEVERS:

Position No.	Part Name	OEM Number	Supersedes
1	PLATE ASSEMBLY, Sound Attenuator	817495A1
2	GASKET	27-892211
3	SCREW, (.250-28 x 2.500)	10-884891
4	WASHER, (.281 x .734 x .063)	12-69057
5	CAP	19-815784	22-14685
6	LINK, Throttle Comment: (BOTTOM CARB IS WMH SERIES)	18180
7	LINK (W/STUB SHAFT) Comment: (BOTTOM CARB IS WMH SERIES)	18181
6A	LINK KIT, Throttle Comment: (BOTTOM CARB IS WMH-A SERIES)	825204A1
7	LINK (W/STUB SHAFT) Comment: (BOTTOM CARB IS WMH-A SERIES)	18181
7A	LINK (W/BALL SHAFT) Comment: (BOTTOM CARB IS WMH-A SERIES)	181811
8	ROLLER	18178
9	SCREW, (#10-32 x .500)	10-87926
10	WASHER, (.203 x .406 x .040)	12-89302
11	LOCKWASHER, External	10,13-69432
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90

CRANKSHAFT, PISTONS AND CONNECTING RODS

Below is the parts list for Mercury V-200XRI (EFI) CRANKSHAFT, PISTONS AND CONNECTING RODS:

Position No.	Part Name	OEM Number	Supersedes
1	CRANKSHAFT ASSEMBLY	455-9536T4
2	BEARING, Ball (LOWER)	30-67923T
3	RING	53-67446
4	GEAR SEGMENT KIT, Drive	43-14513A09
5	SCREW, (#6-32 x .620) Socket Head	10-813073
6	NUT, Special	6-32,11-813134
7	CARRIER ASSEMBLY	54196A6
8	PACKING	65800
9	RING, Sealing, CRANKSHAFT	39-67377T
10	BEARING KIT	31-16756A6
11	PISTON (STARBOARD-STANDARD) Comment: 135/150	765-7441T32
11	PISTON (STARBOARD-.015 O.S.) Comment: 135/150	765-7443A11
11	PISTON (STARBOARD-.030 OS.) Comment: 135/150	765-7445T11
11	PISTON (PORT-STANDARD) Comment: 135/150	765-7442T32
11	PISTON (PORT-.015 O.S.) Comment: 135/150	765-7444A11
11	PISTON (PORT-.030 O.S.) Comment: 135/150	765-7446A11
11	PISTON ASSEMBLY (STARBOARD-STANDARD) Comment: XR6/MAGNUM III/175/200/TRACKER SN# 0G052594 & Below	785-9738T9
11	PISTON ASSEMBLY (STARBOARD-.015 O.S.) Comment: XR6/MAGNUM III/175/200/TRACKER SN# 0G052594 & Below	785-9738T10
11	PISTON ASSEMBLY (PORT-STANDARD) Comment: XR6/MAGNUM III/175/200/TRACKER SN# 0G052594 & Below	785-9737T9
11	PISTON ASSEMBLY (PORT-.015 O.S.) Comment: XR6/MAGNUM III/175/200/TRACKER SN# 0G052594 & Below	785-9737A10
11	PISTON ASSEMBLY, Standard (STARBOARD-STANDARD) Comment: XR6/MAGNUM III/175/200/TRACKER SN# 0G052595 & Up	785-9738T9
11	PISTON ASSEMBLY, .015 Oversize (STARBOARD-.015 O.S.) Comment: XR6/MAGNUM III/175/200/TRACKER SN# 0G052595 & Up	785-9738T10
11	PISTON ASSEMBLY, Standard (PORT-STANDARD) Comment: SN# 0G052595 & Up	785-9737T9
11	PISTON ASSEMBLY, .015 Oversize (PORT-.015 O.S.) Comment: XR6/MAGNUM III/175/200/TRACKER SN# 0G052595 & Up	785-9737A10
12	RING SET, Piston - Standard (STANDARD) Comment: 135/150	39-93481A12
12	RING SET, Piston - .015 Oversize (.015 O.S.) Comment: 135/150	39-78918A4
12	RING SET, Piston - .030 Oversize (.030 O.S.) Comment: 135/150	39-85636A4
12	RING SET, Piston (STD.) (1-1/2 MM) Comment: XR6/MAGNUM III/175/200/TRACKER SN# 0G052594 & Below	39-815515A12
12	RING SET, Piston (.015 O.S.) (1-1/2 MM) Comment: XR6/MAGNUM III/175/200/TRACKER SN# 0G052594 & Below	39-815268A4
12	RING KIT, Piston - Standard (STD.) (2MM) Comment: XR6/MAGNUM III/175/200/TRACKER SN# 0G052595 & Up	39-822321A12	39-822321A 8, 39-824905A12 XR6/MAGNUM III/175/200/TRACKER SN# 0G052595 & Up
12	RING KIT, Piston - .015 Oversize (.015 O.S.) (2MM) Comment: XR6/MAGNUM III/175/200/TRACKER SN# 0G052595 & Up	39-822321A1
13	RING, Lock	53-857196	40-52035
14	CONNECTING ROD KIT	644-818141A13	644-818141A 2
15	SCREW, (.312-24 x .875)	10-763491
16	WASHER	12-8M0012298	12-812876
17	BEARING KIT	8M0234886
18	BEARING, Needle	29-8M0204691
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	POWERHEAD ASSEMBLY Comment: (135/150)	878365T00	812815T00, 812815T97, 812815A97, 812815A96, 812815A92, 812815A90 (135/150)
-	POWERHEAD ASSEMBLY Comment: (XR6/Magnum III) SN# 0D284787 & Below	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (XR6/Magnum III) SN# 0D284787 & Below
-	POWERHEAD ASSEMBLY Comment: (XR6/Magnum III) SN# 0D284788 & Up	823434T97	823434A97, 823434A96, 823434A93 (XR6/Magnum III) SN# 0D284788 & Up
-	POWERHEAD ASSEMBLY Comment: (Tracker 150)	823434T97	823434A97, 823434A96, 823434A93 (Tracker 150)
-	POWERHEAD ASSEMBLY Comment: (175)	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (175)
-	POWERHEAD ASSEMBLY Comment: (200)	813043T97	813043A97, 813043A96, 813043A94, 812827A92, 813043A92 (200)

CYLINDER BLOCK AND END CAPS

Below is the parts list for Mercury V-200XRI (EFI) CYLINDER BLOCK AND END CAPS:

Position No.	Part Name	OEM Number	Supersedes
1	CYLINDER BLOCK (135/150)	884-859211T2
1	CYLINDER BLOCK (XR6/Magnum III) Comment: SN# 0D284787 & Below	884-9763T17
1	CYLINDER BLOCK (XR6/Magnum III) Comment: SN# 0D284788 & Up	884-9763T23
1	CYLINDER BLOCK (175)	884-9763T17
1	CYLINDER BLOCK (200)	884-9763T61
1	CYLINDER BLOCK ( 150 TRACKER)	884-9763T23
2	STUD (1-7/8") (OLD DESIGN)	16-76175
2	STUD (1-3/4")	16-8M0034455	16-818138 4
3	STUD (5-1/2")	16-670654
3	STUD (6-3/4")	16-8M0034454	16-78438 5
4	PIN, Dowel - Without Hole (.375 x .625)	17-43044
5	PIN (BEARING RACE)	17-8M0036405	17-67296
6	GASKET	27-11338
7	COVER (UPPER)	8M0088723	42249 1
8	SCREW, (.312-18 x 1.500) Hex Flange	10-828213
8	SCREW, (.312-18 x 1.50) (Use with 13-26993 washer)	10-73657
9	LOCKWASHER, (.312) (Use with 10-73657 screw)	13-8M0204647
10	COVER (LOWER)	76867
11	SCREW, (.312-18 x 2.00)	10-815549	10-25503, 10-77065
11	SCREW, (.312-18 x 2.00) Hex Flange	10-828214
11A	BUSHING	23-99448
12	SCREW, (.375-16 x 3.250)	10-66717
12	SCREW, (.312-18 x 1.250)	10-74824
13	END CAP ASSEMBLY, Upper	1159-858521T1
14	O-RING, (2.800 x .103)	25-54029
15	BEARING KIT	31-16756A4
16	SEAL	26-41953
17	SCREW AND LOCKWASHER, (.312-18 x 1.00)	10-30225
19	J CLIP	54-63153
20	STUD, (.190-32 x 1.870)	16-15094
21	STUD, (#10-32 x 1.00)	16-8M0034435	16-15093
22	SPACER	23-67269
23	WASHER, (.187 x .500 x .062) Neoprene	12-8M0204663
25	WING NUT,	10-32,11-816874	11-73651, 11-816873, 11-90052
26	BRACKET	422482
27	SCREW, (.250-20 x .750)	10-49668
28	END CAP ASSEMBLY	1156-7809T1
29	O-RING, (3.237 x .103)	25-62700
30	SEAL	26-41953
31	SCREW, (.250-20 x .750)	10-28636
32	LOCKWASHER, (.250) Stainless Steel	13-26992
33	SCREW, (.250-20 x 2.125)	10-64022
34	NUT, (.250-20)	11-64015
35	CAP, Nylon	26852
36	IDLE SPEED CONTROL	87076A10
38	SCREW, (#10-32 x .875)	10-690201
39	WASHER	12-38833
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	POWERHEAD ASSEMBLY Comment: (135/150)	878365T00	812815T00, 812815T97, 812815A97, 812815A96, 812815A92, 812815A90 (135/150)
-	POWERHEAD ASSEMBLY Comment: (XR6/Magnum III) SN# 0D284787 & Below	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (XR6/Magnum III) SN# 0D284787 & Below
-	POWERHEAD ASSEMBLY Comment: (XR6/Magnum III) SN# 0D284788 & Up	823434T97	823434A97, 823434A96, 823434A93 (XR6/Magnum III) SN# 0D284788 & Up
-	POWERHEAD ASSEMBLY Comment: (Tracker 150)	823434T97	823434A97, 823434A96, 823434A93 (Tracker 150)
-	POWERHEAD ASSEMBLY Comment: (175)	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (175)
-	POWERHEAD ASSEMBLY Comment: (200)	813043T97	813043A97, 813043A96, 813043A94, 812827A92, 813043A92 (200)

Crankshaft, Pistons And Connecting Rods

Below is the parts list for Mercury V-200XRI (EFI) Crankshaft, Pistons And Connecting Rods:

Position No.	Part Name	OEM Number	Supersedes
1	CRANKSHAFT ASSEMBLY	455-9536T4
2	BEARING, Ball, Lower	30-67923T
3	RING	53-67446
4	GEAR SEGMENT KIT, Drive	43-14513A09
5	SCREW, (#6-32 x .620) Socket Head	10-813073
6	NUT, Special	6-32,11-813134
7	CARRIER ASSEMBLY	54196A6
8	PACKING	65800
9	RING, Sealing, Sealing - Crankshaft	39-67377T
10	BEARING KIT, Crankshaft	31-16756A6
11	PISTON ASSEMBLY, Starboard - Standard Comment: SN# 0G052594 & Below	785-9738T9
11	PISTON ASSEMBLY, Starboard (.015 O.S.) Comment: SN# 0G052594 & Below	785-9738T10
11	PISTON ASSEMBLY, Port - Standard Comment: SN# 0G052594 & Below	785-9737T9
11	PISTON ASSEMBLY, Port (.015 O.S.) Comment: SN# 0G052594 & Below	785-9737A10
12	RING SET, Piston, Standard (1.50 MM) Comment: SN# 0G052594 & Below	39-815515A12
12	RING SET, Piston (.015 O.S.) (1.50 MM) Comment: SN# 0G052594 & Below	39-815268A4
13	RING, Lock Comment: SN# 0G052594 & Below	53-857196	40-52035 SN# 0G052594 & Below
11	PISTON ASSEMBLY, Standard, Starboard - Standard Comment: SN# 0G052595 & Up	785-9738T9
11	PISTON ASSEMBLY, .015 Oversize, Starboard (.015 O.S.) Comment: SN# 0G052595 & Up	785-9738T10
11	PISTON ASSEMBLY, Standard, Port Standard Comment: SN# 0G052595 & Up	785-9737T9
11	PISTON ASSEMBLY, .015 Oversize, Port (.015 O.S.) Comment: SN# 0G052595 & Up	785-9737A10
12	RING KIT, Piston - Standard, Standard (2MM) Comment: SN# 0G052595 & Up	39-822321A12	39-822321A 8, 39-824905A12 SN# 0G052595 & Up
12	RING KIT, Piston - .015 Oversize (.015 O.S.) (2MM) Comment: SN# 0G052595 & Up	39-822321A1
13	RING, Lock Comment: SN# 0G052595 & Up	53-857196	40-52035 SN# 0G052595 & Up
14	CONNECTING ROD KIT	644-818141A13	644-818141A 2
15	SCREW, (.312-24 x .875), Connecting Rod	10-763491
16	WASHER, Needle Locating	12-8M0012298	12-812876
17	BEARING KIT	8M0234886
18	BEARING, Needle, Piston End	29-8M0204691
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90

Cylinder Block And End Caps

Below is the parts list for Mercury V-200XRI (EFI) Cylinder Block And End Caps:

Position No.	Part Name	OEM Number	Supersedes
1	CYLINDER BLOCK (150)	884-9763T23
1	CYLINDER BLOCK (175)	884-9763T17
1	CYLINDER BLOCK (200)	884-9763T61
2	STUD, Powerhead (1.875) (Old Design)	16-76175
2	STUD, Powerhead (1.75")	16-8M0034455	16-818138 4
3	STUD, Powerhead (5.50")	16-670654
3	STUD, Powerhead (6.75")	16-8M0034454	16-78438 5
4	PIN, Dowel - Without Hole (.375 x .625), Locating	17-43044
5	PIN, Bearing Race	17-8M0036405	17-67296
6	GASKET, Sealing	27-11338
7	COVER, Starter Motor-Upper	8M0088723	42249 1
8	SCREW, (.312-18 x 1.500) Hex Flange, Hex Flange	10-828213
8	SCREW, (.312-18 x 1.50), Use with Lockwasher	10-73657
9	LOCKWASHER, (.312)	13-8M0204647
10	COVER, Lower	76867
11	SCREW, (.312-18 x 2.00)	10-815549	10-25503, 10-77065
11	SCREW, (.312-18 x 2.00) Hex Flange, Hex Head Flange	10-828214
12	BUSHING	23-99448
13	CABLE ASSEMBLY	84-88807A20
14	SCREW, (.375-16 x 3.250)	10-66717
14	SCREW, (.312-18 x 1.250)	10-74824
15	END CAP ASSEMBLY, Upper	1159-858521T1
16	O-RING, (2.800 x .103)	25-54029
17	BEARING KIT	31-16756A4
18	SEAL	26-41953
19	SCREW AND LOCKWASHER, (.312-18 x 1.00)	10-30225
20	J CLIP	54-63153
21	STUD, (.190-32 x 1.870)	16-15094
22	SPACER	23-67269
23	WASHER, (.187 x .500 x .062) Neoprene	12-8M0204663
24	WING NUT,	10-32,11-816874	11-73651, 11-816873, 11-90052
25	CLAMP	54-16793
26	SCREW, (.250-20 x .500) Stainless Steel	10-41508
27	STUD, (#10-32 x 1.00)	16-8M0034435	16-15093
28	BRACKET	422482
29	SCREW, (.250-20 x .750)	10-49668
30	END CAP ASSEMBLY	1156-7809T1
31	O-RING, (3.237 x .103)	25-62700
32	SEAL	26-41953
33	SCREW, (.250-20 x .750)	10-28636
34	LOCKWASHER, (.250) Stainless Steel	13-26992
35	SCREW, (.250-20 x 2.125)	10-64022
36	NUT, (.250-20)	11-64015
37	CAP, Nylon	26852
38	IDLE SPEED CONTROL	87076A10
39	SCREW, (#10-32 x .875)	10-690201
40	WASHER	12-38833
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	POWERHEAD ASSEMBLY (150)	823434T97	823434A97, 823434A96, 823434A93
-	POWERHEAD ASSEMBLY (175)	812817T97	812817A97, 812817A96, 812817A92, 821861A92
-	POWERHEAD ASSEMBLY (200)	813043T97	813043A97, 813043A96, 813043A94, 812827A92, 813043A92

DRIVESHAFT HOUSING AND EXHAUST TUBE

Below is the parts list for Mercury V-200XRI (EFI) DRIVESHAFT HOUSING AND EXHAUST TUBE:

Position No.	Part Name	OEM Number	Supersedes
1	HOUSING ASSEMBLY, Driveshaft (BLACK) Comment: LONG	1590-8343T10
1	HOUSING ASSEMBLY, Driveshaft (GRAY) Comment: LONG	1590-8343T11
1	HOUSING ASSEMBLY, Driveshaft (TRACKER) Comment: LONG	1590-8343T12
1	HOUSING ASSEMBLY, Driveshaft (BLACK) Comment: X-LONG	3503-813563T1
1	HOUSING ASSEMBLY, Driveshaft (GRAY) Comment: X-LONG	3503-813563T2
1	HOUSING ASSEMBLY, Driveshaft (JET) (BLACK)	1590-8343A13
1	HOUSING ASSEMBLY, Driveshaft (JET) (GRAY)	1590-8343A14
2	STUD, (.437 x 2.69)	16-56295
4	SCREW, (.500-20 x 6.00)	10-898831	10-63474
5	MOUNT (LONG)(JET)	78249
5	MOUNT (TRACKER/XR6/MAGNUM III/X-LONG)	77327
6	WASHER, (.8125)	12-49339
7	NUT, (.500-20)	11-898832	11-826708 17
8	CABLE ASSEMBLY, Ground	88238A10
9	CLAMP	54-8M0036782	54-67076
10	SCREW, (.312-18 x 1.250)	10-66727
11	COVER, Black (BLACK)	100-8M4500752	8M0001130, 67077T
11	COVER (GRAY)	67077F1
11	COVER (TRACKER)	100-8M4500752	8M0001130, 67077T
12	SCREW, (#12-24 x .620)	10-88417
13	NUT	11-35521
14	CABLE ASSEMBLY, Ground	88238A10
15	SCREW, (.250-20 x .500) Stainless Steel	10-41508
16	WASHER	12-48926
17	NUT, (.437-20) Stainless Steel	11-8M0204653
18	WASHER, (.453 x .812 x .105) Stainless Steel	12-45176
19	NUT, (.437-20) Stainless Steel	11-8M0204653
20	PLUG	19-64649
21	TUBE, Exhaust	18276T
22	SEAL (LOWER)	66350001
23	SEAL (UPPER)	8M0039076	17726 1
24	TUBE, Water (LONG)(JET)	32-8M0042788	32-859097 1
24	TUBE (X-LONG)	32-8M0042790	32-859097 2
25	GASKET	27-991734
26	PLATE ASSEMBLY	18233A20
27	SEAL	8M0043165	814701 2
28	BRACKET	68011
29	SCREW, (#10-16 x .500)	10-878608	10-812832
30	PIN, Dowel	17-43044
31	SEAL	26-38970
32	SCREW, (.250-20 x .750) Stainless Steel	10-90192
33	GASKET	27-183076
34	WASHER, (.406 x .734 x .063)	12-20553
35	NUT	11-69254
36	EXTENSION, Exhaust Comment: (135/175/XR6/MAGNUM III/TRACKER)	812834A2
36	EXTENSION, Exhaust (150/200)(JET)	879288T71	41942 4
37	GASKET	27-782461
38	BOOT	814618
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90

DUAL ENGINE EXTENSION KIT

Below is the parts list for Mercury V-200XRI (EFI) DUAL ENGINE EXTENSION KIT:

Position No.	Part Name	OEM Number	Supersedes
-	EXTENSION KIT, Dual Engine	92876A9
1	O-RING, (.614 x .070)	25-48462
2	TUBE ASSEMBLY	71565A2
3	MOUNT	41055
4	TAB WASHER	14-42100
5	NUT, (.875-14)	11-8M0041651	11-37984
6	TAB WASHER	88404
7	SCREW, (.250-28 x 1.250)	10-38601
8	BRACKET	17729A1
9	SCREW, (.312-24 x 1.250)	10-62055
10	TAB WASHER	17728
11	SCREW, (.375-24 x 1.25)	10-849838	10-14000
12	NUT, (.375-24)	11-8M0204726
13	STEERING EYE	8M0026167	8M0005848, 97933 1
14	SLEEVE, (1.625)	23-23651
15	TUBING, (4.00 Inches)	97931
16	COUPLER, (15.00 Inches)	8M0026098	814951 3
17	NUT, (.562-18)	11-42099
18	COUPLING	22-821169
19	WASHER, (.406 x .734 x .063) Stainless Steel	12-34931
20	SCREW, (.375-24 x 1.5)	10-94319

Detonation Controller/Temperature Sensor

Below is the parts list for Mercury V-200XRI (EFI) Detonation Controller/Temperature Sensor:

Position No.	Part Name	OEM Number	Supersedes
1	CONTROLLER ASSEMBLY, Detonation Comment: (200)	826800A8
2	SCREW, (.190-32 x 1.62), Detonation Controller Comment: (200)	10-88447
3	WASHER, Detonation Controller Screw Comment: (200)	12-38833
4	PLATE Comment: (200)	13381
5	CABLE ASSEMBLY Comment: (200)	84-88807A10
6	SCREW, (#10-16 x .375), Cable To Plate Comment: (200)	10-62568
7	SPACER Comment: (200)	23-94304
8	MODULE ASSEMBLY, Oil Injection Warning	41470A25
9	INDICATOR, Throttle Position	14851T03
10	SCREW, (#8-32 x .625), Indicator	10-15150
11	LOCKWASHER, Stainless Steel, Indicator Screw	8,13-26995
12	WASHER, (.192 x .375 x .0312) Stainless Steel, Indicator Screw	12-30164
13	SLEEVE	23-15885
14	SENSOR ASSEMBLY, Temperature	13221T01
15	O-RING, (.612 x .103)	25-45711
16	SCREW, (#8-32 x .375)	10-57583T
17	LOCKWASHER, Stainless Steel	8,13-26995
18	SCREW, (#10-32 X .380)	10-42813
19	PLATE	813501
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90

Drive Shaft Housing And Exhaust Tube

Below is the parts list for Mercury V-200XRI (EFI) Drive Shaft Housing And Exhaust Tube:

Position No.	Part Name	OEM Number	Supersedes
1	HOUSING ASSEMBLY, Driveshaft, Black Comment: (Long)	1590-8343T10
1	HOUSING ASSEMBLY, Driveshaft, Gray Comment: (Long)	1590-8343T11
1	HOUSING ASSEMBLY, Driveshaft, Tracker Comment: (Long)	1590-8343T12
1	HOUSING ASSEMBLY, Driveshaft, Black Comment: (X-Long)	3503-813563T1
1	HOUSING ASSEMBLY, Driveshaft, Gray Comment: (X-Long)	3503-813563T2
2	STUD, (.437 x 2.69)	16-56295
4	SCREW, (.500-20 x 6.00)	10-898831	10-63474
5	MOUNT, No Markings	78249
5	MOUNT, Tracker - White Dot	77327
6	WASHER, (.8125)	12-49339
7	NUT, (.500-20)	11-898832	11-826708 17
8	CABLE ASSEMBLY, Ground	88238A10
9	CLAMP	54-8M0036782	54-67076
10	SCREW, (.312-18 x 1.250)	10-66727
11	COVER, Black, Black	100-8M4500752	8M0001130, 67077T
11	COVER, Gray	67077F1
11	COVER, Tracker	100-8M4500752	8M0001130, 67077T
12	SCREW, (#12-24 x .620)	10-88417
13	NUT	11-35521
14	CABLE ASSEMBLY, Ground	88238A10
15	SCREW, (.250-20 x .500) Stainless Steel	10-41508
16	WASHER	12-48926
17	NUT, (.437-20) Stainless Steel	11-8M0204653
18	WASHER, (.453 x .812 x .105) Stainless Steel	12-45176
19	NUT, (.437-20) Stainless Steel	11-8M0204653
20	PLUG	19-64649
21	TUBE, Exhaust	18276T
22	SEAL, Lower	66350001
23	SEAL, Upper	8M0039076	17726 1
24	TUBE, Water, Jet Comment: (Long)	32-8M0042788	32-859097 1 (Long)
24	TUBE Comment: (X-Long)	32-8M0042790	32-859097 2 (X-Long)
25	GASKET	27-991734
26	PLATE ASSEMBLY	18233A20
27	SEAL	8M0043165	814701 2
28	BRACKET	68011
29	SCREW, (#10-16 x .500)	10-878608	10-812832
30	PIN, Dowel	17-43044
31	SEAL	26-38970
32	SCREW, (.250-20 x .750) Stainless Steel	10-90192
33	GASKET	27-183076
34	WASHER, (.406 x .734 x .063)	12-20553
35	NUT	11-69254
36	EXTENSION, Exhaust (13.50")	812834A2
36	EXTENSION, Exhaust (7.50")	879288T71	41942 4
37	GASKET	27-782461
38	BOOT	814618
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90

Dual Engine Extension Kit

Below is the parts list for Mercury V-200XRI (EFI) Dual Engine Extension Kit:

Position No.	Part Name	OEM Number	Supersedes
-	EXTENSION KIT, Dual Engine	92876A9
1	O-RING, (.614 x .070)	25-48462
2	TUBE ASSEMBLY, Cable Guide	71565A2
3	MOUNT	41055
4	TAB WASHER	14-42100
5	NUT, (.875-14)	11-8M0041651	11-37984
6	TAB WASHER	88404
7	SCREW, (.250-28 x 1.250)	10-38601
8	BRACKET	17729A1
9	SCREW, (.312-24 x 1.250)	10-62055
10	TAB WASHER	17728
11	SCREW, (.375-24 x 1.25)	10-849838	10-14000
12	NUT, (.375-24)	11-8M0204726
13	STEERING EYE	8M0026167	8M0005848, 97933 1
14	SLEEVE, (1.625)	23-23651
15	TUBING, (4.00 Inches)	97931
16	COUPLER, (15.00 Inches)	8M0026098	814951 3
17	NUT, (.562-18)	11-42099
18	COUPLING	22-821169
19	WASHER, (.406 x .734 x .063) Stainless Steel	12-34931
20	SCREW, (.375-24 x 1.5)	10-94319

EXHAUST MANIFOLD AND EXHAUST PLATE

Below is the parts list for Mercury V-200XRI (EFI) EXHAUST MANIFOLD AND EXHAUST PLATE:

Position No.	Part Name	OEM Number	Supersedes
1	GASKET	27-190503
2	PLATE, Divider	827323A2
3	SEAL, (12.50 Inches)	26-814754	42838 1, 69668, 88726
4	CLAMP	54-814634
5	SCREW AND WASHER, (.312-18 x 1.500)	10-8263561
6	FITTING, (.500-14)	22-8144301
7	FITTING, (.250-18) (90 DEGREES)	22-920071
8	HOSE, (57.00 Inches Bulk) (Cut to 23.5 Inches)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
9	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
10	COVER	8M0039767	68729 1
11	SCREW, (.312-18 x 1.250)	10-74824
12	GASKET	27-78690002
13	SCREW, (#10-16 x .750)	10-69570
14	WASHER	12-76451
15	DIAPHRAGM	144791
16	DEFLECTOR, Water	16496
17	PLATE	16497A1
18	SPRING, (Black)	24-64878
19	WASHER	12-85303
20	POPPET	14480
21	GROMMET	25-64872
22	CARRIER	65848
23	GASKET	27-991764
24	PLATE ASSEMBLY, Exhaust	18260T2
25	CONNECTOR, (.125-27) (STRAIGHT)	22-89772Q1
26	PIN, Dowel	17-43044
27	SEAL	8M0043164	814701 1
28	BRACKET	680101
29	SCREW, (#10-16 x .500)	10-878608	10-812832
30	WASHER, (.406 x .734 x .063)	12-20553
31	NUT	11-69254
32	BUSHING	23-27132
33	GROMMET	25-8M0179867
34	GROMMET Comment: SN# 0G201874 & Below	25-12602002
34	GROMMET Comment: SN# 0G201875 & Up	25-19565002
35	SCREW, (.312-18 x 1.250)	10-66727
36	SCREW, (.312-18 x 2.50)	10-68783
37	SCREW, (.375-16 x 3.50)	10-898833	10-66725
38	BRACKET ASSEMBLY	812905T	812905A 5
39	SCREW, (.312-18 x .625)	10-90285
40	WASHER, (.330 x .750 x .060) Stainless Steel	12-56720
41	WASHER	12-187031
42	GROMMET	25-18778001
43	BRACKET ASSEMBLY, Rear	18578T09
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	POWERHEAD ASSEMBLY Comment: (135/150)	878365T00	812815T00, 812815T97, 812815A97, 812815A96, 812815A92, 812815A90 (135/150)
-	POWERHEAD ASSEMBLY Comment: (XR6/Magnum III) SN# 0D284787 & Below	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (XR6/Magnum III) SN# 0D284787 & Below
-	POWERHEAD ASSEMBLY Comment: (XR6/Magnum III) SN# 0D284788 & Up	823434T97	823434A97, 823434A96, 823434A93 (XR6/Magnum III) SN# 0D284788 & Up
-	POWERHEAD ASSEMBLY Comment: (Tracker 150)	823434T97	823434A97, 823434A96, 823434A93 (Tracker 150)
-	POWERHEAD ASSEMBLY Comment: (175)	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (175)
-	POWERHEAD ASSEMBLY Comment: (200)	813043T97	813043A97, 813043A96, 813043A94, 812827A92, 813043A92 (200)

Electronic Control Unit Assembly

Below is the parts list for Mercury V-200XRI (EFI) Electronic Control Unit Assembly:

Position No.	Part Name	OEM Number	Supersedes
1	ECU, Engine Control Unit (150)	824003T04	824003A 4
1	ECU, Engine Control Unit (175)	824003T02	824003A 2
1	ECU, Engine Control Unit (200)	824003T01	824003A 1
2	SPACER	23-34948
3	CLIP	54-146951
4	MOUNT, Cowl Mounting Bracket	90435
5	WASHER	12-21249
6	NUT, (.250-28)	11-8267089
7	CABLE ASSEMBLY	84-88807A19
8	GROMMET	14637
9	BUSHING	23-14636
10	SCREW, (.250-20 x 1.00) Stainless Steel	10-28667
11	LOCKWASHER, (.250) Stainless Steel	13-26992
12	WASHER, (.265 x .750 x .048) Stainless Steel	12-65567
13	MODULE ASSEMBLY, Water Sensor	13202A2
14	CABLE ASSEMBLY, Black	84-88807A18
15	SCREW, (.190-32 x .500)	10-37571
16	WASHER, (.203 x .406 x .040)	12-89302
17	HARNESS ASSEMBLY, Electronic Control Unit And Injectors	84-98866A14
18	COUPLE RING	190491
19	CABLE ASSEMBLY (150/175)	84-87895A4
20	CAVITY PLUG	832948A1
21	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275

Exhaust Manifold And Exhaust Plate

Below is the parts list for Mercury V-200XRI (EFI) Exhaust Manifold And Exhaust Plate:

Position No.	Part Name	OEM Number	Supersedes
1	GASKET	27-190503
2	PLATE, Divider	827323A2
3	SEAL, (12.50 Inches)	26-814754	42838 1, 69668, 88726
4	CLAMP	54-814634
5	SCREW AND WASHER, (.312-18 x 1.500)	10-8263561
6	FITTING, (.500-14)	22-8144301
7	FITTING, (.250-18) (90_)	22-920071
8	LINE, (57.00 Inches Bulk) (Cut to 23.50 Inch Length)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
9	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
10	COVER, Relief Valve	8M0039767	68729 1
11	SCREW, (.312-18 x 1.250)	10-74824
12	GASKET	27-78690002
13	SCREW, (#10-16 x .750)	10-69570
14	WASHER	12-76451
15	DIAPHRAGM	144791
16	DEFLECTOR, Water	16496
17	PLATE	16497A1
18	SPRING, (Black)	24-64878
19	WASHER	12-85303
20	POPPET	14480
21	GROMMET	25-64872
22	CARRIER	65848
23	GASKET	27-991764
24	PLATE ASSEMBLY, Exhaust	18260T2
25	CONNECTOR, (.125-27), Straight	22-89772Q1
26	PIN, Dowel	17-43044
27	SEAL	8M0043164	814701 1
28	BRACKET	680101
29	SCREW, (#10-16 x .500)	10-878608	10-812832
30	WASHER, (.406 x .734 x .063)	12-20553
31	NUT	11-69254
32	BUSHING	23-27132
33	GROMMET	25-8M0179867
34	GROMMET Comment: SN# 0G201874 & Below	25-12602002
34	GROMMET Comment: SN# 0G201875 & Up	25-19565002
35	SCREW, (.312-18 x 1.250)	10-66727
36	SCREW, (.312-18 x 2.50)	10-68783
37	SCREW, (.375-16 x 3.50)	10-898833	10-66725
38	BRACKET ASSEMBLY	812905T	812905A 5
39	SCREW, (.312-18 x .625)	10-90285
39A	WASHER, (.330 x .750 x .060) Stainless Steel	12-56720
40	WASHER	12-187031
41	GROMMET	25-18778001
42	BRACKET ASSEMBLY, Rear	18578T09
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90

FLYWHEEL/STARTER MOTOR

Below is the parts list for Mercury V-200XRI (EFI) FLYWHEEL/STARTER MOTOR:

Position No.	Part Name	OEM Number	Supersedes
1	COVER KIT	18896A1
2	MARKER	79022
3	SCREW, (.190-32 x .380)	10-37572
4	WASHER, (.203 x .562 x .060) Stainless Steel	12-72761
5	PLUG	19-89219001
6	PLUG, Yellow	19-45907
7	NUT, (.625-18)	11-52901
8	WASHER, (.641 x 1.250 x .190)	12-33001
9	FLYWHEEL Comment: SN# 0G052511 & Below	271-859238T16	271-859238T 8 SN# 0G052511 & Below
9	FLYWHEEL Comment: SN# 0G052512 & Up	271-859238T16	271-859238T 8 SN# 0G052512 & Up
10	STATOR	398-9610A19
11	SCREW, (#10-32 x 1.375)	10-90045
12	LOCKWASHER, Stainless Steel	10,13-26996
13	PLATE ASSEMBLY, Trigger	96455A9
14	STARTER MOTOR ASSEMBLY	50-893893	50-79472T 2, 50-79472 2
15	COLLAR	23-8M0034918	23-8M0001391, 56703
16	STOP, Rubber	8M0043376	68042
17	SCREW AND LOCKWASHER, (.250-20 x .625) Stainless Steel	10-69035
18	CABLE ASSEMBLY, (6.00 Inches) Black	84-93388A1
19	CABLE ASSEMBLY (BLACK)	84-93388A14
20	LOCKWASHER, (.250) Stainless Steel	13-26992
21	NUT, (.250-20)	11-20890

FUEL LINES(Use With WMH -30/31/32/33/34 Carburetors)

Below is the parts list for Mercury V-200XRI (EFI) FUEL LINES(Use With WMH -30/31/32/33/34 Carburetors):

Position No.	Part Name	OEM Number	Supersedes
1	CONNECTOR ASSEMBLY, Fuel - Plastic	22-816856Q3
2	SCREW, (.250-20 x 1.375)	10-69067
3	SEAL	812782
4	HOSE	32-8M0108349	32-8M0047448, 32-830757130, 32-830757 80
5	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
6	CONNECTOR, Tee	22-818993
7	HOSE	32-18175
8	CHECK VALVE	22-8189941
9	TUBING, (10.00 Inches Bulk)	32-82381335
10	HOSE	32-830762	32-824001
11	FILTER, Fuel	35-816296Q2
12	HOSE, (57.00 Inches Bulk)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
13	GASKET	27-677511
14	STUD, (.250-28 x 1.125)	16-270372
15	LOCKWASHER, (.250) Stainless Steel	13-26992
16	NUT, (.250-28) Stainless Steel	11-29598
17	SCREW, (.250-20 x .880)	10-55715
18	VALVE ASSEMBLY, Enrichner	42859A2
19	CLAMP	54-633001
20	SCREW, (.250-20 x .500) Stainless Steel	10-73286
21	TUBING, (36.00 Inches Bulk)	32-9912688
22	TUBING, (20.00 Feet Bulk)	32-892024122	32-99130122
23	TERMINAL BLOCK	86-45915
24	SCREW, (#10-16 x .600)	10-878609	10-812832 1
24	SCREW, (#10-16 x .380)	10-878607	10-817626
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90

FUEL LINES(Use With WMH-12A/B thru WMH-28 Carburtors)

Below is the parts list for Mercury V-200XRI (EFI) FUEL LINES(Use With WMH-12A/B thru WMH-28 Carburtors):

Position No.	Part Name	OEM Number	Supersedes
1	CONNECTOR ASSEMBLY, Fuel - Plastic	22-816856Q3
2	SCREW, (.250-20 x 1.375)	10-69067
3	SEAL	812782
4	HOSE	32-8M0108349	32-8M0047448, 32-830757130, 32-830757 80
5	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
6	CONNECTOR, Tee	22-818993
7	HOSE	32-18175
8	CHECK VALVE	22-8189941
9	TUBING, (10.00 Inches Bulk)	32-82381335
10	FILTER, Fuel	35-816296Q2
11	GASKET	27-677511
12	STUD, (.250-28 x 1.125)	16-270372
13	HOSE, (57.00 Inches Bulk)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
14	SCREW, (.250-20 x .880)	10-55715
15	LOCKWASHER, (.250) Stainless Steel	13-26992
16	NUT, (.250-28) Stainless Steel	11-29598
17	HOSE, (.187) (26.00 Inches Bulk)	32-9912878
18	TUBING, (20.00 Feet Bulk)	32-892024122	32-99130122
19	VALVE ASSEMBLY, Enrichner	42859A2
20	CLAMP	54-633001
21	SCREW, (.250-20 x .500) Stainless Steel	10-73286
22	TUBING, (36.00 Inches Bulk)	32-9912688
23	TERMINAL BLOCK	86-45915
24	SCREW, (#10-16 x .625) Stainless Steel	10-48409
24	SCREW, (#10-16 x .440)	10-69079
25	HOSE	32-830762	32-824001
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90

FUEL PUMP

Below is the parts list for Mercury V-200XRI (EFI) FUEL PUMP:

Position No.	Part Name	OEM Number	Supersedes
1	PUMP ASSEMBLY, Fuel	14360A78
2	DIAPHAGM KIT	21-857005A1
3	NOT SOLD SEPARATE, Check Valve-Rubber	NSS
4	NOT SOLD SEPARATE, Check Valve	NSS
5	NOT SOLD SEPARATE, Retainer	NSS
6	NOT SOLD SEPARATE, Gasket-Boost	NSS
7	NOT SOLD SEPARATE, Cap	NSS
8	NOT SOLD SEPARATE, Spring	NSS
9	NOT SOLD SEPARATE, Diaphragm	NSS
10	NOT SOLD SEPARATE, Gasket-Pulse	NSS
11	NOT SOLD SEPARATE, Spring	NSS
12	NOT SOLD SEPARATE, Cap	NSS
13	GASKET	27-8M0204705
14	BASE	144303
15	PLATE	987752
16	ELBOW	22-996642
17	HOSE, (57.00 Inches Bulk)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
18	ELBOW	22-996642
19	SCREW, (M6 x 50)	10-82130050
20	SCREW, (M5 x 40)	10-82104540
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	DIAPHAGM KIT	21-857005A1
-	POWERHEAD ASSEMBLY Comment: (135/150)	878365T00	812815T00, 812815T97, 812815A97, 812815A96, 812815A92, 812815A90 (135/150)
-	POWERHEAD ASSEMBLY Comment: (XR6/Magnum III) SN# 0D284787 & Below	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (XR6/Magnum III) SN# 0D284787 & Below
-	POWERHEAD ASSEMBLY Comment: (XR6/Magnum III) SN# 0D284788 & Up	823434T97	823434A97, 823434A96, 823434A93 (XR6/Magnum III) SN# 0D284788 & Up
-	POWERHEAD ASSEMBLY Comment: (Tracker 150)	823434T97	823434A97, 823434A96, 823434A93 (Tracker 150)
-	POWERHEAD ASSEMBLY Comment: (175)	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (175)
-	POWERHEAD ASSEMBLY Comment: (200)	813043T97	813043A97, 813043A96, 813043A94, 812827A92, 813043A92 (200)

Flywheel/Starter Motor

Below is the parts list for Mercury V-200XRI (EFI) Flywheel/Starter Motor:

Position No.	Part Name	OEM Number	Supersedes
1	COVER KIT	18896A1
2	MARKER	79022
3	SCREW, (.190-32 x .380)	10-37572
4	WASHER, (.203 x .562 x .060) Stainless Steel	12-72761
5	PLUG	19-89219001
6	PLUG, Yellow	19-45907
7	NUT, (.625-18)	11-52901
8	WASHER, (.641 x 1.250 x .190)	12-33001
9	FLYWHEEL	271-859238T16	271-859238T 8
10	STATOR	398-9610A19
11	SCREW, (#10-32 x 1.375)	10-90045
12	LOCKWASHER, Stainless Steel	10,13-26996
13	PLATE ASSEMBLY, Trigger	96455A9
14	STARTER MOTOR ASSEMBLY	50-893893	50-79472T 2, 50-79472 2
15	COLLAR	23-8M0034918	23-8M0001391, 56703
16	STOP, Rubber	8M0043376	68042
17	SCREW AND LOCKWASHER, (.250-20 x .625) Stainless Steel	10-69035
18	CABLE ASSEMBLY, (6.00 Inches) Black	84-93388A1
19	CABLE ASSEMBLY, Black	84-93388A14
20	LOCKWASHER, (.250) Stainless Steel	13-26992
21	NUT, (.250-20)	11-20890

Fuel Management System

Below is the parts list for Mercury V-200XRI (EFI) Fuel Management System:

Position No.	Part Name	OEM Number	Supersedes
1C	LEVER KIT, Link	827697
1D	SCREW KIT	10-827698
1E	FUEL RAIL Comment: (Metal)	827699
1E	FUEL RAIL Comment: (Plastic)	827699T2
1F	JOINT KIT, Fuel Pipe	809057T	809057
1G	SCREW KIT	10-8276981
1H	SCHRADER VALVE KIT	809059
28	LINK Comment: (Design I)	15444
28A	LINK Comment: (Design II)	8276891

Fuel Management System(Breakdown)

Below is the parts list for Mercury V-200XRI (EFI) Fuel Management System(Breakdown):

Position No.	Part Name	OEM Number	Supersedes
-	MANAGEMENT ASSEMBLY, Fuel	14817A19
1	THROTTLE BODY	827693
1A	COVER	827692
1B	RETAINER KIT	827696
2	ROLLER, CAM	67748
3	INJECTOR, Fuel	18715T
4	FILTER, INJECTOR	35-17422
5	HARNESS KIT	84-15443
6	FILTER KIT, Fuel Comment: (Design I)	35-15442
6A	FILTER KIT, Fuel Comment: (Design II)	35-154422
7	FILTER, Fuel	35-150282
8	SCREW, (M5 x 14), Filter Cover	10-400034
9	LOCKWASHER, (M5), Cover Screw	13-400255
10	TUBING, (30.00 Inches Bulk) (.50" O.D.)	32-1350385
11	TUBING, (36.00 Inches Bulk) (.125" I.D.)	32-9912688
12	TUBING, (20.00 Feet Bulk) (.0937" I.D.)	32-892024122	32-99130122
13	REGULATOR, Pressure	15027
14	ELBOW KIT	814233
15	GASKET, Pressure Regulator	27-18791
16	PLATE, Pressure Regulator	814012
17	SCREW	10-814076
18	COVER KIT	814010
19	SCREW, (M4 x 16), Cover To Seperator	10-4001987
20	LOCKWASHER, Stainless Steel, Cover Screw	8,13-26995
21	SEAL, Vapor Seperator	26-18790
22	O-RING AND SEAL KIT	15029
23	VALVE KIT, Float	15446
24	FLOAT KIT	15445
25	BODY KIT	814011
26	CHECK VALVE	21-424811
27	SCREW, (M6 x 35), Separator	10-4000332
29	CHECK VALVE	21-18241
30	VALVE, Shut-Off	814077
31	SEAL, Injector Manifold	26-18792
32	SPACER	23-19275
34	SPACER	23-814913
35	WASHER, (.255 x .620 x .030) Stainless Steel, Large	12-35280
36	WASHER, (.281 x .734 x .063), Small	12-69057
37	CLAMP, (15.7), Hose	54-8M0214911
38	TUBING, (30.00 Inches Bulk) (Cut to 1.75 Inch Length)	32-1350385
39	CLAMP, Worm Gear	54-F698772
40	BLANKET, Fuel Pump	14639
41	COVER, Fuel Pump	14640T
42	SCREW, (#10-32 x .625)	10-32228
43	LOCKWASHER, Stainless Steel	10,13-26996
44	SCREW, (.250-20 x 4)	10-845674	10-90088
45	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
46	PUMP ASSEMBLY, Fuel	14307T01
47	HOSE	32-146332
48	FILTER, Fuel	35-885188	35-823501

Fuel Pump And Fuel Filter

Below is the parts list for Mercury V-200XRI (EFI) Fuel Pump And Fuel Filter:

Position No.	Part Name	OEM Number	Supersedes
1	PUMP ASSEMBLY, Fuel	14360A78
2	DIAPHAGM KIT	21-857005A1
3	NOT AVAILABLE, Rubber
4	NOT AVAILABLE, Gasket, Boost
5	NOT AVAILABLE, Diaphragm
6	NOT AVAILABLE, Gasket, Pulse
7	NOT AVAILABLE, Spring
8	NOT AVAILABLE, Cap
9	NOT AVAILABLE, Check Valve
10	NOT AVAILABLE, Retainer
11	NOT AVAILABLE, Spring
12	NOT AVAILABLE, Cap
13	GASKET, Base	27-8M0204705
14	BASE, Fuel Pump	144303
15	PLATE, Fuel Pump	987752
16	ELBOW	22-996642
17	SCREW, (M5 x 40), Fuel Pump	10-82104540
18	SCREW, (M6 x 50), Fuel Pump To Crankcase	10-82130050
19	HOSE, Pulse	32-8M0108349	32-8M0047448, 32-830757130, 32-830757 80
20	ELBOW	22-996642
21	HOSE	32-8M0108349	32-8M0047448, 32-830757130, 32-830757 80
22	TIE STRAP, (8.00 Inches), Fuel Tubing	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
23	CONNECTOR ASSEMBLY, Fuel - Plastic	22-816856Q3
24	SCREW, (.250-20 x 1.375)	10-69067
25	SEAL	812782
26	TUBING, (30.00 Inches Bulk)	32-1350385
27	BASE, Fuel Filter Comment: (Design I)	13170A3
28	SCREW, (.250-20 x .875) Stainless Steel, Fuel Filter Base Comment: (Design I)	10-28668
29	No Longer Available, Bracket (Order 13170A3) Comment: (Design I)	NLA
30	SCREW, (.250-20 x 1.375) Comment: (Design I)	10-69067
31	FITTING, Base (Included With Ref. #34)	22-136071
32	FILTER ASSEMBLY, Fuel	35-18458Q3
33	PROBE, Water Sensing	14570
34	BASE Comment: (Design II)	13170A3
35	SCREW, (.250-20 x 1.12) Comment: (Design II)	10-455611
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	DIAPHAGM KIT	21-857005A1

GEAR HOUSING CHART

Below is the parts list for Mercury V-200XRI (EFI) GEAR HOUSING CHART:

Position No.	Part Name	OEM Number
-	GEAR HOUSING ASSEMBLY, Standard Rotation 2:1 Gear Ratio (LONG)(BLACK) Comment: (135/150 ) DESIGN II ANODES NOT INCLUDED	1647-9148T81
-	GEAR HOUSING ASSEMBLY, Standard Rotation 2:1 Gear Ratio (X-LONG)(BLACK) Comment: (135/150 ) DESIGN II ANODES NOT INCLUDED	1647-9148T82
-	GEAR HOUSING ASSEMBLY, Standard Rotation 2:1 Gear Ratio (LONG)(GRAY) Comment: (135/150 ) DESIGN II ANODES NOT INCLUDED	1647-9148T87
-	GEAR HOUSING ASSEMBLY, Standard Rotation 2:1 Gear Ratio (X-LONG)(GRAY) Comment: (135/150 ) DESIGN II ANODES NOT INCLUDED	1647-9148T88
-	GEAR HOUSING ASSEMBLY, 2.3:1 Gear Ratio (HIGH ALTITUDE) (BLACK) Comment: DESIGN II ANODES NOT INCLUDED	1647-9148A78
-	GEAR HOUSING ASSEMBLY, 2.3:1 Gear Ratio (HIGH ALTITUDE) (GRAY) Comment: DESIGN II ANODES NOT INCLUDED	1647-9148A79
-	GEAR HOUSING ASSEMBLY, 1.78:1 Gear Ratio - Black (BLACK) Comment: (XR6/MAGNUM III) DESIGN II ANODES NOT INCLUDED	1674-814247T3
-	GEAR HOUSING ASSEMBLY, 1.78:1 Gear Ratio - Gray (GRAY) Comment: (XR6/MAGNUM III) DESIGN II ANODES NOT INCLUDED	1674-814247T4
-	GEAR HOUSING ASSEMBLY, Standard Rotation 1.87:1 Gear Ratio (X-LONG) TRACKER Comment: (175/200/TRACKER/XR6/MAGNUM III) DESIGN II ANODES NOT INCLUDED	1647-9148T85
-	GEAR HOUSING ASSEMBLY, Standard Rotation 1.87:1 Gear Ratio (LONG) (GRAY) Comment: (175/200/TRACKER/XR6/MAGNUM III) DESIGN II ANODES NOT INCLUDED	1647-9148T84
-	GEAR HOUSING ASSEMBLY, Standard Rotation 1.87:1 Gear Ratio (X-LONG) (GRAY) Comment: (175/200/TRACKER/XR6/MAGNUM III) DESIGN II ANODES NOT INCLUDED	1647-9148T91
-	GEAR HOUSING ASSEMBLY, Standard Rotation 1.87:1 Gear Ratio, TRACKER Comment: DESIGN II ANODES NOT INCLUDED	1647-9148T84
-	GEAR HOUSING ASSEMBLY, Counter Rotation (X-LONG) (BLACK) Comment: (135/150) DESIGN II ANODES NOT INCLUDED	1647-9148T83
-	GEAR HOUSING ASSEMBLY, Counter Rotation (X-LONG) (GRAY) Comment: (135/150) DESIGN II ANODES NOT INCLUDED	1647-9148T89
-	GEAR HOUSING ASSEMBLY, Counter Rotation (X-LONG) (BLACK) Comment: (175/200) DESIGN II ANODES NOT INCLUDED	1647-9148T86
-	GEAR HOUSING ASSEMBLY, Counter Rotation (X-LONG) (GRAY) Comment: (175/200) DESIGN II ANODES NOT INCLUDED	1647-9148T92
-	GEAR HOUSING ASSEMBLY, Standard Rotation 2:1 Gear Ratio (LONG) (BLACK) Comment: (135/150) DESIGN II ANODES INCLUDED	1647-9148T81
-	GEAR HOUSING ASSEMBLY, Standard Rotation 2:1 Gear Ratio (X-LONG) (BLACK) Comment: (135/150) DESIGN II ANODES INCLUDED	1647-9148T82
-	GEAR HOUSING ASSEMBLY, Standard Rotation 2:1 Gear Ratio (LONG) (GRAY) Comment: (135/150) DESIGN II ANODES INCLUDED	1647-9148T87
-	GEAR HOUSING ASSEMBLY, Standard Rotation 2:1 Gear Ratio (X-LONG) (GRAY) Comment: (135/150) DESIGN II ANODES INCLUDED	1647-9148T88
-	GEAR HOUSING ASSEMBLY, 2.3:1 Gear Ratio (HIGH ALTITUDE)(BLACK) Comment: DESIGN II ANODES INCLUDED	1647-9148A78
-	GEAR HOUSING ASSEMBLY, 2.3:1 Gear Ratio (HIGH ALTITUDE)(GRAY) Comment: DESIGN II ANODES INCLUDED	1647-9148A79
-	GEAR HOUSING ASSEMBLY, Standard Rotation 1.87:1 Gear Ratio (LONG)(BLACK) Comment: (175/200/TRACKER/XR6/MAGNUM III) DESIGN II ANODES INCLUDED	1647-9148T84
-	GEAR HOUSING ASSEMBLY, Standard Rotation 1.87:1 Gear Ratio (X-LONG) (BLACK) Comment: (175/200/TRACKER/XR6/MAGNUM III) DESIGN II ANODES INCLUDED	1647-9148T85
-	GEAR HOUSING ASSEMBLY, Standard Rotation 1.87:1 Gear Ratio (LONG) (GRAY) Comment: (175/200/TRACKER/XR6/MAGNUM III) DESIGN II ANODES INCLUDED	1647-9148T84
-	GEAR HOUSING ASSEMBLY, Standard Rotation 1.87:1 Gear Ratio (X-LONG)(GRAY) Comment: (175/200/TRACKER/XR6/MAGNUM III) DESIGN II ANODES INCLUDED	1647-9148T91
-	GEAR HOUSING ASSEMBLY, Standard Rotation 1.87:1 Gear Ratio, TRACKER Comment: DESIGN II ANODES INCLUDED	1647-9148T84
-	GEAR HOUSING ASSEMBLY, Counter Rotation (X-LONG)(BLACK) Comment: (135/150) DESIGN II ANODES INCLUDED	1647-9148T83
-	GEAR HOUSING ASSEMBLY, Counter Rotation (X-LONG)(GRAY) Comment: (135/150) DESIGN II ANODES INCLUDED	1647-9148T89
-	GEAR HOUSING ASSEMBLY, Counter Rotation (X-LONG) (BLACK) Comment: (175/200) DESIGN II ANODES INCLUDED	1647-9148T86
-	GEAR HOUSING ASSEMBLY, Counter Rotation (X-LONG)(GRAY) Comment: (175/200) DESIGN II ANODES INCLUDED	1647-9148T92

GEAR HOUSING(DRIVESHAFT)

Below is the parts list for Mercury V-200XRI (EFI) GEAR HOUSING(DRIVESHAFT):

Position No.	Part Name	OEM Number	Supersedes
1	GEAR HOUSING ASSEMBLY (BASIC) (BLACK)	1647-9148T47
1	GEAR HOUSING ASSEMBLY (BASIC) (GRAY)	1647-9148T47
1	GEAR HOUSING ASSEMBLY (BASIC) (TRACKER)	1647-9148T49
2	CONNECTOR ASSEMBLY (USE WHERE APPLICABLE)	22-85822A10
3	PIN, Dowel - Without Hole (.375 x .625)	17-43044
4	STUD, (.438 x 3.12) (LONG)	16-786382
4	STUD, (.438 x 3.69) (X-LONG)	16-8M0034464	16-18978 3
5	STUD, (.437-14/.437-20 x 2.060)	16-8M0133358
6	STUD, (.312 x 3.38)	16-8M0034463	16-56297 2
7	STUD, (.250-20/.250-28 x 3.125)	16-306671
8	BEARING ASSEMBLY, Roller	31-42647A1
9	SLEEVE (OLD DESIGN)	23-43998
9A	ANODE Comment: DESIGN II	97-826134Q	826134, 826134A 1 DESIGN II
9B	SCREW, (M6 x 40) Comment: DESIGN II	10-4000333
9C	NUT, (M6) Comment: DESIGN II	11-401386
11	DRIVESHAFT (LONG)	45-897624T	45-44000 1
11	DRIVESHAFT (X-LONG)	45-897625T	45-44209 1
11	DRIVESHAFT (20") Comment: HIGH ALTITUDE - 2.3:1 GEAR RATIO	45-16292
11	DRIVESHAFT (25") Comment: HIGH ALTITUDE - 2.3:1 GEAR RATIO	45-815237
12	Not Sold Separate, Pinion Gear (Part of Forward Gear Set) (#N.S.S.)
13	WASHER	12-92721
14	NUT, (.625-18)	11-35921
15	SHIM SET	15-42637A1
16	BEARING, Roller	31-8M0146566
17	RETAINER	8245191
18	BASE ASSEMBLY, Water Pump	46-8M0077147	46-42579A 3
19	GASKET	27-8M0204678
20	O-RING, (2.175 x .175)	25-8M0142854
21	SEAL, Oil	26-89238
22	SEAL, Oil	26-16977
23	GASKET	27-8M0090319	27-85608 1
24	GASKET	27-858524	27-85609 1, 27-85609B 1
25	FACE PLATE	8M0204677
26	BODY ASSEMBLY, Water Pump	46-96148T1
27	INSERT	48752T
28	SEAL	26-38970
29	IMPELLER	47-89984T3
30	KEY	28-8M0214992
31	SCREW, (#14-8 x 2.25)	10-8M0215009
32	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
33	NUT, (.250-28)	11-8267119
34	WASHER	12-36001
35	NUT	11-13436
37	SLEEVE	23-29804T
38	SHIFT SHAFT (USE W/O E-RING)	789022
38	SHAFT Comment: USE WITH E-RING	789022
39	E RING Comment: USE WITH E-RING	53-29641
41	O-RING, (.862 x .103)	25-25439
42	BUSHING ASSEMBLY	23-77631A2
43	SEAL, Oil	26-8M0204708
44	WASHER	12-77674
45	SCREW, (.375-16 x .250)	10-79953Q04
46	SCREW, Magnetic	22-8M0058389	22-67892A06
47	WASHER, Fiber	12-191833
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	REPAIR KIT, Water Pump	46-96148A8
-	SEAL KIT	26-89238A2

GEAR HOUSING(DRIVESHAFT) - COUNTER ROTATION

Below is the parts list for Mercury V-200XRI (EFI) GEAR HOUSING(DRIVESHAFT) - COUNTER ROTATION:

Position No.	Part Name	OEM Number	Supersedes
1	GEAR HOUSING ASSEMBLY (BASIC) (BLACK) Comment: DESIGN II W/ANODES	1647-9148T47
1	GEAR HOUSING ASSEMBLY (BASIC) (GRAY) Comment: DESIGN II W/ANODES	1647-9148T47
2	CONNECTOR ASSEMBLY (USE WHERE APPLICABLE)	22-85822A10
3	PIN, Dowel - Without Hole (.375 x .625)	17-43044
4	STUD, (.438 x 3.69)	16-8M0034464	16-18978 3
5	STUD, (.437-14/.437-20 x 2.060)	16-8M0133358
6	STUD, (.312 x 3.38)	16-8M0034463	16-56297 2
7	STUD, (.250-20/.250-28 x 3.125)	16-306671
8	BEARING ASSEMBLY, Roller	31-42647A1
9	SLEEVE (OLD DESIGN)	23-43998
9A	ANODE Comment: DESIGN II	97-826134Q	826134, 826134A 1 DESIGN II
9B	SCREW, (M6 x 40) Comment: DESIGN II	10-4000333
9C	NUT, (M6) Comment: DESIGN II	11-401386
11	DRIVESHAFT	45-897625T	45-44209 1
12	Not Sold Separate, Pinion Gear (PART OF 43-18572A1 OR 43-18475A1) (#N.S.S.)
13	WASHER	12-92721
14	NUT, (.625-18)	11-35921
15	SHIM SET	15-42637A1
16	BEARING, Roller	31-8M0146566
17	RETAINER	8245191
18	BASE ASSEMBLY, Water Pump	46-8M0077147	46-42579A 3
19	GASKET	27-8M0204678
20	O-RING, (2.175 x .175)	25-8M0142854
21	SEAL, Oil	26-89238
22	SEAL, Oil	26-16977
23	GASKET	27-8M0090319	27-85608 1
24	GASKET	27-858524	27-85609 1, 27-85609B 1
25	FACE PLATE	8M0204677
26	BODY ASSEMBLY, Water Pump	46-96148T1
27	INSERT	48752T
28	SEAL	26-38970
29	IMPELLER	47-89984T3
30	KEY	28-8M0214992
31	SCREW, (#14-8 x 2.25)	10-8M0215009
32	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
33	NUT, (.250-28)	11-8267119
34	WASHER	12-36001
35	NUT	11-13436
37	SLEEVE	23-29804T
38	SHIFT SHAFT (USE W/O E-RING)	789022
38	SHAFT Comment: USE WITH E-RING	789022
39	E RING Comment: USE WITH E-RING	53-29641
40	WASHER, Fiber	12-191833
41	O-RING, (.862 x .103)	25-25439
42	BUSHING ASSEMBLY	23-77631A2
43	SEAL, Oil	26-8M0204708
44	WASHER	12-77674
45	SCREW, (.375-16 x .250)	10-79953Q04
46	SCREW, Magnetic	22-8M0058389	22-67892A06
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	REPAIR KIT, Water Pump	46-96148A8
-	SEAL KIT	26-89238A2

GEAR HOUSING(PROPSHAFT)

Below is the parts list for Mercury V-200XRI (EFI) GEAR HOUSING(PROPSHAFT):

Position No.	Part Name	OEM Number	Supersedes
1	GEAR HOUSING ASSEMBLY (BASIC) (BLACK)	1647-9148T47
1	GEAR HOUSING ASSEMBLY (BASIC) (GRAY)	1647-9148T47
1	GEAR HOUSING ASSEMBLY (BASIC) (TRACKER)	1647-9148T49
49	FOLLOWER ASSEMBLY	89594A1
48	SHIFT CAM	789562
50	ROD	79911A1
51	SPRING	24-79910
52	WASHER	12-78910
53	PIN	17-8M0084245	17-78906
54	SHIM SET (.002-3-5-10)	15-47397A1
55	BEARING ASSEMBLY, Tapered Roller	31-78172A1
56	GEAR ASSEMBLY, Forward (135/150) (INCLS. REVERSE GEAR) Comment: SN# 0G052417 & Below	43-44102A2
56	GEAR SET (135/150) (DOES NOT INCL. REVERSE GEAR) Comment: SN# 0G052418 & Up	43-44102A7
56	GEAR SET, HIGH ALTITUDE - 2.3:1 GEAR RATIO	43-16294A5
56	GEAR ASSEMBLY, Forward (175/200/XR6/MAGNUM III) (INCLS. REVERSE GEAR) Comment: SN# 0G052417 & Below	43-44104T2
56	GEAR SET (175/200/XR6/MAGNUM III) (DEOS NOT INCLUDE REVERSE GEAR) Comment: SN# 0G052418 & Up	43-44104A8
57	BEARING, Roller	31-549281
58	CLUTCH	52-823174T	52-823174, 52-78959
59	PIN, Cross	17-8M0084243	17-78905
60	PIN, Detent	17-78909
61	SPRING	24-78962
62	PROPELLER SHAFT	44-94148
63	Not Sold Separate, Reverse Gear (Part of Forward Gear Set (#N.S.S.) Comment: SN# 0G052417 & Below
63	GEAR ASSEMBLY, Reverse (135/150) Comment: SN# 0G052418 & Up	43-824987A2
63	GEAR ASSEMBLY, Reverse (175/200/XR6/MAG. III) Comment: SN# 0G052418 & Up	43-824986A2
63A	SPACER Comment: SN# 0G052418 & Up	23-824108
64	RING, Thrust	681001
65	BEARING, Ball	30-88957T
66	O-RING	25-8M0214920
67	CARRIER ASSEMBLY, Bearing	43567T1
68	BEARING, Needle	31-30956T
69	SEAL	26-8M0204670
70	KEY	28-30281
71	TAB WASHER	14-79447
72	RETAINER	8M2011027	79448
73	TRIM TAB (USE WITH GEAR HOUSING W/O ANODES)	97-31640Q4
73	TRIM TAB (USE WITH GEAR HOUSING W/ANODES)	31640T07
74	SCREW, (.437-14 x 1.750) (1-5/8")	10-8M0204686
75	FILLER BLOCK	8M0039169	67891
76	NUT, (.437-20) Stainless Steel Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	11-8M0204653
77	SCREW, (.375-16 x 1.00) Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	10-65210
78	THRUST HUB Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	12-835467Q01	12-835467 1 THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT
79	WASHER, Splined Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	12-31211Q03
80	TAB WASHER Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	14-816629Q	14-816629, 14-31210, 14-816629B THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT
81	PROP NUT KIT, (.750-16) Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	11-52707Q1
82	LOCKWASHER, Toothed Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	13-423511
83	WASHER, (.453 x .812 x .105) Stainless Steel Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	12-45176
-	GASKET SET, Engine Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT
-	SEAL KIT Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	26-89238A2

GEAR HOUSING(PROPSHAFT) - COUNTER ROTATION

Below is the parts list for Mercury V-200XRI (EFI) GEAR HOUSING(PROPSHAFT) - COUNTER ROTATION:

Position No.	Part Name	OEM Number	Supersedes
1	GEAR HOUSING ASSEMBLY (BASIC) (BLACK)	1647-9148T47
1	GEAR HOUSING ASSEMBLY (BASIC) (GRAY)	1647-9148T47
47	SHIFT CAM	789562
48	FOLLOWER ASSEMBLY	89594A1
49	ROD	79911A1
50	SPRING	24-79910
51	WASHER	12-78910
52	PIN	17-8M0084245	17-78906
53	CUP, Bearing	14469T
54	BEARING, Ball	30-88957T
55	Not Sold Separate, Reverse Gear (PART OF 43-18572A1 OR 43-18475A1) (#N.S.S.)
56	BEARING ASSEMBLY, Roller	31-15844
57	PIN, Detent	17-78909
58	CLUTCH	52-823174T	52-823174, 52-78959
59	PIN, Cross	17-8M0084243	17-78905
60	SPRING	24-78962
61	GEAR ASSEMBLY, Forward (135/150)	43-18572T1
61	GEAR ASSEMBLY, Forward (175/200)	43-18475T1
62	SPACER SHIM, (.125)	23-176151
62	SPACER SHIM, (.127)	23-176152
62	SPACER SHIM, (.129)	23-176153
62	SPACER SHIM, (.131)	23-176154
62	SPACER SHIM, (.133)	23-176155
62	SPACER SHIM, (.135)	23-176156
62	SPACER SHIM, (.137)	23-176157
62	SPACER SHIM, (.139)	23-176158
62	SPACER SHIM, (.141)	23-176159
62	SPACER SHIM, (.143)	23-1761510
62	SPACER SHIM, (.145)	23-1761511
62	SPACER SHIM, (.147)	23-1761512
62	SPACER SHIM, (.149)	23-1761513
63	BEARING, Roller	31-15841
64	THRUST RING	12-17616
65	O-RING	25-8M0214920
66	ADAPTOR ASSEMBLY, Bearing	18447T2
67	BEARING, Roller	31-15843T
68	THRUST WASHER	12-18448
69	BEARING, Thrust	31-15842
70	PROPELLER SHAFT	44-18446
71	CARRIER ASSEMBLY, Bearing	818896T2
72	BEARING, Needle	31-30956T
73	SEAL	26-8M0204670
73A	SEAL	26-8M0204670
74	TAB WASHER	14-183231
75	RETAINER	8M2011027	79448
76	KEY	28-30281
77	TRIM TAB (USE WITH GEAR HOUSING W/O ANODES)	97-31640Q4
77	TRIM TAB (USE WITH GEAR HOUSING W/ANODES)	31640T07
78	SCREW, (.437-14 x 1.750)	10-8M0204686
79	FILLER BLOCK	8M0039169	67891
80	WASHER, (.453 x .812 x .105) Stainless Steel Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	12-45176
81	NUT, (.437-20) Stainless Steel Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	11-8M0204653
82	THRUST HUB Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	12-835467Q01	12-835467 1 THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT
83	WASHER, Splined Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	12-31211Q03
84	TAB WASHER Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	14-816629Q	14-816629, 14-31210, 14-816629B THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT
85	PROP NUT KIT, (.750-16) Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	11-52707Q1
86	LOCKWASHER, Toothed Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	13-423511
87	SCREW, (.375-16 x 1.00) Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	10-65210
-	GASKET SET, Engine Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT
-	SEAL KIT Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	26-89238A2

GEAR HSG(DRIVESHAFT)(XR6/MAG III - 1.78:1 RATIO)

Below is the parts list for Mercury V-200XRI (EFI) GEAR HSG(DRIVESHAFT)(XR6/MAG III - 1.78:1 RATIO):

Position No.	Part Name	OEM Number	Supersedes
1	GEAR HOUSING ASSEMBLY, Basic - Black	1674-814247T1
1	GEAR HOUSING ASSEMBLY, Basic - Gray	1674-814247T2
2	CONNECTOR ASSEMBLY (USE WHERE APPLICABLE)	22-85822A10
2A	SLEEVE (OLD DESIGN)	23-43998
3	PIN, Dowel - Without Hole (.375 x .625)	17-43044
4	STUD, (.438 x 3.12)	16-786382
5	STUD, (.437-14/.437-20 x 2.060)	16-8M0133358
6	STUD, (.312 x 3.38)	16-8M0034463	16-56297 2
7	STUD, (.250-20/.250-28 x 3.125)	16-306671
8	BEARING ASSEMBLY, Roller	31-35934A1
9	SCREW, (.375-16 x .250)	10-79953Q04
10	SCREW, Magnetic	22-8M0058389	22-67892A06
11	DRIVESHAFT	45-815168
12	Not Sold Separate, Pinion Gear (PART OF 43-16279A2) (#N.S.S.)
13	WASHER, Fiber	12-191833
14	NUT, (.625-18)	11-35921
15	SHIM SET	15-42637A1
16	BEARING, Roller	31-8M0146566
17	RETAINER	8245191
18	BASE ASSEMBLY, Water Pump	46-8M0077147	46-42579A 3
19	GASKET	27-8M0204678
20	O-RING, (2.175 x .175)	25-8M0142854
21	SEAL, Oil	26-89238
22	SEAL, Oil	26-16977
23	GASKET	27-8M0090319	27-85608 1
24	GASKET	27-858524	27-85609 1, 27-85609B 1
25	FACE PLATE	8M0204677
26	BODY ASSEMBLY, Water Pump	46-96148T1
27	INSERT	48752T
28	SEAL	26-38970
29	IMPELLER	47-89984T3
30	KEY	28-8M0214992
31	SCREW, (#14-8 x 2.25)	10-8M0215009
32	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
33	NUT, (.250-28)	11-8267119
34	WASHER	12-36001
35	NUT	11-13436
37	SLEEVE	23-29804T
38	SHIFT SHAFT (USE W/O E-RING)	8152641
38	SHIFT SHAFT, LOWER Comment: USE WITH E-RING	8152641
39	E RING Comment: USE WITH E-RING	53-29641
40	O-RING, (.862 x .103)	25-25439
41	BUSHING ASSEMBLY	23-77631A2
42	SEAL, Oil	26-8M0204708
43	WASHER, SHIFT SHAFT BUSHING	12-77674
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	REPAIR KIT, Water Pump	46-96148A8
-	SEAL KIT	26-89238A2

GEAR HSG(PROP SHAFT)(XR6/MAG III - 1.78:1 RATIO)

Below is the parts list for Mercury V-200XRI (EFI) GEAR HSG(PROP SHAFT)(XR6/MAG III - 1.78:1 RATIO):

Position No.	Part Name	OEM Number	Supersedes
1	GEAR HOUSING ASSEMBLY, Basic - Black	1674-814247T1
1	GEAR HOUSING ASSEMBLY, Basic - Gray	1674-814247T2
44	CAM, Shift Control	760394
45	FOLLOWER KIT, Cam	850315A1
46	SPRING	24-30622
47	SHIM SET	15-44491A1
48	BEARING SET, Cup And Cone	31-30894A1
49	GEAR ASSEMBLY, Forward	43-16279A2
50	BEARING, Needle	31-30895T
51	CLUTCH	52-822539T	52-822539, 52-814756, 52-12777
52	PIN, Cross	17-8M0100263	17-8M0084681, 17-8M0020941, 17-30632
53	SPRING	24-30893
54	PROPELLER SHAFT	44-12238T
55	Not Sold Separate, Reverse Gear (PART OF 43-16279A2) (#N.S.S.)
56	THRUST WASHER	12-76358
57	O-RING	25-29976
58	CARRIER ASSEMBLY, Bearing	41529T2
59	FITTING, Grease	22-8M0169588
60	BEARING, Needle	31-30956T
61	SEAL	26-8M0204670
62	KEY	28-30281
63	TAB WASHER	14-52700
64	COVER	52699
65	FILLER BLOCK	8M0039169	67891
66	SCREW, (.375-16 x 1.00) Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	10-65210
68	TAB WASHER Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	14-816629Q	14-816629, 14-31210, 14-816629B THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT
69	PROP NUT KIT, (.750-16) Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	11-52707Q1
70	TRIM TAB Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	97-31640Q4
71	SCREW, (.437-14 x 1.750) Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	10-8M0204686
72	WASHER, (.453 x .812 x .105) Stainless Steel Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	12-45176
73	NUT, (.437-20) Stainless Steel Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	11-8M0204653
74	THRUST WASHER Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	13191Q01
-	GASKET SET, Engine Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT
-	SEAL KIT Comment: THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT	26-89238A2

Gear Housing Chart

Below is the parts list for Mercury V-200XRI (EFI) Gear Housing Chart:

Position No.	Part Name	OEM Number
-	GEAR HOUSING ASSEMBLY, 1.78:1 Gear Ratio - Black Comment: (Black)(Standard)(Without Anodes)	1674-814247T3
-	GEAR HOUSING ASSEMBLY, 1.78:1 Gear Ratio - Gray Comment: (Gray)(Standard)(Without Anodes)	1674-814247T4
-	GEAR HOUSING ASSEMBLY, Standard Rotation 1.87:1 Gear Ratio Comment: (Long-Black)(Without Anodes)	1647-9148T84
-	GEAR HOUSING ASSEMBLY, Standard Rotation 1.87:1 Gear Ratio Comment: (X-Long-Black)(Without Anodes)	1647-9148T85
-	GEAR HOUSING ASSEMBLY, Standard Rotation 1.87:1 Gear Ratio Comment: (Long-Gray)(Without Anodes)	1647-9148T84
-	GEAR HOUSING ASSEMBLY, Standard Rotation 1.87:1 Gear Ratio Comment: (X-Long-Gray)(Without Anodes)	1647-9148T91
-	GEAR HOUSING ASSEMBLY, Standard Rotation 1.87:1 Gear Ratio Comment: (Tracker)(Without Anodes)	1647-9148T84
-	GEAR HOUSING ASSEMBLY, Standard Rotation 2:1 Gear Ratio Comment: (Long-Black)(Without Anodes)	1647-9148T81
-	GEAR HOUSING ASSEMBLY, Standard Rotation 2:1 Gear Ratio Comment: (Long-Gray)(Without Anodes)	1647-9148T87
-	GEAR HOUSING ASSEMBLY, Counter Rotation Comment: (X-Long-Black)(Without Anodes)	1647-9148T86
-	GEAR HOUSING ASSEMBLY, Counter Rotation Comment: (X-Long-Gray)(Without Anodes)	1647-9148T92
-	GEAR HOUSING ASSEMBLY, Standard Rotation 2:1 Gear Ratio Comment: (Long-Black)(With Anodes)	1647-9148T81
-	GEAR HOUSING ASSEMBLY, Standard Rotation 2:1 Gear Ratio Comment: (X-Long-Black)(With Anodes)	1647-9148T82
-	GEAR HOUSING ASSEMBLY, Standard Rotation 2:1 Gear Ratio Comment: (Long-Gray)(With Anodes)	1647-9148T87
-	GEAR HOUSING ASSEMBLY, Standard Rotation 2:1 Gear Ratio Comment: (X-Long-Gray)(With Anodes)	1647-9148T88
-	GEAR HOUSING ASSEMBLY, Standard Rotation 1.87:1 Gear Ratio Comment: (Long-Black)(With Anodes)	1647-9148T84
-	GEAR HOUSING ASSEMBLY, Standard Rotation 1.87:1 Gear Ratio Comment: (X-Long-Black)(With Anodes)	1647-9148T85
-	GEAR HOUSING ASSEMBLY, Standard Rotation 1.87:1 Gear Ratio Comment: (Long-Gray)(Long-Black)(With Anodes)	1647-9148T84
-	GEAR HOUSING ASSEMBLY, Standard Rotation 1.87:1 Gear Ratio Comment: (X-Long-Gray)(With Anodes)	1647-9148T91
-	GEAR HOUSING ASSEMBLY, Standard Rotation 1.87:1 Gear Ratio Comment: (Tracker)(With Anodes)	1647-9148T84
-	GEAR HOUSING ASSEMBLY, Counter Rotation Comment: (X-Long-Black)(With Anodes)	1647-9148T86
-	GEAR HOUSING ASSEMBLY, Counter Rotation Comment: (X-Long-Gray)(With Anodes)	1647-9148T92

Gear Housing, Driveshaft - 2:1 Gear Ratio

Below is the parts list for Mercury V-200XRI (EFI) Gear Housing, Driveshaft - 2:1 Gear Ratio:

Position No.	Part Name	OEM Number	Supersedes
1	GEAR HOUSING ASSEMBLY, Basic Gray Comment: (Design I With Out Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Gray Comment: (Design I With Out Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Black Comment: (Design II With Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Gray Comment: (Design II With Anodes)	1647-9148T47
2	CONNECTOR ASSEMBLY, Use Where Applicable	22-85822A10
3	PIN, Dowel - Without Hole (.375 x .625)	17-43044
4	STUD, (.438 x 3.12), Long	16-786382
4	STUD, (.438 x 3.69), X-Long	16-8M0034464	16-18978 3
5	STUD, (.44 x 2.06)	16-8M0133358
6	STUD, (.312 x 3.38)	16-8M0034463	16-56297 2
7	STUD, (.250-20/.250-28 x 3.125)	16-306671
8	BEARING ASSEMBLY, Roller	31-42647A1
9	SLEEVE, Old Design	23-43998
9A	ANODE Comment: (Design II)	97-826134Q	826134, 826134A 1 (Design II)
9B	SCREW, (M6 x 40) Comment: (Design II)	10-4000333
9C	NUT, (M6) Comment: (Design II)	11-401386
11	DRIVESHAFT, Long	45-897624T	45-44000 1
11	DRIVESHAFT, X-Long	45-897625T	45-44209 1
12	Not Sold Separate, Pinion Gear (Part Of 43- 44102A 2 Or 43- 44102A 7) (#N.S.S.)
13	WASHER	12-92721
14	NUT, (.625-18)	11-35921
15	SHIM SET	15-42637A1
16	BEARING, Roller	31-8M0146566
17	RETAINER	8245191
18	BASE ASSEMBLY, Water Pump	46-8M0077147	46-42579A 3
19	GASKET	27-8M0204678
20	O-RING, (2.175 x .175)	25-8M0142854
21	SEAL, Oil	26-89238
22	SEAL, Oil	26-16977
23	GASKET, Lower	27-8M0090319	27-85608 1
24	GASKET, Upper	27-858524	27-85609 1, 27-85609B 1
25	FACE PLATE	8M0204677
26	BODY ASSEMBLY, Water Pump	46-96148T1
27	INSERT	48752T
28	SEAL, Rubber	26-38970
29	IMPELLER	47-89984T3
30	KEY	28-8M0214992
31	SCREW, (#14-8 x 2.25)	10-8M0215009
32	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
33	NUT, (.250-28)	11-8267119
34	WASHER	12-36001
35	NUT	11-13436
37	SLEEVE	23-29804T
38	SHIFT SHAFT Comment: (Use With Out E-Ring)	789022
38	SHAFT Comment: (Use With E-Ring)	789022
39	E RING	53-29641
41	O-RING, (.862 x .103)	25-25439
42	BUSHING ASSEMBLY	23-77631A2
43	SEAL, Oil	26-8M0204708
44	WASHER, Rubber	12-77674
45	SCREW, (.375-16 x .250), Grease Filler	10-79953Q04
46	SCREW, Magnetic, Drain	22-8M0058389	22-67892A06
47	WASHER, Fiber	12-191833
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	REPAIR KIT, Water Pump	46-96148A8
-	SEAL KIT	26-89238A2

Gear Housing, Driveshaft - Counter Rotation

Below is the parts list for Mercury V-200XRI (EFI) Gear Housing, Driveshaft - Counter Rotation:

Position No.	Part Name	OEM Number	Supersedes
1	GEAR HOUSING ASSEMBLY, Basic Black Comment: (Design I With Out Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Gray Comment: (Design I With Out Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Gray Comment: (Design II With Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Gray Comment: (Design II With Anodes)	1647-9148T47
2	CONNECTOR ASSEMBLY, Use Where Applicable	22-85822A10
3	PIN, Dowel - Without Hole (.375 x .625)	17-43044
4	STUD, (.438 x 3.69)	16-8M0034464	16-18978 3
5	STUD, (.44 x 2.06)	16-8M0133358
6	STUD, (.312 x 3.38)	16-8M0034463	16-56297 2
7	STUD, (.250-20/.250-28 x 3.125)	16-306671
8	BEARING ASSEMBLY, Roller	31-42647A1
9	SLEEVE, Old Design	23-43998
9A	ANODE Comment: (Design II)	97-826134Q	826134, 826134A 1 (Design II)
9B	SCREW, (M6 x 40) Comment: (Design II)	10-4000333
9C	NUT, (M6) Comment: (Design II)	11-401386
11	DRIVESHAFT	45-897625T	45-44209 1
12	Not Sold Separate, Pinion Gear (Part Of 43- 18475A 1) (#N.S.S.)
13	WASHER	12-92721
14	NUT, (.625-18)	11-35921
15	SHIM SET	15-42637A1
16	BEARING, Roller	31-8M0146566
17	RETAINER	8245191
18	BASE ASSEMBLY, Water Pump	46-8M0077147	46-42579A 3
19	GASKET	27-8M0204678
20	O-RING, (2.175 x .175)	25-8M0142854
21	SEAL, Oil	26-89238
22	SEAL, Oil	26-16977
23	GASKET, Lower	27-8M0090319	27-85608 1
24	GASKET, Upper	27-858524	27-85609 1, 27-85609B 1
25	FACE PLATE	8M0204677
26	BODY ASSEMBLY, Water Pump	46-96148T1
27	INSERT	48752T
28	SEAL	26-38970
29	IMPELLER	47-89984T3
30	KEY	28-8M0214992
31	SCREW, (#14-8 x 2.25)	10-8M0215009
32	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
33	NUT, (.250-28)	11-8267119
34	WASHER	12-36001
35	NUT	11-13436
37	SLEEVE	23-29804T
38	SHIFT SHAFT Comment: (Use With Out E-Ring)	789022
38	SHAFT Comment: (Use With E-Ring)	789022
39	E RING	53-29641
40	WASHER, Fiber	12-191833
41	O-RING, (.862 x .103)	25-25439
42	BUSHING ASSEMBLY	23-77631A2
43	SEAL, Oil	26-8M0204708
44	WASHER, Rubber	12-77674
45	SCREW, (.375-16 x .250)	10-79953Q04
46	SCREW, Magnetic	22-8M0058389	22-67892A06
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	REPAIR KIT, Water Pump	46-96148A8
-	SEAL KIT	26-89238A2

Gear Housing, Driveshaft-1.87:1 Gear Ratio 4.75 Inch Dia

Below is the parts list for Mercury V-200XRI (EFI) Gear Housing, Driveshaft-1.87:1 Gear Ratio 4.75 Inch Dia:

Position No.	Part Name	OEM Number	Supersedes
1	GEAR HOUSING ASSEMBLY, Basic Black Comment: (Design I With Out Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Gray Comment: (Design I With Out Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Tracker Comment: (Design I With Out Anodes)	1647-9148T49
1	GEAR HOUSING ASSEMBLY, Basic Black Comment: (Design II With Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Gray Comment: (Design II With Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Tracker Comment: (Design II With Anodes)	1647-9148T49
2	CONNECTOR ASSEMBLY, Use Where Applicable	22-85822A10
3	PIN, Dowel - Without Hole (.375 x .625)	17-43044
4	STUD, (.438 x 3.12), Long	16-786382
4	STUD, (.438 x 3.69), X-Long	16-8M0034464	16-18978 3
5	STUD, (.44 x 2.06)	16-8M0133358
6	STUD, (.312 x 3.38)	16-8M0034463	16-56297 2
7	STUD, (.250-20/.250-28 x 3.125)	16-306671
8	BEARING ASSEMBLY, Roller	31-42647A1
9	SLEEVE, Old Design	23-43998
9A	ANODE Comment: (Design II)	97-826134Q	826134, 826134A 1 (Design II)
9B	SCREW, (M6 x 40) Comment: (Design II)	10-4000333
9C	NUT, (M6) Comment: (Design II)	11-401386
11	DRIVESHAFT, Long	45-897624T	45-44000 1
11	DRIVESHAFT, Extra Long	45-897625T	45-44209 1
12	NOT SOLD SEPARATE, Pinion Gear (Part Of 43- 44104A 2 Or 43- 44104A 8)	NSS
13	WASHER	12-92721
14	NUT, (.625-18)	11-35921
15	SHIM SET	15-42637A1
16	BEARING, Roller	31-8M0146566
17	RETAINER	8245191
18	BASE ASSEMBLY, Water Pump	46-8M0077147	46-42579A 3
19	GASKET	27-8M0204678
20	O-RING, (2.175 x .175)	25-8M0142854
21	SEAL, Oil	26-89238
22	SEAL, Oil	26-16977
23	GASKET, Lower	27-8M0090319	27-85608 1
24	GASKET, Upper	27-858524	27-85609 1, 27-85609B 1
25	FACE PLATE	8M0204677
26	BODY ASSEMBLY, Water Pump	46-96148T1
27	INSERT	48752T
28	SEAL	26-38970
29	IMPELLER	47-89984T3
30	KEY	28-8M0214992
31	SCREW, (#14-8 x 2.25)	10-8M0215009
32	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
33	NUT, (.250-28)	11-8267119
34	WASHER	12-36001
35	NUT	11-13436
37	SLEEVE	23-29804T
38	SHIFT SHAFT, Use With Out E-Ring	789022
38	SHAFT, Use With E-Ring	789022
39	E RING	53-29641
41	O-RING, (.862 x .103)	25-25439
42	BUSHING ASSEMBLY	23-77631A2
43	SEAL, Oil	26-8M0204708
44	WASHER	12-77674
45	SCREW, (.375-16 x .250), Grease Filler	10-79953Q04
46	SCREW, Magnetic, Drain	22-8M0058389	22-67892A06
47	WASHER, Fiber	12-191833
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	REPAIR KIT, Water Pump	46-96148A8
-	SEAL KIT	26-89238A2

Gear Housing, Driveshaft-178:1 Gear Ratio 4.25 Inch Dia

Below is the parts list for Mercury V-200XRI (EFI) Gear Housing, Driveshaft-178:1 Gear Ratio 4.25 Inch Dia:

Position No.	Part Name	OEM Number	Supersedes
1	GEAR HOUSING ASSEMBLY, Basic - Black	1674-814247T1
1	GEAR HOUSING ASSEMBLY, Basic - Gray	1674-814247T2
2	CONNECTOR ASSEMBLY	22-85822A10
2A	SLEEVE, Old Design	23-43998
3	PIN, Dowel - Without Hole (.375 x .625)	17-43044
4	STUD, (.438 x 3.12)	16-786382
5	STUD, (.44 x 2.06)	16-8M0133358
6	STUD, (.312 x 3.38)	16-8M0034463	16-56297 2
7	STUD, (.250-20/.250-28 x 3.125)	16-306671
8	BEARING ASSEMBLY, Roller	31-35934A1
9	SCREW, (.375-16 x .250), Greese Filler	10-79953Q04
10	SCREW, Magnetic, Drain	22-8M0058389	22-67892A06
11	DRIVESHAFT	45-815168
12	Not Sold Separate, Pinion Gear (Part Of 43- 16279A 2) (#N.S.S.)
13	WASHER, Fiber	12-191833
14	NUT, (.625-18)	11-35921
15	SHIM SET	15-42637A1
16	BEARING, Roller	31-8M0146566
17	RETAINER	8245191
18	BASE ASSEMBLY, Water Pump	46-8M0077147	46-42579A 3
19	GASKET	27-8M0204678
20	O-RING, (2.175 x .175)	25-8M0142854
21	SEAL, Oil	26-89238
22	SEAL, Oil	26-16977
23	GASKET, Lower	27-8M0090319	27-85608 1
24	GASKET, Upper	27-858524	27-85609 1, 27-85609B 1
25	FACE PLATE	8M0204677
26	BODY ASSEMBLY, Water Pump	46-96148T1
27	INSERT	48752T
28	SEAL, Rubber	26-38970
29	IMPELLER	47-89984T3
30	KEY	28-8M0214992
31	SCREW, (#14-8 x 2.25)	10-8M0215009
32	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
33	NUT, (.250-28)	11-8267119
34	WASHER	12-36001
35	NUT	11-13436
37	SLEEVE	23-29804T
38	SHIFT SHAFT Comment: (Use With Out E-Ring)	8152641
38	SHIFT SHAFT Comment: (Use With E-Ring)	8152641
39	E RING	53-29641
40	O-RING, (.862 x .103)	25-25439
41	BUSHING ASSEMBLY	23-77631A2
42	SEAL, Oil	26-8M0204708
43	WASHER, Rubber - Shift Shaft Bushing	12-77674
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	REPAIR KIT, Water Pump	46-96148A8
-	SEAL KIT	26-89238A2

Gear Housing, Propshaft - 2:1 Gear Ratio

Below is the parts list for Mercury V-200XRI (EFI) Gear Housing, Propshaft - 2:1 Gear Ratio:

Position No.	Part Name	OEM Number	Supersedes
1	GEAR HOUSING ASSEMBLY, Basic Black Comment: (Design I With Out Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Gray Comment: (Design I With Out Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Gray Comment: (Design II With Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Gray Comment: (Design II With Anodes)	1647-9148T47
48	SHIFT CAM	789562
49	FOLLOWER ASSEMBLY	89594A1
50	ROD	79911A1
51	SPRING	24-79910
52	WASHER	12-78910
53	PIN	17-8M0084245	17-78906
54	SHIM SET (.002-3-5-10)	15-47397A1
55	BEARING ASSEMBLY, Tapered Roller	31-78172A1
56	GEAR ASSEMBLY, Forward, Includes Reverse Gear Comment: SN# G052417 & Below	43-44102A2
56	GEAR SET, Does Not Include Reverse Gear Comment: SN# G052418 & Up	43-44102A7
56	GEAR SET, High Altitude - 2.3:1 Gear Ratio	43-16294A5
57	BEARING, Roller	31-549281
58	CLUTCH	52-823174T	52-823174, 52-78959
59	PIN, Cross	17-8M0084243	17-78905
60	PIN, Detent	17-78909
61	SPRING	24-78962
62	PROPELLER SHAFT	44-94148
63	Not Sold Separate, Gear (Part Of 43- 44102A 2) (#N.S.S.) Comment: SN# G052417 & Below
63	GEAR ASSEMBLY, Reverse Comment: SN# G052418 & Up	43-824987A2
63A	SPACER	23-824108
64	RING, Thrust	681001
65	BEARING, Ball	30-88957T
66	O-RING	25-8M0214920
67	CARRIER ASSEMBLY, Bearing	43567T1
68	BEARING, Needle	31-30956T
69	SEAL	26-8M0204670
70	KEY	28-30281
71	TAB WASHER	14-79447
72	RETAINER	8M2011027	79448
73	TRIM TAB Comment: (Use With Gear Housing With Out Anodes)	97-31640Q4
73	TRIM TAB Comment: (Use With Gear Housing With Anodes)	31640T07
74	SCREW, (.437-14 x 1.750)	10-8M0204686
75	FILLER BLOCK	8M0039169	67891
76	NUT, (.437-20) Stainless Steel	11-8M0204653
77	SCREW, (.375-16 x 1.00)	10-65210
78	THRUST HUB	12-835467Q01	12-835467 1
79	WASHER, Splined	12-31211Q03
80	TAB WASHER	14-816629Q	14-816629, 14-31210, 14-816629B
81	PROP NUT KIT, (.750-16)	11-52707Q1
82	LOCKWASHER, Toothed	13-423511
83	WASHER, (.453 x .812 x .105) Stainless Steel	12-45176
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	SEAL KIT	26-89238A2

Gear Housing, Propshaft - Counter Rotation

Below is the parts list for Mercury V-200XRI (EFI) Gear Housing, Propshaft - Counter Rotation:

Position No.	Part Name	OEM Number	Supersedes
1	GEAR HOUSING ASSEMBLY, Basic Black Comment: (Design I With Out Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Gray Comment: (Design I With Out Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Gray Comment: (Design II With Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Gray Comment: (Design II With Anodes)	1647-9148T47
47	SHIFT CAM	789562
48	FOLLOWER ASSEMBLY	89594A1
49	ROD	79911A1
50	SPRING	24-79910
51	WASHER	12-78910
52	PIN	17-8M0084245	17-78906
53	CUP, Bearing	14469T
54	BEARING, Ball	30-88957T
55	Not Sold Separate, Reverse Gear (Part Of 43- 18475A 1) (#N.S.S.)
56	BEARING ASSEMBLY, Roller	31-15844
57	PIN, Detent	17-78909
58	CLUTCH	52-823174T	52-823174, 52-78959
59	PIN, Cross	17-8M0084243	17-78905
60	SPRING	24-78962
61	GEAR ASSEMBLY, Forward	43-18475T1
62	SPACER SHIM, (.125)	23-176151
62	SPACER SHIM, (.127)	23-176152
62	SPACER SHIM, (.129)	23-176153
62	SPACER SHIM, (.131)	23-176154
62	SPACER SHIM, (.133)	23-176155
62	SPACER SHIM, (.135)	23-176156
62	SPACER SHIM, (.137)	23-176157
62	SPACER SHIM, (.139)	23-176158
62	SPACER SHIM, (.141)	23-176159
62	SPACER SHIM, (.143)	23-1761510
62	SPACER SHIM, (.145)	23-1761511
62	SPACER SHIM, (.147)	23-1761512
62	SPACER SHIM, (.149)	23-1761513
63	BEARING, Roller	31-15841
64	THRUST RING	12-17616
65	O-RING	25-8M0214920
66	ADAPTOR ASSEMBLY, Bearing	18447T2
67	BEARING, Roller	31-15843T
68	THRUST WASHER	12-18448
69	BEARING, Thrust	31-15842
70	PROPELLER SHAFT	44-18446
71	CARRIER ASSEMBLY, Bearing	818896T2
72	BEARING, Needle	31-30956T
73	SEAL	26-8M0204670
73A	SEAL	26-8M0204670
74	TAB WASHER	14-183231
75	RETAINER	8M2011027	79448
76	KEY	28-30281
77	TRIM TAB Comment: (Use With Gear Housing With Out Anodes)	97-31640Q4
77	TRIM TAB Comment: (Use With Gear Housing With Anodes)	31640T07
78	SCREW, (.437-14 x 1.750)	10-8M0204686
79	FILLER BLOCK	8M0039169	67891
80	WASHER, (.453 x .812 x .105) Stainless Steel	12-45176
81	NUT, (.437-20) Stainless Steel	11-8M0204653
82	THRUST HUB	12-835467Q01	12-835467 1
83	WASHER, Splined	12-31211Q03
84	TAB WASHER	14-816629Q	14-816629, 14-31210, 14-816629B
85	PROP NUT KIT, (.750-16)	11-52707Q1
86	LOCKWASHER, Toothed	13-423511
87	SCREW, (.375-16 x 1.00)	10-65210
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	SEAL KIT	26-89238A2

Gear Housing, Propshaft 1.78:1 Gear Ratio 4.25 Inch Dia

Below is the parts list for Mercury V-200XRI (EFI) Gear Housing, Propshaft 1.78:1 Gear Ratio 4.25 Inch Dia:

Position No.	Part Name	OEM Number	Supersedes
1	GEAR HOUSING ASSEMBLY, Basic - Black	1674-814247T1
1	GEAR HOUSING ASSEMBLY, Basic - Gray	1674-814247T2
44	CAM, Shift Control	760394
45	FOLLOWER KIT, Cam	850315A1
46	SPRING	24-30622
47	SHIM SET	15-44491A1
48	BEARING SET, Cup And Cone	31-30894A1
49	GEAR ASSEMBLY, Forward	43-16279A2
50	BEARING, Needle	31-30895T
51	CLUTCH	52-822539T	52-822539, 52-814756, 52-12777
52	PIN, Cross	17-8M0100263	17-8M0084681, 17-8M0020941, 17-30632
53	SPRING	24-30893
54	PROPELLER SHAFT	44-12238T
55	Not Sold Separate, Reverse Gear (Part Of 43- 16279A 2) (#N.S.S.)
56	THRUST WASHER	12-76358
57	O-RING	25-29976
58	CARRIER ASSEMBLY, Bearing	41529T2
59	FITTING, Grease	22-8M0169588
60	BEARING, Needle	31-30956T
61	SEAL	26-8M0204670
62	KEY	28-30281
63	TAB WASHER	14-52700
64	COVER	52699
65	FILLER BLOCK	8M0039169	67891
66	SCREW, (.375-16 x 1.00)	10-65210
68	TAB WASHER	14-816629Q	14-816629, 14-31210, 14-816629B
69	PROP NUT KIT, (.750-16)	11-52707Q1
70	TRIM TAB	97-31640Q4
71	SCREW, (.437-14 x 1.750)	10-8M0204686
72	WASHER, (.453 x .812 x .105) Stainless Steel	12-45176
73	NUT, (.437-20) Stainless Steel	11-8M0204653
74	THRUST WASHER	13191Q01
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	SEAL KIT	26-89238A2

Gear Housing, Propshaft-1.87:1 Gear Ratio 4.75 Inch Dia

Below is the parts list for Mercury V-200XRI (EFI) Gear Housing, Propshaft-1.87:1 Gear Ratio 4.75 Inch Dia:

Position No.	Part Name	OEM Number	Supersedes
1	GEAR HOUSING ASSEMBLY, Basic Black Comment: (Design I With Out Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Gray Comment: (Design I With Out Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Tracker Comment: (Design I With Out Anodes)	1647-9148T49
1	GEAR HOUSING ASSEMBLY, Basic Black Comment: (Design II With Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Gray Comment: (Design II With Anodes)	1647-9148T47
1	GEAR HOUSING ASSEMBLY, Basic Tracker Comment: (Design II With Anodes)	1647-9148T49
48	SHIFT CAM	789562
49	FOLLOWER ASSEMBLY	89594A1
50	ROD	79911A1
51	SPRING	24-79910
52	WASHER	12-78910
53	PIN	17-8M0084245	17-78906
54	SHIM SET	15-47397A1
55	BEARING ASSEMBLY, Tapered Roller	31-78172A1
56	GEAR ASSEMBLY, Forward (Includes Reverse Gear) Comment: SN# G052417 & Below	43-44104T2
56	GEAR SET (Does Not Include Reverse Gear) Comment: SN# G052418 & Up	43-44104A8
57	BEARING, Roller	31-549281
58	CLUTCH	52-823174T	52-823174, 52-78959
59	PIN, Cross	17-8M0084243	17-78905
60	PIN, Detent	17-78909
61	SPRING	24-78962
62	PROPELLER SHAFT	44-94148
63	NOT SOLD SEPARATE (Part Of 43- 44104A 2) (#N.S.S) Comment: SN# G052417 & Below
63	GEAR ASSEMBLY, Reverse Comment: SN# G052418 & Up	43-824986A2
63A	SPACER	23-824108
64	RING, Thrust	681001
65	BEARING, Ball	30-88957T
66	O-RING	25-8M0214920
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	SEAL KIT	26-89238A2
67	CARRIER ASSEMBLY, Bearing	43567T1
68	BEARING, Needle	31-30956T
69	SEAL	26-8M0204670
70	KEY	28-30281
71	TAB WASHER	14-79447
72	RETAINER	8M2011027	79448
73	TRIM TAB (Use With Gear Housing With Out Anodes)	97-31640Q4
73	TRIM TAB (Use With Gear Housing With Anodes)	31640T07
74	SCREW, (.437-14 x 1.750)	10-8M0204686
75	FILLER BLOCK	8M0039169	67891
76	NUT, (.437-20) Stainless Steel Comment: (These Replacement Parts Are Not Included With Complete Gear Housing Replacement)	11-8M0204653
77	SCREW, (.375-16 x 1.00) Comment: (These Replacement Parts Are Not Included With Complete Gear Housing Replacement)	10-65210
78	THRUST HUB Comment: (These Replacement Parts Are Not Included With Complete Gear Housing Replacement)	12-835467Q01	12-835467 1 (These Replacement Parts Are Not Included With Complete Gear Housing Replacement)
79	WASHER, Splined Comment: (These Replacement Parts Are Not Included With Complete Gear Housing Replacement)	12-31211Q03
80	TAB WASHER Comment: (These Replacement Parts Are Not Included With Complete Gear Housing Replacement)	14-816629Q	14-816629, 14-31210, 14-816629B (These Replacement Parts Are Not Included With Complete Gear Housing Replacement)
81	PROP NUT KIT, (.750-16) Comment: (These Replacement Parts Are Not Included With Complete Gear Housing Replacement)	11-52707Q1
82	LOCKWASHER, Toothed Comment: (These Replacement Parts Are Not Included With Complete Gear Housing Replacement)	13-423511
83	WASHER, (.453 x .812 x .105) Stainless Steel Comment: (These Replacement Parts Are Not Included With Complete Gear Housing Replacement)	12-45176
-	SEAL KIT	26-89238A2

IGNITION COIL/VOLTAGE REGULATOR

Below is the parts list for Mercury V-200XRI (EFI) IGNITION COIL/VOLTAGE REGULATOR:

Position No.	Part Name	OEM Number	Supersedes
1	MOUNTING PLATE	195872
2	STUD	16-33778
3	BUSHING	23-19661
4	LOCKWASHER, (.250) Stainless Steel	13-26992
5	NUT, (.250-28)	11-8267119
6	CABLE ASSEMBLY	84-88807A35
7	REGULATOR, Voltage	8M0084173	883072T, 854515T 1
8	SOLENOID ASSEMBLY Comment: SN# 0G201874 & Below	89-8M0185145
9	INSULATOR Comment: SN# 0G201874 & Below	85-97861
10	SCREW, (.250-20 x 1.12) Comment: SN# 0G201874 & Below	10-455611
11	WASHER, (.273 x .437 x .031) Stainless Steel Comment: SN# 0G201874 & Below	12-35950
12	NUT, (.250-20) Stainless Steel Comment: SN# 0G201874 & Below	11-8M0207776
13	NUT, Brass Comment: SN# 0G201874 & Below	8-32,11-26419
14	NUT, (.250-20) Brass Comment: SN# 0G201874 & Below	11-94330
15	HARNESS ASSEMBLY (2,4,6)	84-69738A9
15	HARNESS ASSEMBLY (1,3,5)	84-69739A6
16	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
17	COVER	43542
18	COIL ASSEMBLY, Ignition Comment: SN# 0G129221 & Below	339-832757A4
18	COIL ASSEMBLY, Ignition Comment: SN# 0G129222 & Up	339-832757A4
19	SCREW, (#10-32 x 2.125)	10-90048
20	NUT,	10-32,11-90078
21	CABLE KIT, Ignition	84-813715A9
22	BOOT/TERMINAL KIT	85-63709A1
23	SPARK PLUG (NGK-BU8H)	33-13686Q
23	SPARK PLUG (NGK-BUZ8H - CANADA/BELGIUM)	33-896329885
24	NUT, Brass	10-32,11-45076
25	CABLE ASSEMBLY Comment: SN# 0G201874 & Below	84-88807A13
26	SCREW, (#10-32 x .500) Stainless Steel	10-69022
27	WIRE ASSEMBLY, (2.750 Inches) Comment: SN# 0G201874 & Below	84-87379A14
28	WASHER, (.203 x .406 x .040)	12-89302
29	HARNESS ASSEMBLY Comment: SN# 0G201875 & Up	84-826802A4
30	RELAY Comment: SN# 0G201875 & Up	8M0207773
31	BRACKET Comment: SN# 0G201875 & Up	828102
32	SCREW, (.250-20 x 1.12) Comment: SN# 0G201875 & Up	10-455611
33	BUSHING Comment: SN# 0G201875 & Up	23-8M0214955
34	GROMMET Comment: SN# 0G201875 & Up	25-818967
35	WASHER, (.273 x .437 x .031) Stainless Steel Comment: SN# 0G201875 & Up	12-35950
36	NUT, (.250-20) Stainless Steel Comment: SN# 0G201875 & Up	11-8M0207776

INSTRUMENTATION

Below is the parts list for Mercury V-200XRI (EFI) INSTRUMENTATION:

Position No.	Part Name	OEM Number	Supersedes
1	SWITCH ASSEMBLY, Lanyard	87-19674A1
2	SCREW, (.190-16 x 1.750) Stainless Steel	10-18303
3	ADAPTER	813679	12051
4	LANYARD ASSEMBLY	15920Q54
5	SCREW, (#10-32 x 2.00) Stainless Steel	10-32866
6	CLAMP, Mounting	18321
7	WASHER, (.200 x .440 x .032)	12-24676
8	NUT, Stainless Steel	10-32,11-68219
9	RETAINER	79146
10	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
11	DIODE ASSEMBLY	812497A2
12	CABLE ASSEMBLY, (6.00 Inches)	84-11149A2

Ignition Coil/Voltage Regulator

Below is the parts list for Mercury V-200XRI (EFI) Ignition Coil/Voltage Regulator:

Position No.	Part Name	OEM Number	Supersedes
1	MOUNTING PLATE	195872
2	STUD	16-33778
3	BUSHING	23-19661
4	LOCKWASHER, (.250) Stainless Steel	13-26992
5	NUT, (.250-28)	11-8267119
6	CABLE ASSEMBLY	84-88807A35
7	REGULATOR, Voltage	8M0084173	883072T, 854515T 1
8	SOLENOID ASSEMBLY Comment: SN# 0G201874 & Below	89-8M0185145
9	INSULATOR Comment: SN# 0G201874 & Below	85-97861
10	SCREW, (.250-20 x 1.12) Comment: SN# 0G201874 & Below	10-455611
11	WASHER, (.187 x .500 x .062) Neoprene Comment: SN# 0G201874 & Below	12-8M0204663
12	NUT, (.250-20) Stainless Steel Comment: SN# 0G201874 & Below	11-8M0207776
13	NUT, Brass, Solenoid Terminal Comment: SN# 0G201874 & Below	8-32,11-26419
14	NUT, (.250-20) Brass, Solenoid Terminal Comment: SN# 0G201874 & Below	11-94330
15	HARNESS ASSEMBLY	84-69739A7
16	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
17	COVER, Ignition Coil	43542
18	COIL ASSEMBLY, Ignition Comment: SN# 0G129221 & Below	339-832757A4
18	COIL ASSEMBLY, Ignition Comment: (This Coil can be used on all engines regardless of serial number) SN# 0G129222 & Up	339-832757A4
19	SCREW, (#10-32 x 2.125), Ignition Coil Cover	10-90048
20	NUT, , Cover Screw/Ground Wire	10-32,11-90078
21	CABLE KIT, Ignition, High Tension	84-813715A9
22	BOOT/TERMINAL KIT, High Tension Cable	85-63709A1
23	SPARK PLUG (NGK #BU8H)	33-13686Q
23	SPARK PLUG (NGK #BUZ8H - Canda/Belgium)	33-896329885
24	NUT, Brass, Ignition Coil Terminal	10-32,11-45076
25	CABLE ASSEMBLY Comment: SN# 0G201874 & Below	84-88807A13
26	SCREW, (#10-32 x .500) Stainless Steel, Grounding Wire	10-69022
27	WIRE ASSEMBLY, (2.750 Inches) Comment: SN# 0G201874 & Below	84-87379A14
28	WASHER, (.203 x .406 x .040)	12-89302
29	HARNESS ASSEMBLY Comment: SN# 0G201875 & Up	84-826802A4
30	RELAY Comment: SN# 0G201875 & Up	8M0207773
31	BRACKET Comment: SN# 0G201875 & Up	828102
32	SCREW, (.250-20 x 1.12) Comment: SN# 0G201875 & Up	10-455611
33	BUSHING Comment: SN# 0G201875 & Up	23-8M0214955
34	GROMMET Comment: SN# 0G201875 & Up	25-818967
35	WASHER, (.273 x .437 x .031) Stainless Steel Comment: SN# 0G201875 & Up	12-35950
36	NUT, (.250-20) Stainless Steel Comment: SN# 0G201875 & Up	11-8M0207776

Instrumentation

Below is the parts list for Mercury V-200XRI (EFI) Instrumentation:

Position No.	Part Name	OEM Number	Supersedes
1	SWITCH ASSEMBLY, Lanyard	87-19674A1
2	SCREW, (.190-16 x 1.750) Stainless Steel	10-18303
3	ADAPTER	813679	12051
4	LANYARD ASSEMBLY	15920Q54
5	SCREW, (#10-32 x 2.00) Stainless Steel	10-32866
6	CLAMP, Mounting	18321
7	WASHER, (.200 x .440 x .032)	12-24676
8	NUT, Stainless Steel	10-32,11-68219
9	RETAINER	79146
10	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
11	DIODE ASSEMBLY	812497A2
12	CABLE ASSEMBLY, (6.00 Inches)	84-11149A2

JET COMPONENTS

Below is the parts list for Mercury V-200XRI (EFI) JET COMPONENTS:

Position No.	Part Name	OEM Number	Supersedes
1	SCREW, (.190-32 x 1.62)	10-88447
2	WASHER	12-38833
3	SPACER	23-94304
4	PLATE	13381
5	REV LIMITER	821889A30	821889A20
6	HARNESS ASSEMBLY, Adaptor - Rev Limiter	84-823147A5
7	GREASE KIT	91-30500A2
8	BASE ASSEMBLY, Water Pump	46-8M0077147	46-42579A 3
9	GASKET	27-8M0204678
10	SEAL, Oil	26-89238
11	SEAL, Oil	26-16977
12	GASKET	27-8M0090319	27-85608 1
13	GASKET	27-858524	27-85609 1, 27-85609B 1
14	FACE PLATE	8M0204677
15	BODY ASSEMBLY, Water Pump	46-96148T1
16	INSERT	48752T
17	SEAL	26-38970
18	IMPELLER	47-89984T3
19	KEY	28-8M0214992
20	SCREW, (#14-8 x 2.25)	10-8M0215009
21	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
22	NUT, (.250-28)	11-8267119
23	SCREW, (.312-18 x 2.75)	10-19924275
24	WASHER	12-36001
25	SLEEVE	23-29804T
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	REPAIR KIT, Water Pump	46-96148A8
-	SEAL KIT	26-89238A2

JET PUMP ASSEMBLY

Below is the parts list for Mercury V-200XRI (EFI) JET PUMP ASSEMBLY:

Position No.	Part Name	OEM Number	Supersedes
-	JET PUMP (BLACK)	855766150	801400150, 801401150
-	JET PUMP (GRAY)	855766150	801400150, 801401150
1	HOUSING, Pump	801411150
1A	HOSE, Lube	32-827490
2	IMPELLER	47-803984T	47-801414150, 47-855708150
3	HOUSING, Intake	80141290
3A	LINER	8271883
4	SHAFT, Drive	45-801413150
4A	SLEEVE	23-8271891
4B	NUT	11-8271901
5	KEY	28-801405875
6	SHIM, Impeller	15-801404875
7	TAB WASHER	14-801403875
8	SCREW, (.312-18 x 1.00)	10-812618	10-73169, 10-847568
9	SCREW, (.250-20 x .875)	10-19923088
10	SCREW, (.250-20 x .625)	10-19923062
11	SCREW, (.312-18 x 1.250)	10-60411
12	BRACKET, Cable Support	801410
13	NUT, (.312-18)	11-82670910
14	PIN, Dowel	17-801407
15	STUD, (.438 x 3.12)	16-786382
16	STUD, (.437-14/.437-20 x 2.060)	16-8M0133358
17	BOLT, (.312-18 x 2.750)	10-69064
18	STUD, (.250-20/.250-28 x 3.125)	16-306671
19	SCREW, (.375-16 x 3.00) Stainless Steel	10-68299
20	WASHER, (.406 x .750 x .104)	12-8M0214963

MISCELLANEOUS PARTS/ACCESSORIES

Below is the parts list for Mercury V-200XRI (EFI) MISCELLANEOUS PARTS/ACCESSORIES:

Position No.	Part Name	OEM Number	Supersedes
-	PARTS MANUAL, 135/150/175/200/XR6/MAGNUM III	90-81609892
-	DECAL SET (BLACK 135/150/175) Comment: DESIGN I	37-813220A89
-	DECAL SET (XR6) Comment: DESIGN I	37-808552A94	37-812563A92 DESIGN I
-	DECAL SET (BLACK 200) Comment: DESIGN I	37-812563A93	37-812563A90 DESIGN I
-	DECAL SET (GRAY 135/150) Comment: DESIGN I	37-813036A92	37-813035A90, 37-813036A89, 37-813036A90, 37-813035A89 DESIGN I
-	DECAL SET (MAGNUM III) Comment: DESIGN I	37-813034A94	37-813034A92 DESIGN I
-	DECAL SET (GRAY 175) Comment: DESIGN I	37-813037A94	37-813037A92, 37-813037A90, 37-813037A89 DESIGN I
-	DECAL SET (GRAY 200) Comment: DESIGN I	37-815630A90
-	DECAL SET (BLACK 135) Comment: DESIGN II	37-813220A94
-	DECAL SET (BLACK 150) Comment: DESIGN II	37-824103A94
-	DECAL SET (BLACK 175) Comment: DESIGN II	37-824911A94
-	DECAL SET (XR6) Comment: DESIGN II	37-808552A94	37-812563A92 DESIGN II
-	DECAL SET (BLACK 200 LONG) Comment: DESIGN II	37-812563A94
-	DECAL SET (BLACK 200 XL/CXL) Comment: DESIGN II	37-808562A94
-	DECAL SET (GRAY 135) Comment: DESIGN II	37-813036A94
-	DECAL SET (GRAY 150) Comment: DESIGN II	37-824104A94
-	DECAL SET (GRAY 175) Comment: DESIGN II	37-824911A94
-	DECAL SET (XR6) Comment: DESIGN II	37-808552A94	37-812563A92 DESIGN II
-	DECAL SET (BLACK 200 LONG) Comment: DESIGN II	37-812563A94
-	DECAL SET (BLACK 200 XL/CXL) Comment: DESIGN II	37-808562A94
-	DECAL SET (GRAY 135) Comment: DESIGN II	37-813036A94
-	DECAL SET (GRAY 150) Comment: DESIGN II	37-824104A94
-	DECAL SET (MAGNUM III) Comment: DESIGN II	37-813034A94	37-813034A92 DESIGN II
-	DECAL SET (GRAY 175) Comment: DESIGN II	37-813037A94	37-813037A92, 37-813037A90, 37-813037A89 DESIGN II
-	DECAL SET (GRAY 200 LONG) Comment: DESIGN II	37-815630A94
-	DECAL SET (GRAY 200 XL/CXL) Comment: DESIGN II	37-808563A94
-	DECAL SET (TRACKER 150) Comment: DESIGN II	37-824736A94
-	DECAL SET (TRACKER 175) Comment: DESIGN II	37-808620A94
-	DECAL SET (TRACKER 200) Comment: DESIGN II	37-808681A94
-	DECAL SET (BLACK 105 JET) Comment: DESIGN II	37-826331A95
-	DECAL SET (GRAY 105 JET) Comment: DESIGN II	37-826332A95
-	DECAL SET (BLACK 140 JET) Comment: DESIGN II	37-826333A95
-	DECAL SET (GRAY 140 JET) Comment: DESIGN II	37-826334A95
-	OWNERS MANUAL (BLACK) Comment: DESIGN II	90-11149940
-	OWNERS MANUAL (GRAY) Comment: DESIGN II	90-11142940
-	OWNERS MANUAL (BLACK JET) Comment: DESIGN II	90-826598940
-	OWNERS MANUAL (GRAY JET) Comment: DESIGN II	90-826603940

OIL INJECTION COMPONENTS

Below is the parts list for Mercury V-200XRI (EFI) OIL INJECTION COMPONENTS:

Position No.	Part Name	OEM Number	Supersedes
1	SENSOR ASSEMBLY	12430A4
2	SCREW, (#10-16 x .600)	10-878609	10-812832 1
3	WARNING MODULE ASSEMBLY	41470A26
4	WASHER	12-38833
5	SCREW, (#10-32 x .875)	10-690201
6	PUMP, Oil (135/150)	815698T	815698, 41032
6	PUMP ASSEMBLY, Oil (XR6/MAGNUM III/175/200)	815699T	815699, 41033
7	BUSHING, Worm	8141032
8	O-RING	25-11379
9	BEARING ASSEMBLY	23-41429A2
10	GEAR, Driven	43-14563
11	LINK	1938516
12	SCREW, (#10-32 X .380)	10-42813
13	SCREW, (#10-32 x .625)	10-32228
13	SCREW, (#10-32 x 1.120)	10-41507
14	TANK	1257-87421
15	CAP ASSEMBLY	36-43298A2
16	O-RING, (2.225 x .210)	25-11332
17	HOUSING ASSEMBLY, Adapter	816190A4
18	O-RING, (2.225 x .210)	25-11332
19	TUBE	32-99802
20	HOSE, (114.00 Inches)	32-99439
21	FITTING (CRANKCASE)	21-8781051
22	BRACKET KIT	12335A1
23	CORD/HOOK KIT	12323A1
24	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
25	RESERVOIR, Oil	994436
26	SCREW, (#10-32 x .875)	10-690201
27	WASHER	12-42118
28	GROMMET	25-42117
29	BUSHING	23-42116
30	TUBING, (15.500 Inches Bulk) (Cut to 4.75 Inches)	32-82381455
31	CAP ASSEMBLY	36-43300A9
32	GASKET	27-43307T
33	FLOAT ASSEMBLY	8M0187298
34	PUSH NUT	11-99265
35	CLAMP Comment: USE WHERE APPLICABLE	54-415824
36	CLAMP Comment: USE WHERE APPLICABLE	54-415823
37	HOSE, (57.00 Inches Bulk) (Cut to 5.25 Inches)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
38	TEE	22-42425
-	POWERHEAD ASSEMBLY Comment: (135/150)	878365T00	812815T00, 812815T97, 812815A97, 812815A96, 812815A92, 812815A90 (135/150)
-	POWERHEAD ASSEMBLY Comment: (XR6/Magnum III) SN# 0D284787 & Below	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (XR6/Magnum III) SN# 0D284787 & Below
-	POWERHEAD ASSEMBLY Comment: (XR6/Magnum III) SN# 0D284788 & Up	823434T97	823434A97, 823434A96, 823434A93 (XR6/Magnum III) SN# 0D284788 & Up
-	POWERHEAD ASSEMBLY Comment: (Tracker 150)	823434T97	823434A97, 823434A96, 823434A93 (Tracker 150)
-	POWERHEAD ASSEMBLY Comment: (175)	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (175)
-	POWERHEAD ASSEMBLY Comment: (200)	813043T97	813043A97, 813043A96, 813043A94, 812827A92, 813043A92 (200)

Oil Injection Components

Below is the parts list for Mercury V-200XRI (EFI) Oil Injection Components:

Position No.	Part Name	OEM Number	Supersedes
1	SENSOR ASSEMBLY	12430A4
2	SCREW, (#10-16 x .600), Sensor Attaching	10-878609	10-812832 1
6	PUMP ASSEMBLY, Oil	815699T	815699, 41033
7	BUSHING, Worm	8141032
8	O-RING	25-11379
9	BEARING ASSEMBLY, Drive Gear	23-41429A2
10	GEAR, Driven	43-14563
11	LINK ASSEMBLY, Throttle Lever To Oil Pump	1938512
13	SCREW, (#10-32 x .625)	10-32228
13	SCREW, (#10-32 x 1.120)	10-41507
14	TANK	1257-87421
15	CAP ASSEMBLY, Oil Tank	36-43298A2
16	O-RING, (2.225 x .210), Cap	25-11332
17	HOUSING ASSEMBLY, Adapter	816190A4
18	O-RING, (2.225 x .210), Adaptor Housing	25-11332
19	TUBE, Oil Pick-Up	32-99802
20	HOSE, (114.00 Inches)	32-99439
21	FITTING, Ceck Valve (Crankcase)	21-8781051
22	BRACKET KIT	12335A1
23	CORD/HOOK KIT	12323A1
24	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
25	RESERVOIR, Oil	994436
26	SCREW, (#10-32 x .875), Oil Reservoir Attatching	10-690201
27	WASHER, Oil Reservoir Screw	12-42118
28	GROMMET, Oil Reservoir Screw	25-42117
29	BUSHING, Oil Reservoir Screw	23-42116
30	TUBING, (15.500 Inches Bulk), Oil Reservoir To Oil Pump Comment: (Cut to 4.75 Inch Length)	32-82381455
31	CAP ASSEMBLY, Oil Reservoir	36-43300A9
32	GASKET, Reservoir Cap	27-43307T
33	FLOAT ASSEMBLY	8M0187298
34	PUSH NUT	11-99265
35	CLAMP, Oil Hose Comment: (Use Where Applicable)	54-415824
36	CLAMP, Oil Hose	54-415823
37	LINE, (57.00 Inches Bulk), Oil Comment: (Cut to 5.25 Inch Length)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821 (Cut to 5.25 Inch Length)
38	TEE, Oil Tubing	22-42425

POWER STEERING COMPONENTS(REMOTE)

Below is the parts list for Mercury V-200XRI (EFI) POWER STEERING COMPONENTS(REMOTE):

Position No.	Part Name	OEM Number	Supersedes
1	MOUNT	17771
2	SCREW, (.250-28 x .875) Stainless Steel	10-59702
3	TAB WASHER	88404
4	SEAL KIT	19624A1
5	TUBE ASSEMBLY	71565A2
6	COUPLING	17776
7	SCREW, (.375-24 x 2.75)	10-817040
8	WASHER, (.406 x .734 x .063) Stainless Steel	12-34931
9	SCREW	10-856722	10-90092
10	NUT, (.375-24)	11-8M0204726
11	TAB WASHER	14-42100
12	NUT, (.875-14)	11-8M0041651	11-37984
13	ACCUMULATOR (See Accumulator for Breakdown)	811290	811288
14	BRACKET	817372
15	SCREW, (.250-10 x 1.25)	10-16862
16	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
17	SCREW, (M10 x 70)	10-4000383
18	WASHER	12-4002319
19	NUT, (M10)	11-40140
20	ACTUATOR	828588A2
21	SCREW, (.375-24 x 1.5)	10-94319
22	SPACER	23-17405
23	NUT, (.375-24)	11-8M0204726
24	SCREW, (.375-24 x 1.25)	10-849838	10-14000
25	LINK ROD ASSEMBLY	92876A4
26	WASHER, (..88 x .39 x .06)	12-68300
27	SCREW, (M6 x 25)	10-8M0204707
28	WASHER	12-4002315
29	NUT, (M6)	11-401386
30	CLAMP	811292
31	SCREW	10-818182
32	NUT, (M5)	11-400263
33	BRACKET	811291
34	SCREW, (.250-28 x 1.250)	10-38601
35	CLAMP	54-197491
36	RELAY SWITCH	87-18211
37	HARNESS ASSEMBLY	84-18244A1
38	SCREW, (#10-32 x .750)	10-18124
39	GROMMET	25-90329
40	SPACER	23-309772
41	BRACKET	816994
42	WASHER	12-42118
43	NUT,	10-32,11-8M0204718
44	DECAL	37-81563024

POWER TRIM COMPONENTS

Below is the parts list for Mercury V-200XRI (EFI) POWER TRIM COMPONENTS:

Position No.	Part Name	OEM Number	Supersedes
-	POWER TRIM ASSEMBLY Comment: SN# 0G201874 & Below	826729A10	826729A09, 826729A08, 826729A07, 826729A 4 SN# 0G201874 & Below
-	TRIM AND TILT ASSEMBLY Comment: SN# 0G201875 & Up	855998A11	855998A08, 855998A07, 855998A10, 855998A09, 855998A05, 855998A 3 SN# 0G201875 & Up
1	MANIFOLD ASSEMBLY	811604F	811604T
2	PLUG, Pipe (.0625-27)	22-56800
3	TILT CYLINDER ASSEMBLY	880952A03	880952A02, 880952A 1
4	ROD KIT, Trim And Tilt Piston (BOLT TYPE- SEE NOTE)	811608
5	ROD KIT, Trim Piston (NUT TYPE)	823553T	823553, 811609
6	GUIDE KIT	878239A02	878239A 1
7	REPAIR KIT	811607A1
8	CHECK VALVE KIT	811610A1
9	GUIDE ASSEMBLY	1100-8M0021648	878243A 1
10	PISTON/ROD ASSEMBLY, Power Trim (PORT)	878413A1
10	PISTON/ROD ASSEMBLY, Power Trim (STARBOARD)	878414T01	878414A 1
11	TRIM FILTER ASSEMBLY	35-12184A1
12	PIN, Trilobe	17-821539	17-13794, 17-19603
13	MANUAL RELEASE ASSEMBLY	893929A01	813442A 2
14	E RING	53-815949001	53-812844, 53-835104
15	SCREW, (M6 x 14)	10-4000327
16	WASHER	12-4002315
17	COVER	811611
18	O-RING KIT	811612A3
19	TRIM MOTOR (See Breakdown on Power Trim Motor) Comment: SN# 0G201874 & Below	878265A6
19A	MOTOR ASSEMBLY (See Breakdown on Power Trim Motor) Comment: SN# 0G201875 & Up	878265A4
20	DRIVESHAFT Comment: SN# 0G201874 & Below	811619
20	DRIVE JOINT Comment: SN# 0G201875 & Up	828710
21	SHAFT	99625002
22	SCREW (LONG) Comment: SN# 0G201874 & Below	10-811615
22	SCREW (LONG) Comment: SN# 0G201875 & Up	10-881768A1
22	SCREW (SHORT)	10-811616
23	PLUG ASSEMBLY	19-811613
24	PUMP	811617T1
25	SHAFT ASSEMBLY	8M0142997
26	PLUG, Pipe (.0625-27)	22-56800
27	ANODE KIT	97-818298Q1
28	SCREW, (M6 x 25)	10-8M0204707
29	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
30	STRIKER PLATE	8M0045383	99630 1
31	LOCKWASHER, (.375)	13-58643
32	NUT, (.375-24)	11-46335
33	PIN, Groove	17-878267	17-44431
34	SCREW, (M10 x 30)	10-4000377
35	WASHER	12-4002319
36	CLIP Comment: SN# 0G201874 & Below	54-22875
36	CLAMP Comment: SN# 0G201875 & Up	54-26550
37	C WASHER	8M0084613	69205
38	SCREW, (#10-16 x .380)	10-878607	10-817626

POWER TRIM MOTOR

Below is the parts list for Mercury V-200XRI (EFI) POWER TRIM MOTOR:

Position No.	Part Name	OEM Number
-	TRIM MOTOR Comment: SN# 0G201874 & Below	878265A6
1	FRAME AND FIELD KIT Comment: SN# 0G201874 & Below	811624
2	BRUSH CARD KIT Comment: SN# 0G201874 & Below	811625
3	END FRAME KIT Comment: SN# 0G201874 & Below	811623
4	SEAL KIT Comment: SN# 0G201874 & Below	811626
5	ARMATURE KIT Comment: SN# 0G201874 & Below	811627
-	MOTOR ASSEMBLY Comment: SN# 0G201875 & Up	878265A4
6	BRUSH AND SEAL KIT Comment: SN# 0G201875 & Up	828714A1
7	ARMATURE KIT Comment: SN# 0G201875 & Up	828713T1
8	END FRAME (COMPLETE) Comment: SN# 0G201875 & Up	828715A1

Power Trim Components

Below is the parts list for Mercury V-200XRI (EFI) Power Trim Components:

Position No.	Part Name	OEM Number	Supersedes
-	POWER TRIM ASSEMBLY Comment: SN# 0G201874 & Below	826729A10	826729A09, 826729A08, 826729A07, 826729A 4 SN# 0G201874 & Below
-	TRIM AND TILT ASSEMBLY Comment: SN# 0G201875 & Up	855998A11	855998A08, 855998A07, 855998A10, 855998A09, 855998A05, 855998A 3 SN# 0G201875 & Up
1	MANIFOLD ASSEMBLY	811604F	811604T
2	PLUG, Pipe (.0625-27)	22-56800
3	TILT CYLINDER ASSEMBLY	880952A03	880952A02, 880952A 1
4	ROD KIT, Trim And Tilt Piston, Bolt Type Comment: (Bolt type piston rod is stamped with a B)	811608
5	ROD KIT, Trim Piston, Nut Type	823553T	823553, 811609
6	GUIDE KIT	878239A02	878239A 1
7	REPAIR KIT	811607A1
8	CHECK VALVE KIT	811610A1
9	GUIDE ASSEMBLY	1100-8M0021648	878243A 1
10	PISTON/ROD ASSEMBLY, Power Trim Comment: (Port)	878413A1
10	PISTON/ROD ASSEMBLY, Power Trim Comment: (Starboard)	878414T01	878414A 1 (Starboard)
11	TRIM FILTER ASSEMBLY	35-12184A1
12	PIN, Trilobe	17-821539	17-13794, 17-19603
13	MANUAL RELEASE ASSEMBLY	893929A01	813442A 2
14	E RING	53-815949001	53-812844, 53-835104
15	SCREW, (M6 x 14)	10-4000327
16	WASHER	12-4002315
17	COVER	811611
18	O-RING KIT	811612A3
19	TRIM MOTOR	878265A6
19A	MOTOR ASSEMBLY	878265A4
20	DRIVESHAFT Comment: SN# 0G201874 & Below	811619
20	DRIVE JOINT Comment: SN# 0G201875 & Up	828710
21	SHAFT	99625002
22	SCREW, Long Comment: SN# 0G201874 & Below	10-811615
22	SCREW, Long Comment: SN# 0G201875 & Up	10-881768A1
22	SCREW, Short	10-811616
23	PLUG ASSEMBLY	19-811613
24	PUMP	811617T1
25	SHAFT ASSEMBLY	8M0142997
26	PLUG, Pipe (.0625-27)	22-56800
27	ANODE KIT	97-818298Q1
28	SCREW, (M6 x 25)	10-8M0204707
29	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
30	STRIKER PLATE	8M0045383	99630 1
31	LOCKWASHER, (.375)	13-58643
32	NUT, (.375-24)	11-46335
33	PIN, Groove	17-878267	17-44431
34	SCREW, (M10 x 30), Manifold	10-4000377
35	WASHER, Manifold Screw	12-4002319
36	CLIP, Pump Wire Comment: SN# 0G201874 & Below	54-22875
36	CLAMP, Pump Wire Comment: SN# 0G201875 & Up	54-26550
37	C WASHER	8M0084613	69205
38	SCREW, (#10-16 x .380)	10-878607	10-817626

Power Trim Motor

Below is the parts list for Mercury V-200XRI (EFI) Power Trim Motor:

Position No.	Part Name	OEM Number
-	TRIM MOTOR Comment: SN# 0G201874 & Below	878265A6
-	MOTOR ASSEMBLY Comment: SN# 0G201875 & Up	878265A4
1	FRAME AND FIELD KIT Comment: SN# 0G201874 & Below	811624
2	BRUSH CARD KIT Comment: SN# 0G201874 & Below	811625
3	END FRAME KIT Comment: SN# 0G201874 & Below	811623
4	SEAL KIT Comment: SN# 0G201874 & Below	811626
5	ARMATURE KIT Comment: SN# 0G201874 & Below	811627
6	BRUSH AND SEAL KIT Comment: SN# 0G201875 & Up	828714A1
7	ARMATURE KIT Comment: SN# 0G201875 & Up	828713T1
8	END FRAME, Complete Comment: SN# 0G201875 & Up	828715A1

REED BLOCK AND CYLINDER HEAD

Below is the parts list for Mercury V-200XRI (EFI) REED BLOCK AND CYLINDER HEAD:

Position No.	Part Name	OEM Number	Supersedes
1	CYLINDER HEAD Comment: 135/150	18787A18
1	CYLINDER HEAD Comment: XR6/MAGNUM III/TRACKER/175/200 SN# 0D262673 & Below	900-8M0143213
1	CYLINDER HEAD Comment: XR6/MAGNUM III/TRACKER/175 SN# 0D262674 & Up	900-8M0143213
1	CYLINDER HEAD Comment: 200 SN# 0G052594 & Below	900-8M0143213
1	CYLINDER HEAD ASSEMBLY Comment: 200 SN# 0G052595 & Up	18488F2
2	GASKET Comment: 135/150	27-18785T
2	GASKET Comment: XR6/MAGNUM III/TRACKER/175/200 SN# 0D262673 & Below	27-822844T05	27-822844T04, 27-822844 1, 27-822844004 XR6/MAGNUM III/TRACKER/175/200 SN# 0D262673 & Below
2	GASKET Comment: XR6/MAGNUM III/TRACKER/175 SN# 0D262674 & Up	27-822844T05	27-822844T04, 27-822844 1, 27-822844004 XR6/MAGNUM III/TRACKER/175 SN# 0D262674 & Up
2	GASKET Comment: 200 SN# 0D262674 & Up	27-822844T05	27-822844T04, 27-822844 1, 27-822844004 200 SN# 0D262674 & Up
3	SCREW, (.375-16 x 2.30)	10-98534
4	WASHER, (.406 x .812 x .065) (USE WHERE APPLICABLE)	12-25909
5	GASKET	27-8M0204714
6	COVER KIT	90390A1
7	THERMOSTAT	75692
8	SCREW, (.312-18 x 1.00)	10-35386
9	FITTING, (.250-18) 90 Degree - Brass	22-687271
10	HOSE, (24.500 Inches Bulk)	32-77653101
11	FITTING	22-68728
12	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
13	SENDER, Temperature (STBD.)	97465
14	PLATE ASSEMBLY	43517A9
15	SCREW, (.250-20 x .875) Stainless Steel	10-28668
16	GASKET	27-146972
17	PIN, Dowel (.250 x .625)	17-63779
18	REED BLOCK	75953
19	REED ASSEMBLY	34-75362A1
20	CLAMP, Reed	961832
21	SCREW, (#8-32 x .250)	10-823588	10-14783, 10-18308
22	SCREW, (.250-20 x .880)	10-55715
23	SCREW, (.250-20 x 2.00)	10-96529
24	VALVE, Thermal Air (OLD DESIGN)	814612
25	CLIP	54-23567
26	C WASHER	8M0084613	69205
27	SCREW, (#10-16 x .500)	10-878608	10-812832
28	SENSOR ASSEMBLY, Temperature (PORT) (2-WIRE)	13536A7
28A	SENSOR ASSEMBLY, Temperature (PORT) (4-WIRE)	13536A6
29	RETAINER	137151
30	SCREW, (.312-18 x .500)	10-98257
31	FITTING, Barbed	22-56759
32	TUBING, (20.00 Feet Bulk)	32-892024122	32-99130122
33	CHECK VALVE (PRESS-IN 13/16")	21-426982
33	CHECK VALVE (PRESS-IN 11/16")	21-426233
34	FITTING, Elbow (PRESS-IN)	22-822715
35	J CLIP	54-8M0024808
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	POWERHEAD ASSEMBLY Comment: (135/150)	878365T00	812815T00, 812815T97, 812815A97, 812815A96, 812815A92, 812815A90 (135/150)
-	POWERHEAD ASSEMBLY Comment: (XR6/Magnum III) SN# 0D284787 & Below	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (XR6/Magnum III) SN# 0D284787 & Below
-	POWERHEAD ASSEMBLY Comment: (XR6/Magnum III) SN# 0D284788 & Up	823434T97	823434A97, 823434A96, 823434A93 (XR6/Magnum III) SN# 0D284788 & Up
-	POWERHEAD ASSEMBLY Comment: (Tracker 150)	823434T97	823434A97, 823434A96, 823434A93 (Tracker 150)
-	POWERHEAD ASSEMBLY Comment: (175)	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (175)
-	POWERHEAD ASSEMBLY Comment: (200)	813043T97	813043A97, 813043A96, 813043A94, 812827A92, 813043A92 (200)

Reed Block And Cylinder Head

Below is the parts list for Mercury V-200XRI (EFI) Reed Block And Cylinder Head:

Position No.	Part Name	OEM Number	Supersedes
1	CYLINDER HEAD (Casting #18488C3) Comment: (150) SN# 0D262673 & Below	900-8M0143213
1	CYLINDER HEAD (Casting #18488C3) Comment: (175) SN# 0D262673 & Below	900-8M0143213
1	CYLINDER HEAD (Casting #18488C3) Comment: (200) SN# 0D262673 & Below	900-8M0143213
1	HEAD (Casting #18488C2) Comment: (200XL/CXL) SN# 0D246107 THRU 0G052594	18488F2
1	CYLINDER HEAD (Casting #18488C4) Comment: (150/175) SN# D262674 & Up	900-8M0143213
1	CYLINDER HEAD (Cast #18488C4) Comment: (200) SN# D26674 THRU G052594	900-8M0143213
1	CYLINDER HEAD ASSEMBLY (Casting #18488C5) Comment: (200) SN# G052595 & Up	18488F2
2	GASKET	27-822844T05	27-822844T04, 27-822844 1, 27-822844004
3	SCREW, (.375-16 x 2.30) Comment: (QTY. OF 24 ON 150/175)	10-98534
3	SCREW, (.375-16 x 2.30) Comment: (200) SN# G146482 & Below	10-13450
3	SCREW Comment: (200) SN# G146483 & Up	10-827426
4	WASHER, (.406 x .812 x .065), Use Where Applicable	12-25909
5	THERMOSTAT	75692
6	GASKET	27-8M0204714
7	COVER KIT	90390A1
8	SCREW, (.312-18 x 1.00)	10-35386
9	FITTING, (.250-18) 90 Degree - Brass	22-687271
10	HOSE, (24.500 Inches Bulk)	32-77653101
11	FITTING	22-68728
12	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
13	PIN, Dowel (.250 x .625)	17-63779
14	RETAINER	137151
15	SCREW, (.312-18 x .500)	10-98257
16	SCREW, (.250-20 x .880)	10-55715
16	SCREW, (.250-20 x 1.125)	10-90197
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
17	GASKET	27-167371
18	ADAPTOR PLATE ASSEMBLY	17735A2
19	CLAMP, Reed	961832
20	GASKET	27-146972
21	REED BLOCK	75953
22	REED ASSEMBLY	34-75362A1
23	SCREW, (.250-20 x .875) Stainless Steel	10-28668
24	SCREW, (#8-32 x .250)	10-823588	10-14783, 10-18308
25	SENSOR ASSEMBLY, Detonation Comment: Black (200) SN# D239647 & Below	825164A1
25	SENSOR, Detonation Comment: Gray (200) SN# D239648 THRU G146482	825164
25	SENSOR, Knock Comment: (200) SN# G146483 & Up	826858
26	SENDER, Temperature, Starboard	97465
27	SENSOR ASSEMBLY, Temperature, Port (4-Wire)	13536A6
28	NUT, Brass	10-32,11-45076
29	J CLIP	54-8M0024808
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90

STARTER MOTOR

Below is the parts list for Mercury V-200XRI (EFI) STARTER MOTOR:

Position No.	Part Name	OEM Number	Supersedes
-	STARTER MOTOR ASSEMBLY	50-893893	50-79472T 2, 50-79472 2
1	DRIVE KIT	90645
2	PINION ASSEMBLY, Drive	13310T1
3	PLATE	75660
4	BOLT	10-74968
6	Not Sold Separate, Washer (AMERICAN BOSCH #WA3122) (#N.S.S.)
7	ARMATURE	79216
8	BRUSH/SPRING KIT	898265016	75384, 75384 1
9	HOLDER	898265014	61787
10	Not Sold Separate, Screw (AMERICAN BOSCH #02441-22-SC-30SM) (#N.S.S.)
11	END CAP	15386001

STEERING ATTACHING KIT

Below is the parts list for Mercury V-200XRI (EFI) STEERING ATTACHING KIT:

Position No.	Part Name	OEM Number	Supersedes
-	ATTACHING KIT, Steering (SINGLE)	92876A8
1	BRACKET ASSEMBLY	41055A1
2	TUBE ASSEMBLY	71565A2
3	O-RING, (.614 x .070)	25-48462
4	LOCKWASHER	13-821203
5	NUT, (.875-14)	11-8M0041651	11-37984
6	SCREW, (.250-28 x 1.250)	10-38601
7	LOCKWASHER, Internal (.250)	13-78968
8	COUPLING	850791T	850791, 88319
9	SCREW, (.375-24 x 1.120)	10-73732
10	WASHER, (.406 x .734 x .063) Stainless Steel	12-34931
11	NUT, (.375-24)	11-8M0204726

SWIVEL BRACKET AND STEERING ARM

Below is the parts list for Mercury V-200XRI (EFI) SWIVEL BRACKET AND STEERING ARM:

Position No.	Part Name	OEM Number	Supersedes
1	SWIVEL BRACKET ASSEMBLY (BLACK)	1499-8M0102865	1499-8710T20
1	SWIVEL BRACKET ASSEMBLY (GRAY)	1499-8710T21
1	SWIVEL BRACKET ASSEMBLY (TRACKER)	1499-8710A22
2	SEAL, Oil (LOWER)	26-87735
3	BUSHING	23-818764	23-67669
4	SPACER	23-816039
5	O-RING	25-8M0214926
6	FITTING, Grease	22-8M0169589
7	BUSHING	23-821207	23-99608
8	THRUST WASHER	12-816432
9	SCREW, (.437-20 x 7.50)	10-8M0176309
10	MOUNT (LONG)(JET)	78687T
10	MOUNT (X-LONG - XR6/MAGNUM III/TRACKER)	77326
11	WASHER	12-66921
12	WASHER	12-78688
13	NUT, (.437-20) Stainless Steel	11-8M0204653
14	LINK ASSEMBLY, Steering	92876A12
15	SCREW, (.375-24 x 1.25)	10-849838	10-14000
16	NUT, (.375-24)	11-8M0204726
17	WASHER, (.406 x .734 x .063) Stainless Steel	12-34931
18	SWIVEL PIN ASSEMBLY, Steering Arm (BLACK)	17-67706A55
18	SWIVEL PIN ASSEMBLY, Steering Arm (GRAY)	17-67706A55
18	SWIVEL PIN ASSEMBLY (TRACKER)	17-67706A55
19	YOKE ASSEMBLY, Bottom (BLACK)	86580A1
19	YOKE ASSEMBLY, Bottom (GRAY)	86580A1
19	YOKE, Bottom (TRACKER)	86580A1
20	RING, Retaining	53-67684
21	J CLIP Comment: SN# 0G201874 & Below	54-54457
22	BUMPER	8M0000516	88882 1
23	SCREW, (.250-28 x .500)	10-64014
24	SENDER ASSEMBLY, Trim	8M0074846	821180A 6
25	SCREW, (#10-24 x .750)	10-852368	10-56682
26	LOCKWASHER, Stainless Steel	10,13-26996
27	WASHER, (.203 x .406 x .040)	12-89302

Service/Support Material

Below is the parts list for Mercury V-200XRI (EFI) Service/Support Material:

Position No.	Part Name	OEM Number	Supersedes
-	DECAL SET (Black 150/175/200XRI) Comment: (Design I)	37-812563A93	37-812563A90 (Design I)
-	DECAL SET (Gray 175 Ski) Comment: (Design I)	37-808555A94	37-815630A92 (Design I)
-	DECAL SET (150/175/200 Magnum) Comment: (Design I)	37-813033A93	37-813033A92, 37-813033A91, 37-813033A89 (Design I)
-	DECAL SET (Black 150 Anniversary) Comment: (Design II)	37-809513A95
-	DECAL SET (Gray 150 Anniversary) Comment: (Design II)	37-809514A95
-	DECAL SET (Black 150) Comment: (Design II)	37-808553A94
-	DECAL SET (Black 175) Comment: (Design II)	37-808559A94
-	DECAL SET (Black 200 Long) Comment: (Design II)	37-808554A94
-	DECAL SET (Black 200 XL/CXL) Comment: (Design II)	37-808558A94
-	DECAL SET (Black-Tracker 150) Comment: (Design II)	37-808591A94
-	DECAL SET (Gray-Tracker 150) Comment: (Design II)	37-808602A94
-	DECAL SET (Black-Tracker 175) Comment: (Design II)	37-808680A94
-	DECAL SET (Gray-Tracker 175) Comment: (Design II)	37-808652A94
-	DECAL SET (Black-Tracker 200) Comment: (Design II)	37-808621A94
-	DECAL SET (Gray-Tracker 200) Comment: (Design II)	37-808641A94
-	DECAL SET (Gray 150) Comment: (Design II)	37-813033A94
-	DECAL SET (Gray 175 Ski) Comment: (Design II)	37-808555A94	37-815630A92 (Design II)
-	DECAL SET (175 Magnum) Comment: (Design II)	37-808557A94
-	DECAL SET (Gray 200 Long) Comment: (Design II)	37-808556A94
-	DECAL SET (Gray 200 XL/CXL) Comment: (Design II)	37-808561A94
-	OWNERS GUIDE, Black Comment: (Design II)	90-11149950
-	OWNERS GUIDE, Gray Comment: (Design II)	90-11142950
-	PARTS MANUAL, 175 XRI /175 MAGNUM 200 XRI (EFI) Comment: (Design II)	90-81741890

Starter Motor

Below is the parts list for Mercury V-200XRI (EFI) Starter Motor:

Position No.	Part Name	OEM Number	Supersedes
-	STARTER MOTOR ASSEMBLY	50-893893	50-79472T 2, 50-79472 2
1	DRIVE KIT	90645
2	PINION ASSEMBLY, Drive	13310T1
3	PLATE	75660
4	BOLT	10-74968
5	Not Sold Separate, Washer (#N.S.S.) Comment: (American Bosch #WA3122)
7	ARMATURE	79216
8	BRUSH/SPRING KIT	898265016	75384, 75384 1
9	HOLDER	898265014	61787
10	Not Sold Separate, Screw (#N.S.S.) Comment: (American Bosch #02441-22-SC-30SM)
11	END CAP	15386001

Steering Attaching Kit

Below is the parts list for Mercury V-200XRI (EFI) Steering Attaching Kit:

Position No.	Part Name	OEM Number	Supersedes
-	ATTACHING KIT, Steering, Single	92876A8
1	BRACKET ASSEMBLY	41055A1
2	TUBE ASSEMBLY	71565A2
3	O-RING, (.614 x .070)	25-48462
4	LOCKWASHER	13-821203
5	NUT, (.875-14)	11-8M0041651	11-37984
6	SCREW, (.250-28 x 1.250)	10-38601
7	WASHER, (.250 External Star)	13-93702
8	COUPLING	850791T	850791, 88319
9	SCREW, (.375-24 x 1.120)	10-73732
10	WASHER, (.406 x .734 x .063) Stainless Steel	12-34931
11	NUT, (.375-24)	11-8M0204726

Swivel Bracket And Steering Arm

Below is the parts list for Mercury V-200XRI (EFI) Swivel Bracket And Steering Arm:

Position No.	Part Name	OEM Number	Supersedes
1	SWIVEL BRACKET ASSEMBLY, Black	1499-8M0102865	1499-8710T20
1	SWIVEL BRACKET ASSEMBLY, Gray	1499-8710T21
1	SWIVEL BRACKET ASSEMBLY, Tracker	1499-8710A22
2	SEAL, Oil, Lower	26-87735
3	BUSHING	23-818764	23-67669
4	SPACER	23-816039
5	O-RING	25-8M0214926
6	FITTING, Grease	22-8M0169589
7	BUSHING	23-821207	23-99608
8	THRUST WASHER	12-816432
9	SCREW, (.437-20 x 7.50)	10-8M0176309
10	MOUNT, Rubber - Upper Comment: (Long) (Jet)	78687T
10	MOUNT (X-Long - XR6/Magnum ILI/Tracker)	77326
11	WASHER	12-66921
12	WASHER	12-78688
13	NUT, (.437-20) Stainless Steel	11-8M0204653
14	LINK ASSEMBLY, Steering	92876A12
15	SCREW, (.375-24 x 1.25)	10-849838	10-14000
16	NUT, (.375-24)	11-8M0204726
17	WASHER, (.406 x .734 x .063) Stainless Steel	12-34931
18	SWIVEL PIN ASSEMBLY, Steering Arm, Black	17-67706A55
18	SWIVEL PIN ASSEMBLY, Steering Arm, Gray	17-67706A55
18	SWIVEL PIN ASSEMBLY, Tracker	17-67706A55
19	YOKE ASSEMBLY, Bottom, Black	86580A1
19	YOKE ASSEMBLY, Bottom, Gray	86580A1
19	YOKE, Bottom, Tracker	86580A1
20	RING, Retaining	53-67684
21	J CLIP Comment: SN# 0G201874 & Below	54-54457
22	BUMPER	8M0000516	88882 1
23	SCREW, (.250-28 x .500)	10-64014
24	SENDER ASSEMBLY, Trim	8M0074846	821180A 6
25	SCREW, (#10-24 x .750)	10-852368	10-56682
26	LOCKWASHER, Stainless Steel	10,13-26996
27	WASHER, (.203 x .406 x .040)	12-89302

THROTTLE LEVER AND SHIFT SHAFT

Below is the parts list for Mercury V-200XRI (EFI) THROTTLE LEVER AND SHIFT SHAFT:

Position No.	Part Name	OEM Number	Supersedes
1	BUSHING Comment: DESIGN I	23-55171
2	BALL JOINT ASSEMBLY Comment: DESIGN I	62459T
3	NUT, Brass Comment: DESIGN I	10-32,11-45076
4	ROD Comment: DESIGN I	76035
5	NUT, Comment: DESIGN I	10-32,11-46438
6	LEVER ASSEMBLY (DESIGN I)	41094A3
6	LEVER, Spark Advance (DESIGN II)	823705A1
7	SCREW, (.250-20 x 2.125)	10-64022
8	NUT, (.250-20)	11-64015
9	CAP, Nylon	26852
10	SWIVEL BASE Comment: DESIGN II	93254
11	SWIVEL BALL Comment: DESIGN II	93421
12	LINK Comment: DESIGN II	823706
13	PIVOT	74897T
14	SCREW, (.190-32 x 1.250)	10-13627
15	NUT, Stainless Steel	10-32,11-68219
16	CAP	48039
17	SPRING	24-823235
18	WASHER, (.390 x 1.50 x .120)	12-46765
19	SCREW, (.250-20 x 2.125)	10-64022
20	NUT, (.250-20)	11-64015
21	CAP, Nylon	26852
22	LATCH	39483
23	SCREW, (.250-28 x .880)	10-69026
24	SPRING	24-20099
25	NUT, (.250-28)	11-826709109	11-33825, 11-35045
26	LEVER	410952
27	SCREW, (.375-16 x 1.75)	10-818165	10-55337
28	BUSHING	23-55164
29	BARREL	14638
30	ROD	814929
31	BUSHING	23-8M0215006
32	NUT, (.250-28)	11-826709109	11-33825, 11-35045
33	STUD, (.250-28 x 1.750)	16-20353
34	CAM, Throttle	815539T
35	BRACKET ASSEMBLY	814283A2
36	CUP	39519
37	DRIVE SCREW	10-42975
38	LATCH	98889
39	SCREW, (.312-18 x .880)	10-53167T
40	SHIFT SHAFT ASSEMBLY (LONG)	79932A16
40	SHIFT SHAFT ASSEMBLY (X-LONG)	79932A17
41	GUIDE BLOCK	814284
42	SPRING	24-20099
43	LINK ROD ASSEMBLY	67073A1
44	WEAR PLATE	52100
45	LATCH	8M0036768	38279
46	WASHER, (.2656 x .625 x .0625) Stainless Steel	12-35462
47	NUT, (.250-28)	11-826709109	11-33825, 11-35045
48	BUSHING	23-26600
49	WAVE WASHER	13-29720
50	WASHER, (.2656 x .625 x .0625) Stainless Steel	12-35462
51	NUT, (.250-28)	11-826709109	11-33825, 11-35045
52	IDLE STABILIZING SHIFT KIT Comment: XR6/175/MAGNUM III/TRACKER	87-814281A1
53	SCREW, (#6-32 x .875) Comment: XR6/175/MAGNUM III/TRACKER	10-77478
54	WASHER Comment: XR6/175/MAGNUM III/TRACKER	12-27882
55	RESISTOR MODULE Comment: XR6/175/MAGNUM III/TRACKER	17461A3

TOP COWL AND FRONT SHIELD

Below is the parts list for Mercury V-200XRI (EFI) TOP COWL AND FRONT SHIELD:

Position No.	Part Name	OEM Number	Supersedes
1	TOP COWL ASSEMBLY (BLACK)(Without Decals) Comment: 135/150/175/200	2196-9742T88
1	TOP COWL ASSEMBLY (SILVER)(Without Decals) Comment: 135/150/175/200	2196-9743T11
1	TOP COWL ASSEMBLY (XR6)(Without Decals)	2196-9742T92
1	TOP COWL ASSEMBLY (MAGNUM III -GRAY)(Without Decals)	2196-9743T10
1	TOP COWL ASSEMBLY (MAGNUM III-SILVER)(Without Decals)	2196-9743T10
1	TOP COWL ASSEMBLY (150 TRACKER)(Without Decals)	2196-9743A8
1	TOP COWL ASSEMBLY (175/200 TRACKER)(Without Decals)	2196-9743A13
2	SEAL	812784
3	SEAL	815478	813566
4	SOUND BLANKT KIT	814823A1
4	SOUND BLANKET KIT Comment: (XR6/MAGNUM III/TRACKER 150)	815225A1
5	SOUND BLANKET Comment: (XR6/MAGNUM III/TRACKER 150)	815227
6	SCREW, (.312-18 x 1.750)	10-69267
7	WASHER, (.323 x .563 x .063) Stainless Steel	12-8M0042642	12-70132
8	SCREW, (.250-20 x .500) Stainless Steel	10-73286
9	NUT, (.312)	11-815848
10	BRACKET	184741
11	GROMMET	25-18506001
12	SCREW, (.250-20 x .750)	10-28636
13	WASHER, (.330 x .750 x .060) Stainless Steel	12-56720
14	HOOK Comment: SN# 0G029197 & Below	813096A2
15	WASHER Comment: SN# 0G029197 & Below	12-36001
16	ROLLER Comment: SN# 0G029197 & Below	8M0207770
17	RING, Retaining Comment: SN# 0G029197 & Below	53-13194
14	HOOK KIT Comment: SN# 0G029198 & Up	813096A2
16	ROLLER Comment: SN# 0G029198 & Up	8M0207770
17	RING, Retaining Comment: SN# 0G029198 & Up	53-8237951
18	SCREW	10-816992
19	LOCATOR	187021
20	BRACKET ASSEMBLY, Latch Roller	893763	18173
21	SPACER	816838
22	ROPE AND HANDLE KIT, Manual/Emergency Start (FOR MANUAL STARTING)	47341A11
23	FRONT SHIELD ASSEMBLY (BLACK)(Without Decals)	18755A1
23	FRONT SHIELD ASSEMBLY (GRAY)(Without Decals)	18755A2
23	FRONT SHIELD ASSEMBLY (SILVER)(Without Decals)	18755A4
23	FRONT SHIELD ASSEMBLY (TRACKER)(Without Decals)	18755A3
24	SCREW, (.190-16 x .620)	10-77137
25	WASHER, (.203 x .500 x .032)	12-8M0204666
26	SEAL	813562

TRANSOM BRACKETS

Below is the parts list for Mercury V-200XRI (EFI) TRANSOM BRACKETS:

Position No.	Part Name	OEM Number	Supersedes
1	BRACKET, Transom (STARBOARD) (BLACK)	3401-8718F7
1	BRACKET, Transom (STARBOARD) (GRAY)	3401-8718F8
1	BRACKET, Transom (STARBOARD) (TRACKER)	3401-8718F10
2	BRACKET ASSEMBLY, Transom (PORT) (BLACK)	3400-8716A8
2	BRACKET ASSEMBLY, Transom (PORT) (GRAY)	3400-8716A9
2	BRACKET ASSEMBLY, Transom (PORT) (TRACKER)	3400-8716A10
3	FITTING, Grease (PORT)	22-8M0169588
4	NUT, (.875-14)	11-8M0041651	11-37984
5	TUBE KIT, Tilt (CARBON STEEL)	99170A2
5	TILT TUBE (STAINLESS STEEL)	826125A1
6	NUT, (1.00-14) Brass/Nickel Plate (BLACK)	11-826135
6	NUT, (1.00-14) (GRAY)	11-859133	11-34862, 11-90068F 3, 11-90068F 4
6	NUT, (1.00-14) (TRACKER)	11-859133	11-34862, 11-90068F 3, 11-90068F 4
7	O-RING, (.612 x .103)	25-45711
8	WASHER	13-88750
9	NUT, (.875-14)	11-826164
10	SCREW, (.500-20 x 4.500)	10-8M0149747
11	WASHER, (1.5 x 3.05 x 0.13) Stainless Steel	12-8M0204648
12	NUT, (.500-20)	11-91962
13	LEVER ASSEMBLY	8M0115104	8M0115103, 99629T 2
14	WAVE WASHER	13-99611
15	NYLINER	23-65830
16	KNOB	99633
17	PIN, Groove	17-99615
18	SPRING	24-99622
19	PIN, Groove	17-99604
20	BOLT ASSEMBLY	10-96930A1
21	NUT, (.375-24)	11-23161
22	STOP	814207
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90

TRANSOM MOUNT POWER STEERING KIT

Below is the parts list for Mercury V-200XRI (EFI) TRANSOM MOUNT POWER STEERING KIT:

Position No.	Part Name	OEM Number	Supersedes
-	POWER STEERING KIT	17443A15
1	ACCUMULATOR	811290	811288
2	STUD	16-17772
3	WASHER	12-4002319
4	NUT, (M10)	11-40140
5	SCREW, (.375-24 x 1.5)	10-94319
6	SPACER	23-17405
7	NUT, (.375-24)	11-8M0204726
8	SCREW, (.375-24 x 1.25)	10-849838	10-14000
9	LINK ROD ASSEMBLY	92876A4
10	WASHER, (..88 x .39 x .06)	12-68300
11	ACTUATOR	828588A2
-	REPAIR KIT	811632A1
12	SCREW, (M6 x 25)	10-8M0204707
13	WASHER	12-4002315
14	NUT, (M6)	11-401386
15	CLAMP	811292
16	SCREW	10-818182
17	NUT, (M5)	11-400263
18	SCREW, (M8 x 55)	10-81742755
19	SPACER, (.250 x .390 x .630) Stainless Steel	23-66751
20	BRACKET	811291
21	SCREW, (.250-28 x 1.250)	10-38601
22	TAB WASHER	88404
23	RELAY SWITCH	87-18211
24	HARNESS ASSEMBLY	84-18244A1
25	SCREW, (#10-32 x .750)	10-18124
26	GROMMET	25-90329
27	SPACER	23-309772
28	BRACKET	816994
29	WASHER	12-42118
30	NUT,	10-32,11-8M0204718
31	CLAMP	54-197491
32	DECAL	37-81563024

Throttle Lever And Shift Shaft

Below is the parts list for Mercury V-200XRI (EFI) Throttle Lever And Shift Shaft:

Position No.	Part Name	OEM Number	Supersedes
1	BUSHING Comment: (Design I)	23-55171
2	BALL JOINT ASSEMBLY Comment: (Design I)	62459T
3	NUT, Brass Comment: (Design I)	10-32,11-45076
4	ROD Comment: (Design I)	76035
5	NUT, Comment: (Design I)	10-32,11-46438
6	LEVER ASSEMBLY Comment: (Design I)	41094A3
6	LEVER, Spark Advance Comment: (Design II)	823705A1
7	SCREW, (.250-20 x 2.125)	10-64022
8	NUT, (.250-20)	11-64015
9	CAP, Nylon	26852
10	SWIVEL BASE Comment: (Design II)	93254
11	SWIVEL BALL Comment: (Design II)	93421
12	LINK Comment: (Design II)	823706
13	PIVOT	74897T
14	SCREW, (.190-32 x 1.250)	10-13627
15	NUT, Stainless Steel	10-32,11-68219
16	CAP	48039
17	SPRING	24-823235
18	WASHER, (.390 x 1.50 x .120)	12-46765
19	SCREW, (.250-20 x 2.125)	10-64022
20	NUT, (.250-20)	11-64015
21	CAP, Nylon	26852
22	LATCH	39483
23	SCREW, (.250-28 x .880)	10-69026
24	SPRING	24-20099
25	NUT, (.250-28)	11-826709109	11-33825, 11-35045
26	LEVER	410952
27	SCREW, (.375-16 x 1.75)	10-818165	10-55337
28	BUSHING	23-55164
29	BARREL	14638
30	ROD	14634
31	BUSHING	23-8M0215006
32	CAM	8142392
33	BUSHING	23-26856
34	NUT, (.250-28)	11-826709109	11-33825, 11-35045
35	BRACKET ASSEMBLY	814283A2
36	CUP	39519
37	DRIVE SCREW	10-42975
38	LATCH	98889
39	SCREW, (.312-18 x .880)	10-53167T
40	SHIFT SHAFT ASSEMBLY Comment: (Long)	79932A16
40	SHIFT SHAFT ASSEMBLY Comment: (X-Long)	79932A17
41	GUIDE BLOCK	814284
42	SPRING	24-20099
43	LINK ROD ASSEMBLY	67073A1
44	WEAR PLATE	52100
45	LATCH	8M0036768	38279
46	WASHER, (.2656 x .625 x .0625) Stainless Steel	12-35462
47	NUT, (.250-28)	11-826709109	11-33825, 11-35045
48	BUSHING	23-26600
49	WAVE WASHER	13-29720
50	WASHER, (.2656 x .625 x .0625) Stainless Steel	12-35462
51	NUT, (.250-28)	11-826709109	11-33825, 11-35045
52	IDLE STABILIZING SHIFT KIT Comment: (150/175)	87-814281A1
53	SCREW, (#6-32 x .875) Comment: (150/175)	10-77478
54	WASHER Comment: (150/175)	12-27882
55	RESISTOR MODULE Comment: (150/175)	17461A3

Top Cowl And Front Shield

Below is the parts list for Mercury V-200XRI (EFI) Top Cowl And Front Shield:

Position No.	Part Name	OEM Number	Supersedes
1	TOP COWL ASSEMBLY, Black Comment: (Long)	2196-9742T92
1	TOP COWL ASSEMBLY, Gray Comment: (Long)	2196-9743T10
1	TOP COWL ASSEMBLY, Silver Comment: (Long)	2196-9743T10
1	TOP COWL ASSEMBLY, Black Comment: (X-Long)	2196-9742T88
1	TOP COWL ASSEMBLY, Gray Comment: (X-Long)	2196-9743T11
1	TOP COWL ASSEMBLY, Silver Comment: (X-Long)	2196-9743T11
1	TOP COWL ASSEMBLY Comment: (Tracker)	2196-9743A8
2	SEAL	812784
3	SEAL	815478	813566
4	SOUND BLANKT KIT Comment: (X-Long)	814823A1
4	SOUND BLANKET KIT Comment: (Long/Tracker)	815225A1
5	SOUND BLANKET Comment: (Long/Tracker)	815227
6	SCREW, (.312-18 x 1.750)	10-69267
7	WASHER, (.323 x .563 x .063) Stainless Steel	12-8M0042642	12-70132
8	SCREW, (.250-20 x .500) Stainless Steel	10-73286
9	NUT, (.312)	11-815848
10	BRACKET, Rear	184741
11	GROMMET	25-18506001
12	SCREW, (.250-20 x .750)	10-28636
13	WASHER, (.330 x .750 x .060) Stainless Steel	12-56720
14	HOOK Comment: (Design I Use With Ref. #15)	813096A2
15	WASHER Comment: (Design I Use With Ref. #15)	12-36001
16	ROLLER Comment: (Design I Use With Ref. #15)	8M0207770
17	RING, Retaining Comment: (Design I Use With Ref. #15)	53-13194
14	HOOK KIT Comment: (Design II Use With Out Ref. #15)	813096A2
16	ROLLER Comment: (Design II Use With Out Ref. #15)	8M0207770
17	RING, Snap Comment: (Design II Use With Out Ref. #15)	53-8237951
18	SCREW	10-816992
19	LOCATOR	187021
20	BRACKET ASSEMBLY, Latch Roller	893763	18173
21	SPACER	816838
22	ROPE AND HANDLE KIT, Manual/Emergency Start, For Manual Starting	47341A11
23	FRONT SHIELD ASSEMBLY	18755A1
23	FRONT SHIELD ASSEMBLY	18755A2
23	FRONT SHIELD ASSEMBLY, Silver	18755A4
23	FRONT SHIELD ASSEMBLY	18755A3
24	SCREW, (.190-16 x .620)	10-77137
25	WASHER, (.203 x .500 x .032)	12-8M0204666
26	SEAL	813562

Transom Brackets

Below is the parts list for Mercury V-200XRI (EFI) Transom Brackets:

Position No.	Part Name	OEM Number	Supersedes
1	BRACKET, Transom, Starboard - Black	3401-8718F7
2	BRACKET ASSEMBLY, Transom, Port - Black	3400-8716A8
1	BRACKET, Transom, Starboard - Gray	3401-8718F8
2	BRACKET ASSEMBLY, Transom, Port - Gray	3400-8716A9
1	BRACKET, Transom, Starboard - Tracker	3401-8718F10
2	BRACKET ASSEMBLY, Transom, Port - Tracker	3400-8716A10
3	FITTING, Grease, Port	22-8M0169588
4	NUT, (.875-14)	11-8M0041651	11-37984
5	TUBE KIT, Tilt, Carbon Steel	99170A2
5	TILT TUBE, Stainless Steel	826125A1
6	NUT, (1.00-14) Nylon Insert, Black	11-826135
6	NUT, (1.00-14), Gray	11-859133	11-34862, 11-90068F 3, 11-90068F 4
6	NUT, (1.00-14), Tracker	11-859133	11-34862, 11-90068F 3, 11-90068F 4
7	O-RING, (.612 x .103)	25-45711
8	WASHER	13-88750
9	NUT, (.875-14)	11-826164
10	SCREW, (.500-20 x 4.500)	10-8M0149747
11	WASHER, (1.5 x 3.05 x 0.13) Stainless Steel	12-8M0204648
12	NUT, (.500-20)	11-91962
13	LEVER ASSEMBLY	8M0115104	8M0115103, 99629T 2
14	WAVE WASHER	13-99611
15	NYLINER	23-65830
16	KNOB	99633
17	PIN, Groove	17-99615
18	SPRING	24-99622
19	PIN, Groove	17-99604
20	BOLT ASSEMBLY	10-96930A1
21	NUT, (.375-24)	11-23161
22	STOP	814207
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90

WIRING HARNESS/STARTER SOLENOID

Below is the parts list for Mercury V-200XRI (EFI) WIRING HARNESS/STARTER SOLENOID:

Position No.	Part Name	OEM Number	Supersedes
1	IGNITION PLATE	434292
2	SWITCHBOX ASSEMBLY	332-7778A12
3	SCREW, (#12-24 x 2.00)	10-13669
4	BUSHING	23-94453
5	CABLE ASSEMBLY	84-62310A2
6	NUT, Brass	10-32,11-45076
7	WIRE ASSEMBLY	84-60871A10
8	SCREW, (#10-16 x .380)	10-878607	10-817626
9	CABLE ASSEMBLY, Black	84-65999A3
10	SCREW, (1.25)	10-60411
11	LOCKWASHER, (.312)	13-8M0204647
12	WASHER	12-36042
13	WASHER, (Rubber)	12-67264
14	BUSHING	23-67268
15	CABLE ASSEMBLY (3" - WHITE/BLACK)	84-91865A1
15	CABLE ASSEMBLY (6" - RED/WHITE)	84-88528A2
16	CABLE ASSEMBLY, Positive - Battery	84-88439A3
16	CABLE ASSEMBLY, Battery - Negative	84-88439A4
17	SCREW, (#10-32 x .500)	10-87926
18	CLAMP (OLD DESIGN)	54-814634
19A	HARNESS ASSEMBLY, Engine Wiring Comment: SN# 0G201875 & Up	84-826730A4
19	HARNESS ASSEMBLY, Engine Wiring Comment: SN# 0G201874 & Below	84-96220A16
20	FUSE, 20 Ampere	88-8M0207796
22	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
23	INSULATOR	85-78866
24	NUT, Brass	10-32,11-45076
25	SOLENOID ASSEMBLY, Starter (DESIGN I)	89-853654A1
26	NUT, Brass	10-32,11-45076
27	LOCKWASHER, (.312)	13-53166
28	NUT, (.312-18)	11-8M0204668
29	SCREW, (.250-20 x 1.12) Comment: (USE With Reference 36)	10-455611
29	SCREW, (.250-20 x .620) Comment: (Use with Reference 25)	10-31716
30	LOCKWASHER, (.250) Stainless Steel Comment: (Use with Reference 25)	13-26992
31	CABLE ASSEMBLY, Black	84-65999A2
32	TERMINAL BLOCK	86-194372
33	SCREW, (.190-32 x .620)	10-38055
34	WASHER, (.203 x .406 x .040)	12-89302
35	NUT, Brass	10-32,11-45076
36	SOLENOID ASSEMBLY, (#10-32 / .3125-18 Terminals) Comment: DESIGN II	89-817109A2
37	BUSHING Comment: DESIGN II	23-8M0214955

Wiring Harness/Starter Solenoid

Below is the parts list for Mercury V-200XRI (EFI) Wiring Harness/Starter Solenoid:

Position No.	Part Name	OEM Number	Supersedes
1	IGNITION PLATE	434292
2	SWITCHBOX ASSEMBLY	332-7778A12
3	SCREW, (#12-24 x 2.00)	10-13669
4	BUSHING	23-94453
5	CABLE ASSEMBLY	84-62310A2
6	NUT, Brass	10-32,11-45076
7	WIRE ASSEMBLY	84-60871A10
8	SCREW, (#10-16 x .380)	10-878607	10-817626
9	CABLE ASSEMBLY, Black, Black	84-65999A3
10	SCREW, (1.25)	10-60411
11	LOCKWASHER, (.312)	13-8M0204647
12	WASHER	12-36042
13	WASHER, (Rubber), Rubber	12-67264
14	BUSHING	23-67268
15	CABLE ASSEMBLY (3" - White/Black)	84-91865A1
15	CABLE ASSEMBLY (6" - Red/White)	84-88528A2
16	CABLE ASSEMBLY, Positive - Battery	84-88439A3
16	CABLE ASSEMBLY, Battery - Negative	84-88439A4
17	SCREW, (#10-32 x .500)	10-87926
18	CLAMP, Old Design	54-814634
19A	HARNESS ASSEMBLY, Engine Wiring Comment: SN# 0G201875 & Up	84-826730A4
19	HARNESS ASSEMBLY, Engine Wiring Comment: SN# 0G201874 & Below	84-96220A16
20	FUSE, 20 Ampere	88-8M0207796
22	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
23	INSULATOR	85-78866
24	NUT, Brass	10-32,11-45076
25	SOLENOID ASSEMBLY, Starter Comment: (Design I)	89-853654A1
26	NUT, Brass	10-32,11-45076
27	LOCKWASHER, (.312)	13-53166
28	NUT, (.312-18)	11-8M0204668
29	SCREW, (.250-20 x 1.12), Use With Ref. #36	10-455611
29	SCREW, (.250-20 x .620), Use With Ref. #25	10-31716
30	LOCKWASHER, (.250) Stainless Steel, Use With Ref. #25	13-26992
31	CABLE ASSEMBLY, Black, Black	84-65999A2
32	TERMINAL BLOCK	86-194372
33	SCREW, (.190-32 x .620)	10-38055
34	WASHER, (.203 x .406 x .040)	12-89302
35	NUT, Brass	10-32,11-45076
36	SOLENOID ASSEMBLY, (#10-32 / .3125-18 Terminals) Comment: (Design II)	89-817109A2
37	BUSHING Comment: (Design II)	23-8M0214955

Download this page as PDF: Click here

For Mercury Owners:

To assist you in maintaining and repairing your marine engines, we hope the following resources may be of use:

Mercury / Mercruiser / Mariner Parts from JLM Marine

About JLM Marine

Founded in 2002, JLM Marine has established itself as a dedicated manufacturer of high-quality marine parts, based in China. Our commitment to excellence in manufacturing has earned us the trust of top marine brands globally.

As a direct supplier, we bypass intermediaries, which allows us to offer competitive prices without compromising on quality. This approach not only supports cost-efficiency but also ensures that our customers receive the best value directly from the source.

We are excited to expand our reach through retail channels, bringing our expertise and commitment to quality directly to boat owners and enthusiasts worldwide.
