Mercury V-200XRI (EFI) Outboard Motor Parts Diagram & Catalog – Free PDF Download

BLEED SYSTEM

Below is the parts list for Mercury V-200XRI (EFI) BLEED SYSTEM:

Position No.	Part Name	OEM Number	Supersedes
1	TUBING, (20.00 Feet Bulk), BLEED	32-892024122	32-99130122
2	FITTING	22-59169003
3	CHECK VALVE (PRESS-IN - 13/16" LONG)	21-426982
4	CHECK VALVE (PRESS-IN - 11/16" LONG)	21-426233
5	FITTING (PRESS-IN)	22-15133
6	FITTING, Press-In	22-56759
7	CAP, ELBOW (YELLOW)	22-15026
8	TEE	22-18205
9	TUBING, (36.00 Inches Bulk)	32-9912688
10	FILTER	35-8M0207786

BOTTOM COWL

Below is the parts list for Mercury V-200XRI (EFI) BOTTOM COWL:

Position No.	Part Name	OEM Number	Supersedes
1	BOTTOM COWL ASSEMBLY (PORT) (BLACK)(Without Decals)	2197-9744A16
1	BOTTOM COWL ASSEMBLY , Gray (PORT)(Without Decals)	2197-9744A16
2	BOTTOM COWL ASSEMBLY (STARBOARD)(BLACK)(Without Decals)	2197-9745A5
2	BOTTOM COWL ASSEMBLY (STARBOARD)(GRAY)(Without Decals)	2197-9745A5
3	SEAL KIT, BOTTOM COWLS	18701A1
4	SCREW, (.250-20 x 1.320), COWL (STARBOARD)	10-18699
5	CHECK VALVE ASSEMBLY, Drain	21-817519A1
6	FITTING, TELLTALE	22-813613
7	FUEL LINE, (57.00 Inches Bulk), TELLTALE	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
8	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
9	LOCK PIN (OLD DESIGN)	17-815296	17-813930
10	SWITCH ASSEMBLY	87-8M0042301	87-896620, 87-856990, 87-850691, 87-18286A40
11	RETAINER	8M0032848	812443 1
12	T-FITTING, TELL TALE	22-815914
13	HOSE, (24.500 Inches Bulk)	32-77653101
14	HANDLE ASSEMBLY (PORT) (BLACK)	19648A2
14	HANDLE ASSEMBLY (PORT) (GRAY)	19648A2
15	HANDLE ASSEMBLY (STARBOARD) (BLACK)	19647A3
15	HANDLE ASSEMBLY (STARBOARD) (GRAY)	19647A3
16	NYLINER	23-65830
17	WAVE WASHER	13-99611
18	PAWL, STARBOARD	19369
19	PAWL, PORT	19370
20	WASHER, (.281 x .734 x .063)	12-69057
21	LOCKWASHER, (.250)	13-26992
22	SCREW, (.250-20 x .500)	10-73286
23	CLAMP, UPPER	54-19749
24	CLAMP, LOWER	54-197481
25	SCREW, (#10-16 x 1.12)	10-92799
26	COVER ASSEMBLY (BLACK)	18872A1
26	COVER ASSEMBLY (GRAY)	18872A2
27	LOCK NUT	11-8136921
28	Not Sold Seperate, Front Handle Assembly (#N.S.S.) Comment: (Replace with 813076A2)
29	Not Sold Seperate, Handle (#N.S.S.) Comment: (Replace with 813076A2)
30	Not Sold Seperate, Handle Lock (#N.S.S.) Comment: (Replace with 813076A2)
31	Not Sold Seperate, Screw (#N.S.S.) Comment: (Replace with 813076A2)
32	Not Sold Seperate, Spring (#N.S.S.) Comment: (Replace with 813076A2)
33	SCREW, (.250-20 x .620)	10-18192
34	BUSHING	23-19666
35	ROD	18727
36	FRONT HANDLE (NEW DESIGN)	8130764

Bottom Cowl

Below is the parts list for Mercury V-200XRI (EFI) Bottom Cowl:

Position No.	Part Name	OEM Number	Supersedes
1	BOTTOM COWL ASSEMBLY (BLACK) Comment: (PORT)	2197-9744A16
1	BOTTOM COWL ASSEMBLY , Gray Comment: (PORT)	2197-9744A16
2	BOTTOM COWL ASSEMBLY (BLACK) Comment: (STARBOARD)	2197-9745A5
2	BOTTOM COWL ASSEMBLY (GRAY) Comment: (STARBOARD)	2197-9745A6
3	SEAL KIT, BOTTOM COWLS-(PORT/STBD.)	18701A1
4	SCREW, (.250-20 x 1.320), COWL (STARBOARD)	10-18699
5	CHECK VALVE, Drain (PORT/STBD.)	21-817519A1
6	FITTING, TELLTALE-STARBOARD	22-813613
7	FUEL LINE, (57.00 Inches Bulk), TELLTALE-STARBOARD	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
8	CABLE TIE, (8.00 Inches) (STARBOARD)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
9	LOCK PIN (USE WHERE APPLICABLE)(STARBOARD)	17-815296	17-813930
10	SWITCH ASSEMBLY	87-8M0042301	87-896620, 87-856990, 87-850691, 87-18286A40
11	RETAINER	8M0032848	812443 1
12	T-FITTING, TELLTALE	22-815914
13	HOSE, (24.500 Inches Bulk)	32-77653101
14	HANDLE ASSEMBLY (BLACK)(PORT)	19648A2
14	HANDLE ASSEMBLY (GRAY)(PORT)	19648A2
15	HANDLE ASSEMBLY (BLACK)(STARBOARD)	19647A3
15	HANDLE ASSEMBLY (GRAY)(STARBOARD)	19647A3
16	NYLINER	23-65830
17	WAVE WASHER	13-99611
18	PAWL (STARBOARD)	19369
19	PAWL (PORT)	19370
20	WASHER, (.281 x .734 x .063)	12-69057
21	LOCKWASHER, (.250)	13-26992
22	SCREW, (.250-20 x .500)	10-73286
23	CLAMP, UPPER (W/O POWER STEERING)	54-19749
23	CLAMP, UPPER (WITH POWER STEERING)	54-197491
24	CLAMP, LOWER	54-197481
25	SCREW, (#10-16 x 1.12)	10-92799
26	COVER ASSEMBLY (BLACK)	18872A1
26	COVER ASSEMBLY (GRAY)	18872A2
27	LOCK NUT	11-8136921
28	NOT SOLD SEPARATE, Front Handle Comment: (REPLACE WITH 813076A2)	NSS
29	NOT SOLD SEPARATE, Handle Comment: (REPLACE WITH 813076A2)	NSS
30	NOT SOLD SEPARATE, Lock-Handle Comment: (REPLACE WITH 813076A2)	NSS
31	NOT SOLD SEPARATE, Screw Comment: (REPLACE WITH 813076A2)	NSS
32	NOT SOLD SEPARATE, Spring Comment: (REPLACE WITH 813076A2)	NSS
33	SCREW, (.25-20 x .62)	10-18192
34	BUSHING	23-19666
35	ROD	18727
36	FRONT HANDLE	8130764

CRANKSHAFT(Conn Rod Forging # is 636-8118)

Below is the parts list for Mercury V-200XRI (EFI) CRANKSHAFT(Conn Rod Forging # is 636-8118):

Position No.	Part Name	OEM Number	Supersedes
1	CRANKSHAFT ASSEMBLY	455-9536T4
2	BEARING, Ball (LOWER)	30-67923T
3	RING	53-67446
4	GEAR KIT	43-14513A09
5	SCREW, (#6-32 x .620)	10-813073
6	NUT, (#6-32 Special)	11-813134
7	BEARING ASSEMBLY, Roller	31-16756A6
8	CARRIER ASSEMBLY	54196A6
9	PACKING	65800
10	RING, SEALING (.124 THICK)	39-67377T
11	PISTON ASSEMBLY (STARBOARD - STANDARD) (175)	766-8666T42
11	PISTON ASSEMBLY, (Starboard) (STARBOARD - .015 O.S.) (175)	766-8666A43
11	PISTON ASSEMBLY (PORT - STANDARD) (175)	766-8667T42
11	PISTON ASSEMBLY, (Port) (PORT - .015 O.S.) (175)	766-8667A43
12	PISTON RING ASSEMBLY (STANDARD) (175)	39-18487A12
12	PISTON RING ASSEMBLY (.015 O.S.) (175)	39-815267A4
11	PISTON (STARBOARD - STANDARD) (200)	785-9738T4
11	PISTON (STARBOARD - .015 O.S.) (200)	785-9738A5
11	PISTON (PORT - STANDARD) (200)	785-9737T4
11	PISTON (PORT - .015 O.S.) (200)	785-9737A5
12	PISTON RING (STANDARD) (200)	39-815515A12
12	PISTON RING (.015 O.S.) (200)	39-815268A4
13	RING, Lock	53-857196	40-52035
14	CONNECTING ROD ASSEMBLY	636-8119A6
15	SCREW, (.312-28 x .875)	10-93886
16	WASHER	12-8M0032839	12-47247
17	BEARING, Needle	29-67483
18	BEARING KIT	8M0234886
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)
-	GASKET SET Comment: (175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (175)

CRANKSHAFT(Conn. Rod Forging # is 644-818141)

Below is the parts list for Mercury V-200XRI (EFI) CRANKSHAFT(Conn. Rod Forging # is 644-818141):

Position No.	Part Name	OEM Number	Supersedes
1	CRANKSHAFT ASSEMBLY	455-9536T4
2	BEARING, Ball (LOWER)	30-67923T
3	RING	53-67446
4	GEAR KIT	43-14513A09
5	SCREW, (#6-32 x .620)	10-813073
6	NUT, (#6-32 Special)	11-813134
7	BEARING ASSEMBLY, Roller	31-16756A6
8	CARRIER ASSEMBLY	54196A6
9	PACKING	65800
10	RING (.124 THICK)	39-67377T
11	PISTON (STARBOARD - STANDARD)	785-9738T9
11	PISTON (STARBOARD - .015 O.S.)	785-9738T10
11	PISTON (PORT - STANDARD)	785-9737T9
11	PISTON (PORT - .015 O.S.)	785-9737A10
12	PISTON RING (STANDARD)	39-815515A12
12	PISTON RING (.015 O.S.)	39-815268A4
13	RING, Lock, PISTON	53-857196	40-52035
14	CONNECTING ROD KIT	644-818141A13	644-818141A 2
15	SCREW, (.312-24 x .875), CONNECTING ROD	10-763491
16	WASHER, NEEDLE LOCATING	12-8M0012298	12-812876
17	BEARING, Needle, PISTON END	29-8M0204691
18	BEARING KIT	8M0234886
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)
-	GASKET SET Comment: (175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (175)

CYLINDER BLOCK AND END CAPS

Below is the parts list for Mercury V-200XRI (EFI) CYLINDER BLOCK AND END CAPS:

Position No.	Part Name	OEM Number	Supersedes
1	CYLINDER BLOCK (175)	884-9764T12
1	CYLINDER BLOCK (200)	884-9763T6
2	STUD, POWERHEAD (1-3/4")	16-8M0034455	16-818138 4
2	STUD, POWERHEAD (1-7/8")	16-76175
3	STUD, POWERHEAD (5-1/2")	16-670654
3	STUD, POWERHEAD (6-3/4")	16-8M0034454	16-78438 5
4	PIN, Dowel, LOCATING	17-43044
5	PIN (BEARING RACE)	17-8M0036405	17-67296
6	GASKET, SEALING	27-11338
7	COVER, STARTER MOTOR (UPPER)	8M0088723	42249 1
8	SCREW, (.312-18 x 1.50), COVER TO CRANKCASE	10-73657
9	LOCKWASHER, (.312)	13-8M0204647
10	COVER, STARTER MOTOR (LOWER)	76867
11	SCREW, (.312-18 x 2), COVER TO CRANKCASE	10-815549	10-25503, 10-77065
12	BUSHING	23-99448
13	CABLE ASSEMBLY, COVER	84-88807A20
14	SCREW, (.375-16 x 3.250)	10-66717
14	SCREW, (.312-18 x 1.250)	10-74824
15	END CAP ASSEMBLY, Upper	1159-858521T1
16	O-RING, (2.800 x .103), END CAP	25-54029
17	BEARING ASSEMBLY, Roller, END CAP	31-16756A4
18	SEAL, END CAP	26-41953
19	SCREW AND LOCKWASHER, (.312-18 x 1.00)	10-30225
20	J CLIP	54-63153
22	STUD, (.190-32 x 1.870)	16-15094
23	STUD, (#10-32 x 1.00), FLYWHEEL COVER TO BRACKET	16-8M0034435	16-15093
24	SPACER, FLYWHEEL COVER STUD	23-67269
25	WASHER, FLYWHEEL COVER STUD	12-8M0204663
26	WASHER, (.203 x .562 x .060), FLYWHEEL COVER STUD	12-72761
27	WING NUT, , FLYWHEEL COVER STUD	10-32,11-816874	11-73651, 11-816873, 11-90052
28	BRACKET, FLYWHEEL COVER	422482
29	SCREW, (.250-20 x .750), BRACKET TO CRANKCASE	10-49668
30	END CAP ASSEMBLY, LOWER	1156-7809T1
31	O-RING, (3.237 x .103), END CAP	25-62700
32	SEAL, END CAP	26-41953
33	SCREW, (.250-20 x .750)	10-28636
34	LOCKWASHER, (.250), LOWER END CAP SCREW	13-26992
35	SCREW, (.250-20 x 2.125), ADJUSTING - CYLINDER BLOCK	10-64022
36	NUT, (.250-20), JAM - ADJUSTING SCREW	11-64015
37	CAP, NYLON - ADJUSTING SCREW	26852
38	IDLE SPEED CONTROL ASSEMBLY (200)	87076A10
39	SCREW, (#10-32 x .875)	10-690201
40	WASHER	12-38833
41	ADVANCED MODULE (175)	93772A11
42	CLAMP (175)	54-16793
43	SCREW, (.250-20 x .500) (175)	10-73286
-	POWERHEAD, COMPLETE (175)	812817T90	812817A90
-	POWERHEAD ASSEMBLY, COMPLETE (200)	812827T91	812827A91, 812827A90, 813043A91, 813043A90
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)
-	GASKET SET Comment: (175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (175)

Carburetor

Below is the parts list for Mercury V-200XRI (EFI) Carburetor:

Position No.	Part Name	OEM Number	Supersedes
1	CARBURETOR ASSEMBLY Comment: (135 - WMH-8-Top)	3311-818650A28	3308-813682A 7, 3311-818650A16, 3308-9672A50, 3311-818650A13 (135 - WMH-8-Top)
1	CARBURETOR ASSEMBLY Comment: (135 - WMH-8-Center)	3311-818650A29	3308-813682A 8, 3311-818650A17, 3308-9672A51, 3311-818650A14 (135 - WMH-8-Center)
1	CARBURETOR ASSEMBLY Comment: (135 - WMH-8-Bottom)	3311-818650A55	3308-813682A 9, 3311-818650A30, 3311-818650A18, 3308-9672A52, 3311-818650A15 (135 - WMH-8-Bottom)
1	CARBURETOR ASSEMBLY Comment: (135 - WMH-8A-Top)	3311-818650A28	3308-813682A 7, 3311-818650A16, 3308-9672A50, 3311-818650A13 (135 - WMH-8A-Top)
1	CARBURETOR ASSEMBLY Comment: 135 - WMH-8A-Center)	3311-818650A29	3308-813682A 8, 3311-818650A17, 3308-9672A51, 3311-818650A14 135 - WMH-8A-Center)
1	CARBURETOR ASSEMBLY Comment: (135 - WMH-8A-Bottom)	3311-818650A55	3308-813682A 9, 3311-818650A30, 3311-818650A18, 3308-9672A52, 3311-818650A15 (135 - WMH-8A-Bottom)
1	CARBURETOR ASSEMBLY Comment: (150 - WMH-1-Top)	3311-818650A31	3311-818650A10, 3308-9672A19, 3308-9672A35 (150 - WMH-1-Top)
1	CARBURETOR ASSEMBLY Comment: (150 - WMH-1-Center)	3311-818650A32	3311-818650A11, 3308-9672A20, 3308-9672A36 (150 - WMH-1-Center)
1	CARBURETOR ASSEMBLY Comment: (150 - WMH-1-Bottom)	3311-818650A56	3311-818650A33, 3311-818650A12, 3308-9672A21, 3308-9672A37 (150 - WMH-1-Bottom)
1	CARBURETOR ASSEMBLY Comment: (150 - WMH-7-Top)	3311-818650A31	3311-818650A10, 3308-9672A19, 3308-9672A35 (150 - WMH-7-Top)
1	CARBURETOR ASSEMBLY Comment: (150 - WMH-7-Center)	3311-818650A32	3311-818650A11, 3308-9672A20, 3308-9672A36 (150 - WMH-7-Center)
1	CARBURETOR ASSEMBLY Comment: (150 - WMH-7-Bottom)	3311-818650A56	3311-818650A33, 3311-818650A12, 3308-9672A21, 3308-9672A37 (150 - WMH-7-Bottom)
1	CARBURETOR Comment: (XR4/MAGNUM II-Top)	3308-9672A61
1	CARBURETOR Comment: (XR4/MAGNUM II-Center)	3308-9672A62
1	CARBURETOR Comment: (XR4/MAGNUM II-Bottom)	3308-9672A63
1	CARBURETOR Comment: (175 - WMH-2-Top)	3311-818650A37	3311-818650A 7 (175 - WMH-2-Top)
1	CARBURETOR Comment: (175 - WMH-2-Center)	3311-818650A38	3311-818650A 8 (175 - WMH-2-Center)
1	CARBURETOR Comment: (175 - WMH-2-Bottom)	3311-818650A58	3311-818650A39, 3311-818650A 9 (175 - WMH-2-Bottom)
1	CARBURETOR Comment: (175 - WMH-11-Top)	3311-818650A37	3311-818650A 7 (175 - WMH-11-Top)
1	CARBURETOR Comment: (175 - WMH-11-Center)	3311-818650A38	3311-818650A 8 (175 - WMH-11-Center)
1	CARBURETOR Comment: (175 - WMH-11-Bottom)	3311-818650A58	3311-818650A39, 3311-818650A 9 (175 - WMH-11-Bottom)
1	CARBURETOR Comment: (200-Top)	3311-818650A52	3311-818650A 4, 3311-818650A40 (200-Top)
1	CARBURETOR Comment: (200-Center)	3311-818650A53	3311-818650A 5, 3311-818650A41 (200-Center)
1	CARBURETOR Comment: (200-Bottom)	3311-818650A59	3311-818650A 6, 3311-818650A42 (200-Bottom)
2	CAP	810779
3	GASKET, MOUNTING FLANGE	27-677511
4	EMULSLON TUBE Comment: (135/150/XR4/Magnum II/175)	810743
4	EMULSION TUBE Comment: (200)	810764
5	ACCELERATOR LEVER ASSEMBLY	810748
6	ACCELERATOR LINK	810723
7	NOT SOLD SEPARATE, Bushing, Accelerator Link	NSS
8	NOT SOLD SEPARATE, Ring, Accelerator Link	NSS
9	THROTTLE LEVER (TOP/CENTER)	810721
9	THROTTLE LEVER (BOTTOM)	810722
10	NOT SOLD SEPARATE, Screw, Accelerator Lever	NSS
11	SPACER, THROTTLE LEVER Comment: (135/150/XR4/Magnum II/175)	1395-811284	23-810746 (135/150/XR4/Magnum II/175)
11	SPACER Comment: (200)	1395-811284	23-810746 (200)
12	WASHER, LEVER RETAINER NUT	12-810745
13	NUT, LEVER RETAINER	11-810744
14	NOT SOLD SEPARATE, Spring, Throttle Return	NSS
15	JET, (.084), BOWL VENT Comment: (150)	1399-3517
15	JET, (.070), BOWL VENT Comment: (135)(WMH-5)	1395-6030
15	JET, (.048), BOWL VENT Comment: (135)(WMH-8)	1395-6246
15	JET, BOWL VENT Comment: (XRR/Magnum II)	19266040
15	JET, (.080), BOWL VENT Comment: (175)	1395-6201
15	JET, (.076), BOWL VENT Comment: (200)	1399-3796
16	MAIN FUEL JET, (.042), IDLE AIR BLEED Comment: (150)	1399-5315
16	JET, (.044), IDLE AIR BLEED Comment: (135-WMH-5)(175)	1395-7394
16	JET, (.048), IDLE AIR BLEED Comment: (135-WMH-8)(175)	1395-6246
16	JET, IDLE AIR BLEED Comment: (XR4/Magnum II-WMH-4)	19266036
16	JET, (.052), IDLE AIR BLEED Comment: (175)	1395-6359
16	JET, IDLE AIR BLEED Comment: (200)	19266040
16	JET, (.046), IDLE AIR BLEED Comment: (200)	1399-5317
17	JET, (.044), PROGRESSION AIR Comment: (150)(175-WMH-2)	810742
17	JET, (.036), PROGRESSION AIR Comment: (135-WMH-5)	1399-3026
17	JET, .040, PROGRESSION AIR Comment: (135WMH-8)(WMH-8)	1399-7570
17	JET, (.030), PROGRESSION AIR Comment: (XR4/Magnum II)	810741
17	JET, PROGRESSION AIR Comment: (175-WMH-11)	815633070
17	JET, (.034), PROGRESSION AIR Comment: (200)	1399-3251
18	STEM, ACCELERATOR PUMP	17-810747
19	COVER ASSEMBLY, ACCELERATOR	810737
20	NOT SOLD SEPARATE, Screw, Accelerator	NSS
21	NOT SOLD SEPARATE, Gasket, Fuel Bowl	NSS
22	NOT SOLD SEPARATE, Spring, Accelerator Pump	NSS
23	PUMP CUP ASSEMBLY	810762	810765
24	NOT SOLD SEPARATE, Cup	NSS
25	NOT SOLD SEPARATE, Spring, Accelerator Pump	NSS
26	FLOAT ASSEMBLY	810738
27	NOT SOLD SEPARATE, Float Shaft	NSS
28	NOT SOLD SEPARATE, Screw, Float Shaft	NSS
29	VALVE SEAT KIT	1395-8116901
30	NOT SOLD SEPARATE, Gasket, Valve Seat	NSS
31	FUEL BOWL (W/FITTLNG-TOP) Comment: (135/150/175/XR4/Magnum II/175-WHM-2/200)	810729
31	FUEL BOWL (CENTER/BOTTOM) Comment: (135/150/175/XR4/Magnum II/175-WHM-2/200)	810734
31	FUEL BOWL (TOP) Comment: (175-WMH-11)	1395-811932
31	FUEL BOWL (CENTER/BOTTOM) Comment: (175-WMH-11)	1395-811931
32	PLUG, POWER JET	1395-811694	1395-9596 1
33	NOT SOLD SEPARATE, Gasket, Power/Progression Jet	NSS
34	MAIN JET, (.062) Comment: (150)(XR4/Magnum II)	1399-4217
34	JET, (.050) Comment: (135)	1395-6028
34	JET, (.064) Comment: (175/200)	1399-4216
35	JET, POWER Comment: (150-WMH-1/XR4/Magnum II/175-WMH-2)	810740
35	JET, POWER Comment: (150-WMH-7)	1395-811283
35	JET, POWER Comment: (135-WMH-5)	816151
35	JET, POWER Comment: (135-WMH-8)	1395-811293
35	JET, POWER Comment: (135-WMH-8A)	1395-811685
35	POWER JET, POWER Comment: (XR4/Magnum II-WMH-6)	1395-811285
35	POWER JET, POWER Comment: (175-WMH-11)	1395-811925
35	POWER JET, POWER Comment: (200)	810763
36	NOT SOLD SEPARATE, Screw, Fuel Bowl	NSS
37	NOT SOLD SEPARATE, Metering Ball	NSS
38	NOT SOLD SEPARATE, Metering Spring	NSS
39	NOT SOLD SEPARATE, Retainer, Metering Spring	NSS
40	TEE FITTING (TOP/CENTER)	1395-7900
41	ELBOW (BOTTOM)	1395-7901
-	GASKET SET Comment: (135/150)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (135/150)
-	GASKET SET Comment: (XR4/Magnum II/175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (XR4/Magnum II/175)
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)
-	REPAIR KIT, Carb	1395-8116912
-	GASKET SET, Carb	8107492

Choke Plate and Throttle Levers

Below is the parts list for Mercury V-200XRI (EFI) Choke Plate and Throttle Levers:

Position No.	Part Name	OEM Number	Supersedes
1	COVER, SOUND ATTENUATOR	18866T
2	SCREW, (#10-16 x .625), COVER TO CHOKE PLATE	10-48409
3	GASKET, SOUND ATTENUATOR	27-188891
4	SOUNG ATTENUATOR PLATE	817495A1
5	GASKET, ATTENUATOR TO CARBURETOR	27-892211
6	SCREW, (.24-28 X 1.00), CHOKE PLATE TO CARBURETOR	10-68000
7	WASHER, CHOKE PLATE SCREW	12-20583
8	CHECK VALVE	21-64871A2
9	TUBING, (20.00 Feet Bulk)	32-892024122	32-99130122
10	THROTTLE LINK	18180
11	LINK	18181
12	ROLLER	18178
13	SCREW, (#10-32 x .500)	10-87926
14	WASHER, (.203 x .406 x .040)	12-89302
15	LOCKWASHER, (#10 External)	13-69432

Crankshaft(Connecting Rod Forging # is 636-8118)

Below is the parts list for Mercury V-200XRI (EFI) Crankshaft(Connecting Rod Forging # is 636-8118):

Position No.	Part Name	OEM Number	Supersedes
1	CRANKSHAFT ASSEMBLY	455-9536T4
2	BEARING, Ball, CRANKSHAFT (LOWER)	30-67923T
3	RING, BALL BEARING	53-67446
4	GEAR KIT	43-14513A09
5	SCREW, (#6-32 x .620)	10-813073
6	NUT, (#6-32 Special)	11-813134
7	CARRIER ASSEMBLY, SEAL	54196A6
8	PACKING, CARRIER	65800
9	RING, SEALING - CRANKSHAFT	39-67377T
10	ROLLER BEARING, CRANKSHAFT	31-16756A6
11	PISTON (STARBOARD-STANDARD) Comment: (135/150)	765-7441T36
11	PISTON (STARBOARD-.015 O.S.) Comment: (135/150)	765-7443A12
11	PISTON (STARBOARD-.030 OS.) Comment: (135/150)	765-7445A12
11	PISTON (PORT-STANDARD) Comment: (135/150)	765-7442T36
11	PISTON (PORT-.015 O.S.) Comment: (135/150)	765-7444A12
11	PISTON (PORT-.030 O.S.) Comment: (135/150)	765-7446T12
11	PISTON ASSEMBLY (STARBOARD-STANDARD) Comment: (XR4/MAGNUM II/175)	766-8666T42
11	PISTON ASSEMBLY, (Starboard) (015 O.S.) Comment: (XR4/MAGNUM II/ 175)	766-8666A43
11	PISTON ASSEMBLY (PORT-STANDARD) Comment: (XR4/MAGNUM II/ 175)	766-8667T42
11	PISTON ASSEMBLY, (Port) (.015 O.S.) Comment: (XR4/MAGNUM II/ 175)	766-8667A43
11	PISTON (STARBOARD-STANDARD) Comment: (200)	785-9738T4
11	PISTON (STARBOARD-.015 O.S.) Comment: (200)	785-9738A5
11	PISTON (PORT-STANDARD) Comment: (200)	785-9737T4
11	PISTON (PORT-.015 O.S.) Comment: (200)	785-9737A5
12	PISTON RING (STANDARD) Comment: (135/150)	39-93481A12
12	PISTON RING (.015 O.S.) Comment: (135/150)	39-78918A4
12	PISTON RING (.030 O.S.) Comment: (135/150)	39-85636A4
12	PISTON RING ASSEMBLY (STANDARD) Comment: (XR4/MAGNUM II/175)	39-18487A12
12	PISTON RING ASSEMBLY (.015 O.S.) Comment: (XR4/MAGNUM II/175)	39-815267A4
12	PISTON RING (STANDARD) Comment: (200)	39-815515A12
12	PISTON RING (.015 O.S.) Comment: (200)	39-815268A4
13	RING, Lock	53-857196	40-52035
14	CONNECTING ROD ASSEMBLY	636-8119A6
15	SCREW, (.3125-28 X .875), CONNECTING ROD	10-93886
16	WASHER, NEEDLE LOCATING	12-8M0032839	12-47247
17	BEARING KIT	8M0234886
18	NEEDLE BEARING, PISTON END	29-67483
-	GASKET SET Comment: (135/150)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (135/150)
-	GASKET SET Comment: (XR4/Magnum II/175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (XR4/Magnum II/175)
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)

Crankshaft(Connecting Rod Forging # is 644-818141)

Below is the parts list for Mercury V-200XRI (EFI) Crankshaft(Connecting Rod Forging # is 644-818141):

Position No.	Part Name	OEM Number	Supersedes
1	CRANKSHAFT ASSEMBLY	455-9536T4
2	BEARING, Ball (LOWER)	30-67923T
3	RING	53-67446
4	GEAR KIT	43-14513A09
5	SCREW, (#6-32 x .620)	10-813073
6	NUT, (#6-32 Special)	11-813134
7	CARRIER ASSEMBLY	54196A6
8	PACKING	65800
9	RING, SEALING - CRANKSHAFT	39-67377T
10	ROLLER BEARING, CRANKSHAFT	31-16756A6
11	PISTON (STARBOARD-STANDARD) Comment: (135/150)	765-7441T32
11	PISTON (STARBOARD-.015 O.S.) Comment: (135/150)	765-7443A11
11	PISTON (STARBOARD-.030 OS.) Comment: (135/150)	765-7445T11
11	PISTON (PORT-STANDARD) Comment: (135/150)	765-7442T32
11	PISTON (PORT-.015 O.S.) Comment: (135/150)	765-7444A11
11	PISTON (PORT-.030 O.S.) Comment: (135/150)	765-7446A11
11	PISTON (STARBOARD-STANDARD) Comment: (200)	785-9738T9
11	PISTON (STARBOARD-.015 O.S.) Comment: (200)	785-9738T10
11	PISTON (PORT-STANDARD) Comment: (200)	785-9737T9
11	PISTON (PORT-.015 O.S.) Comment: (200)	785-9737A10
12	PISTON RING (STANDARD) Comment: (135/150)	39-93481A12
12	PISTON RING (.015 O.S.) Comment: (135/150)	39-78918A4
12	PISTON RING (.030 O.S.) Comment: (135/150)	39-85636A4
12	PISTON RING (STANDARD) Comment: (200)	39-815515A12
12	PISTON RING (.015 O.S.) Comment: (200)	39-815268A4
13	RING, Lock	53-857196	40-52035
14	CONNECTING ROD KIT	644-818141A13	644-818141A 2
15	SCREW, (.312-24 x .875), CONNECTING ROD	10-763491
16	WASHER, NEEDLE LOCATING	12-8M0012298	12-812876
17	BEARING KIT	8M0234886
18	NEEDLE BEARING, PISTON END	29-8M0204691
-	GASKET SET Comment: (135/150)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (135/150)
-	GASKET SET Comment: (XR4/Magnum II/175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (XR4/Magnum II/175)
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)

Cylinder Block and End Caps

Below is the parts list for Mercury V-200XRI (EFI) Cylinder Block and End Caps:

Position No.	Part Name	OEM Number	Supersedes
1	CYLINDER BLOCK (135/150)	884-859211T2
1	CYLINDER BLOCK (XR4/MAGNUM II)	884-9764T13
1	CYLINDER BLOCK (175)	884-9764T12
1	CYLINDER BLOCK (200)	884-9763T6
2	STUD, POWERHEAD (1-7/8")	16-76175
2	STUD, POWERHEAD (1-3/4")	16-8M0034455	16-818138 4
3	STUD, POWERHEAD (5-1/2")	16-670654
3	STUD, POWERHEAD (6-3/4")	16-8M0034454	16-78438 5
4	PIN, Dowel, LOCATING	17-43044
5	PIN (BEARING RACE)	17-8M0036405	17-67296
6	GASKET, SEALING	27-11338
7	COVER, STARTER MOTOR (UPPER)	8M0088723	42249 1
8	SCREW, (.312-18 x 1.50)	10-73657
9	LOCKWASHER, (.312)	13-8M0204647
10	COVER (LOWER)	76867
11	SCREW, (.312-18 x 2)	10-815549	10-25503, 10-77065
11A	BUSHING	23-99448
12	SCREW, (.375-16 x 3.250)	10-66717
12	SCREW, (.312-18 x 1.250)	10-74824
13	UPPER END CAP ASSEMBLY, UPPER	1159-858521T1
14	O-RING	25-54029
15	ROLLER BEARING	31-16756A4
16	SEAL	26-41953
17	SCREW WITH LOCKWASHER, (.312-18 x 1.00)	10-30225
19	J CLIP	54-63153
20	STUD, (.190-32 x 1.870)	16-15094
21	STUD, (#10-32 x 1.00)	16-8M0034435	16-15093
22	SPACER, FLYWHEEL COVER STUD	23-67269
23	WASHER, FLYWHEEL COVER STUD	12-8M0204663
24	WASHER, FLYWHEEL COVER STUD	12-72761
25	WING NUT, , FLYWHEEL COVER STUD	10-32,11-816874	11-73651, 11-816873, 11-90052
26	BRACKET, FLYWHEEL COVER	422482
27	SCREW, (.250-20 x .750), BRACKET TO CRANKCASE	10-49668
28	END CAP ASSEMBLY, LOWER	1156-7809T1
29	O-RING, (3.250 Inside Diameter), END CAP	25-62700
30	SEAL, END CAP	26-41953
31	SCREW, (.250-20 x .750)	10-28636
32	LOCKWASHER, (.250), LOWER END CAP SCREW	13-26992
33	SCREW, (.250-20 x 2.125), ADJUSTING - CYLINDER BLOCK	10-64022
34	NUT, ( #8-32), JAM - ADJUSTING SCREW	11-64015
35	CAP, NYLON - ADJUSTING SCREW	26852
36	IDLE SPEED CONTROL ASSEMBLY Comment: SN# 0C254932 & Up	87076A10
36	ADVANCED MODULE Comment: SN# 0C247591 THRU 0C254931	93772A11
37	SCREW, (#10-32 x .875)	10-690201
38	WASHER	12-38833
-	POWERHEAD (135/150)	878365T00	812815T00, 812815T97, 812815A97, 812815A96, 812815A92, 812815A90
-	POWERHEAD (XR4/MAGNUM II)	815908T90	815908A90
-	POWERHEAD (175)	812817T90	812817A90
-	POWERHEAD (200)	812827T91	812827A91, 812827A90, 813043A91, 813043A90
-	GASKET SET Comment: (135/150)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (135/150)
-	GASKET SET Comment: (XR4/Magnum II/175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (XR4/Magnum II/175)
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)

DETONATION CONTROLLER/TEMPERATURE SENSOR

Below is the parts list for Mercury V-200XRI (EFI) DETONATION CONTROLLER/TEMPERATURE SENSOR:

Position No.	Part Name	OEM Number	Supersedes
1	DETONATION CONTROLLER ASSEMBLY (200)	826800A8
2	SCREW, (.190-32 x 1.62), DETONATION CONTROLLER (200)	10-88447
3	WASHER, DETONATION CONTROLLER SCREW (200)	12-38833
4	PLATE (200)	13381
5	CABLE ASSEMBLY (200)	84-88807A10
6	SCREW, (#10-16 x .375), CABLE TO PLATE (200)	10-62568
7	SPACER (200)	23-94304
8	OIL INJECTION WARNING MODULE ASSEMBLY	41470A25
9	INDICATOR, THROTTLE POSITION	14851T03
10	SCREW, INDICATOR	10-15150
11	LOCKWASHER, , INDICATOR SCREW	8,13-26995
12	WASHER, INDICATOR SCREW	12-30164
13	SLEEVE	23-15885
14	TEMPERATURE SENSOR ASSEMBLY	13221T01
15	O-RING, (.612 x .103)	25-45711
16	SCREW, (#8-32 x .375), TEMPERATURE SENSOR	10-57583T
17	LOCKWASHER, , TEMPERATURE SENSOR SCREW	8,13-26995
18	SCREW	10-42813
19	PLATE	813501
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)
-	GASKET SET Comment: (175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (175)

DRIVESHAFT HOUSING AND EXHAUST TUBE

Below is the parts list for Mercury V-200XRI (EFI) DRIVESHAFT HOUSING AND EXHAUST TUBE:

Position No.	Part Name	OEM Number	Supersedes
1	DRIVESHAFT HOUSING (BLACK)	1590-8343T10
1	DRIVESHAFT HOUSING (GRAY)	1590-8343T11
2	STUD, (.437 x 2.69), DRIVE SHAFT HSG./GEAR HSG.	16-56295
3	BUMPER, LOWER MOUNT SCREW	25067
4	SCREW, (.500-20 x 6.00), LOWER MOUNT	10-898831	10-63474
5	MOUNT, LOWER	78249
6	WASHER, (.8125), LOWER MOUNT SCREW	12-49339
7	NUT, LOWER MOUNT SCREW	11-25096
8	WIRE ASSEMBLY, Ground	88238A10
9	CLAMP, LOWER MOUNT	54-8M0036782	54-67076
10	SCREW, (.312-18 x 1.250), LOWER MOUNT CLAMP ATTACHING	10-66727
11	COVER, LOWER MOUNT CLAMP (BLACK)	100-8M4500752	8M0001130, 67077T
11	COVER, LOWER MOUNT CLAMP (GRAY)	67077F1
12	SCREW, (#12-24 x .620), COVER ATTACHING	10-88417
13	NUT, NYLON - COVER TO CLAMP SCREW	11-35521
14	WIRE ASSEMBLY, Ground	88238A10
15	SCREW, (.250-20 x .500), GROUND WIRE	10-41508
16	WASHER, GEAR HOUSING STUD	12-48926
17	NUT, GEAR HOUSING STUD (CAP)	11-29489
18	WASHER, (.453 x .812 x .105), GEAR HOUSING STUD	12-45176
19	NUT, (.437-20), GEAR HOUSING STUD	11-8M0204653
20	PLUG, DRIVE SHAFT HOUSING	19-64649
21	EXHAUST TUBE	18276T
22	SEAL, EXHAUST TUBE (LOWER)	66350001
23	SEAL, EXHAUST TUBE (UPPER)	8M0039076	17726 1
24	TUBE, WATER	32-8M0042788	32-859097 1
25	GASKET, DRIVE SHAFT HOUSING TO PLATE	27-991734
26	PLATE ASSEMBLY, DRIVE SHAFT HOUSING	18233A20
27	SEAL, BRACKET	8M0043165	814701 2
28	BRACKET, SEAL RETAINING	68011
29	SCREW, (#10-16 x .500), BRACKET TO PLATE	10-878608	10-812832
30	PIN, Dowel, LOCATING	17-43044
31	SEAL, WATER TUBE	26-38970
32	SCREW, (.250-20 x .750), EXTENSION TO PLATE	10-90192
33	GASKET, DRIVE SHAFT HOUSING PLATE	27-183076
34	WASHER, POWER HEAD STUD	12-20553
35	NUT, POWER HEAD STUD	11-69254
36	DIFFUSER (175)	17303T1
36	EXH. EXTENSION (200)	879288T71	41942 4
37	GASKET, EXHAUST EXTENSION	27-782461
38	BOOT, IDLE EXHAUST	814618
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)
-	GASKET SET Comment: (175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (175)

Driveshaft Housing

Below is the parts list for Mercury V-200XRI (EFI) Driveshaft Housing:

Position No.	Part Name	OEM Number	Supersedes
1	DRIVESHAFT HOUSING (BLACK)(LONG)	1590-8343T10
1	DRIVESHAFT HOUSING (GRAY)(LONG)	1590-8343T11
1	DRIVESHAFT HOUSING (BLACK) (X-LONG)	3503-813563T1
1	DRIVESHAFT HOUSING (GRAY)(X-LONG)	3503-813563T2
2	STUD, (.437 x 2.69), DRIVE SHAFT HSG./GEAR HSG.	16-56295
3	BUMPER, LOWER MOUNT SCREW	25067
4	SCREW, (.500-20 x 6.00), LOWER MOUNT	10-898831	10-63474
5	MOUNT, LOWER (LONG)	78249
5	MOUNT (X-LONG) (USE ON XR4/MAGNUM II)	77327
6	WASHER, (.8125), LOWER MOUNT SCREW	12-49339
7	NUT, LOWER MOUNT SCREW	11-25096
8	GROUND WIRE ASSEMBLY	88238A10
9	CLAMP, LOWER MOUNT	54-8M0036782	54-67076
10	SCREW, (.312-18 x 1.250), LOWER MOUNT CLAMP ATTACHING	10-66727
11	COVER, LOWER MOUNT CLAMP (BLACK)	100-8M4500752	8M0001130, 67077T
11	COVER, LOWER MOUNT CLAMP (GRAY)	67077F1
12	SCREW, (#12-24 x .620), COVER ATTACHING	10-88417
13	NUT, NYLON - COVER TO CLAMP SCREW	11-35521
14	GROUND WIRE ASSEMBLY	88238A10
15	SCREW, (.250-20 x .500), GROUND WIRE	10-41508
16	WASHER, GEAR HOUSING STUD	12-48926
17	NUT, GEAR HOUSING STUD (CAP)	11-29489
18	WASHER, (.453 x .812 x .105), GEAR HOUSING STUD	12-45176
19	NUT, (.437-20), GEAR HOUSING STUD	11-8M0204653
20	PLUG, DRIVE SHAFT HOUSING	19-64649
21	EXHAUST TUBE	18276T
22	SEAL, EXHAUST TUBE - LOWER	66350001
23	SEAL, EXHAUST TUBE - UPPER	8M0039076	17726 1
24	TUBE, WATER (LONG)	32-8M0042788	32-859097 1
24	TUBE, WATER (X-LONG)	32-8M0042790	32-859097 2
25	GASKET, DRIVE SHAFT HOUSING TO PLATE	27-991734
26	PLATE ASSEMBLY, DRIVE SHAFT HOUSING	18233A20
27	SEAL, BRACKET	8M0043165	814701 2
28	BRACKET, SEAL RETAINING	68011
29	SCREW, (#10-16 x .500), BRACKET TO PLATE	10-878608	10-812832
30	PIN, Dowel, LOCATING	17-43044
31	SEAL, WATER TUBE	26-38970
32	SCREW, (.250-20 x .750), EXTENSION TO PLATE	10-90192
33	GASKET	27-183076
34	WASHER, POWER HEAD STUD	12-20553
35	NUT, POWER HEAD STUD	11-69254
36	DIFFUSER (XR4/MAGNUM II)	17303T1
36	EXH. EXTENSION (135/150/175/200)	879288T71	41942 4
37	GASKET, EXHAUST EXTENSION	27-782461
38	BOOT, IDLE EXHAUST	814618
-	GASKET SET Comment: (135/150)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (135/150)
-	GASKET SET Comment: (XR4/Magnum II/175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (XR4/Magnum II/175)
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)

Dual Engine Extension Kit

Below is the parts list for Mercury V-200XRI (EFI) Dual Engine Extension Kit:

Position No.	Part Name	OEM Number	Supersedes
-	DUAL ENGINE EXTENSION KIT	92876A9
1	SEAL KIT	19624A1
2	TUBE-CABLE GUIDE, CABLE GUIDE	71565
3	MOUNT	41055A1
4	TAB WASHER	14-42100
5	NUT, (.875-14)	11-8M0041651	11-37984
6	TAB WASHER	88404
7	SCREW, (.250-28 x 1.250)	10-38601
8	BRACKET	17729A1
9	SCREW, (.3125-24 x 1.25)	10-62055
10	TAB WASHER	17728
11	SCREW, (.375-24 x 1.25)	10-849838	10-14000
12	NUT, (.375-24)	11-8M0204726
13	STEERING EYE	97933A1
14	SLEEVE, (1.625)	23-23651
15	TUBING, (4.00 Inches)	97931
16	TUBE	8M0026098	814951 3
17	NUT, (.562-18)	11-42099

E.C.U. ASSEMBLY

Below is the parts list for Mercury V-200XRI (EFI) E.C.U. ASSEMBLY:

Position No.	Part Name	OEM Number	Supersedes
1	E.C.U. ASSEMBLY (175)	824003T14	824003A14, 824003 14
1	E.C.U. ASSEMBLY (200)	824003T16	824003A16, 14632A13
2	SPACER	23-34948
3	CLIP	54-146951
4	MOUNT, COWL MOUNTING BRACKET	90435
5	WASHER, MOUNT ATTACHING	12-21249
6	NUT, (.250-28), MOUNT ATTACHING	11-8267089
7	CABLE ASSEMBLY	84-88807A19
8	GROMMET	14637
9	BUSHING	23-14636
10	SCREW, (.250-20 x 1.00)	10-28667
11	LOCKWASHER, (.250)	13-26992
12	WASHER, (.265 x .750 x .048)	12-65567
13	WATER SENSOR MODULE ASSEMBLY	13202A2
14	CABLE ASSEMBLY (BLACK)	84-88807A18
15	SCREW, (.190-32 x .500), WATER SENSOR MODULE	10-37571
16	WASHER, (.203 x .406 x .040), WATER SENSOR MODULE SCREW	12-89302
17	WIRING HARNESS, E.C.U. AND INJECTORS	84-98866A14
18	CABLE (175)	84-87895A4

EXHAUST MANIFOLD AND EXHAUST PLATE

Below is the parts list for Mercury V-200XRI (EFI) EXHAUST MANIFOLD AND EXHAUST PLATE:

Position No.	Part Name	OEM Number	Supersedes
1	DIVIDER PLATE	19036T1
2	GASKET, DIVIDER PLATE	27-190503
3	SEAL, DIVIDER PLATE	26-814754	42838 1, 69668, 88726
4	CLAMP	54-814634
5	SCREW, (.312-18 x 1.375), DIVIDER PLATE	10-31984
5	SCREW, (.312-18 x .880), DIVIDER PLATE	10-53167T
6	TERMINAL BLOCK	86-194373
7	SCREW, (.250-20 x .750), TERMINAL BLOCK	10-90192
8	COVER, RELIEF VALVE	8M0039767	68729 1
9	NUT, , TERMINAL BLOCK	10-32,11-45076
10	CAPNUT, , TERMINAL BLOCK	10-32,11-813938
11	SCREW, (.312-18 x 1.250)	10-74824
12	GASKET, RELIEF VALVE PLATE	27-78690002
13	SCREW, (#10-16 x .750), DIAPHRAGM TO PLATE	10-69570
14	WASHER, DIAPHRAGM SCREW	12-76451
15	DIAPHRAGM	144791
16	WATER DEFLECTOR	16496
17	PLATE, RELIEF VALVE	16497A1
18	SPRING, COMPRESSION POPPET VALVE	24-64878
19	WASHER, POPPET SPRING	12-85303
20	POPPET, VALVE	14480
21	GROMMET, POPPET VALVE	25-64872
22	CARRIER, POPPET VALVE	65848
23	GASKET, EXHAUST PLATE	27-991764
24	EXHAUST PATE, EXHAUST	18260T2
26	PIN, Dowel, LOCATING - EXHAUST PLATE	17-43044
27	SEAL, EXHAUST PLATE	8M0043164	814701 1
28	BRACKET, SEAL RETAINING	680101
29	SCREW, (#10-16 x .500)	10-878608	10-812832
30	CONNECTOR, (.125-27) (STRAIGHT)	22-89772
32	GROMMET	25-12602002
33	GROMMET	25-8M0179867
34	BUSHING, EXHAUST PLATE	23-27132
35	SCREW, (.312-18 x 1.250)	10-66727
36	SCREW, (.312-18 x 2.50)	10-68783
37	SCREW, (.375-16 x 3.50)	10-898833	10-66725
38	BRACKET ASSEMBLY, FRONT	812905T	812905A 5
39	SCREW, (.312-18 x .625), FRONT BRACKET	10-90285
40	WASHER	12-187031
41	GROMMET	25-18778001
42	BRACKET ASSEMBLY, REAR	18578T09
43	FITTING, (.500-14)	22-8144301
44	FITTING, (.250-18) (90 Degree)	22-920071
45	FUEL LINE, (57.00 Inches Bulk)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
46	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
47	WASHER, POWERHEAD STUD	12-20553
48	NUT, POWERHEAD STUD	11-69254
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)
-	GASKET SET Comment: (175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (175)

Exhaust Manifold and Exhaust Plate

Below is the parts list for Mercury V-200XRI (EFI) Exhaust Manifold and Exhaust Plate:

Position No.	Part Name	OEM Number	Supersedes
1	GASKET, DIVIDER PLATE	27-190503
2	DIVIDER PLATE	19036T1
3	SEAL, DIVIDER PLATE	26-814754	42838 1, 69668, 88726
4	CLAMP	54-814634
5	SCREW, (.312-18 x 1.375), DIVIDER PLATE	10-31984
5	SCREW, (.312-18 x .880), DIVIDER PLATE	10-53167T
6	TERMINAL BLOCK (3 TERMINALS)	86-194373
7	SCREW, (.250-20 x .750), TERMINAL BLOCK	10-90192
8	COVER, RELIEF VALVE	8M0039767	68729 1
9	NUT, , TERMINAL BLOCK	10-32,11-45076
10	CAPNUT,	10-32,11-813938
11	SCREW, (.312-18 x 1.250), COVER TO CYLINDER BLOCK	10-74824
12	GASKET, RELIEF VALVE PLATE	27-78690002
13	SCREW, (#10-16 x .750), DIAPHRAGM TO PLATE	10-69570
14	WASHER, DIAPHRAGM SCREW	12-76451
15	DIAPHRAGM	144791
16	WATER DEFLECTOR	16496
17	PLATE, RELIEF VALVE	16497A1
18	SPRING, COMPRESSION POPPET VALVE	24-64878
19	WASHER, POPPET SPRING	12-85303
20	POPPET, VALVE	14480
21	GROMMET, POPPET VALVE	25-64872
22	CARRIER, POPPET VALVE	65848
23	GASKET, EXHAUST PLATE	27-991764
24	EXHAUST PLATE (W/STBD. SIDE FITTINGS)	18260A3
24	EXHAUST PATE (W/O FITTINGS)	18260T2
25	FITTING, (.250-18 Brass), EXHAUST PLATE (STARBOARD)	22-687271
26	PIN, Dowel	17-43044
27	SEAL, EXHAUST PLATE	8M0043164	814701 1
28	BRACKET, SEAL RETAINING	680101
29	SCREW, (#10-16 x .500), BRACKET TO EXHAUST PLATE	10-878608	10-812832
30	CONNECTOR, (.125-27) (STRAIGHT)	22-89772
31	HOSE, (24.500 Inches Bulk) (STARBOARD FITTINGS)	32-77653101
32	BUSHING, EXHAUST PLATE	23-27132
33	GROMMET	25-8M0179867
34	GROMMET, EXHAUST PLATE	25-12602002
35	SCREW, (.312-18 x 1.250), EXHAUST PLATE ATTACHING	10-66727
36	SCREW, (.312-18 x 2.50), EXHAUST PLATE ATTACHING	10-68783
37	SCREW, (.375-16 x 3.50), EXHAUST PLATE ATTACHING	10-898833	10-66725
38	BRACKET ASSEMBLY, FRONT	812905T	812905A 5
39	SCREW, (.312-18 x .625), FRONT BRACKET	10-90285
40	WASHER	12-187031
41	GROMMET	25-18778001
42	BRACKET ASSEMBLY, REAR	18578T09
43	FITTING, (.500-14)	22-8144301
44	FITTING, (.250-18) (90 DEG.)	22-920071
45	FUEL LINE, (57.00 Inches Bulk)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
46	CABLE TIE, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
47	WASHER, POWERHEAD STUD	12-20553
48	NUT, POWERHEAD STUD	11-69254
-	GASKET SET Comment: (135/150)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (135/150)
-	GASKET SET Comment: (XR4/Magnum II/175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (XR4/Magnum II/175)
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)

FLYWHEEL/STARTER MOTOR

Below is the parts list for Mercury V-200XRI (EFI) FLYWHEEL/STARTER MOTOR:

Position No.	Part Name	OEM Number	Supersedes
1	COVER KIT, FLYWHEEL	18896A1
2	MARKER, TIMING	79022
3	SCREW, (.190-32 x .380), TIMING MARKER	10-37572
4	WASHER, (.203 x .562 x .060), TIMING MARKER SCREW	12-72761
5	PLUG, FLYWHEEL COVER	19-89219001
6	PLUG, Yellow, FLYWHEEL	19-45907
7	NUT, (.625-18), FLYWHEEL	11-52901
8	WASHER, (.641 x 1.250 x .190), FLYWHEEL	12-33001
9	FLYWHEEL (OLD DESIGN)	271-859238T16	271-859238T 8
10	SCREW, (.250-28 x .625), FLYWHEEL PLATE (OLD DESIGN)	10-32417
11	SCREW, (.312-24 x .750), FLYWHEEL HUB (OLD DESIGN)	10-68997
12	STATOR	398-9610A5
13	SCREW, (#10-32 x 1.375), STATOR	10-90045
14	LOCKWASHER, , STATOR SCREW	10,13-26996
15	TRIGGER PLATE ASSEMBLY	96455A9
16	CABLE ASSEMBLY, Black	84-93388A1
17	STARTER MOTOR ASSEMBLY	50-893893	50-79472T 2, 50-79472 2
18	COLLAR, STARTER MOTOR	23-8M0034918	23-8M0001391, 56703
19	STOP, RUBBER - STARTER MOTOR	8M0043376	68042
20	LOCKWASHER, (.250), STARTER MOTOR TERMINAL	13-26992
21	NUT, (.250-20), STARTER MOTOR TERMINAL	11-20890
22	CABLE ASSEMBLY, Black	84-93388A14
23	SCREW AND LOCKWASHER, (.250-20 x .625) Stainless Steel, CABLE TO STARTER MOTOR	10-69035
24	FLYWHEEL (NEW DESIGN)	271-859238T16	271-859238T 8

FUEL MANAGEMENT SYSTEM

Below is the parts list for Mercury V-200XRI (EFI) FUEL MANAGEMENT SYSTEM:

Position No.	Part Name	OEM Number	Supersedes
1	FUEL MANAGEMENT ASSEMBLY	14817A19
2	ROLLER, CAM	67748
3	FUEL INJECTOR	18715T
4	FILTER, INJECTOR	35-17422
5	HARNESS KIT	84-15443
6	FUEL FILTER KIT	35-15442
7	FUEL FILTER	35-150282
8	SCREW, (M5 x 14), FILTER COVER	10-400034
9	LOCKWASHER, (M5), COVER SCREW	13-400255
10	HOSE (1/2" O.D.)	32-1350385
11	TUBING, (36.00 Inches Bulk) (1/8" I.D.)	32-9912688
12	TUBING, (20.00 Feet Bulk) (3/32" I.D.)	32-892024122	32-99130122
13	REGULATOR, PRESSURE	15027
14	ELBOW KIT	814233
15	GASKET, PRESSURE REGULATOR	27-18791
16	PLATE, PRESSURE REGULATOR	814012
17	SCREW	10-814076
18	COVER KIT	814010
19	SCREW, (M4 x 16), COVER TO SEPARATOR	10-4001987
20	LOCKWASHER, , COVER SCREW	8,13-26995
21	SEAL, VAPOR SEPARATOR	26-18790
22	O-RING AND SEAL KIT	15029
23	FLOAT VALVE KIT	15446
24	FLOAT KIT	15445
25	BODY KIT	814011
26	CHECK VALVE	21-424811
27	SCREW, (M6 x 35), SEPARATOR	10-4000332
28	LINK	15444
29	CHECK VALVE	21-18241
30	VALVE, Shut-Off	814077
31	SEAL, INJECTOR MANIFOLD	26-18792
32	SPACER	23-19275
34	SPACER	23-814913
35	WASHER, (.255 x .620 x .030) (LARGE)	12-35280
36	WASHER (SMALL)	12-69057
37	CLAMP, (15.7), HOSE	54-8M0214911
38	HOSE (1-3/4")	32-1350385
39	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
40	BLANKET, FUEL PUMP	14639
41	COVER, FUEL PUMP	14640T
42	SCREW, (#10-32 x .625)	10-32228
43	LOCKWASHER,	10,13-26996
44	SCREW, (.250-20 x 4)	10-845674	10-90088
45	WASHER, (.281 x .500 x .060)	12-8M0204649
46	FUEL PUMP	14307T01
47	HOSE	32-146332

FUEL PUMP AND FUEL FILTER

Below is the parts list for Mercury V-200XRI (EFI) FUEL PUMP AND FUEL FILTER:

Position No.	Part Name	OEM Number	Supersedes
1	FUEL PUMP ASSEMBLY	15930A15
2	DIAPHRAGM KIT	21-857005A1
3	NOT SOLD SEPARATE, Check Valve-Rubber	NSS
4	NOT SOLD SEPARATE, Gasket-Boost	NSS
5	NOT SOLD SEPARATE, Diaphragm	NSS
6	NOT SOLD SEPARATE, Gasket-Pulse	NSS
7	NOT SOLD SEPARATE, Spring	NSS
8	NOT SOLD SEPARATE, Cap	NSS
9	NOT SOLD SEPARATE, Check Valve	NSS
10	NOT SOLD SEPARATE, Retainer	NSS
11	NOT SOLD SEPARATE, Spring	NSS
12	NOT SOLD SEPARATE, Cap	NSS
13	GASKET, BASE	27-8M0204705
14	FITTING, FUEL PUMP (ELBOW)	22-14868
15	FITTING, Straight, FUEL PUMP	22-16604
16	TUBING	32-8M0108349	32-8M0047448, 32-830757130, 32-830757 80
17	BASE, FUEL PUMP	144303
18	PLATE, FUEL PUMP	987752
19	PLUG, Pipe (.0625-27)	22-56800
20	FITTING	22-15979
21	SCREW, (#12-24 x 2.00), FUEL PUMP	10-16452
22	SCREW, (M5 x 40), FUEL PUMP TO CRANKCASE	10-4000310
23	WASHER, FUEL PUMP SCREW	12-4002314
24	HOSE, PULSE	32-9072925
25	FITTING, PULSE HOSE (90 Degree)	22-997511
26	TUBING, (30 Inch Bulk)	32-1350385
27	TIE STRAP, (8.00 Inches), FUEL TUBING	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
28	CONNECTOR ASSEMBLY, Fuel	22-816856Q3
29	SCREW, (.250-20 x 1.375)	10-69067
30	SEAL	812782
31	BRACKET	813657
32	SCREW, (.250-20 x 1.375)	10-69067
33	SCREW, (.250-20 x .875), FUEL FILTER BASE	10-28668
34	BASE, FUEL FILTER	13170A3
35	FITTING, BASE	22-136071
36	FUEL FILTER ASSEMBLY	35-18458Q3
37	PROBE, WATER SENSING	14570
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)
-	GASKET SET Comment: (175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (175)

Flywheel/Starter Motor

Below is the parts list for Mercury V-200XRI (EFI) Flywheel/Starter Motor:

Position No.	Part Name	OEM Number	Supersedes
1	COVER KIT, FLYWHEEL	18896A1
2	COVER KIT (NON-LOUVERED)	79918A1
3	SCREW, (.190-32 x .380), TIMING MARKER	10-37572
4	WASHER, TIMING MARKER SCREW	12-72761
5	MARKER, TIMING	79022
6	PLUG, (Yellow), FLYWHEEL	19-45907
7	NUT, (.625-18), FLYWHEEL	11-52901
8	WASHER, FLYWHEEL	12-33001
9	FLYWHEEL (USE WITH REF. NO. 1) Comment: (WITH SCREWS)	271-859238T16	271-859238T 8 (WITH SCREWS)
9	FLYWHEEL (USE WITH REF. NO. 2) Comment: (WITH SCREWS)	271-859238A9
10	SCREW, (.250-28 x .625), FLYWHEEL PLATE Comment: (WITH SCREWS)	10-32417
11	SCREW, (.3125-24 X .75), FLYWHEEL HUB Comment: (WITH SCREWS)	10-68997
12	STATOR (40 AMP) Comment: (USE WITH REF. NO. 1)	398-9610A5
12	STATOR (16 AMP) Comment: (USE WITH REF. NO. 2 & 9)	398-5454A35
12	STATOR (16 AMP - SEE NOTE) Comment: (USE WITH REF. NO. 2 & 25)(398-9873A4 STATOR IS INCLUDED WITH 271-817632A9 FLYWHEEL)	398-9873A4
13	SCREW, (#10-32 x 1.375), STATOR Comment: (USE WITH REF. NO. 1)	10-90045
13	SCREW, STATOR Comment: (USE WITH REF. NO. 2 & 9)	10-90028
13	SCREW Comment: (USE WITH REF. NO. 2 & 25)	10-817044
14	LOCKWASHER, , STATOR SCREW Comment: (USE WITH REF. NO. 1)	10,13-26996
14	LOCKWASHER, Comment: (USE WITH REF. NO. 2 & 25)	10,13-26996
15	TRIGGER PLATE ASSEMBLY	96455A9
16	CABLE ASSEMBLY, Black	84-93388A1
17	STARTER MOTOR	50-893893	50-79472T 2, 50-79472 2
18	COLLAR, STARTER MOTOR	23-8M0034918	23-8M0001391, 56703
19	STOP, RUBBER - STARTER MOTOR	8M0043376	68042
20	LOCKWASHER, (.250), STARTER MOTOR TERMINAL	13-26992
21	NUT, (.250-20), STARTER MOTOR TERMINAL	11-20890
22	WIRE, (Black)	84-93388A14
23	SCREW AND LOCKWASHER, (.250-20 x .625) SS, CABLE TO STARTER MOTOR	10-69035
24	PLUG	19-89219001
25	FLYWHEEL (USE WITH REF. NO. 1) Comment: (WITHOUT SCREWS)	271-859238T16	271-859238T 8 (WITHOUT SCREWS)
25	FLYWHEEL (USE WITH REF. NO. 2) Comment: (WITHOUT SCREWS)	271-859238A9

Fuel Lines

Below is the parts list for Mercury V-200XRI (EFI) Fuel Lines:

Position No.	Part Name	OEM Number	Supersedes
1	FUEL CONNECTOR, Plastic	22-816856Q3
2	SCREW, (.25-20 X 1.375), FUEL CONNECTOR	10-69067
3	SEAL	812782
4	TUBING	32-8M0108349	32-8M0047448, 32-830757130, 32-830757 80
5	CABLE TIE, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
6	FITTING	22-814964	22-814964 1
7	FITTING (ELBOW)	22-19688
8	TUBING, (8.00 Inch)	32-82381335
9	FUEL LINE, (57.00 Inches Bulk)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
10	FILTER, Fuel	35-816296Q03	35-816296Q, 35-816296, 35-16494
11	GASKET	27-67751
12	STUD, (.250-28 x 1.125)	16-270372
13	J CLIP	54-8M0024808
14	SCREW, (.250-20 x .880)	10-55715
15	LOCKWASHER, (.250)	13-26992
16	NUT, (.250-28)	11-29598
17	HOSE, (26.00 Inches Bulk)	32-9912878
18	TUBING, (20.00 Feet Bulk)	32-892024122	32-99130122
19	ENRICHNER VALVE	42859A2
20	CLAMP	54-633001
21	SCREW, (.250-20 x .500)	10-73286
22	TUBING, (36.00 Inches Bulk)	32-9912688
23	TERMINAL BLOCK	86-45915
24	SCREW, (#10-16 x .500)	10-48408
24	SCREW, (.190-32 X .62)	10-38055
24	SCREW, (#10-16 x .375)	10-62568
24	SCREW, (#10-16 x .440)	10-69079
-	GASKET SET Comment: (135/150)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (135/150)
-	GASKET SET Comment: (XR4/Magnum II/175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (XR4/Magnum II/175)
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)

Fuel Pump

Below is the parts list for Mercury V-200XRI (EFI) Fuel Pump:

Position No.	Part Name	OEM Number	Supersedes
1	FUEL PUMP ASSEMBLY	15930A15
2	DIAPHRAGM KIT	21-857005A1
3	NOT SOLD SEPARATE, Check Valve, Rubber	NSS
4	NOT SOLD SEPARATE, Check Valve	NSS
5	NOT SOLD SEPARATE, Retainer	NSS
6	NOT SOLD SEPARATE, Gasket-Boost	NSS
7	NOT SOLD SEPARATE, Cap	NSS
8	NOT SOLD SEPARATE, Spring	NSS
9	NOT SOLD SEPARATE, Diaphragm	NSS
10	NOT SOLD SEPARATE, Gasket-Pulse	NSS
11	NOT SOLD SEPARATE, Spring	NSS
12	NOT SOLD SEPARATE, Cap	NSS
13	GASKET, BASE	27-8M0204705
14	BASE, FUEL PUMP	144303
15	PLATE, FUEL PUMP	987752
16	PLUG, Pipe (.0625-27)	22-56800
17	FITTING	22-15979
18	SCREW, (#12-24 x 2.00), FUEL PUMP	10-16452
19	SCREW, (M5 x 40), FUEL PUMP TO CRANKCASE	10-4000310
20	WASHER, FUEL PUMP SCREW	12-4002314
21	HOSE	32-9072925
22	FITTING, PULSE HOSE	22-997511
-	GASKET SET Comment: (135/150)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (135/150)
-	GASKET SET Comment: (XR4/Magnum II/175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (XR4/Magnum II/175)
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)

GEAR HOUSING(DRIVE SHAFT)(2.0:1)

Below is the parts list for Mercury V-200XRI (EFI) GEAR HOUSING(DRIVE SHAFT)(2.0:1):

Position No.	Part Name	OEM Number	Supersedes
-	GEAR HOUSING, STANDARD ROTATION 2:1 GEAR RATIO	1647-9148T87
1	GEAR HOUSING ASSEMBLY	1647-9148T47
2	CONNECTOR ASSEMLBY	22-85822A10
3	PIN, Dowel	17-43044
4	STUD, (.438 x 3.12) (LONG)	16-786382
4	STUD, (.438 x 3.69) (X-LONG)	16-8M0034464	16-18978 3
5	STUD, (.44 x 2.06)	16-8M0133358
6	STUD, (.312 x 3.38)	16-8M0034463	16-56297 2
7	STUD, (.250-20/.250-28 x 3.125)	16-306671
8	BEARING ASSEMBLY, Roller	31-42647A1
9	SLEEVE	23-43998
11	DRIVESHAFT (LONG)	45-897624T	45-44000 1
11	DRIVESHAFT (X-LONG)	45-897625T	45-44209 1
12	Not Sold Seperate, Pinion Gear (PART OF 43-44102A2) (#N.S.S.)
13	WASHER	12-92721
14	NUT, (.625-18)	11-35921
15	SHIM SET	15-42637A1
16	BEARING, Roller	31-8M0146566
17	NUT	8245191
18	WATER PUMP BASE ASSEMBLY	46-8M0077147	46-42579A 3
19	GASKET	27-8M0204678
20	O-RING, (2.175 x .175)	25-8M0142854
21	OIL SEAL	26-89238
22	OIL SEAL	26-16977
23	GASKET, LOWER	27-8M0090319	27-85608 1
24	GASKET, UPPER	27-858524	27-85609 1, 27-85609B 1
25	FACE PLATE	8M0204677
26	WATER PUMP BODY ASSEMBLY	46-96148T1
27	INSERT	48752T
28	SEAL, RUBBER	26-38970
29	IMPELLER	47-89984T4
30	KEY	28-8M0214992
31	SCREW, (#14-8 x 2.25)	10-8M0215009
32	WASHER, (.281 x .500 x .060)	12-8M0204649
33	NUT, (.250-28)	11-8267119
34	WASHER	12-36001
35	NUT	11-13436
36	RING (OLD DESIGN)	25-8M0214918
37	SLEEVE	23-29804T
38	SHAFT, LOWER	789022
39	E RING	53-29641
40	RETAINING RING (OLD DESIGN)	53-78907
41	O-RING, (.862 x .103)	25-25439
42	BUSHING ASSEMBLY	23-77631A2
43	OIL SEAL	26-8M0204708
44	WASHER, RUBBER	12-77674
45	SCREW, (.375-16 x .250), GREASE FILLER	10-79953Q04
46	SCREW, Magnetic, DRAIN	22-8M0058389	22-67892A06
47	WASHER, Fiber	12-191833
-	WATER PUMP REBUILD KIT	46-96148A8
-	SEAL KIT	26-89238A2
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)
-	GASKET SET Comment: (175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (175)

GEAR HOUSING(DRIVESHAFT)(1.87:1)

Below is the parts list for Mercury V-200XRI (EFI) GEAR HOUSING(DRIVESHAFT)(1.87:1):

Position No.	Part Name	OEM Number	Supersedes
-	GEAR HOUSING, STANDARD ROTATION 1.87:1 GEAR RATIO (BLACK)	1647-9148T84
-	GEAR HOUSING, STANDARD ROTATION 1.87:1 GEAR RATIO (GRAY)	1647-9148T84
1	GEAR HOUSING ASSEMBLY (BASIC - BLACK)	1647-9148T47
1	GEAR HOUSING ASSEMBLY (BASIC - GRAY)	1647-9148T47
2	CONNECTOR ASSEMLBY	22-85822A10
3	PIN, Dowel	17-43044
4	STUD, (.438 x 3.12)	16-786382
5	STUD, (.44 x 2.06)	16-8M0133358
6	STUD, (.312 x 3.38)	16-8M0034463	16-56297 2
7	STUD, (.250-20/.250-28 x 3.125)	16-306671
8	BEARING ASSEMBLY, Roller	31-42647A1
9	SLEEVE, LUBRICATION	23-43998
11	DRIVESHAFT	45-897624T	45-44000 1
12	Not Sold Seperate, Pinion Gear (PART OF 43-44104A2) (#N.S.S.)
13	WASHER	12-92721
14	NUT, (.625-18)	11-35921
15	SHIM SET	15-42637A1
16	BEARING, Roller	31-8M0146566
17	NUT	8245191
18	WATER PUMP BASE ASSEMBLY	46-8M0077147	46-42579A 3
19	GASKET	27-8M0204678
20	O-RING, (2.175 x .175)	25-8M0142854
21	OIL SEAL	26-89238
22	OIL SEAL	26-16977
23	GASKET (LOWER)	27-8M0090319	27-85608 1
24	GASKET (UPPER)	27-858524	27-85609 1, 27-85609B 1
25	FACE PLATE	8M0204677
26	WATER PUMP BODY ASSEMBLY	46-96148T1
27	INSERT	48752T
28	SEAL	26-38970
29	IMPELLER	47-89984T4
30	KEY	28-8M0214992
31	SCREW, (#14-8 x 2.25)	10-8M0215009
32	WASHER, (.281 x .500 x .060)	12-8M0204649
33	NUT, (.250-28)	11-8267119
34	WASHER	12-36001
35	NUT	11-13436
36	RING, RUBBER (DRIVE SHAFT) (OLD DESIGN)	25-8M0214918
37	SLEEVE	23-29804T
38	SHAFT, SHIFT LOWER	789022
39	E RING	53-29641
40	RETAINING RING (OLD DESIGN)	53-78907
41	O-RING, (.862 x .103)	25-25439
42	BUSHING ASSEMBLY	23-77631A2
43	OIL SEAL	26-8M0204708
44	WASHER, RUBBER	12-77674
45	SCREW, (.375-16 x .250), GREASE FILLER	10-79953Q04
46	SCREW, Magnetic, DRAIN	22-8M0058389	22-67892A06
47	WASHER, Fiber	12-191833
-	WATER PUMP REBUILD KIT	46-96148A8
-	SEAL KIT	26-89238A2
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)
-	GASKET SET Comment: (175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (175)

GEAR HOUSING(PROPELLER SHAFT)(1.87:1)

Below is the parts list for Mercury V-200XRI (EFI) GEAR HOUSING(PROPELLER SHAFT)(1.87:1):

Position No.	Part Name	OEM Number	Supersedes
-	GEAR HOUSING, STANDARD ROTATION 1.87:1 GEAR RATIO (BLACK)	1647-9148T84
-	GEAR HOUSING, STANDARD ROTATION 1.87:1 GEAR RATIO (GRAY)	1647-9148T84
1	GEAR HOUSING ASSEMBLY (BASIC - BLACK)	1647-9148T47
1	GEAR HOUSING ASSEMBLY (BASIC - GRAY)	1647-9148T47
48	SHIFT CAM	789562
49	FOLLOWER	89594A1
50	ROD	79911A1
51	SPRING	24-79910
52	WASHER	12-78910
53	PIN	17-8M0084245	17-78906
54	SHIM SET (.002-3-5-10)	15-47397A1
55	BEARING ASSEMBLY, Tapered Roller	31-78172A1
56	FORWARD GEAR ASSEMBLY	43-44104T2
57	BEARING, Roller (5/8")	31-73363T
57	BEARING, Roller (1")	31-549281
58	RATCHET	52-823174T	52-823174, 52-78959
59	PIN, Cross	17-8M0084243	17-78905
60	PIN, Detent	17-78909
61	SPRING	24-78962
62	PROPELLER SHAFT	44-94148
63	Not Sold Seperate, Reverse Gear (PART OF 43-44104A2) (#N.S.S.)
64	RING, Thrust	681001
65	BEARING, Ball	30-88957T
66	O-RING	25-8M0214920
67	CARRIER ASSEMBLY, Bearing	43567T1
68	BEARING, Needle	31-30956T
69	SEAL	26-8M0204670
70	KEY	28-30281
71	TAB WASHER	14-79447
72	RETAINER	8M2011027	79448
73	TRIM TAB ASSEMBLY	97-31640Q4
74	SCREW, (.437-14 x 1.75)	10-66024
75	FILLER BLOCK	8M0039169	67891
76	NUT, (.437-20)	11-8M0204653
77	SCREW, (.375-16 x 1.00)	10-65210
78	THRUST HUB	12-835467Q01	12-835467 1
79	WASHER, Splined	12-31211Q03
80	TAB WASHER	14-816629Q	14-816629, 14-31210, 14-816629B
81	NUT KIT, Propeller	11-52707Q1
82	LOCKWASHER, Toothed	13-423511
83	WASHER, (.453 x .812 x .105)	12-45176
-	SEAL KIT	26-89238A2
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)
-	GASKET SET Comment: (175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (175)

GEAR HOUSING(PROPELLER SHAFT)(2.0:1)

Below is the parts list for Mercury V-200XRI (EFI) GEAR HOUSING(PROPELLER SHAFT)(2.0:1):

Position No.	Part Name	OEM Number	Supersedes
-	GEAR HOUSING, STANDARD ROTATION 2:1 GEAR RATIO (Complete)	1647-9148T87
1	GEAR HOUSING ASSEMBLY (Basic)	1647-9148T47
48	SHIFT CAM	789562
49	FOLLOWER, CAM	89594A1
50	ROD, CLUTCH ACTUATOR	79911A1
51	SPRING, COMPRESSION	24-79910
52	WASHER, COMPRESSION SPRING	12-78910
53	PIN, SPRING LOCATOR	17-8M0084245	17-78906
54	SHIM SET, BEARING OUTER RACE (.002-3-5-10)	15-47397A1
55	BEARING ASSEMBLY, Tapered Roller	31-78172A1
56	FORWARD GEAR ASSEMBLY	43-44102A2
57	BEARING, Roller (5/8")	31-73363T
57	BEARING, Roller (1")	31-549281
58	RATCHET, SLIDING CLUTCH	52-823174T	52-823174, 52-78959
59	PIN, Cross, RATCHET TO PROPELLER SHAFT	17-8M0084243	17-78905
60	PIN, Detent, RATCHET	17-78909
61	SPRING, RETAINING-CROSS PIN	24-78962
62	PROPELLER SHAFT	44-94148
63	Not Sold Seperate, Reverse Gear (PART OF 43-44102A2) (#N.S.S.)
64	RING, THRUST - BEARING CARRIER	681001
65	BEARING, Ball, BALL - REVERSE GEAR	30-88957T
66	O-RING, BEARING CARRIER	25-8M0214920
67	CARRIER ASSEMBLY, Bearing	43567T1
68	BEARING, Needle, BEARING CARRIER	31-30956T
69	SEAL, BEARING CARRIER	26-8M0204670
70	KEY, LOCATING - BEARING CARRIER	28-30281
71	TAB WASHER, GEAR HOUSING COVER	14-79447
72	RETAINER, GEAR HOUSING	8M2011027	79448
73	TRIM TAB, GEAR HOUSING	97-31640Q4
74	SCREW, (.437-14 x 1.75), TRIM TAB TO GEAR HOUSING	10-66024
75	FILLER BLOCK	8M0039169	67891
76	NUT, (.437-20)	11-8M0204653
77	SCREW, (.375-16 x 1.00)	10-65210
77	SCREW, (.375-16 x 6.00)	10-74727
78	THRUST HUB	12-835467Q01	12-835467 1
79	WASHER, Splined	12-31211Q03
80	TAB WASHER	14-816629Q	14-816629, 14-31210, 14-816629B
81	NUT KIT, Propeller	11-52707Q1
82	LOCKWASHER	13-423511
83	WASHER, (.453 x .812 x .105)	12-45176
-	SEAL KIT	26-89238A2
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)
-	GASKET SET Comment: (175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (175)

Gear Housing(Drive-Standard/Counter Rotation)

Below is the parts list for Mercury V-200XRI (EFI) Gear Housing(Drive-Standard/Counter Rotation):

Position No.	Part Name	OEM Number	Supersedes
-	GEAR HOUSING (LONG) Comment: (Black 135/150)(Standard)	1647-9148T81
-	GEAR HOUSING (X-LONG) Comment: (Black 135/150)(Standard)	1647-9148T82
-	GEAR HOUSING (LONG) Comment: (Gray 135/150)(Standard)	1647-9148T87
-	GEAR HOUSING (X-LONG) Comment: (Gray 135/150)(Standard)	1647-9148T88
-	GEAR HOUSING BLACK Comment: (XR4)	1674-814247T3
-	GEAR HOUSING GRAY Comment: (Magnum II)	1674-814247T4
-	GEAR HOUSING BLACK Comment: (XR4)	1674-814247T3
-	GEAR HOUSING GRAY Comment: (Magnum II)	1674-814247T4
-	GEAR HOUSING (LONG) Comment: (Black 175/200)(Standard)	1647-9148T84
-	GEAR HOUSING ( X-LONG) Comment: (Black 175/200)(Standard)	1647-9148T85
-	GEAR HOUSING (LONG) Comment: (Gray 175/200)(Standard)	1647-9148T84
-	GEAR HOUSING (X-LONG) Comment: (Gray 175/200)(Standard)	1647-9148T91
-	GEAR HOUSING (X-LONG) Comment: (Black 135/150)(Counter Rotation)	1647-9148T83
-	GEAR HOUSING (X-LONG) Comment: (Gray 135/150)(Counter Rotation)	1647-9148T89
-	GEAR HOUSING (X-LONG) Comment: (Black 175/200)(Counter Rotation)	1647-9148T86
-	GEAR HOUSING (X-LONG) Comment: (Gray 175/200)(Counter Rotation)	1647-9148T92
1	GEAR HOUSING ASSEMBLY (BLACK-Basic) Comment: (135/150/175/200)	1647-9148T47
1	GEAR HOUSING ASSEMBLY (GRAY-Basic) Comment: (135/150/175/200)	1647-9148T47
1	GEAR HOUSING (BLACK-Basic) Comment: (XR4)	1674-814247T8
1	GEAR HOUSING, Basic Black Comment: (XR4)	1674-814247T1
1	GEAR HOUSING (GRAY-Basic) Comment: (Magnum II)	1674-814247T9
1	GEAR HOUSING , Basic Gray Comment: (Magnum II)	1674-814247T2
2	CONNECTOR ASSEMLBY	22-85822A10
3	PIN, Dowel	17-43044
4	STUD, (.438 x 3.12) (LONG)	16-786382
4	STUD, (.438 x 3.69) (X-LONG)	16-8M0034464	16-18978 3
5	STUD, (.44 x 2.06)	16-8M0133358
6	STUD, (.312 x 3.38)	16-8M0034463	16-56297 2
7	STUD, (.250-20/.250-28 x 3.125)	16-306671
8	BEARING ASSEMBLY, Roller Comment: (135/150/175/200)	31-42647A1
8	BEARING Comment: (XR4/Magnum II)	31-32898T
8	ROLLER BEARING Comment: (XR4/Magnum II)	31-35934A1
9	SLEEVE	23-43998
11	DRIVESHAFT (LONG) Comment: (135/150/175/200)	45-897624T	45-44000 1 (135/150/175/200)
11	DRIVESHAFT (Long) Comment: (XR4/Magnum II)	45-15298
11	DRIVESHAFT (X-LONG)(135/150/175/200)	45-897625T	45-44209 1
11	DRIVESHAFT (X-Long) Comment: (XR4/Magnum II)	45-815168
12	NOT SOLD SEPARATE, Pinion Gear (PART OF 43-44102A2) Comment: (135/150-Standard Rotation)	NSS
12	NOT SOLD SEPARATE, Pinion Gear (PART OF 43-16279A2) Comment: (XR4/Magnum II)	NSS
12	NOT SOLD SEPARATE, Pinion Gear (PART OF 43-44104A2) Comment: (175/200-Standard Rotation)	NSS
12	NOT SOLD SEPARATE, Pinion Gear (PART OF 43-18572A1) Comment: (135/150-Counter Rotation)	NSS
12	NOT SOLD SEPARATE, Pinion Gear (PART OF 43-18475A1) Comment: (175/200-Counter Rotation)	NSS
13	WASHER	12-92721
14	NUT, (.625-18)	11-35921
15	SHIM SET	15-42637A1
16	BEARING, Roller	31-8M0146566
17	NUT	8245191
18	WATER PUMP BASE ASSEMBLY	46-8M0077147	46-42579A 3
19	GASKET	27-8M0204678
20	O-RING, (2.175 x .175)	25-8M0142854
21	OIL SEAL	26-89238
22	OIL SEAL	26-16977
23	GASKET, LOWER	27-8M0090319	27-85608 1
24	GASKET, UPPER	27-858524	27-85609 1, 27-85609B 1
25	FACE PLATE	8M0204677
26	WATER PUMP BODY ASSEMBLY	46-96148T1
27	INSERT	48752T
28	SEAL, RUBBER	26-38970
29	IMPELLER	47-89984T4
30	KEY	28-8M0214992
31	SCREW, (#14-8 x 2.25)	10-8M0215009
32	WASHER, (.281 x .500 x .060)	12-8M0204649
33	NUT, (.250-28)	11-8267119
34	WASHER	12-36001
35	NUT	11-13436
36	RING (Use where Applicable)	25-8M0214918
37	SLEEVE	23-29804T
38	SHAFT Comment: (135/150/175/200)	789022
38	SHAFT Comment: (XR4/Magnum II)	15299
38	SHIFT SHAFT Comment: (XR4/Magnum II)	8152641
39	E-RING	53-29641
40	RETAINING RING (Use Where Applicable)	53-78907
41	O-RING, (.862 x .103)	25-25439
42	BUSHING ASSEMBLY	23-77631A2
43	OIL SEAL	26-8M0204708
44	WASHER, RUBBER	12-77674
45	SCREW, (.375-16 x .250), GREASE FILLER	10-79953Q04
46	SCREW, Magnetic, DRAIN	22-8M0058389	22-67892A06
47	WASHER, Fiber	12-191833
-	WATER PUMP REBUILD KIT	46-96148A8
-	SEAL KIT	26-89238A2
-	GASKET SET Comment: (135/150)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (135/150)
-	GASKET SET Comment: (XR4/Magnum II/175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (XR4/Magnum II/175)
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)

Gear Housing(Prop-Counter Rotation 135/150/175/200)

Below is the parts list for Mercury V-200XRI (EFI) Gear Housing(Prop-Counter Rotation 135/150/175/200):

Position No.	Part Name	OEM Number	Supersedes
-	GEAR HOUSING (X-LONG) Comment: (Black 135/150)	1647-9148T83
-	GEAR HOUSING (X-LONG) Comment: (Gray 135/150)	1647-9148T89
-	GEAR HOUSING (X-LONG)(BLACK) Comment: (Black 175/200)	1647-9148T86
-	GEAR HOUSING (X-LONG) Comment: (Gray 175/200)	1647-9148T92
1	GEAR HOUSING ASSEMBLY (BLACK)(BASIC)	1647-9148T47
1	GEAR HOUSING ASSEMBLY (GRAY)(BASIC)	1647-9148T47
47	SHIFT CAM	789562
48	FOLLOWER, CAM	89594A1
49	ROD, CLUTCH ACTUATOR	79911A1
50	SPRING, COMPRESSION	24-79910
51	WASHER, SPRING	12-78910
52	PIN, SPRING LOCATOR	17-8M0084245	17-78906
53	BEARING CUP	14469T
54	BEARING	30-88957T
55	NOT SOLD SEPARATE, Reverse Gear (PART OF 43-18572A1 or 43-18475A1)	NSS
56	BEARING ASSEMBLY, Roller	31-15844
57	PIN, Detent, RATCHET	17-78909
58	RATCHET, SLIDING CLUTCH	52-823174T	52-823174, 52-78959
59	PIN, Cross, RATCHET	17-8M0084243	17-78905
60	SPRING, RETAINING - CROSS PIN	24-78962
61	FORWARD GEAR Comment: (135/150)	43-18572T1
61	FORWARD GEAR Comment: (175/200)	43-18475T1
62	SPACER SHIM Comment: (.125)	23-176151
62	SPACER SHIM Comment: (.127)	23-176152
62	SPACER SHIM Comment: (.129)	23-176153
62	SPACER SHIM Comment: (.131)	23-176154
62	SPACER SHIM Comment: (.133)	23-176155
62	SPACER SHIM Comment: (.135)	23-176156
62	SPACER SHIM Comment: (.137)	23-176157
62	SPACER SHIM Comment: (.139)	23-176158
62	SPACER SHIM Comment: (.141)	23-176159
62	SPACER SHIM Comment: (.143)	23-1761510
62	SPACER SHIM Comment: (.145)	23-1761511
62	SPACER SHIM Comment: (.147)	23-1761512
62	SPACER SHIM Comment: (.149)	23-1761513
63	ROLLER BEARING	31-15841
64	THRUST RING	12-17616
65	O-RING, BEARING CARRIER	25-8M0214920
66	BEARING ADAPTOR	18447T2
67	ROLLER BEARING	31-15843T
68	THRUST WASHER	12-18448
69	BEARING, Thrust	31-15842
70	PROPELLER SHAFT	44-18446
71	BEARING CARRIER	818896T2
72	ROLLER BEARING, BEARING CARRIER	31-30956T
73	SEAL	26-8M0204670
74	TAB WASHER, GEAR HOUSING COVER	14-79447
75	RETAINER, GEAR HOUSING	8M2011027	79448
76	KEY, LOCATING - BEARING CARRIER	28-30281
77	TRIM TAB ASSEMBLY, GEAR HOUSING	97-31640Q4
78	SCREW, (.437-14 x 1.75), TRIM TAB TO GEAR HOUSING	10-66024
79	FILLER BLOCK	8M0039169	67891
80	WASHER, (.453 x .812 x .105), DRIVE SHAFT HOUSING STUDS	12-45176
81	NUT, (.437-20), DRIVE SHAFT HOUSING STUDS	11-8M0204653
82	THRUST HUB	12-835467Q01	12-835467 1
83	WASHER, Splined, PROPELLER NUT	12-31211Q03
84	TAB WASHER, PROPELLER NUT	14-816629Q	14-816629, 14-31210, 14-816629B
85	NUT, Propeller	11-52707Q1
86	LOCKWASHER, Toothed, PROPELLER SHAFT	13-423511
87	SCREW, (.375-16 x 1.00), GEAR HOUSING	10-65210
-	SEAL KIT	26-89238A2

Gear Housing(Prop-Standard Rotation135/150/175/200)

Below is the parts list for Mercury V-200XRI (EFI) Gear Housing(Prop-Standard Rotation135/150/175/200):

Position No.	Part Name	OEM Number	Supersedes
-	GEAR HOUSING (LONG) (BLACK) Comment: (135/150)	1647-9148T81
-	GEAR HOUSING (X-LONG)(BLACK) Comment: (135/150)	1647-9148T82
-	GEAR HOUSING (LONG)(GRAY) Comment: (135/150)	1647-9148T87
-	GEAR HOUSING (X-LONG) (GRAY) Comment: (135/150)	1647-9148T88
-	GEAR HOUSING (LONG)(BLACK) Comment: (175/200)	1647-9148T84
-	GEAR HOUSING (X-LONG)(BLACK) Comment: (175/200)	1647-9148T85
-	GEAR HOUSING (LONG)(GRAY) Comment: (175/200)	1647-9148T84
-	GEAR HOUSING (X-LONG)(GRAY) Comment: (175/200)	1647-9148T91
1	GEAR HOUSING ASSEMBLY (BLACK)(BASIC)	1647-9148T47
1	GEAR HOUSING ASSEMBLY (GRAY) (BASIC)	1647-9148T47
48	SHIFT CAM	789562
49	FOLLOWER, CAM	89594A1
50	ROD, CLUTCH ACTUATOR	79911A1
51	SPRING, COMPRESSION	24-79910
52	WASHER, COMPRESSION SPRING	12-78910
53	PIN, SPRING LOCATOR	17-8M0084245	17-78906
54	SHIM SET, BEARING OUTER RACE (.002-3-5-10)	15-47397A1
55	BEARING ASSEMBLY, Tapered Roller	31-78172A1
56	FORWARD GEAR ASSEMBLY Comment: (135/150)	43-44102A2
56	FORWARD GEAR ASSEMBLY Comment: (175/200)	43-44104T2
57	ROLLER BEARING (5/8")	31-73363T
57	ROLLER BEARING (1")	31-549281
58	RATCHET, SLIDING CLUTCH	52-823174T	52-823174, 52-78959
59	PIN, Cross, RATCHET TO PROPELLER SHAFT	17-8M0084243	17-78905
60	PIN, Detent, RATCHET	17-78909
61	SPRING, RETAINING-CROSS PIN	24-78962
62	PROPELLER SHAFT	44-94148
63	NOT SOLD SEPARATE, Reverse Gear (Part of 43-44102A2 or 43-44104A2)	NSS
64	RING, Thrust, BEARING CARRIER	681001
65	BEARING, BALL - REVERSE GEAR	30-88957T
66	O-RING, BEARING CARRIER	25-8M0214920
67	BEARING CARRIER ASSEMBLY	43567T1
68	ROLLER BEARING, BEARING CARRIER	31-30956T
69	SEAL, BEARING CARRIER	26-8M0204670
70	KEY, LOCATING - BEARING CARRIER	28-30281
71	TAB WASHER, GEAR HOUSING COVER	14-79447
72	RETAINER, GEAR HOUSING	8M2011027	79448
73	TRIM TAB ASSEMBLY, GEAR HOUSING	97-31640Q4
74	SCREW, (.437-14 x 1.75), TRIM TAB TO GEAR HOUSING	10-66024
75	FILLER BLOCK	8M0039169	67891
76	NUT, (.437-20)	11-8M0204653
77	SCREW, (.375-16 x 1.00)	10-65210
77	SCREW, (.375-16 X 6.00)	10-74727
78	THRUST HUB	12-835467Q01	12-835467 1
79	WASHER, Splined	12-31211Q03
80	TAB WASHER	14-816629Q	14-816629, 14-31210, 14-816629B
81	NUT, Propeller	11-52707Q1
82	LOCKWASHER, Toothed	13-423511
83	WASHER, (.453 x .812 x .105)	12-45176
-	SEAL KIT	26-89238A2
-	GASKET SET Comment: (135/150)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (135/150)
-	GASKET SET Comment: (XR4/Magnum II/175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (XR4/Magnum II/175)
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)

Gear Housing(Propshaft)(XR4/Magnum II)

Below is the parts list for Mercury V-200XRI (EFI) Gear Housing(Propshaft)(XR4/Magnum II):

Position No.	Part Name	OEM Number	Supersedes
-	GEAR HOUSING BLACK Comment: COMPLETE	1674-814247T3
-	GEAR HOUSING GRAY Comment: COMPLETE	1674-814247T4
-	GEAR HOUSING BLACK Comment: COMPLETE	1674-814247T3
-	GEAR HOUSING GRAY Comment: COMPLETE	1674-814247T4
1	GEAR HOUSING (BLACK) Comment: BASIC	1674-814247T8
1	GEAR HOUSING (GRAY) Comment: BASIC	1674-814247T9
1	GEAR HOUSING, Basic Black	1674-814247T1
1	GEAR HOUSING , Basic Gray	1674-814247T2
44	SHIFT CAM	760394
45	CAM FOLLOWER ASSEMBLY	850315A1
46	SPRING, COMPRESSION - CAM FOLLOWER	24-30622
47	SHIM SET	15-44491A1
48	BEARING SET, Cup And Cone	31-30894A1
49	FORWARD GEAR	43-16279A2
50	ROLLER BEARING	31-30895T
51	CLUTCH	52-822539T	52-822539, 52-814756, 52-12777
52	PIN, Cross	17-8M0100263	17-8M0084681, 17-8M0020941, 17-30632
53	SPRING	24-30893
54	PROPELLER SHAFT	44-12238T
55	NOT SOLD SEPARATE, Reverse Gear (Part of 43-16279A2)	NSS
56	THRUST WASHER, BEARING CARRIER	12-76358
57	O-RING, BEARING CARRIER	25-29976
58	BEARING CARRIER ASSEMBLY	41529T2
59	FITTING, Grease	22-8M0169588
60	ROLLER BEARING, BEARING CARRIER	31-30956T
61	SEAL	26-8M0204670
62	KEY, LOCATING - BEARING CARRIER	28-30281
63	TAB WASHER, GEAR HOUSING COVER	14-52700
64	COVER, GEAR HOUSING	52699
65	FILLER BLOCK	8M0039169	67891
66	SCREW, (.375-16 x 1.00) (SOCKET HEAD)	10-30206
66	SCREW, (.375-16 x 1.00) (HEX HEAD)	10-65210
68	TAB WASHER, PROPELLER NUT	14-816629Q	14-816629, 14-31210, 14-816629B
69	NUT, Propeller	11-52707Q1
70	TRIM TAB	97-15300
71	SCREW, ANODIC PLATE	10-15797
70	TRIM TAB ASSEMBLY	97-31640Q4
71	SCREW, (.437-14 x 1.75)	10-66024
72	WASHER, (.453 x .812 x .105), DRIVE SHAFT HOUSING STUDS	12-45176
73	NUT, (.437-20), DRIVE SHAFT HOUSING STUDS	11-8M0204653
74	THRUST HUB AND WASHER ASSEMBLY	13191Q01
-	SEAL KIT	26-89238A2
-	GASKET SET Comment: (135/150)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (135/150)
-	GASKET SET Comment: (XR4/Magnum II/175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (XR4/Magnum II/175)
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)

IGNITION COIL/VOLTAGE REGULATOR

Below is the parts list for Mercury V-200XRI (EFI) IGNITION COIL/VOLTAGE REGULATOR:

Position No.	Part Name	OEM Number	Supersedes
1	PLATE, MOUNTING	195872
2	SCREW, VOLTAGE REGULATOR	10-99263
3	LOCKWASHER, (.250)	13-26992
4	SPACER	23-19661A1
5	VOLTAGE REGULATOR	18736A21
6	SEAL	18717
7	SOLENOID, Starter	8M0185622
7	SOLENOID (OFF WHITE)	89-8M0185144
8	SCREW, (.250-20 x .620), STARTER SOLENOID	10-31716
9	CABLE ASSEMBLY, (3.50 Inches) Black	84-88807A6
10	NUT, (.250-20), SOLENOID SCREW	11-8267098
11	NUT, Brass, SOLENOID TERMINAL	8-32,11-26419
12	NUT, (.250-20) Brass, SOLENOID TERMINAL	11-94330
13	HARNESS ASSEMBLY (#2, 4 AND 6)	84-69739A7
14	WIRE ASSEMBLY, (2.750 Inches) (RED)	84-87379A14
14	CABLE ASSEMBLY, (3.50 Inches) Black	84-88807A8
15	CABLE ASSEMBLY (9" - BLACK)	84-88807A29
16	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
17	COVER, IGNITION COIL	43542
18	IGNITION COIL ASSEMBLY	339-832757A4
19	SCREW, (#10-32 x 2.125), IGNITION COIL COVER	10-90048
20	NUT, , COVER SCREW/GROUND WIRE	10-32,11-90078
21	CABLE KIT, HIGH TENSION	84-813715A9
22	BOOT/TERMINAL KIT, HIGH TENSION CABLE	85-63709A1
23	SPARK PLUG (NGK #BU8H)	33-13686Q
24	NUT, , IGNITION COIL TERMINAL	10-32,11-45076
25	CABLE ASSEMBLY (5-1/2" - BLACK)	84-88807A13
26	SCREW, (#10-32 x .500), GROUNDING WIRE	10-69022
27	COVER, COIL PLATE	814423T
28	SCREW, (#10-32 x 2.380), COVER	10-814343
29	INSULATOR	85-97861

Ignition Coil/Voltage Regulator

Below is the parts list for Mercury V-200XRI (EFI) Ignition Coil/Voltage Regulator:

Position No.	Part Name	OEM Number	Supersedes
1	PLATE, MOUNTING	195872
2	BUSHING Comment: (OLD DESIGN)	23-19661
2	SPACER Comment: (NEW DESIGN)	23-19661A1
3	SCREW, (.250-20 x 2.25) Comment: (OLD DESIGN)	10-30720
3	SCREW, (.250-20 x 1.500) SS Comment: (OLD DESIGN)	10-86885
3	SCREW (2-3/8") Comment: (NEW DESIGN)	10-99263
3	SCREW, (.25-20 X 1.375) Comment: (NEW DESIGN)	10-69067
4	LOCKWASHER, (.250)	13-26992
5	VOLTAGE REGULATOR	18736A21
6	SEAL	18717
7	SOLENOID STARTER	8M0185622
7	SOLENOID (OFF WHITE)	89-8M0185144
8	SCREW, (.250-20 x .62), STARTER SOLENOID	10-31716
9	WIRE, (3.50 Inches) Black	84-88807A6
10	NUT, (.250-20), SOLENOID SCREW	11-8267098
11	NUT, , SOLENOID TERMINAL	8-32,11-26419
12	NUT, (.250-20), SOLENOID TERMINAL	11-94330
13	SCREW, (#10-16 x .625), CABLE	10-48409
14	WIRE ASSEMBLY, (Black- 3.5 Inches)	84-88807A8
15	CABLE	84-88807A29
16	CABLE TIE, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
17	COVER, IGNITION COIL	43542
18	IGNITION COIL ASSEMBLY	339-832757A4
19	SCREW, (#10-32 x 2.125), IGNITION COIL COVER	10-90048
20	NUT, , COVER SCREW/GROUND WIRE	10-32,11-90078
21	CABLE KIT, HIGH TENSION	84-813715A9
22	BOOT KIT, HIGH TENSION CABLE	85-63709A1
23	SPARK PLUG (NGK #BU8H)	33-13686Q
24	NUT, , IGNITION COIL TERMINAL	10-32,11-45076
25	CABLE ASSEMBLY	84-88807A13
26	SCREW, (#10-32 x .500), GROUNDING WIRE	10-69022
27	HARNESS ASSEMBLY (# 2,4 & 6)	84-69738A9
27	HARNESS ASSEMBLY (# 1,3 & 5)	84-69739A6
28	COVER, COIL PLATE	814423T
29	SCREW, (#10-32 x 2.380), COIL PLATE COVER	10-814343
30	COVER	19380
31	GASKET	27-193901
32	VOLTAGE REGUALTOR	88825A7
33	SCREW, (#10-16 x .625)	10-48409
34	NUT,	10-32,11-45076
35	HARNESS ASSEMBLY	84-13397A1
36	INSULATOR	85-97861

Instrumentation

Below is the parts list for Mercury V-200XRI (EFI) Instrumentation:

Position No.	Part Name	OEM Number	Supersedes
1	TACHOMETER	79-895283Q43	79-825348A 1
2	BRACKET, MOUNTING	79101T
3	LIGHT BULB	88-72729
4	SOCKET, Light Bulb	88-79888
5	NUT,	8-32,11-26419
6	HARNESS ASSEMBLY, Tachometer (5.00 Feet)	84-86396A8
7	TEMPERATURE GAUGE	79-895287Q41	79-825326A 1
8	LIGHT BULB	88-72729
9	SOCKET, Light Bulb	88-79888
10	WASHER	12-26427
11	BRACKET	79480
12	NUT,	8-32,11-26419
13	CABLE ASSEMBLY, (2.00 Feet - Purple)	84-86323A2
13	CABLE ASSEMBLY, (17.00 Inches-Black)	84-61600A16
13	CABLE ASSEMBLY, (45.00 Inches-Tan)	84-88824A4
14	SYNCHRONIZER GAUGE Comment: (COUNTER ROTATION ENGINES)	79-895294Q41	79-825342A 2 (COUNTER ROTATION ENGINES)
15	BRACKET Comment: (COUNTER ROTATION ENGINES)	79480
16	NUT, Comment: (COUNTER ROTATION ENGINES)	8-32,11-26419
17	LIGHT BULB Comment: (COUNTER ROTATION ENGINES)	88-72729
18	SOCKET, Light Bulb Comment: (COUNTER ROTATION ENGINES)	88-79888
19	DRIVER, SYNCHRONIZER Comment: (COUNTER ROTATION ENGINES)	145022
20	SWITCH ASSEMBLY, Lanyard Comment: (COUNTER ROTATION ENGINES)	87-19674A1
21	SCREW, (.190-16 x 1.750) Comment: (COUNTER ROTATION ENGINES)	10-18303
22	ADAPTER Comment: (COUNTER ROTATION ENGINES)	813679	12051 (COUNTER ROTATION ENGINES)
23	LANYARD ASSEMBLY Comment: (COUNTER ROTATION ENGINES)	15920Q54
24	SCREW, (#10-32 x 2.00) Comment: (COUNTER ROTATION ENGINES)	10-32866
25	CLAMP, Mounting Comment: (COUNTER ROTATION ENGINES)	18321
26	WASHER, (.200 x .440 x .032) Comment: (COUNTER ROTATION ENGINES)	12-24676
27	NUT, Comment: (COUNTER ROTATION ENGINES)	10-32,11-68219
28	RETAINER Comment: (COUNTER ROTATION ENGINES)	79146
29	CABLE TIE, (8.00 Inches) Comment: (COUNTER ROTATION ENGINES)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275 (COUNTER ROTATION ENGINES)
30	DIODE ASSEMBLY Comment: (COUNTER ROTATION ENGINES)	812497A2
31	CABLE ASSEMBLY, (6.00 Inches) Comment: (COUNTER ROTATION ENGINES)	84-11149A2
31	CABLE ASSEMBLY (3") Comment: (COUNTER ROTATION ENGINES)	84-11149A3

Key Switch Assembly

Below is the parts list for Mercury V-200XRI (EFI) Key Switch Assembly:

Position No.	Part Name	OEM Number	Supersedes
1	KEY SWITCH ASSEMBLY (20")	84-816626A20	84-17925A20
2	COVER ASSEMBLY, Key	90468A1
3	BRACKET	76424
4	STUD, (#10-32 x 2.00)	16-55422
5	WASHER, (.200 x .440 x .032)	12-24676
6	NUT,	10-32,11-68219
7	PLATE	816479A3
8	KEY SWITCH (SEE CHART FOR KEY)	87-88107A5
9	NUT, Special	11-879755	11-93543
10	INSERT	38-90311
11	ALARM HORN AND WIRE ASSEMBLY	68878A6
12	COVER	68879
13	SPACER, (.375)	23-8127111
13	SPACER, (.250)	23-812711
NS	KEY, Ignition (1A)	894911
NS	KEY, Ignition (2A)	894917
NS	KEY, Ignition (1B)	894912
NS	KEY, Ignition (2B)	894918
NS	KEY, Ignition (1C)	894913
NS	KEY, Ignition (2C)	894919
NS	KEY, Ignition (1D)	894914
NS	KEY, Ignition (2D)	8949110
NS	KEY, Ignition (1E)	894915
NS	KEY, Ignition (2E)	8949111
NS	KEY, Ignition (1F)	894916
NS	KEY, Ignition (2F)	8949112

OIL INJECTION COMPONENTS

Below is the parts list for Mercury V-200XRI (EFI) OIL INJECTION COMPONENTS:

Position No.	Part Name	OEM Number	Supersedes
1	SENSOR ASSEMBLY	12430A4
2	SCREW, (#10-16 x .625), SENSOR ATTACHING	10-48409
3	OIL PUMP (175)	815698T	815698, 41032
3	PUMP ASSEMBLY, Oil (200)	815699T	815699, 41033
4	O-RING, OIL PUMP	25-11379
5	BEARING ASSEMBLY, DRIVE GEAR	23-41429A2
6	GEAR, Driven	43-14563
7	SCREW, (#10-32 x .625), OIL PUMP TO CRANKCASE	10-32228
7	SCREW, (#10-32 x 1.120), OIL PUMP TO CRANKCASE	10-41507
8	LINK ASSEMBLY, THROTTLE LEVER TO OIL PUMP	1938512
9	TUBING, (8.00 Inch), OIL PUMP	32-82381335
10	OIL RESERVOIR	994436
11	CLAMP, OIL HOSE	54-415823
12	TUBING, OIL RESERVOIR TO OIL PUMP	32-82381455
13	SCREW, (#10-32 x .875), OIL RESERVOIR ATTACHING	10-690201
14	WASHER, OIL RESERVOIR SCREW	12-42118
15	GROMMET, OIL RESERVOIR SCREW	25-42117
16	BUSHING, OIL RESERVOIR SCREW	23-42116
17	FUEL LINE, (57.00 Inches Bulk)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
18	TEE, OIL TUBING	22-42425
19	HOSE, OIL (6-3/4")	32-9072925
20	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
21	HOSE, (114.00 Inches), OIL	32-99439
22	CLAMP	54-415824
24	FITTING, CHECK VALVE (CRANKCASE)	21-8781051
25	TANK	1257-87421
26	CAP ASSEMBLY, OIL TANK	36-43298A2
27	O-RING, (2.225 x .210), CAP	25-11332
28	HOUSING ASSEMBLY, Adapter	816190A4
29	O-RING, (2.225 x .210), ADAPTOR HOUSING	25-11332
30	TUBE, OIL PICK-UP	32-99802
31	CAP ASSEMBLY, OIL RESERVOIR	36-43300A9
32	GASKET, RESERVOIR CAP	27-43307T
33	FLOAT ASSEMBLY	8M0187298
34	PUSHNUT	11-99265

Oil Injection Components

Below is the parts list for Mercury V-200XRI (EFI) Oil Injection Components:

Position No.	Part Name	OEM Number	Supersedes
1	SENSOR ASSEMBLY	12430A4
2	SCREW, (#10-16 x .625), SENSOR ATTACHING	10-48409
3	WARNING MODULE ASSEMBLY	41470A26
4	WASHER, WARNING MODULE SCREW	12-38833
5	SCREW, (#10-32 x .875)	10-690201
6	OIL PUMP (135/150/XR4/MAGNUM II/175)	815698T	815698, 41032
6	OIL PUMP ASSEMBLY (200)	815699T	815699, 41033
7	BUSHING, Worm	8141032
8	O-RING	25-11379
9	BEARING ASSEMBLY, DRIVE GEAR	23-41429A2
10	DRIVEN GEAR	43-14563
12	SCREW, WARNING MODULE LEAD	10-42813
13	SCREW, (#10-32 x .625)	10-32228
13	SCREW, (#10-32 x 1.120)	10-41507
14	TANK	1257-87421
15	CAP ASSEMBLY, OIL TANK	36-43298A2
16	O-RING, CAP	25-11332
17	ADAPTOR HOUSING ASSEMBLY Comment: (Old Design)	816190A4
17	HOUSING ASSEMBLY, Adapter Comment: (New Design)	816190A4
18	O-RING, ADAPTOR HOUSING	25-11332
19	TUBE, OIL PICK-UP	32-99802
20	No Longer Available, Quick Disconnect Kit (Order parts Separately)	NLA
21	HOSE, (114.00 Inches), OIL Comment: (Old Design)	32-99439
21	HOSE, (114.00 Inches) Comment: (New Design)	32-99439
22	HOUSING Comment: (Old Design)	12540A3
23	LATCH Comment: (Old Design)	12242A1
24	FITTING, CHECK VALVE (CRANKCASE)	21-8781051
25	OIL RESERVOIR	994436
26	SCREW, (#10-32 x .875), OIL RESERVOIR ATTACHING	10-690201
27	WASHER, OIL RESERVOIR SCREW	12-42118
28	GROMMET, OIL RESERVOIR SCREW	25-42117
29	BUSHING, OIL RESERVOIR SCREW	23-42116
30	TUBING, OIL RESERVOIR TO OIL PUMP (5-1/4")	32-82381455
31	CAP ASSEMBLY, OIL RESERVOIR	36-43300A9
32	GASKET, RESERVOIR CAP	27-43307T
33	FLOAT ASSEMBLY	8M0187298
34	PUSHNUT	11-99265
35	CLAMP, OIL HOSE	54-415824
36	CLAMP, OIL HOSE	54-415823
37	FUEL LINE, (57.00 Inches Bulk), OIL	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
38	TEE, OIL TUBING	22-42425
39	HOSE, OIL (6-3/4")	32-9072925
40	FUEL LINE, (57.00 Inches Bulk)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
41	CABLE TIE, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
42	LINK, THROTTLE LEVER TO OIL PUMP	1938516
43	BRACKET KIT	12335A1
44	CORD/HOOK KIT	12323A1

POWER TRIM COMPONENTS

Below is the parts list for Mercury V-200XRI (EFI) POWER TRIM COMPONENTS:

Position No.	Part Name	OEM Number	Supersedes
1	MANIFOLD ASSEMBLY (BLACK)	99659A21
1	MANIFOLD ASSEMBLY (GRAY)	99659A22
2	PIPE PLUG, MANIFOLD	22-56800
3	TRIM CYLINDER ASSEMBLY (BLACK)	41493A7
3	TRIM CYLINDER ASSEMBLY (GRAY)	41493A7
3A	GUIDE KIT	811600
4	GUIDE ASSEMBLY	41492A1
5	REPAIR KIT	25-41478A1
6	CHECK VALVE KIT	41482A2
7	GUIDE ASSEMBLY, TRIM ROD	1100-8M0021648	878243A 1
8	PISTON AND ROD ASSEMBLY (PORT)	878413A1
9	TRIM FILTER ASSEMBLY	35-12184A1
10	PISTON AND ROD ASSEMBLY (STARBOARD)	878414T01	878414A 1
11	PIN, Groove, TRIM CYLINDER (UPPER)	17-821539	17-13794, 17-19603
12	VALVE ASSEMBLY	893929A01	813442A 2
12A	E RING	53-815949001	53-812844, 53-835104
13	SCREW, (M6 x 14), COVER	10-4000327
14	WASHER, COVER SCREW	12-4002315
15	COVER, MANIFOLD	99642
16	O-RING KIT	25-48462A4
17	PLUG ASSEMBLY	19-99609A1
18	SHAFT ASSEMBLY	99641A1
19	PIPE PLUG, SHAFT	22-56800
20	SCREW, (M6 x 20), PUMP AND MOTOR	10-4008820
21	LOCKWASHER, (M6)	13-400256
22	PUMP AND MOTOR	826729A10	826729A09, 826729A08, 826729A07, 826729A 4
23	SHAFT, UPPER	99625002
24	ANODE ASSEMBLY	97-818298Q1
25	SCREW, (M6 x 25), ANODE	10-8M0204707
26	WASHER, (.281 x .500 x .060), ANODE SCREW	12-8M0204649
27	STRIKER PLATE, TRIM SHAFT	8M0045383	99630 1
28	LOCKWASHER, (.375)	13-58643
29	NUT, (.375-24)	11-46335
30	CONTROL HARNESS, POWER TRIM	84-814609A1
31	CABLE (6-7/8" - RED)	84-88808A22
32	CLIP, PUMP WIRE	54-22875
33	C WASHER, CLIP SCREW	8M0084613	69205
34	SCREW, (#10-16 x .440), CLIP TO TRANSOM BRACKET	10-69079
35	PIN, Groove, TRIM CYLINDER (LOWER)	17-878267	17-44431
36	SCREW, (M10 x 30), MANIFOLD	10-4000377
37	LOCKWASHER, Stainless Steel, MANIFOLD SCREW	13-400258

POWER TRIM PUMP

Below is the parts list for Mercury V-200XRI (EFI) POWER TRIM PUMP:

Position No.	Part Name	OEM Number	Supersedes
-	PUMP AND MOTOR	826729A10	826729A09, 826729A08, 826729A07, 826729A 4
1	FRAME AND FIELD KIT	12659
2	BRUSH SPRING KIT	12665
3	BRUSH CARD KIT	13506
4	PUMP AND END FRAME KIT	12662
5	PUMP SEAL KIT	126631
6	END FRAME KIT	12660
7	ARMATURE KIT	12661
8	THRU BOLT KIT	12664

Power Steering Components

Below is the parts list for Mercury V-200XRI (EFI) Power Steering Components:

Position No.	Part Name	OEM Number	Supersedes
1	MOUNT	17771
2	SCREW, (.250-28 x .875)	10-59702
3	TAB WASHER	88404
4	SEAL KIT	19624A1
5	TUBE-CABLE GUIDE	71565
6	COUPLING	17776
7	SCREW, (.375-24 x 2.75)	10-817040
8	WASHER, (.406 x .734 x .063) SS	12-34931
9	SCREW	10-856722	10-90092
10	NUT, (.375-24)	11-8M0204726
11	TAB WASHER	14-42100
12	NUT, (.875-14)	11-8M0041651	11-37984
13	ACCUMULATOR	811290	811288
14	BRACKET	817372
15	SCREW, (.250-10 x 1.25)	10-16862
16	WASHER, (.281 x .500 x .060)	12-8M0204649
17	SCREW, (M10 x 70)	10-4000383
18	WASHER	12-4002319
19	NUT, (M10)	11-40140
20	ACTUATOR	828588A2
21	SCREW, (.375-24 x 1.5)	10-94319
22	SPACER	23-17405
23	NUT, (.375-24)	11-8M0204726
24	SCREW, (.375-24 x 1.25)	10-849838	10-14000
25	LINK ROD	92876A4
26	WASHER	12-68300
27	SCREW, (M6 x 25)	10-8M0204707
28	WASHER	12-4002315
29	NUT, (M6)	11-401386
30	CLAMP	811292
31	SCREW	10-818182
32	NUT, (M5 X 0.8)	11-400263
33	BRACKET	811291
34	SCREW, (.250-28 x 1.250)	10-38601
35	CLAMP	54-197491
36	RELAY SWITCH	87-18211
37	HARNESS ASSEMBLY	84-18244A1
38	SCREW, (10-32 x .75)	10-18124
39	GROMMET	25-90329
40	SPACER	23-309772
41	BRACKET	816994
42	WASHER	12-42118
43	NUT,	10-32,11-8M0204718
44	DECAL	37-81563024

Power Trim Components(Design I)

Below is the parts list for Mercury V-200XRI (EFI) Power Trim Components(Design I):

Position No.	Part Name	OEM Number	Supersedes
1	MANIFOLD ASSEMBLY (BLACK)	99659A21
1	MANIFOLD ASSEMBLY (GRAY)	99659A22
2	PIPE PLUG, MANIFOLD	22-56800
3	TRIM CYLINDER ASSEMBLY (BLACK)	41493A7
3	TRIM CYLINDER ASSEMBLY (GRAY)	41493A7
3A	GUIDE KIT	811600
4	GUIDE ASSEMBLY	41492A1
5	REPAIR KIT	25-41478A1
6	CHECK VALVE KIT	41482A2
7	GUIDE ASSEMBLY, TRIM ROD	1100-8M0021648	878243A 1
8	PISTON AND ROD ASSEMBLY, PORT	878413A1
9	TRIM FILTER ASSEMBLY	35-12184A1
10	PISTON AND ROD ASSEMBLY, STARBOARD	878414T01	878414A 1
11	PIN, Groove, TRIM CYLINDER (UPPER - W/O HEAD)	17-821539	17-13794, 17-19603
11	PIN, Groove (W/ HEAD)	17-821539	17-13794, 17-19603
12	VALVE ASSEMBLY	893929A01	813442A 2
12A	E RING	53-815949001	53-812844, 53-835104
13	SCREW, (M6 x 14), COVER	10-4000327
14	WASHER, COVER SCREW	12-4002315
15	COVER, MANIFOLD	99642
16	O-RING KIT	25-48462A4
17	PLUG ASSEMBLY	19-99609A1
18	SHAFT ASSEMBLY	99641A1
19	PIPE PLUG, SHAFT	22-56800
20	SCREW, (M6 x 20), PUMP AND MOTOR	10-4008820
21	LOCKWASHER, (M6)	13-400256
22	PUMP AND MOTOR	826729A10	826729A09, 826729A08, 826729A07, 826729A 4
23	SHAFT, UPPER	99625002
24	ANODE ASSEMBLY	97-818298Q1
25	SCREW, (M6 x 25), ANODE	10-8M0204707
26	WASHER, (.281 x .500 x .060), ANODE SCREW	12-8M0204649
27	STRIKER PLATE, TRIM SHAFT	8M0045383	99630 1
28	LOCKWASHER, (.375)	13-58643
29	NUT, (.375-24)	11-46335
30	CONTROL HARNESS, POWER TRIM	84-814609A1
31	CABLE (6-3/8" - RED)	84-88808A22
31	CABLE (24" - RED)	84-88808A23
31	WIRE ASSEMBLY, (2.750 Inches) (RED)	84-87379A14
32	CLIP, PUMP WIRE	54-22875
33	C WASHER, CLIP SCREW	8M0084613	69205
34	SCREW, (#10-16 x .440), CLIP TO TRANSOM BRACKET	10-69079
35	PIN, Groove, TRIM CYLINDER (LOWER)	17-878267	17-44431
36	SCREW, (M10 x 30), MANIFOLD	10-4000377
37	LOCKWASHER, SS, MANIFOLD SCREW	13-400258

Power Trim Components(Design II)

Below is the parts list for Mercury V-200XRI (EFI) Power Trim Components(Design II):

Position No.	Part Name	OEM Number	Supersedes
-	POWER TRIM ASSEMBLY, COMPLETE	826729A10	826729A09, 826729A08, 826729A07, 826729A 4
1	MANIFOLD ASSEMBLY	811604F	811604T
2	PIPE PLUG	22-56800
3	TILT CYLINDER ASSEMBLY	880952A03	880952A02, 880952A 1
4	PISTON ROD (BOLT TYPE)	811608
5	PISTON ROD (NUT TYPE)	823553T	823553, 811609
6	GUIDE KIT	878239A02	878239A 1
7	REPAIR KIT	811607A1
8	CHECK VALVE KIT	811610A1
9	GUIDE ASSEMBLY	1100-8M0021648	878243A 1
10	PISTON AND ROD ASSEMBLY (PORT)	878413A1
10	PISTON AND ROD ASSEMBLY (STARBOARD)	878414T01	878414A 1
11	TRIM FILTER ASSEMBLY	35-12184A1
12	PIN, Groove	17-821539	17-13794, 17-19603
13	VALVE ASSEMBY	893929A01	813442A 2
14	E RING	53-815949001	53-812844, 53-835104
15	SCREW, (M6 x 14)	10-4000327
16	WASHER	12-4002315
17	COVER	811611
18	O-RING KIT	811612A3
19	PLUG ASSEMBLY	19-811613
20	SHAFT ASSEMBLY	8M0142997
21	PIPE PLUG	22-56800
22	TRIM MOTOR	878265A6
23	SCREW (LONG)	10-811615
23	SCREW (SHORT)	10-811616
24	PUMP	811617T1
25	DRIVESHAFT	811619
26	SHAFT	99625002
27	ANODE ASSEMBLY	97-818298Q1
28	SCREW, (M6 x 25)	10-8M0204707
29	WASHER, (.281 x .500 x .060)	12-8M0204649
30	STRIKER PLATE	8M0045383	99630 1
31	LOCKWASHER, (.375)	13-58643
32	NUT, (.375-24)	11-46335
33	PIN, Groove	17-878267	17-44431
34	CONTROL HARNESS, POWER TRIM	84-814609A1
35	CABLE (6-3/8" - RED)	84-88808A22
35	CABLE (24" - RED)	84-88808A23
35	WIRE ASSEMBLY, (2.750 Inches)	84-87379A14
36	CLIP, PUMP WIRE	54-22875
37	C WASHER, CLIP SCREW	8M0084613	69205
38	SCREW, (#10-16 x .440), CLIP TO TRANSOM BRACKET	10-69079
39	SCREW, (M10 x 30), MANIFOLD	10-4000377
40	LOCKWASHER, SS, MANIFOLD SCREW	13-400258

Power Trim Motor(Use With Design II Power Trim System)

Below is the parts list for Mercury V-200XRI (EFI) Power Trim Motor(Use With Design II Power Trim System):

Position No.	Part Name	OEM Number
-	TRIM MOTOR	878265A6
1	FRAME AND FIELD KIT	811624
2	BRUSH CARD KIT	811625
3	END FRAME KIT	811623
4	SEAL KIT	811626
5	ARMATURE KIT	811627

Power Trim Pump(Use With Design I Power Trim Pump)

Below is the parts list for Mercury V-200XRI (EFI) Power Trim Pump(Use With Design I Power Trim Pump):

Position No.	Part Name	OEM Number	Supersedes
-	PUMP AND MOTOR	826729A10	826729A09, 826729A08, 826729A07, 826729A 4
1	FRAME AND FIELD KIT	12659
2	BRUSH SPRING KIT	12665
3	BRUSH CARD KIT	13506
4	PUMP AND END FRAME KIT	12662
5	PUMP SEAL KIT	126631
6	END FRAME KIT	12660
7	ARMATURE KIT	12661
8	THRU BOLT KIT	12664

REED BLOCK AND CYLINDER HEAD

Below is the parts list for Mercury V-200XRI (EFI) REED BLOCK AND CYLINDER HEAD:

Position No.	Part Name	OEM Number	Supersedes
1	CYLINDER HEAD (175)	18789F1
1	CYLINDER HEAD (200)	18488F2
2	GASKET (175)	27-18786T
2	GASKET (200)	27-822844T05	27-822844T04, 27-822844 1, 27-822844004
3	SCREW, (.375-16 x 2.30), CYLINDER HEAD Comment: (QTY. OF 24 ON 175)	10-98534
3	SCREW, (.375-16 x 2.30) (SPECIAL - 200)	10-13450
4	WASHER, (.406 x .812 x .065), CYLINDER HEAD SCREW	12-25909
5	THERMOSTAT	75692
6	GASKET, THERMOSTAT	27-8M0204714
7	COVER KIT, THERMOSTAT	90390A1
8	SCREW, (.312-18 x 1.00), THERMOSTAT COVER	10-35386
9	FITTING, (.250-18) 90 Degree - Brass, ELBOW - WATER HOSES	22-687271
10	HOSE, (24.500 Inches Bulk), WATER DISTRIBUTION	32-77653101
11	FITTING, THERMOSTAT COVER	22-68728
12	TIE STRAP, (8.00 Inches), WATER HOSES	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
13	PIN, Dowel (.250 x .625)	17-63779
14	RETAINER, SENSOR AND SENDER	137151
15	SCREW, (.312-18 x .500), RETAINER	10-98257
16	SCREW, (.250-20 x .750) (175)	10-92160
16	SCREW, (.250-20 x 1.125) (175)	10-90197
16	SCREW, (.250-20 x .875), REED BLOCK ATTACHING (200)	10-28668
17	GASKET, ADAPTOR PLATE	27-167371
18	ADAPTOR PLATE (175)	17735A2
18	PLATE ASSEMBLY (200)	12124A3
19	REED CLAMP (175)	961832
19	REED CLAMP (200)	903911
20	GASKET (175)	27-146972
20	GASKET (200)	27-883775	27-881034, 27-813859
21	REED BLOCK (175)	75953
21	REED BLOCK (200)	87692
22	REED ASSEMBLY (175)	34-75362A1
22	REED ASSEMBLY (200)	34-19719A1
23	SCREW, (.250-20 x .875), ADAPTOR PLATE	10-28668
24	SCREW, (8-32 x .187), REEDS TO REED BLOCK Comment: (QTY. OF 60 ON 175)	10-823588	10-14783, 10-18308 (QTY. OF 60 ON 175)
25	DETONATION SENSOR (200)	825164A1
26	TEMPERATURE SENDER (STARBOARD)	97465
27	TEMPERATURE SENSOR (PORT)	13536A6
28	NUT, (200)	10-32,11-45076
29	J CLIP (200)	54-8M0024808
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)
-	GASKET SET Comment: (175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (175)

Reed Block and Cylinder Head

Below is the parts list for Mercury V-200XRI (EFI) Reed Block and Cylinder Head:

Position No.	Part Name	OEM Number	Supersedes
1	CYLINDER HEAD Comment: (135/150)	18787A18
1	CYLINDER HEAD Comment: (XR4/MAGNUM II/175)	18789F1
1	CYLINDER HEAD Comment: (200)	18488F2
2	GASKET Comment: (135/150)(Component of Powerhead)(Head Gasket not included in Engine Gasket Set)	27-18785T
2	GASKET Comment: (XR4/MAGNUM II/175)(Component of Powerhead)(Head Gasket not included in Engine Gasket Set)	27-18786T
2	GASKET Comment: (20)(Component of Powerhead)(Head Gasket not included in Engine Gasket Set)	27-822844T05	27-822844T04, 27-822844 1, 27-822844004 (20)(Component of Powerhead)(Head Gasket not included in Engine Gasket Set)
3	SCREW, (.375-16 X 2.30)	10-98534
4	WASHER, (.406 x .812 x .065)	12-25909
5	GASKET	27-8M0204714
6	COVER KIT	90390A1
7	THERMOSTAT	75692
8	SCREW, (.312-18 x 1.00)	10-35386
9	FITTING, (.250-18 Brass)	22-687271
10	HOSE, (24.500 Inches Bulk)	32-77653101
11	FITTING	22-68728
12	CABLE TIE, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
13	TEMPERATURE SENDER (STBD.)	97465
14	ADAPTOR PLATE (135/150/XR4/MAGNUM II/175)	43517A9
14	ADAPTOR PLATE (200)	87628A7
15	SCREW, (.250-20 x .875)	10-28668
16	GASKET (135/150/XR4/MAGNUM II/175)	27-146972
16	GASKET (200)	27-883775	27-881034, 27-813859
17	PIN, Dowel (3/4")	17-63779
17	PIN, Dowel (.250 x .625)	17-63779
18	REED BLOCK Comment: (135/150/MAGNUM II/175)	75953
18	REED BLOCK Comment: (200)	87692
19	REED ASSEMBLY Comment: (135/150/MAGNUM II/175)	34-75362A1
19	REED ASSEMBLY Comment: (200)	34-19719A1
20	REED CLAMP Comment: (135/150/MAGNUM II/175)	961832
20	REED CLAMP Comment: (200)	903911
21	SCREW, (8-32 x .187) (QTY. OF 84 ON 200)	10-823588	10-14783, 10-18308
22	SCREW, (.250-20 x .75) Comment: (135/150/MAGNUM II)	10-92160
23	SCREW, (.250-20 x 2.00) Comment: (135/150/MAGNUM II)	10-96529
22/23	SCREW, (.250-20 x .875) Comment: (200)	10-28668
24	THERMAL AIR VALVE	814612
25	CLIP (9/16")	54-23567
25	CLAMP (1")	54-26404
26	C WASHER	8M0084613	69205
27	SCREW, (#10-16 x .440)	10-69079
28	TEMPERATURE SENSOR (PORT)	13536A7
29	RETAINER	137151
30	SCREW, (.312-18 x .500)	10-98257
31	FITTING, Press-In	22-56759
32	TUBING, (20.00 Feet Bulk)	32-892024122	32-99130122
33	CHECK VALVE (PRESS-IN 13/16")	21-426982
33	CHECK VALVE (PRESS-IN 11/16")	21-426233
34	FITTING (PRESS-IN)	22-15133
-	GASKET SET Comment: (135/150)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (135/150)
-	GASKET SET Comment: (XR4/Magnum II/175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (XR4/Magnum II/175)
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)

STARTER MOTOR ASSEMBLY

Below is the parts list for Mercury V-200XRI (EFI) STARTER MOTOR ASSEMBLY:

Position No.	Part Name	OEM Number	Supersedes
-	STARTER MOTOR ASSEMBLY	50-893893	50-79472T 2, 50-79472 2
1	DRIVE KIT	90645
2	PINION ASSEMBLY, Drive	13310T1
3	PLATE, DRIVE END	75660
4	BOLT, THRU	10-74968
6	Not Sold Seperate, Washer (#N.S.S.) Comment: (AMERICAN BOSCH #WA31 22)
7	ARMATURE	79216
8	BRUSH/SPRING KIT	898265016	75384, 75384 1
9	HOLDER, BRUSH	898265014	61787
10	Not Sold Seperate, Screw (#N.S.S.) Comment: (AMER. BOSCH #02441-22-SC-30SM)
11	END CAP, COMMUTATOR	15386001

SWIVEL BRACKET AND STEERING ARM

Below is the parts list for Mercury V-200XRI (EFI) SWIVEL BRACKET AND STEERING ARM:

Position No.	Part Name	OEM Number	Supersedes
1	SWIVEL BERACKET ASSEMBLY (BLACK)	1499-8M0102865	1499-8710T20
1	SWIVEL BRACKET ASSEMBLY (GRAY)	1499-8710T21
2	SEAL, Oil, SWIVEL BRACKET (LOWER)	26-87735
3	BUSHING, SWIVEL BRACKET (LOWER AND UPPER)	23-818764	23-67669
4	O-RING, SWIVEL BRACKET (UPPER)	25-8M0214926
5	SPACER, SWIVEL BRACKET (UPPER)	23-816039
6	FITTING, Grease	22-8M0169589
7	BUSHING, SWIVEL BRACKET	23-821207	23-99608
8	SWIVEL PIN AND STEERING ARM (BLACK)	17-67706A55
8	SWIVEL PIN AND STEERING ARM (GRAY)	17-67706A55
9	SCREW, (.437-20 x 7.50), STEERING ARM TO UPPER MOUNT	10-8M0176309
10	MOUNT, RUBBER (UPPER)	78687T
11	WASHER, UPPER MOUNT BOLT	12-66921
12	WASHER, UPPER MOUNT BOLT	12-78688
13	NUT, (.437-20), UPPER MOUNT BOLT	11-8M0204653
14	LINK ASSEMBLY, Steering	92876A12
15	SCREW, (.375-24 x 1.25), STEERING LINK TO STEERING ARM	10-849838	10-14000
16	NUT, (.375-24), STEERING LINK SCREW	11-8M0204726
17	WASHER, (.406 x .734 x .063) Stainless Steel, STEERING LINK TO STEERING ARM	12-34931
19	BOTTOM YOKE (BLACK)	86580A1
19	BOTTOM YOKE (GRAY)	86580A1
20	RING, Retaining, BOTTOM YOKE	53-67684
21	THRUST WASHER, THRUST - SWIVEL BRACKET	12-816432
22	BUMPER, Top Yoke	88882
23	SCREW, (.250-28 x .500), SWIVEL BRACKET	10-64014
24	J CLIP	54-54457
25	TRIM SENDER ASSEMBLY	8M0074846	821180A 6
26	SCREW, (#10-24 x .750)	10-852368	10-56682
27	LOCKWASHER,	10,13-26996
28	WASHER, (.203 x .406 x .040)	12-89302
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)
-	GASKET SET Comment: (175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (175)

Service/Support Material

Below is the parts list for Mercury V-200XRI (EFI) Service/Support Material:

Position No.	Part Name	OEM Number	Supersedes
-	PARTS MANUAL, 135 / 150 / 175 200(2.5L) XR4/MAGNUM II	90-81609890
-	SERVICE MANUAL	90-8162491
-	GASKET SET (135/150) Comment: (Cylinder head gasket no longer part of Gasket Set)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (Cylinder head gasket no longer part of Gasket Set)
-	GASKET SET (175/XR4/MAGNUM II) Comment: (Cylinder head gasket no longer part of Gasket Set)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (Cylinder head gasket no longer part of Gasket Set)
-	GASKET SET (200) Comment: (Cylinder head gasket no longer part of Gasket Set)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (Cylinder head gasket no longer part of Gasket Set)
-	DECAL SET (BLACK 135/150/175)	37-813220A89
-	DECAL SET (XR4)	37-813031A89
-	DECAL SET (BLACK 200 LONG)	37-812563A94
-	DECAL SET (BLACK 200 XL/CXL)	37-808562A94
-	DECAL SET (MAGNUM II)	37-813034A91	37-813034A90, 37-813034A89
-	DECAL SET (GRAY 135)	37-813036A92	37-813035A90, 37-813036A89, 37-813036A90, 37-813035A89
-	DECAL SET (GRAY 150)	37-813036A92	37-813035A90, 37-813036A89, 37-813036A90, 37-813035A89
-	DECAL SET (GRAY 175)	37-813037A94	37-813037A92, 37-813037A90, 37-813037A89
-	DECAL SET (GRAY 200)	37-815630A90
-	OWNERS MANUAL (BLACK 135/150/175/200)	90-11143912
-	OWNERS MANUAL (GRAY 135/150/175/200)	90-11142912
-	OWNERS MANUAL (XR4)	90-17746912
-	OWNERS MANUAL (MAGNUM II)	90-17747912
-	PARTS MANUAL, 175 XRI /175 MAGNUM 200 XRI (EFI)	90-81741890
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)
-	GASKET SET Comment: (175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (175)
-	DECAL SET (175/200 - BLACK)	37-812563A93	37-812563A90
-	DECAL SET (175 - GRAY)	37-813033A93	37-813033A92, 37-813033A91, 37-813033A89
-	OWNER'S GUIDE (BLACK)	90-13492912
-	OWNER'S GUIDE (GRAY)	90-19592911

Starter Motor Assembly

Below is the parts list for Mercury V-200XRI (EFI) Starter Motor Assembly:

Position No.	Part Name	OEM Number	Supersedes
-	STARTER MOTOR	50-893893	50-79472T 2, 50-79472 2
1	DRIVE KIT	90645
2	DRIVE	13310T1
3	PLATE	75660
4	BOLT	10-74968
6	NOT SOLD SEPARATE, Washer (AMERICAN BOSCH # WA3122)	NSS
7	ARMATURE	79216
8	BRUSH/SPRING KIT	898265016	75384, 75384 1
9	HOLDER	898265014	61787
10	NOT SOLD SEPARATE, Screw (AMER. BOSCH # 02441-22-SC-30SM)	NSS
11	END CAP	15386001

Steering Attaching Kit(XR4/ Magnum II)

Below is the parts list for Mercury V-200XRI (EFI) Steering Attaching Kit(XR4/ Magnum II):

Position No.	Part Name	OEM Number	Supersedes
-	STEERING ATTACHING KIT (SINGLE)	92876A8
1	MOUNT, STEERING TUBE	41055
2	COUPLING, STEERING LINK	850791T	850791, 88319
3	SCREW, (.375-24 x 1.120), COUPLING	10-73732
4	NUT, (.375-24), COUPLING SCREW	11-8M0204726
5	SCREW, (.250-28 x .875), MOUNT ATTACHING	10-59702
6	TAB WASHER, MOUNT SCREW	88404
7	TUBE-CABLE GUIDE, STEERING	71565
8	NUT, (.875-14), STEERING TUBE	11-8M0041651	11-37984
9	TAB WASHER, STEERING TUBE NUT	14-42100
10	SEAL KIT	19624A1
11	SPACER	42101

Swivel Bracket(Casting #1499-8710-6)

Below is the parts list for Mercury V-200XRI (EFI) Swivel Bracket(Casting #1499-8710-6):

Position No.	Part Name	OEM Number	Supersedes
1	SWIVEL BRACKET ASSEMBLY (BLACK)	1499-8M0102865	1499-8710T20
1	SWIVEL BRACKET ASSEMBLY (GRAY)	1499-8710T21
2	SEAL, Oil, SWIVEL BRACKET (LOWER)	26-87735
3	BUSHING, SWIVEL BRACKET-LOWER AND UPPER	23-818764	23-67669
4	O-RING, UPPER	25-33466
5	SPACER, UPPER	23-67668
6	FITTING, Grease	22-8M0169589
7	BUSHING, SWIVEL BRACKET	23-821207	23-99608
8	SWIVEL PIN AND STEERING ARM (BLACK)	17-67706A55
8	SWIVEL PIN AND STEERING ARM (GRAY)	17-67706A55
9	SCREW, (.437-20 x 7.50), STEERING ARM TO UPPER MOUNT	10-8M0176309
10	MOUNT, RUBBER-UPPER (LONG)	78687T
10	MOUNT (X-LONG) (USE ON XR4/MAGNUM II)	77326
11	WASHER, UPPER MOUNT BOLT	12-66921
12	WASHER, UPPER MOUNT BOLT	12-78688
13	NUT, (.437-20), UPPER MOUNT BOLT	11-8M0204653
14	STEERING LINK ASSEMBLY	92876A12
15	SCREW, (.375-24 x 1.25), STEERING LINK TO STEERING ARM	10-849838	10-14000
16	NUT, (.375-24), STEERING LINK SCREW	11-8M0204726
17	WASHER, (.406 x .734 x .063) SS, STEERING LINK TO STEERING ARM	12-34931
18	WAVE WASHER, BOTTOM YOKE	13-78854
19	BOTTOM YOKE (BLACK)	86580A1
19	BOTTOM YOKE (GRAY)	86580A1
20	RETAINING RING, BOTTOM YOKE	53-67684
21	WASHER	12-67670
22	BUMPER, TOP YOKE	88882
23	SCREW, (.250-28 x .500), SWIVEL BRACKET	10-64014
24	J CLIP	54-54457
-	GASKET SET Comment: (135/150)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (135/150)
-	GASKET SET Comment: (XR4/Magnum II/175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (XR4/Magnum II/175)
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)

Swivel Bracket(Casting #1499-8710-7)

Below is the parts list for Mercury V-200XRI (EFI) Swivel Bracket(Casting #1499-8710-7):

Position No.	Part Name	OEM Number	Supersedes
1	SWIVEL BERACKET ASSEMBLY (BLACK)	1499-8M0102865	1499-8710T20
1	SWIVEL BRACKET ASSEMBLY (GRAY)	1499-8710T21
2	SEAL, Oil, SWIVEL BRACKET (LOWER)	26-87735
3	BUSHING, SWIVEL BRACKET-LOWER AND UPPER	23-818764	23-67669
4	SPACER	23-816039
5	O-RING	25-8M0214926
6	FITTING, Grease	22-8M0169589
7	BUSHING, SWIVEL BRACKET	23-821207	23-99608
8	THRUST WASHER,	12-816432
9	SCREW, (.437-20 x 7.50), STEERING ARM TO UPPER MOUNT	10-8M0176309
10	MOUNT, RUBBER-UPPER (LONG)	78687T
10	MOUNT (X-LONG) (USE ON XR4/MAGNUM II)	77326
11	WASHER, UPPER MOUNT BOLT	12-66921
12	WASHER, UPPER MOUNT BOLT	12-78688
13	NUT, (.437-20), UPPER MOUNT BOLT	11-8M0204653
14	STEERING LINK ASSEMBLY	92876A12
15	SCREW, (.375-24 x 1.25), STEERING LINK TO STEERING ARM	10-849838	10-14000
16	NUT, (.375-24), STEERING LINK SCREW	11-8M0204726
17	WASHER, (.406 x .734 x .063) SS, STEERING LINK TO STEERING ARM	12-34931
18	SWIVEL PIN AND STEERING ARM (BLACK)	17-67706A55
18	SWIVEL PIN AND STEERING ARM (GRAY)	17-67706A55
19	BOTTOM YOKE (BLACK)	86580A1
19	BOTTOM YOKE (GRAY)	86580A1
20	RETAINING RING, BOTTOM YOKE	53-67684
21	BUMPER, TOP YOKE	88882
22	SCREW, (.250-28 x .500), SWIVEL BRACKET	10-64014
23	J CLIP	54-54457
24	TRIM SENDER ASSEMBLY	8M0074846	821180A 6
25	SCREW, (#10-24 x .750)	10-852368	10-56682
26	LOCKWASHER,	10,13-26996
27	WASHER, (.203 x .406 x .040)	12-89302

THROTTLE LEVER AND SHIFT SHAFT

Below is the parts list for Mercury V-200XRI (EFI) THROTTLE LEVER AND SHIFT SHAFT:

Position No.	Part Name	OEM Number	Supersedes
1	PIVOT, TRIGGER PLATE	74897T
2	BALL JOINT ASSEMBLY, TRIGGER PLATE	62459T
3	NUT, , LINK ROD	10-32,11-45076
4	ROD, TRIGGER PLATE	76035
5	NUT, , BALLJOINT	10-32,11-46438
6	LEVER ASSEMBLY, SPARK ADVANCE	41094A3
7	SCREW, (.250-20 x 2.125), SPARK ADVANCE LEVER - STOP	10-64022
8	NUT, (.250-20), SPARK ADVANCE STOP SCREW	11-64015
9	CAP, SPARK ADVANCE LEVER STOP SCREW	26852
10	SCREW, (.190-32 x 1.250)	10-13627
11	NUT, Stainless Steel, SPARK ADVANCE LEVER STOP SCREW	10-32,11-68219
12	CAP, SPARK ADVANCE LEVER STOP SCREW	48039
13	LEVER, THROTTLE CONTROL	410952
14	SCREW, (.375-16 x 1.75)	10-818165	10-55337
15	BUSHING, THROTTLE LEVER	23-55164
16	BUSHING, SPARK ADVANCE LEVER	23-55171
17	SPRING	24-55162
18	WASHER, SPARK ADVANCE LEVER	12-46765
19	SCREW, (.250-20 x 2.125), THROTTLE LEVER - STOP	10-64022
20	NUT, (.250-20), THROTTLE LEVER STOP SCREW	11-64015
21	CAP, THROTTLE LEVER STOP SCREW	26852
22	LATCH, CABLE	39483
23	SCREW, (.250-28 x .880), CABLE LATCH TO THROTTLE LEVER	10-69026
24	SPRING, CABLE LATCH TO THROTTLE LEVER	24-20099
25	NUT, (.250-28), CABLE LATCH SCREW	11-826709109	11-33825, 11-35045
26	ROD, THROTTLE CONTROL	14634
27	BARREL, THROTTLE CONTROL ROD	14638
28	CAM	8142392
29	BUSHING	23-8M0215006
30	BUSHING, THROTTLE CAM	23-26856
31	NUT, (.250-28), THROTTLE CAM STUD	11-826709109	11-33825, 11-35045
33	BRACKET, ANCHOR - CONTROL CABLES	814283A2
34	LATCH, CONTROL CABLE	98889
35	SCREW, Drive, LATCH	10-42975
36	SCREW, (.312-18 x .880), ANCHOR BRACKET ATTACHING	10-53167T
37	GUIDE BLOCK, LINK ROD	814284
38	SPRING, LINK ROD TO GUIDE BLOCK	24-20099
39	LINK ROD ASSEMBLY	67073A1
40	WEAR PLATE, LINK ROD	52100
41	LATCH	8M0036768	38279
42	WASHER, (.2656 x .625 x .0625) , LATCH	12-35462
43	NUT, (.250-28), LINK ROD	11-826709109	11-33825, 11-35045
44	SHIFT SHAFT ASSEMBLY	79932A16
45	WAVE WASHER, LINK ROD	13-29720
46	BUSHING, NYLON - LINK ROD	23-26600
47	WASHER, (.2656 x .625 x .0625) , LINK ROD	12-35462
48	NUT, (.250-28), LINK ROD TO SHIFT SHAFT	11-826709109	11-33825, 11-35045
49	CUP, BARREL RETAINER - ANCHOR BAR	39519

TOP COWL AND FRONT SHIELD

Below is the parts list for Mercury V-200XRI (EFI) TOP COWL AND FRONT SHIELD:

Position No.	Part Name	OEM Number	Supersedes
1	TOP COWL ASSEMBLY (BLACK)(Without Decals)	2196-9742T92
1	TOP COWL ASSEMBLY (GRAY)(Without Decals)	2196-9743T10
2	SEAL	812784
3	SEAL	815478	813566
4	SOUND BLANKET (SIDE) Comment: (USE WITHOUT DEFLECTORS)	815225
5	SOUND BLANKET (TOP) Comment: (USE WITHOUT DEFLECTORS)	815226
4/5	SOUND BLANKET KIT Comment: (USE W/DEFLECTORS)	815225A1
6	SOUND BLANKET, FRONT	815227
7	ROPE AND HANDLE KIT Comment: MANUAL STARTING	47341A11
8	NUT, (.312)	11-815848
9	WASHER, (.323 x .563 x .063) Stainless Steel	12-8M0042642	12-70132
10	BRACKET, REAR	184741
11	GROMMET	25-18506001
12	SCREW, (.250-20 x .750), REAR BRACKET	10-28636
13	SCREW	10-816992
14	HOOK	813096A2
15	SCREW, (.250-20 x .500)	10-73286
16	ROLLER	8M0207770
17	RING, Retaining	53-13194
18	WASHER, (.330 x .750 x .060)	12-56720
19	LOCATOR	187021
20	BRACKET ASSEMBLY, Latch Roller	893763	18173
21	SPACER (OLD DESIGN)	813552
21A	SPACER	816838
22	SCREW, (.312-18 x 1.375)	10-31984
22	SCREW, (.312-18 x 1.750)	10-69267
23	FRONT SHIELD ASSEMBLY (BLACK)(Without Decals)	18755A1
23	FRONT SHIELD ASSEMBLY (GRAY)(Without Decals)	18755A2
25	SCREW, (.190-16 x .620)	10-77137
26	WASHER, (.203 x .500 x .032)	12-8M0204666
27	WASHER	12-36001

TRANSOM BRACKETS

Below is the parts list for Mercury V-200XRI (EFI) TRANSOM BRACKETS:

Position No.	Part Name	OEM Number	Supersedes
1	TRANSOM BRACKET (STARBOARD) (BLACK)	3401-8718F7
1	TRANSOM BRACKET (STARBOARD) (GRAY)	3401-8718F8
2	TRANSOM BRACKET (PORT) (BLACK)	3400-8716A8
2	TRAMSOM BRACKET (PORT) (GRAY)	3400-8716A9
3	FITTING, Grease	22-8M0169588
4	NUT, (.875-14)	11-8M0041651	11-37984
5	TILT TUBE	99170A2
6	NUT, TILT TUBE (BLACK)	11-859133	11-34862, 11-90068F 3, 11-90068F 4
6	NUT, TILT TUBE (GRAY)	11-859133	11-34862, 11-90068F 3, 11-90068F 4
7	O-RING, (.612 x .103)	25-45711
8	WASHER	13-88750
9	NUT, (.875-14), TILT TUBE	11-858869	11-30499
10	SCREW, (.500-20 x 4.500), TRANSOM BRACKET TO TRANSOM	10-8M0149747
11	WASHER, (1.5 x 3.05 x 0.13) Stainless Steel, TRANSOM BRACKET BOLT	12-8M0204648
12	NUT, (.500-20), TRANSOM BRACKET BOLT	11-91962
13	LEVER ASSEMBLY	8M0115104	8M0115103, 99629T 2
14	WAVE WASHER	13-99611
15	NYLINER	23-65830
16	KNOB (BLACK)	99633
16	KNOB (GRAY)	99633
17	PIN, Groove	17-99615
18	SPRING	24-99622
19	PIN, Groove	17-99604
20	BOLT ASSEMBLY, TILT LOCK	10-96930A1
21	NUT, (.375-24), BOLT	11-23161
22	STOP	814207

Throttle Lever and Shift Shaft

Below is the parts list for Mercury V-200XRI (EFI) Throttle Lever and Shift Shaft:

Position No.	Part Name	OEM Number	Supersedes
1	PIVOT, TRIGGER PLATE	74897T
2	BALL JOINT ASSEMBLY, TRIGGER PLATE	62459T
3	NUT, , LINK ROD	10-32,11-45076
4	ROD, TRIGGER PLATE	76035
5	NUT, , BALL JOINT	10-32,11-46438
6	LEVER ASSEMBLY, SPARK ADVANCE	41094A3
7	SCREW, (.250-20 x 2.125), SPARK ADVANCE LEVER	10-64022
8	NUT, ( #8-32)	11-64015
9	CAP, SPARK ADVANCE LEVER STOP SCREW	26852
10	SCREW, (.190-32 X 1.25)	10-69560
11	NUT, , SPARK ADVANCE LEVER STOP SCREW	10-32,11-68219
12	CAP, SPARK ADVANCE LEVER STOP SCREW	48039
13	LEVER, THROTTLE CONTROL	410952
14	SCREW, (.375-16 x 1.75)	10-818165	10-55337
15	BUSHING, THROTTLE LEVER	23-55164
16	BUSHING, SPARK ADVANCE LEVER	23-55171
17	SPRING, THROTTLE AND SPARK ADVANCE LEVER	24-55162
18	WASHER, SPARK ADVANCE LEVER	12-46765
19	SCREW, (.250-20 x 2.125), THROTTLE LEVER - STOP	10-64022
20	NUT, ( #8-32), THROTTLE LEVER STOP SCREW	11-64015
21	CAP, THROTTLE LEVER STOP SCREW	26852
22	LATCH, CABLE	39483
23	SCREW, (.250-28 x .88), CABLE LATCH TO THROTTLE LEVER	10-69026
24	SPRING, CABLE LATCH TO THROTTLE LEVER	24-20099
25	NUT, (.250-28), CABLE LATCH SCREW	11-826709109	11-33825, 11-35045
26	ROD, THROTTLE CONTROL	814929
27	BARREL, THROTTLE CONTROL ROD	14638
28	THROTTLE CAM	815539T
29	STUD, (.250-28 x 1.750), THROTTLE CAM ATTACHING	16-20353
30	BUSHING	23-8M0215006
31	NUT, (.250-28), THROTTLE CAM STUD	11-826709109	11-33825, 11-35045
32	SPRING, THROTTLE RETURN (OLD DESIGN)	24-41050
33	BRACKET, ANCHOR - CONTROL CABLES	814283A2
34	LATCH, CONTROL CABLE	98889
35	SCREW, Drive, LATCH	10-42975
36	CUP, BARREL RETAINER	39519
37	BUSHING, NYLON - LINK ROD	23-26600
38	WASHER, (.2656 x .625 x .0625) , LINK ROD	12-35462
39	NUT, (.250-28), LINK ROD TO SHIFT SHAFT	11-826709109	11-33825, 11-35045
40	SCREW, (.312-18 x .880), ANCHOR BRACKET	10-53167T
41	GUIDE BLOCK, LINK ROD	814284
42	SPRING, LINK ROD TO GUIDE BLOCK	24-20099
43	LINK ROD ASSEMBLY	67073A1
44	WEAR PLATE, LINK ROD	52100
45	LATCH	8M0036768	38279
46	WASHER, (.2656 x .625 x .0625) , LATCH	12-35462
47	NUT, (.250-28), LINK ROD	11-826709109	11-33825, 11-35045
48	SHIFT SHAFT ASSEMBLY (LONG)	79932A16
48	SHIFT SHAFT ASSEMBLY (X-LONG)	79932A17
49	WAVE WASHER, LINK ROD	13-29720
50	IDLE STABILIZING SHIFT KIT	87-814281A1
51	SCREW, (#6-32 x .875)	10-77478
52	WASHER	12-27882
53	RESISTOR MODULE	17461A3

Top Cowl and Front Shield

Below is the parts list for Mercury V-200XRI (EFI) Top Cowl and Front Shield:

Position No.	Part Name	OEM Number	Supersedes
1	TOP COWL ASSEMBLY (BLACK) Comment: (135/150/175/200)	2196-9742T88
1	TOP COWL ASSEMBLY (GRAY Comment: (135/150/175/200)	2196-9743T11
1	TOP COWL ASSEMBLY (BLACK) Comment: (XR4)	2196-9742T90
1	TOP COWL ASSEMBLY (GRAY) Comment: (MAGNUM II)	2196-9742A91
2	SEAL	812784
3	SEAL	815478	813566
4	SOUND BLANKET (SIDE) Comment: (USE WITHOUT DEFLECTOR)	814823	813670 (USE WITHOUT DEFLECTOR)
5	SOUND BLANKET Comment: (USE WITHOUT DEFLECTOR)	814837	813671 (USE WITHOUT DEFLECTOR)
4/5	SOUND BLANKT KIT Comment: (USE W/ DEFLECTOR)	814823A1
6	SHIELD, AIR INLET Comment: (XR4/MAGNUM II)	17196A1
7	SPEED/NUT Comment: (XR4/MAGNUM II)	11-11316
8	SEAL, AIR INLET Comment: (XR4/MAGNUM II)	17238
9	SHIELD, AIR INLET (PORT) Comment: (XR4/MAGNUM II)	17194
9	SHIELD, AIR INLET (STBD) Comment: (XR4/MAGNUM II)	17195
10	BRACKET, REAR	184741
11	GROMMET	25-18506001
12	SCREW, (.250-20 x .750)	10-28636
13	WASHER, (.330 x .750 x .060)	12-56720
14	HOOK	813096A2
15	SCREW, (.250-20 x .500)	10-73286
16	ROLLER	8M0207770
17	RING, Retaining	53-13194
18	SCREW	10-816992
19	LOCATOR	187021
20	BRACKET	893763	18173
21	SPACER	813552
21A	SPACER	816838
22	SCREW, (.312-18 x 1.375)	10-31984
22	SCREW, (.312-18 x 1.750)	10-69267
23	NUT, (.312)	11-815848
24	ROPE AND HANDLE KIT (FOR MANUAL STARTING)	47341A11
25	FRONT SHIELD ASSEMBLY (BLACK)	18755A1
25	FRONT SHIELD ASSEMBLY (GRAY)	18755A2
26	SEAL (OLD DESIGN)	813562
27	SCREW, (.190-16 X .62)	10-77137
28	WASHER, (.203 x .500 x .032)	12-8M0204666
29	WASHER, (.323 x .563 x .063)	12-8M0042642	12-70132
30	WASHER	12-36001

Transom Brackets

Below is the parts list for Mercury V-200XRI (EFI) Transom Brackets:

Position No.	Part Name	OEM Number	Supersedes
1	TRANSOM BRACKET (STARBOARD) Comment: (BLACK)	3401-8718F7
1	TRANSOM BRACKET (STARBOARD) Comment: (GRAY)	3401-8718F8
2	TRANSOM BRACKET (PORT) Comment: (BLACK)	3400-8716A8
2	TRAMSOM BRACKET (PORT) Comment: (GRAY)	3400-8716A9
3	FITTING, Grease	22-8M0169588
4	NUT, (.875-14)	11-8M0041651	11-37984
5	TILT TUBE	99170A2
6	NUT (1"-14) (BLACK)	11-859133	11-34862, 11-90068F 3, 11-90068F 4
6	NUT (1"-14) (GRAY)	11-859133	11-34862, 11-90068F 3, 11-90068F 4
7	O-RING	25-45711
8	WAVE WASHER	13-88750
9	NUT, (.875-14)	11-858869	11-30499
10	SCREW, (.500-20 x 4.500)	10-8M0149747
11	WASHER	12-8M0204648
12	NUT	11-91962
13	LEVER ASSEMBLY	8M0115104	8M0115103, 99629T 2
14	WAVE WASHER	13-99611
15	NYLINER	23-65830
16	KNOB (BLACK)	99633
16	KNOB (GRAY)	99633
17	PIN, Groove	17-99615
18	SPRING	24-99622
19	PIN, Groove	17-99604
20	BOLT ASSEMBLY	10-96930A1
21	NUT, (.375-24)	11-23161
22	STOP	814207
-	GASKET SET Comment: (135/150)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (135/150)
-	GASKET SET Comment: (XR4/Magnum II/175)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (XR4/Magnum II/175)
-	GASKET SET Comment: (200)	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90 (200)

WIRING HARNESS/STARTER SOLENOID

Below is the parts list for Mercury V-200XRI (EFI) WIRING HARNESS/STARTER SOLENOID:

Position No.	Part Name	OEM Number	Supersedes
1	IGNITION PLATE, IGNITION	434292
2	SWITCH BOX	332-7778A12
3	SCREW, (#12-24 x 2.00), SWITCH BOX	10-13669
4	BUSHING, SWITCH BOX SCREW	23-94453
6	NUT, , SWITCH BOX TERMINAL	10-32,11-45076
7	WIRE ASSEMBLY, SWITCH BOX	84-60871A10
8	SCREW, (#10-16 x .375), WIRE ATTACHING	10-62568
9	CABLE ASSEMBLY, Black	84-65999A3
10	SCREW, (1.25), IGNITION PLATE	10-60411
11	LOCKWASHER, (.312), IGNITION PLATE SCREW	13-8M0204647
12	WASHER, IGNITION PLATE SCREW	12-36042
13	WASHER, (Rubber), IGNITION PLATE SCREW	12-67264
14	BUSHING, IGNITION PLATE SCREW	23-67268
15	SWITCH ASSEMLBY	87-33386A3
16	SCREW, (.190-32 x .620), MERCURY SWITCH	10-38055
17	NUT, , MERCURY SWITCH TERMINAL	10-32,11-45076
18	SCREW, (#10-32 x .500), LEAD ATTACHING	10-87926
19	BATTERY CABLE, Positive	84-88439A3
19	BATTERY CABLE, Negative	84-88439A4
20	HARNESS, ENGINE	84-96220A12
21	FUSE, 20 Ampere	88-8M0207796
22	CABLE ASSEMBLY, FUSE	84-95084A2
24	TIE STRAP, (8.00 Inches), HARNESS AND CABLES	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
25	SOLENOID ASSEMBLY, Starter	89-853654A1
26	NUT, , SOLENOID TERMINALS	10-32,11-45076
27	LOCKWASHER, (.312)	13-53166
28	NUT, (.312-18), SOLENOID TERMINALS	11-8M0204668
29	SCREW, (.250-20 x .620)	10-31716
30	LOCKWASHER, (.250)	13-26992
31	CABLE ASSEMBLY, Black, UPPER MOUNT	84-65999A2
32	CABLE ASSEMBLY (6" - RED/WHITE)	84-88528A2
32	CABLE ASSEMBLY (3" - WHITE/BLACK - 175)	84-91865A1
33	J CLIP	54-47483
34	TERMINAL BLOCK	86-194372
35	SCREW, (.190-32 x .620)	10-38055
36	WASHER, (.203 x .406 x .040)	12-89302
37	NUT,	10-32,11-45076
38	COVER, IGNITION PLATE	814422T
39	SCREW, (.190-32 x 1.62)	10-88447
40	SCREW, (#10-32 x .875)	10-690201
41	WASHER, (.203 x .406 x .040)	12-89302
42	LOCKWASHER,	10,13-26996
43	CABLE ASSEMBLY (175)	84-62310A2
44	INSULATOR	85-78866

Wiring Harness/Starter Solenoid

Below is the parts list for Mercury V-200XRI (EFI) Wiring Harness/Starter Solenoid:

Position No.	Part Name	OEM Number	Supersedes
1	IGNITION PLATE	434292
2	SWITCH BOX	332-7778A12
3	SCREW, (12-24 x 2.00), SWITCH BOX TO IGNITION PLATE	10-13669
4	BUSHING, SWITCH BOX SCREW	23-94453
5	CABLE ASSEMBLY, SWITCH BOX TO SWITCH BOX	84-62310A2
6	NUT, , SWITCH BOX TERMINAL	10-32,11-45076
7	WIRE ASSEMBLY, SWITCH BOX	84-60871A10
8	SCREW, (#10-16 x .375), WIRE ATTACHING	10-62568
9	CABLE ASSEMBLY, (Black)	84-65999A3
10	SCREW, (1.25), IGNITION PLATE	10-60411
11	LOCKWASHER, (.312), IGNITION PLATE SCREW	13-8M0204647
12	WASHER, IGNITION PLATE SCREW	12-36042
13	WASHER, (Rubber), IGNITION PLATE SCREW	12-67264
14	BUSHING, IGNITION PLATE SCREW	23-67268
15	SWITCH ASSEMLBY	87-33386A3
16	SCREW, (.190-32 X .62), MERCURY SWITCH TO IGNITION PLATE	10-38055
17	NUT, , MERCURY SWITCH TERMINAL	10-32,11-45076
18	SCREW, (#10-32 x .500), LEAD ATTACHING	10-87926
19	BATTERY CABLE, Positive	84-88439A3
19	BATTERY CABLE, Negative	84-88439A4
20	HARNESS, ENGINE (USE W/O RECTIFIER)	84-96220A12
20	HARNESS, ENGINE (USE W/RECTIFIER)	84-96220A4
21	FUSE, (20 Ampere)	88-8M0207796
22	CABLE ASSEMBLY, FUSE	84-95084A2
23	J CLIP	54-47483
24	CABLE TIE, (8.00 Inches), HARNESS AND CABLES	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
25	STARTER SOLENOID	89-853654A1
26	NUT, , SOLENOID TERMINALS	10-32,11-45076
27	LOCKWASHER, (.312), SOLENOID TERMINALS	13-53166
28	NUT, (.312-18), SOLENOID TERMINALS	11-8M0204668
29	SCREW, (.250-20 x .62), SOLENOID TO IGNITION PLATE	10-31716
30	LOCKWASHER, (.250)	13-26992
31	CABLE ASSEMBLY, (Black), UPPER MOUNT	84-65999A2
32	CABLE ASSEMBLY (3" - WHITE/BLACK)	84-91865A1
32	CABLE ASSEMBLY (6" - RED/WHITE)	84-88528A2
33	TERMINAL BLOCK	86-194372
34	SCREW, (.190-32 X .62)	10-38055
35	WASHER, (.203 x .406 x .040)	12-89302
36	NUT,	10-32,11-45076
37	COVER, IGNITION PLATE	814422T
38	SCREW, (.190-32 x 1.62)	10-88447
39	SCREW, (#10-32 x .875)	10-690201
40	WASHER, (.203 x .406 x .040)	12-89302
41	LOCKWASHER,	10,13-26996
42	RECTIFIER	8M0058226	816770T, 816770, 62351A 1, 83-70350A 1, 83-70350A 3
43	SCREW, (.190-32 X .62)	10-38055
44	NUT,	10-32,11-45076
45	INSULATOR	85-78866

Download this page as PDF: Click here

For Mercury Owners:

To assist you in maintaining and repairing your marine engines, we hope the following resources may be of use:

Mercury / Mercruiser / Mariner Parts from JLM Marine

About JLM Marine

Founded in 2002, JLM Marine has established itself as a dedicated manufacturer of high-quality marine parts, based in China. Our commitment to excellence in manufacturing has earned us the trust of top marine brands globally.

As a direct supplier, we bypass intermediaries, which allows us to offer competitive prices without compromising on quality. This approach not only supports cost-efficiency but also ensures that our customers receive the best value directly from the source.

We are excited to expand our reach through retail channels, bringing our expertise and commitment to quality directly to boat owners and enthusiasts worldwide.
