Suzuki DF 250 2022 DF 250AP-240001~ Outboard Motor Parts Diagram & Catalog

by JLM Marine 24 Jun 2025 0 Comments

Camshaft (DF250A:(020,021))

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Camshaft (DF250A:(020,021)):

Position No.	Part Name	OEM Number
1	Camshaft, Intake STBD	12701-98J20-0000
15-1	Shim, Tappet (T:2.175)	12892-93J10-218
2	Camshaft, Intk Port	12705-98J10-0000
15-2	Shim, Tappet (T:2.200)	12892-93J10-220
3	Camshaft, Exh STBD	12721-98J10-0000
15-3	Shim, Tappet (T:2.225)	12892-93J10-223
4	Camshaft, Exh Port	12729-98J20-0000
15-4	Shim, Tappet (T:2.250)	12892-93J10-225
5	Sprocket Assy, Cam Timing (NT: 2/32)	12740-93J00-0000
15-5	Shim, Tappet (T:2.275)	12892-93J10-228
6	Sprocket, Camshaft (NT:22)	12748-93J00-0000
15-6	Shim, Tappet (T:2.300)	12892-93J10-230
7	Bolt, Intake Camshaft	12753-93J00-0000
15-7	Tappet Shim (T:2:325), Tappet (T:2.325)	12892-93J10-233
8	Bolt, Camshaft	12749-93J00-0000
15-8	Tappet Shim (T:2:350), Tappet (T:2.350)	12892-93J10-235
9	Pin (5X12)	09202-05032-0000
15-9	Tappet Shim (T:2:375), Tappet (T:2.375)	12892-93J00-238
10	Pin (5X18)	09261-05006-0000
15-10	Shim, Tappet (T:2.400)	12892-93J10-240
11	Oil Control Valve, Oil Control	16550-93J00-0000
15-11	Shim, Tappet (T:2.425)	12892-93J10-243
12	VVT Valve Gasket, OCV	16555-93J01-0000
15-12	Shim, Tappet (T:2.450)	12892-93J10-245
13	Suzuki Bolt, (6X25)	01550-06257-0000
14	Tappet	12891-93J00-0000
15-13	Shim, Tappet (T:2.475)	12892-93J00-248
15-14	Tappet Shim (T:2.500), Tappet (T:2.500)	12892-93J00-250
15-15	Shim, Tappet (T:2.525)	12892-93J10-253
15-16	Shim, Tappet (T:2.550)	12892-93J10-255
15-17	Shim, Tappet (T:2.575)	12892-93J10-258
15-18	Shim, Tappet (T:2.600)	12892-93J10-260
15-19	Shim, Tappet (T:2.625)	12892-93J00-263
15-20	Shim, Tappet (T:2.650)	12892-93J10-265
15-21	Shim, Tappet (T:2.675)	12892-93J10-268
15-22	Shim, Tappet (T:2.700)	12892-93J10-270
15-23	Shim, Tappet (T:2.725)	12892-93J00-273
15-24	Shim, Tappet (T:2.750)	12892-93J00-275
15-25	Shim, Tappet (T:2.775)	12892-93J10-278
15-26	Shim, Tappet (T:2.800)	12892-93J10-280
15-27	Shim, Tappet (T:2.825)	12892-93J10-283
15-28	Shim, Tappet (T:2.850)	12892-93J00-285
15-29	Shim, Tappet (T:2.875)	12892-93J10-288
15-30	Shim, Tappet (T:2.900)	12892-93J10-290
15-31	Shim, Tappet (T:2.925)	12892-93J10-293
15-32	Shim, Tappet (T:2.950)	12892-93J10-295
15-33	Shim, Tappet (T:2.975)	12892-93J10-298
15-34	Shim, Tappet (T:3.000)	12892-93J10-300
16	Intake Valve, Intake	12911-98J00-0000
17	Exhaust Valve, Exhaust	12915-93J60-0000
18	Spring, Valve	12921-93J11-0000
19	Retainer, Valve Spring	12931-78G00-0000
20	Suzuki Cotter Valve, Valve	12932-24400-0000
21	Valve Spring Seat, Valve Spring	12933-69G10-0000
22	Oil Seal (5.5x11x8.2)	09289-05006-0000

Camshaft (DF250A:022)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Camshaft (DF250A:022):

Position No.	Part Name	OEM Number
1	Camshaft, Intake STBD	12701-98J20-0000
15-1	Shim, Tappet (T:2.175)	12892-93J10-218
2	Camshaft, Intake PORT	12705-98J10-0000
15-2	Shim, Tappet (T:2.200)	12892-93J10-220
3	Camshaft, Exh STBD	12721-98J10-0000
15-3	Shim, Tappet (T:2.225)	12892-93J10-223
4	Camshaft, Exh Port	12729-98J20-0000
15-4	Shim, Tappet (T:2.250)	12892-93J10-225
5	Sprocket Assy, Cam Timing (NT: 2/32)	12740-93J00-0000
15-5	Shim, Tappet (T:2.275)	12892-93J10-228
6	Sprocket, Camshaft (NT:22)	12748-93J00-0000
15-6	Shim, Tappet (T:2.300)	12892-93J10-230
7	Bolt, Intake Camshaft	12753-93J00-0000
15-7	Tappet Shim (T:2:325), Tappet (T:2.325)	12892-93J10-233
8	Bolt, Camshaft	12749-93J00-0000
15-8	Tappet Shim (T:2:350), Tappet (T:2.350)	12892-93J10-235
9	Pin (5X12)	09202-05032-0000
15-9	Shim, Tappet (T:2.375)	12892-93J10-238
10	Pin (5X18)	09261-05006-0000
15-10	Shim, Tappet (T:2.400)	12892-93J10-240
11	Oil Control Valve, Oil Control	16550-93J00-0000
15-11	Shim, Tappet (T:2.425)	12892-93J10-243
12	VVT Valve Gasket, OCV	16555-93J01-0000
15-12	Shim, Tappet (T:2.450)	12892-93J10-245
13	Bolt, (6X25)	01550-0625C-0000
14	Tappet	12891-93J10-0000
15-13	Shim, Tappet (T:2.475)	12892-93J10-248
15-14	Shim, Tappet (T:2.500)	12892-93J10-250
15-15	Shim, Tappet (T:2.525)	12892-93J10-253
15-16	Shim, Tappet (T:2.550)	12892-93J10-255
15-17	Shim, Tappet (T:2.575)	12892-93J10-258
15-18	Shim, Tappet (T:2.600)	12892-93J10-260
15-19	Shim, Tappet (T:2.625)	12892-93J10-263
15-20	Shim, Tappet (T:2.650)	12892-93J10-265
15-21	Shim, Tappet (T:2.675)	12892-93J10-268
15-22	Shim, Tappet (T:2.700)	12892-93J10-270
15-23	Shim, Tappet (T:2.725)	12892-93J10-273
15-24	Shim, Tappet (T:2.750)	12892-93J10-275
15-25	Shim, Tappet (T:2.775)	12892-93J10-278
15-26	Shim, Tappet (T:2.800)	12892-93J10-280
15-27	Shim, Tappet (T:2.825)	12892-93J10-283
15-28	Shim, Tappet (T:2.850)	12892-93J10-285
15-29	Shim, Tappet (T:2.875)	12892-93J10-288
15-30	Shim, Tappet (T:2.900)	12892-93J10-290
15-31	Shim, Tappet (T:2.925)	12892-93J10-293
15-32	Shim, Tappet (T:2.950)	12892-93J10-295
15-33	Shim, Tappet (T:2.975)	12892-93J10-298
15-34	Shim, Tappet (T:3.000)	12892-93J10-300
16	Intake Valve, Intake	12911-98J00-0000
17	Exhaust Valve, Exhaust	12915-93J60-0000
18	Spring, Valve	12921-93J11-0000
19	Retainer, Valve Spring	12931-78G00-0000
20	Suzuki Cotter Valve, Valve	12932-24400-0000
21	Valve Spring Seat, Valve Spring	12933-69G10-0000
22	Oil Seal (5.5x11x8.2)	09289-05006-0000

Clamp Bracket (L-Transom)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Clamp Bracket (L-Transom):

Position No.	Part Name	OEM Number
1-1	Bracket, Clamp STBD (Black)	41111-96J40-YAY
1-2	Bracket, Clamp Port (Black)	41121-96J30-YAY
1-3	Bracket, Clamp STBD (White)	41111-96J40-QTN
1-4	Bracket, Clamp STBD (Black)	41111-96J40-YAY
1-6	Rigging Bolt, (12.7X150)	09100-12086-0000
2-1	Bracket, Clamp STBD (White)	41111-96J40-Y5S
2-2	Bracket, Clamp Port (White)	41121-96J30-Y5S
2-3	Bracket, Clamp Port (White)	41121-96J30-QTN
2-4	Bracket, Clamp Port (Black)	41121-96J30-YAY
2-6	Bolt (12.7X115), (12.7X115)	09100-12085-0000
3	Shaft, Clamp Bracket	41130-92J03-0000
4	Washer, Clamp Bracket Shaft	41135-92J00-0000
5	Nut, (M22)	09159-22006-0000
6-3	Bolt (12X75)	09100-12092-0000
7	Rigging Nut, (12.7X19)	MISC-ITEM-0000
8	Suzuki Washer (13.2X26X3), (13.2X26X3)	09160-13021-0000
9	Washer, (13.2X45X3)	09160-13022-0000
10	Plate, Transom	41155-93J02-0000
11	Protection Anode Set, Clamp Bracket	55320-94900-0000
12	Suzuki Bolt, (6X25)	09116-06121-0000
13	Cam Assy, Tilt Limit Switch	48140-93J01-0000
14	Tilt Limit Switch Holder, Tilt Limit Switch	48144-93J00-0000
15	Bolt (6X25), (6X25)	09103-06278-0000
16	Cover, Tilt Limit Switch	48145-93J00-0000
17	Magnesium Anode	55321-94910-0000
18	Plate, Clamp Bracket Lower STBD	41117-93L00-0000
19	Plate, Clamp Bracket Lower Port	41122-93L00-0000
20	Screw, Clamp Bracket LWR Plate	03542-0516C-0000
21	Washer, Lower Plate Screw	09160-05053-0000

Clamp Bracket (X-Transom,XX-Transom)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Clamp Bracket (X-Transom,XX-Transom):

Position No.	Part Name	OEM Number
1-1	Bracket, Clamp STBD (Black)	41111-93J16-YAY
1-2	Bracket, Clamp Port (Black)	41121-93J08-YAY
1-3	Bracket, Clamp STBD (White)	41111-93J16-QTN
1-4	Bracket, Clamp STBD (Black)	41111-93J16-YAY
1-9	Rigging Bolt, (12.7X150)	09100-12086-0000
2-1	Bracket, Clamp STBD (White)	41111-93J16-Y5S
2-2	Bracket, Clamp Port (White)	41121-93J08-Y5S
2-3	Bracket, Clamp Port (White)	41121-93J08-QTN
2-4	Bracket, Clamp Port (Black)	41121-93J08-YAY
2-9	Bolt (12.7X115), (12.7X115)	09100-12085-0000
3	Clamp Bracket Plate (STBD), Clamp BRKT Lower STBD	41117-93J02-0000
4	Clamp Bracket Plate (PORT), Clamp Bracket Lower Port	41122-93J02-0000
5	Suzuki Screw (6X10)	09125-06063-0000
6	Shaft, Clamp Bracket	41130-93J12-0000
7	Washer, Clamp Bracket Shaft	41135-93J11-0000
8	Nut, (M22)	09159-22006-0000
9-3	Bolt (12X75)	09100-12092-0000
10	Rigging Nut, (12.7X19)	MISC-ITEM-0000
11	Washer, (13.2X45X3)	09160-13022-0000
12	Suzuki Washer (13.2X26X3), (13.2X26X3)	09160-13021-0000
13	Plate, Transom	41155-93J02-0000
14	Protection Anode Set, Clamp Bracket	55320-94900-0000
15	Suzuki Bolt, (6X25)	09116-06121-0000
16	Tilt Lock Pin, Tilt Lock	45421-87D03-0000
17	Nut	09159-14020-0000
18	Cam Assy, Tilt Limit Switch	48140-93J01-0000
19	Tilt Limit Switch Holder, Tilt Limit Switch	48144-93J00-0000
20	Bolt (6X25), (6X25)	09103-06278-0000
21	Magnesium Anode	55321-94910-0000
22	Cover, Tilt Limit Switch	48145-93J00-0000
23	Clamp To Swivel Lead, (L:165)	36894-87D00-0000
24	Suzuki Screw (6X10)	09125-06063-0000

Clutch Rod (020,021)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Clutch Rod (020,021):

Position No.	Part Name	OEM Number
1-1	Shift Drive Rod, Shift Drive	25112-93L00-0000
1-2	Shift Drive Rod, Shift Drive	25112-93L10-0000
1-5	Housing, Shift Rod Guide (Black)	25141-93L10-YAY
2	Shifter Yoke, Shifter	25130-93L00-0000
3	Magnet, Gear Case	25232-90J00-0000
4	Spring Pin (3X20), (3X20)	09205-03004-0000
5-2	Housing, Shift Rod Guide (White)	25141-93L10-Y5S
5-3	Housing, Shift Rod Guide (White)	25141-93L10-QTN
5-4	Housing, Shift Rod Guide (Black)	25141-93L10-YAY
6	Shift Guide Cover, SFT Guide HSG Oil Seal	25222-90J01-0000
7	Oil Seal (10X22X8), (10X22X8)	09283-10011-0000
8	Slider, Shift Horizontal	25321-93L00-0000
9	Suzuki Bolt, (6X20)	29116-93J00-0000
10	Suzuki Washer, (10.5X19X2.0)	09160-10082-0000
11	Gear, Shift Rod (NT:13)	25113-93L00-0000
12	Housing, Magnet	25215-93L00-0000
13	E Ring, (7X14X1.2)	09383-07003-0000
14	Sealing, Shift Rod Guide HSG	55122-93L00-0000
15	Shift Slider Housing, Shift Slider	56141-93L00-0000
16	Water Filter Screen (PORT), Water Port Front Side	17637-93L00-0000
17	Water Filter Screen (STBD), Water STBD Front Side	17638-93L00-0000
18	Internal Protection Anode, Protection	55321-87J01-0000
19	Bolt, (6X35)	01550-06357-0000
20	Suzuki Anode Bolt (6x14), (6X14)	09103-06281-0000
21	Pin (7.4X9X10), (7.4X9X10)	09206-09012-0000
22	Suzuki Screw, (4X18)	09132-04034-0000
23	Holder, Magnet	25231-93L00-0000
24	Gear Case Magnet, Gear Case	25232-94300-0000

Clutch Rod (022)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Clutch Rod (022):

Position No.	Part Name	OEM Number
1-1	Shift Drive Rod, Shift Drive	25112-93L00-0000
1-2	Shift Drive Rod, Shift Drive	25112-93L10-0000
1-5	Housing, Shift Rod Guide (White)	25141-93L10-QTN
2	Shifter Yoke, Shifter	25130-93L00-0000
3	Magnet, Gear Case	25232-90J00-0000
4	Spring Pin (3X20), (3X20)	09205-03004-0000
6	Shift Guide Cover, SFT Guide HSG Oil Seal	25222-90J01-0000
7	Oil Seal (10X22X8), (10X22X8)	09283-10011-0000
8	Slider, Shift Horizontal	25321-93L00-0000
9	Suzuki Bolt, (6X20)	29116-93J00-0000
10	Suzuki Washer, (10.5X19X2.0)	09160-10082-0000
11	Gear, Shift Rod	25113-93L20-0000
12	Housing, Magnet	25215-93L00-0000
13	E Ring, (7X14X1.2)	09383-07003-0000
14	Sealing, Shift Rod Guide HSG	55122-93L00-0000
15	Shift Slider Housing, Shift Slider	56141-93L00-0000
16	Water Filter Screen (PORT), Water Port Front Side	17637-93L00-0000
17	Water Filter Screen (STBD), Water STBD Front Side	17638-93L00-0000
18	Internal Protection Anode, Protection	55321-87J01-0000
19	Bolt, (6X35)	01550-06357-0000
20	Suzuki Anode Bolt (6x14), (6X14)	09103-06281-0000
21	Pin (7.4X9X10), (7.4X9X10)	09206-09012-0000
22	Suzuki Screw, (4X18)	09132-04034-0000
23	Holder, Magnet	25231-93L00-0000
24	Gear Case Magnet, Gear Case	25232-94300-0000

Clutch Shaft

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Clutch Shaft:

Position No.	Part Name	OEM Number
1	Clutch Lever, Clutch	21110-98J02-0000
21-1	Suzuki Bolt, (6X20)	01550-06207-0000
30-1	Bolt	01550-08557-0000
2	Clutch Lever Bushing, Clutch Lever	21131-93J00-0000
21-2	Suzuki Bolt, (6X20)	01550-0620C-0000
30-2	Bolt	01550-0855C-0000
3	Clutch Lever Holder, Clutch Lever	21151-93J00-0000
4	Washer (10X20X3), (10X20X3)	09160-10148-0000
5	Clutch Shaft, Clutch	21210-98J01-0000
6	Clutch Shaft Arm, Clutch Shaft	21230-98J01-0000
7-1	Clutch Rod (L- 20"), Clutch	23111-93J10-0000
7-2	Clutch Rod (X/XX- 25"-30"), Clutch	23111-93J00-0000
8	Link, Clutch Lever	23115-98J00-0000
10	Suzuki Washer (6.5X15X1.5), (6.5X15X1.0)	09160-06094-0000
11	Cotter Pin	09204-01006-0000
12	Spring Pin (10.2X10), (10.2X10)	09205-10006-0000
13	Suzuki Plug (12X9), (12X9)	09248-12011-0000
14	Suzuki Ball	09260-10005-0000
15	Bearing (17X35X8), (17X35X8)	09262-17019-0000
16	Clutch Shaft Seal (18x30X8), (18X30X8)	09289-18001-0000
17	Suzuki Bushing	09306-06005-0000
18	Shift Rod Bushing	09306-10001-0000
19	E Ring	09383-08004-0000
20	Suzuki Spring	09440-07051-0000
22	Suzuki Screw	02142-05107-0000
23	Suzuki Circlip	08331-41359-0000
24	Link, Clutch Lever No. 2	21241-98J10-0000
25	Control Cable End Connector	67467-89J01-0000
26	Nut, Remocon Cable	67471-99E00-0000
27	Washer, (7X12X1.0)	09160-06055-0000
28	Suzuki Clip	09385-06012-0000
29	Holder, Clutch Lever	19115-98J10-0000
31	Cable Connector, Remocon Cable No. 2	67467-89J10-0000
32	Remocon Cable NO.2 Nut, Remocon Cable No. 2	67471-99E10-0000

Cylinder Block

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Cylinder Block:

Position No.	Part Name	OEM Number
1	Engine Front Hook, Engine Front	11293-98J00-0000
24-1	Suzuki Bolt, (6X20)	01550-06207-0000
29-1	Bolt, (8X45)	01550-08457-0000
2-1	Bolt	01550-08207-0000
2-2	Suzuki Bolt, (8X20)	01550-0820C-0000
24-2	Suzuki Bolt, (6X20)	01550-0620C-0000
29-2	Bolt	01550-0845C-0000
4	Plug, Oil Venturi	11112-93J00-0000
5	Bolt, Crankcase	11117-93J10-0000
6	Bolt, Crankcase Stud	11117-98J10-0000
7	Bolt, Cylinder Head	11119-93J00-0000
8	M26 Plug Gasket, M26 Plug	11216-98L00-0000
9	Suzuki Plug (26X11), (M26)	09248-26001-0000
10	Suzuki Washer (18.5X28X2.6), (18.5X28X2.6	09160-18031-0000
11	Suzuki Plug (18X8), (18X8)	09248-18006-0000
12	Nut, (M10)	09159-10116-0000
13	Knock Pin (10.4X13X16), (10.4X13X16)	09206-13019-0000
14	Valve, Piston Jet	16700-93J00-0000
15	Oil Release O-Ring, (D:1.3,ID:9.8)	09280-10009-0000
16	O-Ring	09280-10016-0000
17	Bolt	07130-0616B-0000
18	Bolt	07130-0510A-0000
19	Jet, Piston Cooling	11390-98J00-0000
20	O-Ring, (D:1.9,ID:5.7)	09280-06005-0000
21	Plug, (1/8PT,H:8)	09246-04009-0000
22	Cover, Crankcase WTR JKT	11330-93J01-0000
23	Water Jacket Cover Gasket, Crankcase WTR JKT COV	11332-93J00-0000
25	Cover, Oil Gallery	16430-93J00-0000
26	Plate, Oil Gallery	16431-93J00-0000
27	Gasket, Oil Gallery	16433-93J00-0000
28	Bolt, (8X35)	01550-0835A-0000
30	Suzuki Oil Filter, Oil	16510-96J10-0000

Cylinder Head

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Cylinder Head:

Position No.	Part Name	OEM Number
1-1	Head Assy, Cylinder STBD	11101-98J10-0000
1-1	Bolt	01550-08207-0000
1-2	Camshaft Housing Bolt, CamshaftT Housing (6X39)	11128-90J00-0000
1-2	Suzuki Bolt	01550-0820C-0000
1-5	Head Assy, Cylinder Port	11103-98J10-0000
1-6	Camshaft Housing Bolt, CamshaftT Housing (6X39)	11128-90J00-0000
17-1	Bolt	01550-08207-0000
29-1	Suzuki Bolt (6X25)	01547-06257-0000
30-1	Bolt, (6X50)	01547-06507-0000
2-1	Head Assy, Cylinder STBD	11101-98J10-0000
2-2	Bolt, (6X40)	09103-06266-0000
2-5	Head Assy, Cylinder Port	11103-98J10-0000
2-6	Bolt, (6X40)	09103-06266-0000
17-2	Suzuki Bolt	01550-0820C-0000
29-2	Bolt	01547-0625C-0000
30-2	Bolt	01547-0650C-0000
3	Cover Dowel Pin (8X11), (8X11)	09206-08001-0000
4	Suzuki Bolt, (6X20)	01550-06207-0000
7	Cover Dowel Pin (8X11), (8X11)	09206-08001-0000
8	Suzuki Bolt, (6X20)	01550-06207-0000
9	Plug	11116-93J01-0000
10	Cylinder Head Gasket (STBD), Cylinder Head STBD	11141-98J10-0000
11	Cylinder Head Gasket (PORT), Cylinder Head Port	11142-98J10-0000
12	Suzuki Gasket	11216-98L10-0000
13	Anode Protection Cover, Protection Anode	11261-93J00-0000
14	Internal Anode O-Ring, (D:1.9,ID:21.8)	09280-22019-0000
15	Internal Protection Anode, Protection	55321-87J01-0000
16	Suzuki Anode Bolt (6x14), (6X14)	09103-06281-0000
18	Suzuki Bolt	01550-08607-0000
19	Suzuki Bolt	01550-08607-0000
20	Suzuki Pin, (14X11.4X23)	09206-14004-0000
21	Cover, Cyl Head STBD	11170-93J01-0000
22	Cover, Cylinder Head Port	11180-98J01-0000
23	Plate, Breather STBD	11173-93J00-0000
24	Plate, Breather Port	11183-93J00-0000
25	Cylinder Head Cover Gasket (STBD), CYL Head Cover STBD	11179-93J00-0000
26	Cylinder Head Cover Gasket (PORT), CYL Head Cover Port	11189-93J00-0000
27	Cover Dowel Pin (8X11), (8X11)	09206-08001-0000
28	Screw	02112-0612A-0000
31	Oil Filler Cap, Oil Filler	11382-93J00-0000
32	Suzuki O-Ring, (D:3.1,ID:26.4)	09280-26006-0000
33	NGK BKR6E Spark Plug, NGK BKR6E (BKR6E)	09482-00427-0000
34	Hook, Engine	11291-93J00-0000
36	Guide, Valve (OS)	11115-93J10-001
37	Lifting Eye, Engine	11291-98J00-0000

Drive Shaft Housing (L-Transom)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Drive Shaft Housing (L-Transom):

Position No.	Part Name	OEM Number
1-1	Drive Shaft Housing, Drive Shaft (Black)	52111-98J20-YAY
1-2	Drive Shaft Housing, Drive Shaft (White)	52111-98J20-Y5S
1-3	Drive Shaft Housing, Drive Shaft (White)	52111-98J20-QTN
1-4	Drive Shaft Housing, Drive Shaft (Black)	52111-98J20-YAY
14-1	Lower Mount Bracket, Lower Mount (Black)	54211-93J00-YAY
15-1	Cover, Lower Mount (Black)	54221-93J00-YAY
2	Bolt, (10X44)	09116-10176-0000
14-2	Lower Mount Bracket, Lower Mount (White)	54211-93J00-Y5S
15-2	Cover, Lower Mount (White)	54221-93J00-Y5S
3	Suzuki Pin, (8X12)	09202-08006-0000
14-3	Lower Mount Bracket, Lower Mount (White)	54211-93J00-QTN
15-3	Cover, Lower Mount (White)	54221-93J00-QTN
4	Suzuki Nut, (M10)	09140-10031-0000
14-4	Lower Mount Bracket, Lower Mount (Black)	54211-93J00-YAY
15-4	Cover, Lower Mount (Black)	54221-93J00-YAY
5	Stud Bolt, Stud	09108-10150-0000
6	Suzuki Washer (10.5X19X2), (10.5X19X2)	09160-10141-0000
7	Suzuki Screw (6X10)	09125-06063-0000
8	Mount, Lower Thrust	54150-98J00-0000
9	Lower Mount, Lower	54160-98J00-0000
10	Upper Mount Bolt, Mount (14X220)	54112-93J00-0000
11	Washer (16X32X3), (16X32X3)	09160-16050-0000
12	Upper Mount Bolt Nut, (M14)	09159-14026-0000
13	Washer (16X32X3), (16X32X3)	09160-16050-0000
16	Suzuki Bolt (10X50)	09116-10175-0000
17	Lower Thrust Stopper, Lwr Thrust Reverse	54165-98J00-0000
18	Rev Stopper Washer (14X50X4), (14X50X4)	09160-14066-0000
19	Clamp To Swivel Lead, (L:165)	36894-87D00-0000
20	Suzuki Screw (6X10)	09125-06063-0000

Drive Shaft Housing (X-Transom)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Drive Shaft Housing (X-Transom):

Position No.	Part Name	OEM Number
1-1	Drive Shaft Housing, Drive Shaft (Black)	52111-98J00-YAY
1-2	Drive Shaft Housing, Drive Shaft (White)	52111-98J00-Y5S
1-3	Drive Shaft Housing, Drive Shaft (White)	52111-98J00-QTN
1-4	Drive Shaft Housing, Drive Shaft (Black)	52111-98J00-YAY
15-1	Lower Mount Bracket, Lower Mount (Black)	54211-93J00-YAY
16-1	Cover, Lower Mount (Black)	54221-93J00-YAY
2	Bolt, (10X44)	09116-10176-0000
15-2	Lower Mount Bracket, Lower Mount (White)	54211-93J00-Y5S
16-2	Cover, Lower Mount (White)	54221-93J00-Y5S
3	Suzuki Pin, (8X12)	09202-08006-0000
15-3	Lower Mount Bracket, Lower Mount (White)	54211-93J00-QTN
16-3	Cover, Lower Mount (White)	54221-93J00-QTN
4	Drive Shaft Bushing, Drive Shaft	57130-87D10-0000
15-4	Lower Mount Bracket, Lower Mount (Black)	54211-93J00-YAY
16-4	Cover, Lower Mount (Black)	54221-93J00-YAY
5	Ring	09387-39002-0000
6	Suzuki Screw (6X10)	09125-06063-0000
7	Clamp To Swivel Lead, (L:165)	36894-87D00-0000
8	Suzuki Screw (6X10)	09125-06063-0000
9	Mount, Lower Thrust	54150-98J00-0000
10	Lower Mount, Lower	54160-98J00-0000
11	Upper Mount Bolt, (14X220)	54112-93J00-0000
12	Washer (16X32X3), (16X32X3)	09160-16050-0000
13	Upper Mount Bolt Nut, (M14)	09159-14026-0000
14	Washer (16X32X3), (16X32X3)	09160-16050-0000
17	Suzuki Bolt (10X50)	09116-10175-0000
18	Lower Thrust Stopper, Lower Thrust Reverse	54165-98J00-0000
19	Rev Stopper Washer (14X50X4), (14X50X4)	09160-14066-0000
20	Protection Anode, Protection	55321-93J01-0000
21	Anode Bolt (6X16), (6X16)	09116-06236-0000

Drive Shaft Housing (XX-Transom)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Drive Shaft Housing (XX-Transom):

Position No.	Part Name	OEM Number
1-1	Drive Shaft Housing, Drive Shaft (Black)	52111-98J00-YAY
1-2	Drive Shaft Housing, Drive Shaft (White)	52111-98J00-Y5S
1-3	Drive Shaft Housing, Drive Shaft (White)	52111-98J00-QTN
1-4	Drive Shaft Housing, Drive Shaft (Black)	52111-98J00-YAY
1-7	Case, Extension (Black)	52131-93J00-YAY
19-1	Lower Mount Bracket, Lower Mount (Black)	54211-93J00-YAY
20-1	Cover, Lower Mount (Black)	54221-93J00-YAY
2	Bolt, (10X44)	09116-10176-0000
19-2	Lower Mount Bracket, Lower Mount (White)	54211-93J00-Y5S
20-2	Cover, Lower Mount (White)	54221-93J00-Y5S
3	Suzuki Pin, (8X12)	09202-08006-0000
19-3	Lower Mount Bracket, Lower Mount (White)	54211-93J00-QTN
20-3	Cover, Lower Mount (White)	54221-93J00-QTN
4	Drive Shaft Bushing, Drive Shaft	57130-87D10-0000
19-4	Lower Mount Bracket, Lower Mount (Black)	54211-93J00-YAY
20-4	Cover, Lower Mount (Black)	54221-93J00-YAY
5	Ring	09387-39002-0000
6	Suzuki Screw (6X10)	09125-06063-0000
7-2	Case, Extension (White)	52131-93J00-Y5S
7-3	Case, Extension (White)	52131-93J00-QTN
7-4	Case, Extension (Black)	52131-93J00-YAY
8	Stud Bolt, (10X167)	09108-10115-0000
9	Stud Bolt, Stud	09108-12013-0000
10	Suzuki Pin, (8X12)	09202-08006-0000
11	Clamp To Swivel Lead, (L:165)	36894-87D00-0000
12	Suzuki Screw (6X10)	09125-06063-0000
13	Mount, Lower Thrust	54150-98J00-0000
14	Lower Mount, Lower	54160-98J00-0000
15	Upper Mount Bolt, (14X220)	54112-93J00-0000
16	Washer (16X32X3), (16X32X3)	09160-16050-0000
17	Upper Mount Bolt Nut, (M14)	09159-14026-0000
18	Washer (16X32X3), (16X32X3)	09160-16050-0000
21	Suzuki Bolt (10X50)	09116-10175-0000
22	Lower Thrust Stopper, Lwr Thrust Reverse	54165-98J00-0000
23	Rev Stopper Washer (14X50X4), (14X50X4)	09160-14066-0000
24	Protection Anode, Protection	55321-93J01-0000
25	Anode Bolt (6X16), (6X16)	09116-06236-0000

Engine Cover ((021,022):DF250A)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Engine Cover ((021,022):DF250A):

Position No.	Part Name	OEM Number
1-1	Manual, Owner's	99011-98JA0-03B
1-1	Mark, Emblem Rear	61435-93JP0-0000
1-2	Manual, Owner's	99011-98JB0-03B
1-2	Mark, Emblem Rear	61435-93JQ0-0000
1-2	Top Engine Cover, Top (Black)	61431-98J10-YAY
1-3	Manual, Owner's	99011-98JA0-054
1-4	Manual, Owner's	99011-98JB0-054
1-5	Manual, Owner's	99011-98JA0-059
1-6	Manual, Owner's	99011-98JB0-059
29-1	STBD Engine Cover Stripe, Engine Cover STBD	61443-96L30-0000
30-1	Port Engine Cover Stripe, Engine Cover Port	61453-96L30-0000
2-1	Engine Cover Set (Super Cool White), Engine (White)	61420-98850-QTN
2-2	Top Engine Cover, Engine Top (White)	61431-98J10-QTN
29-2	STBD Engine Cover Stripe, Engine Cover STBD	61443-96L40-0000
30-2	Port Engine Cover Stripe, Engine Cover Port	61453-96L40-0000
3	Air Intake Louver, Air Intake	61432-98J01-0000
4	Upper Engine Grip (STBD), Engine Upper Cover STBD	61433-98J01-0000
5	Upper Engine Grip (PORT), Engine Upper Cover Port	61434-98J02-0000
6	Seal, Grip STBD	61439-98J01-0000
7	Grip Port Seal, Grip Port	61439-98J11-0000
8	Seal, Air Vent No.2	61439-98J21-0000
9	Seal, Air Vent No.1	61476-98J00-0000
10	Suzuki Bolt, (6X16)	01550-06167-0000
11	Suzuki Bolt, (6X20)	01550-06207-0000
12	Suzuki Bolt, (6X16)	01550-06167-0000
13	Bolt, (6X19)	03542-06169-0000
14	Suzuki Bolt, (6X16)	01550-06167-0000
15	Bolt, (6X19)	03542-06169-0000
16	Fastener Front, Front	61610-98J00-0000
17	Fastener, Front	61610-98J30-0000
18	Fastener, STBD	61610-98J40-0000
19	Chrome "S" Badge, Mark S (Chrome)	77811-54GC0-0PG
20	Protector, Fastener	61614-98J00-0000
21	Bracket, Fastener Front	61621-98J02-0000
22	Bracket, Fastener Port	61624-98J11-0000
23	Bracket, Fastener STBD	61625-98J11-0000
24	Cushion, Eng Cover Fastener	61619-98J00-0000
25	Suzuki Bolt (6X16), (6X16)	01547-06167-0000
26	Suzuki Bolt	01550-06127-0000
27	Suzuki Bolt	01550-06127-0000
28	Cushion, Engine Cover	61425-98J00-0000
31	Suzuki Mark, Suzuki	61441-98L00-0000
33	Suzuki Tool Set	09800-81835-0000

Engine Cover (020:DF250A)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Engine Cover (020:DF250A):

Position No.	Part Name	OEM Number
1-1	Engine Cover Set (Nebular Black), Engine (Black)	61420-98802-YAY
1-1	Emblem Front Mark, Emblem Front	61422-98J40-0000
1-1	Mark, Emblem Rear	61435-98J60-0000
1-1	Manual, Owner's	99011-98J91-054
1-2	Top Engine Cover, Engine Top (Black)	61431-98J10-YAY
1-2	Manual, Owner's	99011-98J91-059
1-2	Mark, Emblem Rear	61435-93JD0-0000
1-2	Emblem Front Mark, Emblem Front	61422-93JE0-0000
1-3	Manual, Owner's	99011-98J91-03B
29-1	Stripe, Engine Cover STBD	61443-96J70-0000
30-1	Port Engine Cover Stripe, Engine Cover Port	61453-96J70-0000
2-1	Engine Cover Set (Cool White), Engine (White)	61420-98812-Y5S
2-2	Top Engine Cover, Engine Top (White)	61431-98J10-Y5S
29-2	Stripe, Engine Cover STBD	61443-96J80-0000
30-2	Port Engine Cover Stripe, Engine Cover Port	61453-96J80-0000
3	Air Intake Louver, Air Intake	61432-98J01-0000
4	Upper Engine Grip (STBD), Engine Upper Cover STBD	61433-98J01-0000
5	Upper Engine Grip (PORT), Engine Upper Cover Port	61434-98J02-0000
6	Seal, Grip STBD	61439-98J01-0000
7	Grip Port Seal, Grip Port	61439-98J11-0000
8	Seal, Air Vent No. 2	61439-98J21-0000
9	Seal, Air Vent No. 1	61476-98J00-0000
10	Suzuki Bolt, (6X16)	01550-06167-0000
11	Suzuki Bolt, (6X20)	01550-06207-0000
12	Suzuki Bolt	01550-06167-0000
13	Bolt, (6X19)	03542-06169-0000
14	Suzuki Bolt	01550-06167-0000
15	Bolt, (6X19)	03542-06169-0000
16	Fastener Front, Front	61610-98J00-0000
17	Fastener, Front	61610-98J30-0000
18	Fastener, STBD	61610-98J40-0000
19	Chrome "S" Badge, Mark S (Chrome)	77811-54GC0-0PG
20	Protector, Fastener	61614-98J00-0000
21	Bracket, Fastener Front	61621-98J02-0000
22	Bracket, Fastener Port	61624-98J11-0000
23	Bracket, Fastener STBD	61625-98J11-0000
24	Cushion, Eng Cover Fastener	61619-98J00-0000
25	Suzuki Bolt (6X16), (6X16)	01547-06167-0000
26	Suzuki Bolt	01550-06127-0000
27	Suzuki Bolt	01550-06127-0000
28	Cushion, Engine Cover	61425-98J00-0000
31	Suzuki Mark, Suzuki	61441-98L00-0000
34	Suzuki Tool Set	09800-81835-0000

Engine Holder

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Engine Holder:

Position No.	Part Name	OEM Number
1-1	Engine Holder, Engine (Black)	51111-93J31-YAY
1-1	Upper Thrust Stopper, Upr Thrust	54121-98J01-0000
1-2	Stopper, Upper Thrust	54121-93J20-0000
1-2	Engine Holder, Engine (White)	51111-93J31-Y5S
1-3	Engine Holder, Engine (Black)	51111-93J31-YAY
1-4	Engine Holder, Engine (White)	51111-93J31-Y5S
1-5	Engine Holder, Engine (Black)	51111-93J40-YAY
1-6	Engine Holder, Engine (White)	51111-93J40-QTN
18-1	Engine Holder Cover, Engine Holder (Black)	51140-93J11-YAY
2	Engine Holder Oil Pump Seal, Engine Holder Oil	16519-93J00-0000
18-2	Cover, Holder (Black)	51140-98J00-YAY
3	SUZUKI FLUSH PLUG AND GASKET KIT, Water	150-350-FLUSHPLUG
18-3	Engine Holder Cover, Engine Holder (White)	51140-93J11-Y5S
4	Suzuki Flush Plug Gasket, Water Plug	17914-93J00-0000
18-4	Cover, Engine Holder (White)	51140-98J00-Y5S
5	Seal, Water Return	51116-93J00-0000
18-5	Engine Holder Cover, Engine Holder (White)	51140-93J11-QTN
6	Engine Base Gasket, Engine Holder	51211-93J00-0000
18-6	Cover, Engine Holder (White)	51140-98J00-QTN
7	Water Indicator Pipe, Water Indicator	61155-93J20-0000
18-7	Engine Holder Cover, Engine Holder (Black)	51140-93J11-YAY
8	Cover Dowel Pin (8X11), (8X11)	09206-08001-0000
18-8	Cover, Holder (Black)	51140-98J00-YAY
9	Bolt	01550-08307-0000
10	Grease Nipple (Zerk Fitting), Grease	22511-99011-0000
11	Motor Mount Oil Seal Cover, Mount Oil Seal	51120-98L00-0000
12	Suzuki Oil Seal, Oil	51124-93J01-0000
13	Suzuki Scraper	51125-93J00-0000
14	Motor Mount Cover Gasket, Mount Oil Seal Cover	51123-93J00-0000
15	Engine Mount Bolt (8X120), (8X120)	09103-08109-0000
16	Cover Dowel Pin (8X11), (8X11)	09206-08001-0000
17	Bolt, (8X30)	01550-0830A-0000
19	Engine Holder Gasket, Engine Holder Cover	51142-93J00-0000
20	Suzuki Bolt (8X30), (8X30)	09116-08122-0000
21	Cover, Engine Holder Upper	51151-93J00-0000
22	Engine Holder Upper Cover Seal, Engine Holder Upper Cover	51152-93J00-0000
23	Bolt	01550-08307-0000
24	Suzuki Bolt	01550-08607-0000
25	Upper Mount Plate, Upper Mount	54123-93J03-0000
26	Upper Mount, Upper	54130-93J01-0000
27	Upper Mount Bolt, Mount (14X220)	54112-93J00-0000
28	Upper Mount Bolt Nut, (M14)	09159-14026-0000
29	Washer (15X24X3), (15X24X3)	09160-15051-0000
30	Upper Mount Cover, Upper Mount	54137-93J02-0000
31	Upper Mount Cover Bolt (10X95), (10X95)	09116-10135-0000
32	Suzuki Bolt (10X50)	09116-10175-0000
34	Mount, Upper Thrust Rev	54140-98J01-0000
35	Suzuki Bolt (10X70), (10X70)	09116-10137-0000
36	Suzuki Bolt (10X50)	09116-10175-0000
37	Suzuki Bolt (10X195)	09116-10146-0000
38	Bolt (10X115), (10X115)	09116-10134-0000
39	Suzuki Bolt, (8X65)	09116-08126-0000
40	Suzuki Washer (8.3X15X3), (8.3X15X3)	09169-08038-0000
41	Upper Mount Seal, Upper Mount	54144-93J01-0000

Exhaust Cover

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Exhaust Cover:

Position No.	Part Name	OEM Number
1	Cover, Exhaust STBD	14141-93J01-0000
2	Exhaust Port Cover, Exhaust Port	14140-98J00-0000
3	Exhaust Cover Gasket- STBD, Exhaust Cover STBD	14151-93J00-0000
4	Exhaust Cover Gasket- Port, Exhaust Cover Port	14152-93J00-0000
5	Anode Protection Cover, Protection Anode	11261-93J00-0000
6	Internal Protection Anode, Protection	55321-87J01-0000
7	Suzuki Anode Bolt (6x14), (6X14)	09103-06281-0000
8	Internal Anode O-Ring, (D:1.9,ID:21.8)	09280-22019-0000
9-1	Bolt	01550-08207-0000
9-2	Suzuki Bolt, (8X20)	01550-0820C-0000
10	Suzuki Bolt, (6X25)	01550-06257-0000

Fuel Hose (E01,E11)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Fuel Hose (E01,E11):

Position No.	Part Name	OEM Number
1-1	Hose, Fuel	65700-93J12-0000
1-2	Hose, Fuel	65700-93J14-0000
1-3	Clip
2	Primer Bulb, Squeeze	65770-93J13-0000
3-2	Suzuki Clip	09401-14409-0000

Fuel Injector (E01,E03,E11)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Fuel Injector (E01,E03,E11):

Position No.	Part Name	OEM Number
1	Hose, Fuel	15681-93J02-0000
18-1	Suzuki Bolt (8x40)	01550-08407-0000
23-1	Suzuki Bolt	01550-06127-0000
2	Fuel Injector, Fuel	15710-96J00-0000
18-2	Bolt	01550-0840C-0000
23-2	Suzuki Bolt, (6X12)	01550-0612C-0000
3	Fuel Injector O-Ring	15717-16G00-0000
4	Insulator, Delivery Pipe	15735-58B00-0000
5	Pipe, Delivery	15751-93J00-0000
6	Fuel Hose, Fuel	15756-93J01-0000
7	Gasket, Delivery Pipe	15762-93J00-0000
8	Union, Fuel Main	15830-77EA0-0000
9	Union, Delivery Pipe	15831-93J00-0000
10	Protector, Fuel Hose (L:340)	18498-93J01-0000
11	Plug (14X14), (14X14)	09247-14041-0000
12	Suzuki Cushion, (8.7X16.3X5.5)	09320-08062-0000
13	Suzuki Union Bolt, (14X27)	09360-14009-0000
14	Suzuki Hose Clamp	09401-11425-0000
15	Clamp	09403-16307-0000
16	Clamp, (ID:17.5,ID:11.5)	09408-00105-0000
17	Clamp	09408-00155-0000
19	Hose, Fuel Inlet	15680-93J40-0000
20	Suzuki Clip	09401-14409-0000
21	Clip	09408-00135-0000
22	Fuel Hose Guide, Fuel Hose	15684-98J00-0000
24	Plug, (OD:13.6)	09251-09009-0000

Fuel Pump/Fuel Vapor Separator ((020,021):(E01,E03,E11))

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Fuel Pump/Fuel Vapor Separator ((020,021):(E01,E03,E11)):

Position No.	Part Name	OEM Number
1	Low Pressure Fuel Pump, Fuel	15100-98J00-0000
2	Low Pressure Fuel Filter Assy, Fuel	15410-93J10-0000
3	Fuel Filter Cap, Fuel Filter	15411-93J10-0000
4	Fuel Filter O-Ring, Fuel Filter No.1	15415-93J10-0000
5	Low Pressure Fuel Filter, Fuel	15412-93J10-0000
6	Fuel Filter Case, Fuel Filter	15413-93J10-0000
7	Fuel Filter Cover, Fuel	15644-93J00-0000
8	Hose, Fuel	15633-93J20-0000
9	Fuel Hose (7.5X13.5X600)	09343-75001-600
10	High Pressure Fuel Filter, Fuel	15440-93J00-0000
11	Suzuki Cushion, (8X18X10)	09320-08501-0000
12	Fuel Hose Union (H), Fuel Hose	15773-90J10-0000
13	Union, Three Way Fuel Hose	15830-93J00-0000
14	Washer	09169-06093-0000
15	Fuel Cooler, Fuel	15770-93J00-0000
16	Suzuki Gasket (11.8X22X1.2), (11.8X22X1.2)	09168-12013-0000
17	Union Fuel Filter Bolt, (12X27)	09360-12008-0000
18	Union	09363-08004-0000
19	Fuel Separator Assy, Fuel Vapor	15600-98J21-0000
20	Needle Valve Assy, Needle	13370-93J00-0000
21	VST Seal, Separator	15626-93J00-0000
22	Suzuki Float Assy	15650-93J00-0000
23	High Pressure Fuel Pump, Fuel	15200-98J00-0000
24	Fuel Pump Bush, Fuel Pump	15647-93J00-0000
25	Spacer	15641-90J00-0000
26	Fuel Filter/Strainer	15642-90J00-0000
27	Suzuki Pin	15654-99E00-0000
28	Suzuki Screw	02142-0408B-0000
29	Screw	13602-05108-0000
30	Regulator, Fuel Pressure	15760-93J00-0000
31	Suzuki Screw (L:15), (L:15)	15628-99E00-0000
32	Screw	15627-93J00-0000
33	Silencer Bracket Cushion	09320-12094-0000
34	Bolt, Cooler Bracket	15675-93J00-0000
35	Fuel Hose (7.5X13.5X600)	09343-75001-600
36	Clip, (ID:11.5)	09401-11414-0000
37	Fuel Hose (L), Fuel	15636-93J30-0000
38	Fuel Hose NO.1 Clip, Fuel Hose No. 1	15685-93J00-0000
39	Bracket, Fuel Cooler	15672-93J10-0000
40	Bolt	01500-06167-0000
41	Hose, Fuel	15635-93J30-0000
42	Hose, Fuel	15632-93J30-0000
43	Bracket, Fuel Filter	15673-98J00-0000
44	Suzuki Bolt, (6X25)	01550-06257-0000
45	Fuel Filter, Fuel	15643-93J00-0000
46	Fuel Hose (7.5X13.5X600)	09343-75001-600
47	Hose, Fuel	15634-93J20-0000
48	Bolt (6X35), (6X35)	09116-06525-0000
49	Bracket, Check Valve	15674-93J00-0000
50	Fuel Pump By-Pass Valve, Check	15645-93J00-0000
51	Fuel Hose (L), Fuel	15637-93J30-0000
52	Drain Screw, Drain	15629-99E10-0000
53	Suzuki Hose, (L:120)	15683-87J00-0000
54	Screw	02112-0406B-0000
55	Hose (7X12X600)	09343-70503-600
56	Suzuki Clip	09401-11423-0000
57	Protector, Evap Hose (L:160)	18498-87J51-0000
58	Washer, (6.3X17X1.6)	09169-06062-0000
59	VST Bolt (6X25), (6X25)	09116-06202-0000
60	Bracket, Vapor Separator	15671-93J00-0000
61	Bolt, (6X35)	01550-06357-0000
62	Washer, (8.5X22X2)	09169-08042-0000
63	Suzuki Bolt (8x40)	01550-08407-0000
64	Purge Valve Bracket, Purge Valve	18417-93J00-0000
65	Suzuki Bolt	01550-06127-0000
66	Suzuki Cushion	09320-08520-0000
67	Clamp	09403-14304-0000
68	Clip	13671-02F00-0000
69	Bracket, Fuel Pump No.1	15114-93J00-0000
70	Bracket, Fuel Pump No.1	15115-93J02-0000
71	Union, Evaporation	15695-98L00-0000
72	Hose, Evaporation (5X8.2X1000)	09352-50003-00A
73	Suzuki Clip	09401-08412-0000
74	Clip, (D1:12,D2:8)	09408-00056-0000
75	Clip, (ID:12X2)	09408-00050-0000
76	Protector, Evap Hose (L:900)	18498-93J20-0000
77	Bolt	15118-93J00-0000

Fuel Pump/Fuel Vapor Separator (022:(E01,E03,E11))

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Fuel Pump/Fuel Vapor Separator (022:(E01,E03,E11)):

Position No.	Part Name	OEM Number
1	Low Pressure Fuel Pump, Fuel	15100-98J00-0000
2	Low Pressure Fuel Filter Assy, Fuel	15410-93J10-0000
3	Fuel Filter Cap, Fuel Filter	15411-93J10-0000
4	Fuel Filter O-Ring, Fuel Filter No.1	15415-93J10-0000
5	Low Pressure Fuel Filter, Fuel	15412-93J10-0000
6	Fuel Filter Case, Fuel Filter	15413-93J10-0000
7	Fuel Filter Cover, Fuel Filter	15644-93J00-0000
8	Hose	15633-93J20-0000
9	Fuel Hose (7.5X13.5X600)	09343-75001-600
10	High Pressure Fuel Filter, Fuel	15440-93J00-0000
11	Suzuki Cushion, (8X18X10)	09320-08501-0000
12	Fuel Hose Union (H), Fuel Hose	15773-90J10-0000
13	Union, Three Way Fuel Hose	15830-93J00-0000
14	Washer	09169-06093-0000
15	Fuel Cooler, Fuel	15770-93J00-0000
16	Suzuki Gasket (11.8X22X1.2), (11.8X22X1.2)	09168-12013-0000
17	Union Fuel Filter Bolt, (12X27)	09360-12008-0000
18	Union	09363-08004-0000
19	Fuel Separator Assy, Fuel Vapor	15600-93J50-0000
20	Needle Valve Assy, Needle	13370-93J00-0000
21	VST Seal, Separator	15626-93J00-0000
22	Suzuki Float Assy	15650-93J00-0000
23	High Pressure Fuel Pump, Fuel	15200-98J00-0000
24	Fuel Pump Bush, Fuel Pump	15647-93J00-0000
25	Spacer	15641-90J00-0000
26	Fuel Filter/Strainer	15642-90J00-0000
27	Suzuki Pin	15654-99E00-0000
28	Suzuki Screw	02142-0408B-0000
29	Screw	13602-05108-0000
30	Regulator, Fuel Pressure	15760-93J00-0000
31	Suzuki Screw (L:15), (L:15)	15628-99E00-0000
32	Screw	15627-93J00-0000
33	Silencer Bracket Cushion	09320-12094-0000
34	Bolt, Cooler Bracket	15675-93J00-0000
35	Fuel Hose (7.5X13.5X600)	09343-75001-600
36	Clip, (ID:11.5)	09401-11414-0000
37	Fuel Hose (L), Fuel	15636-93J30-0000
38	Fuel Hose NO.1 Clip, Fuel Hose No. 1	15685-93J00-0000
39	Bracket, Fuel Cooler	15672-93J10-0000
40	Bolt	01500-06167-0000
41	Hose, Fuel	15635-93J30-0000
42	Hose, Fuel	15632-93J30-0000
43	Bracket, Fuel Filter	15673-98J00-0000
44	Suzuki Bolt, (6X25)	01550-06257-0000
45	Fuel Filter, Fuel	15643-93J00-0000
46	Fuel Hose (7.5X13.5X600)	09343-75001-600
47	Hose, Fuel	15634-93J20-0000
48	Bolt (6X35), (6X35)	09116-06525-0000
49	Bracket, Check Valve	15674-93J00-0000
50	Fuel Pump By-Pass Valve, Check	15645-93J00-0000
51	Fuel Hose (L), Fuel	15637-93J30-0000
52	Drain Screw, Drain	15629-99E10-0000
53	Suzuki Hose, (L:120)	15683-87J00-0000
54	Screw	02112-0406B-0000
55	Hose (7X12X600)	09343-70503-600
56	Suzuki Clip	09401-11423-0000
57	Protector (15.4X18.4X70), (15.4X18.4X70)	18498-90J61-0000
58	Washer, (6.3X17X1.6)	09169-06062-0000
59	VST Bolt (6X25), (6X25)	09116-06202-0000
60	Bracket, Vapor Separator	15671-93J00-0000
61	Bolt, (8.5X22X2)	01550-06357-0000
62	Washer, (8.5X22X2)	09169-08042-0000
63	Bolt	01550-0840C-0000
64	Purge Valve Bracket, Purge Valve	18417-93J00-0000
65	Suzuki Bolt, (6X12)	01550-0612C-0000
66	Canister Purge Valve, Waste Gate Cont	18117-52G10-0000
67	Hose	09352-50003-080
68	Clip	13671-02F00-0000
69	Bracket, Fuel Pump No.1	15114-93J00-0000
70	Bracket, Fuel Pump No.2	15115-93J02-0000
71	Union, Evaporation	15695-98L00-0000
72	Hose	09352-50003-810
73	Suzuki Clip	09401-08412-0000
74	Clip, (D1:12,D2:8)	09408-00056-0000
75	Protector, Evap Hose (L:450)	18498-87JC1-0000
76	Protector, Hose	18498-87J01-0000
77	Bolt	15118-93J00-0000
78	Nut	08316-10067-0000
79	Clamp, (ID:17.5,ID:11.5)	09408-00105-0000

Gear Case (E01,E40)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Gear Case (E01,E40):

Position No.	Part Name	OEM Number
1-1	Gear Case Housing, Gear (Black)	55110-93L20-YAY
1-2	Gear Case Housing, Gear (White)	55110-93L20-Y5S
1-3	Gear Case Housing, Gear (White)	55110-93L20-QTN
1-4	Gear Case Housing, Gear (Black)	55110-93L20-YAY
1-11	DF250AP/300AP Trim Tab, Trim (Black)	55125-93L00-YAY
20-1	Propeller (3X16X17), (3X16X17)	58700-93L01-0000
22-1	SUZUKI Watergrip濠电姵娲╅幏绋碩ANDARD ROTATION STAINLESS STEEL PROPELLER, (3X15.5X17)	990C0-00840-17P
2	Suzuki Bearing (35X56X37), (35X56X37)	09263-35048-0000
22-2	SUZUKI Watergrip濠电姵娲╅幏绋碩ANDARD ROTATION STAINLESS STEEL PROPELLER, (3X15.25X19)	990C0-00840-19P
3	Bearing, (80X100X30)	09263-80001-0000
22-3	SUZUKI Watergrip濠电姵娲╅幏绋碩ANDARD ROTATION STAINLESS STEEL PROPELLER, (3X15X21)	990C0-00840-21P
4	Bolt (12X70), (12X70)	09100-12052-0000
22-4	SUZUKI Watergrip濠电姵娲╅幏绋碩ANDARD ROTATION STAINLESS STEEL PROPELLER, (3X14.75X23)	990C0-00840-23P
5	Gear Case Bolt (10X55)	09116-10141-0000
20-5	SUZUKI WATERGRIP濠电姵娲╅幏绋碩AINLESS STEEL STANDARD ROTATING PROPELLER (3 X 16 X ??)	990C0-00810-23P
22-5	Propeller (3X14.5X25), (3X14.5X25)	58700-96J40-0000
6	Suzuki Washer (10.5X19X2), (10.5X19X2)	09160-10141-0000
22-6	Propeller (3X14.5X27), (3X14.5X27)	58700-96J50-0000
7	Washer (12.5X22X2.5), (12.5X22X2.5)	09160-12066-0000
22-7	COUNTER ROATION STAINLESS STEEL PROPELLER	990C0-0084L-17P
8	Suzuki Nut, (M10)	09140-10031-0000
22-8	COUNTER ROATION STAINLESS STEEL PROPELLER	990C0-0084L-19P
9	Suzuki Nut, (12X17)	09159-12014-0000
22-9	COUNTER ROATION STAINLESS STEEL PROPELLER	990C0-0084L-21P
10	Suzuki Pin, (8X12)	09202-08006-0000
20-10	Propeller (4X15.25X18), (4X15.25X18)	58700-93J00-0000
22-10	Propeller (3X14.75X23), (3X14.75X23)	58800-96J30-0000
11-2	DF250AP/300AP Trim Tab, Trim (White)	55125-93L00-Y5S
11-3	DF250AP/300AP Trim Tab, Trim (White)	55125-93L00-QTN
11-4	DF250AP/300AP Trim Tab, Trim (Black)	55125-93L00-YAY
20-11	Suzuki Four Blade WaterGrip濠电姵娲╅幏绋皉opeller, (4X15.25X20)	990C0-00510-20P
22-11	Propeller (3X14.5X25), (3X14.5X25)	58800-96J40-0000
12	Trim Tab Bolt (8X22), (8X22)	09116-08137-0000
20-12	Propeller (4X15.25X22), (4X15.25X22)	58700-93J20-0000
22-12	Propeller (3X14.5X27), (3X14.5X27)	58800-96J50-0000
13	Gearcase Oil Drain Plug, Drain	55128-93J10-0000
14	Gear Oil Drain Plug Gasket, (9.5X16.5X2)	09168-10034-0000
15	Protection Anode, Protection	55321-93J01-0000
16	Anode Bolt (6X16), (6X16)	09116-06236-0000
17	Rubber, Exhaust Seal	55332-98J01-0000
18	Plate, Exhaust Seal	55333-98J00-0000
19	Suzuki Pin (6X12), (6X12)	09202-06031-0000
20-13	Propeller (4X15.25X24), (4X15.25X24)	58700-93J30-0000
20-14	Suzuki Four Blade WaterGrip濠电姵娲╅幏绋皉opeller, (4X15.25X26)	990C0-00510-26P
20-15	SUZUKI Watergrip濠电姵娲╅幏绋碩AINLESS STEEL COUNTER ROTATING PROPELLER (3 X 16 X ??), (3X16X17)	990C0-0081L-17P
20-16	Propeller (3X16X18.5), (3X16X18.5)	58800-93L10-0000
20-17	Propeller (3X16X20), (3X16X20)	58800-93L20-0000
20-18	Propeller (3X16X21.5), (3X16X21.5)	58800-93L30-0000
20-19	Propeller (3X16X23), (3X16X23)	58800-93L40-0000
20-20	SUZUKI Watergrip濠电姵娲╅幏绋碩AINLESS STEEL COUNTER ROTATING PROPELLER (3 X 16 X ??), (3X16X24.5)	990C0-0081L-245
20-21	Propeller (3X16X26), (3X16X26)	58800-93L60-0000
20-22	Propeller (4X15.25X20), (4X15.25X20)	58800-93J10-0000
20-23	Propeller (4X15.25X22), (4X15.25X22)	58800-93J20-0000
20-24	Propeller (4X15.25X24), (4X15.25X24)	58800-93J30-0000
20-25	Propeller (4X15.25X26), (4X15.25X26)	58800-93J40-0000
21	Watergrip濠电姵娲╅幏绋皉opeller Bushing, Propeller	58120-93L00-0000
23	Watergrip濠电姵娲╅幏绋皉opeller Bushing, Propeller	58120-93L00-0000
24	Watergrip濠电姵娲╅幏绋礹rust Washer, Propeller Bush	57632-93L10-0000
25	WaterGrip濠电姵娲╅幏绋皉opeller Nut Spacer, Propeller Nut	57633-93L00-0000
26	Propeller Nut, (M18)	09141-18005-0000
27	Washer (18.5X31X1), (18.5X31X1.0)	09160-18028-0000
28	Cotter Pin, (D:3.6,L:25)	09204-03003-0000
29	Gearcase Oil Drain Plug, Drain	55128-93L00-0000
30	Gearcase Oil Drain Plug, (12.5X22X2.5)	55128-93L00-0000
31	Watergrip濠电姵娲╅幏绋皉op Hardware Kit, Propeller Nut	57630-93L00-0000
32	DF250AP/300AP Gear Case Seal Kit, Gear Case Sealing	25700-93L01-0000

Gear Case (E03,E11)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Gear Case (E03,E11):

Position No.	Part Name	OEM Number
1-1	Gear Case Housing, Gear (Black)	55110-93L20-YAY
1-2	Gear Case Housing, Gear (White)	55110-93L20-Y5S
1-3	Gear Case Housing, Gear (White)	55110-93L20-QTN
1-4	Bolt (12X70), (12X70)	09100-12052-0000
1-5	Gear Case Bolt (10X55)	09116-10141-0000
1-11	DF250AP/300AP Trim Tab, Trim (Black)	55125-93L00-YAY
20-1	Propeller (3X16X17), (3X16X17)	58700-93L01-0000
22-1	SUZUKI Watergrip濠电姵娲╅幏绋碩ANDARD ROTATION STAINLESS STEEL PROPELLER, (3X15.5X17)	990C0-00840-17P
2	Suzuki Bearing (35X56X37), (35X56X37)	09263-35048-0000
22-2	SUZUKI Watergrip濠电姵娲╅幏绋碩ANDARD ROTATION STAINLESS STEEL PROPELLER, (3X15.25X19)	990C0-00840-19P
3	Bearing, (80X100X30)	09263-80001-0000
22-3	SUZUKI Watergrip濠电姵娲╅幏绋碩ANDARD ROTATION STAINLESS STEEL PROPELLER, (3X15X21)	990C0-00840-21P
4-1	Gear Case Housing, Gear (Black)	55110-93L20-YAY
4-2	Bolt (12X70), (12X70)	09100-12052-0000
4-11	DF250AP/300AP Trim Tab, Trim (Black)	55125-93L00-YAY
22-4	SUZUKI Watergrip濠电姵娲╅幏绋碩ANDARD ROTATION STAINLESS STEEL PROPELLER, (3X14.75X23)	990C0-00840-23P
5-2	Gear Case Bolt (10X55)	09116-10141-0000
20-5	SUZUKI WATERGRIP濠电姵娲╅幏绋碩AINLESS STEEL STANDARD ROTATING PROPELLER (3 X 16 X ??)	990C0-00810-23P
22-5	Propeller (3X14.5X25), (3X14.5X25)	58700-96J40-0000
6	Suzuki Washer (10.5X19X2), (10.5X19X2)	09160-10141-0000
22-6	Propeller (3X14.5X27), (3X14.5X27)	58700-96J50-0000
7	Washer (12.5X22X2.5)	09160-12066-0000
22-7	COUNTER ROATION STAINLESS STEEL PROPELLER	990C0-0084L-17P
8	Suzuki Nut, (M10)	09140-10031-0000
22-8	COUNTER ROATION STAINLESS STEEL PROPELLER	990C0-0084L-19P
9	Suzuki Nut, (12X17)	09159-12014-0000
22-9	COUNTER ROATION STAINLESS STEEL PROPELLER	990C0-0084L-21P
10	Suzuki Pin, (8X12)	09202-08006-0000
20-10	Propeller (4X15.25X18), (4X15.25X18)	58700-93J00-0000
22-10	Propeller (3X14.75X23), (3X14.75X23)	58800-96J30-0000
11-2	DF250AP/300AP Trim Tab, Trim (White)	55125-93L00-Y5S
11-3	DF250AP/300AP Trim Tab, Trim (White)	55125-93L00-QTN
20-11	Suzuki Four Blade WaterGrip濠电姵娲╅幏绋皉opeller, (4X15.25X20)	990C0-00510-20P
22-11	Propeller (3X14.5X25), (3X14.5X25)	58800-96J40-0000
12	Trim Tab Bolt (8X22), (8X22)	09116-08137-0000
20-12	Propeller (4X15.25X22), (4X15.25X22)	58700-93J20-0000
22-12	Propeller (3X14.5X27), (3X14.5X27)	58800-96J50-0000
13	Gearcase Oil Drain Plug, Drain	55128-93J10-0000
14	Gear Oil Drain Plug Gasket, (9.5X16.5X2)	09168-10034-0000
15	Protection Anode, Protection	55321-93J01-0000
16	Anode Bolt (6X16), (6X16)	09116-06236-0000
17	Rubber, Exhaust Seal	55332-98J01-0000
18	Plate, Exhaust Seal	55333-98J00-0000
19	Suzuki Pin (6X12), (6X12)	09202-06031-0000
20-13	Propeller (4X15.25X24), (4X15.25X24)	58700-93J30-0000
20-14	Suzuki Four Blade WaterGrip濠电姵娲╅幏绋皉opeller, (4X15.25X26)	990C0-00510-26P
20-15	SUZUKI Watergrip濠电姵娲╅幏绋碩AINLESS STEEL COUNTER ROTATING PROPELLER (3 X 16 X ??), (3X16X17)	990C0-0081L-17P
20-16	Propeller (3X16X18.5), (3X16X18.5)	58800-93L10-0000
20-17	Propeller (3X16X20), (3X16X20)	58800-93L20-0000
20-18	Propeller (3X16X21.5), (3X16X21.5)	58800-93L30-0000
20-19	Propeller (3X16X23), (3X16X23)	58800-93L40-0000
20-20	SUZUKI Watergrip濠电姵娲╅幏绋碩AINLESS STEEL COUNTER ROTATING PROPELLER (3 X 16 X ??), (3X16X24.5)	990C0-0081L-245
20-21	Propeller (3X16X26), (3X16X26)	58800-93L60-0000
20-22	Propeller (4X15.25X20), (4X15.25X20)	58800-93J10-0000
20-23	Propeller (4X15.25X22), (4X15.25X22)	58800-93J20-0000
20-24	Propeller (4X15.25X24), (4X15.25X24)	58800-93J30-0000
20-25	Propeller (4X15.25X26), (4X15.25X26)	58800-93J40-0000
21	Watergrip濠电姵娲╅幏绋皉opeller Bushing, Propeller	58120-93L00-0000
23	Watergrip濠电姵娲╅幏绋皉opeller Bushing, Propeller	58120-93L00-0000
24	Watergrip濠电姵娲╅幏绋礹rust Washer, Propeller Bush	57632-93L10-0000
25	WaterGrip濠电姵娲╅幏绋皉opeller Nut Spacer, Propeller Nut	57633-93L00-0000
26	Propeller Nut, (M18)	09141-18005-0000
27	Washer (18.5X31X1), (18.5X31X1.0)	09160-18028-0000
28	Cotter Pin, (D:3.6,L:25)	09204-03003-0000
29	Gearcase Oil Drain Plug, Drain	55128-93L00-0000
30	Washer (12.5X22X2.5)	09160-12066-0000
31	Watergrip濠电姵娲╅幏绋皉op Hardware Kit, Propeller Nut	57630-93L00-0000
32	DF250AP/300AP Gear Case Seal Kit, Gear Case Sealing	25700-93L01-0000

Harness

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Harness:

Position No.	Part Name	OEM Number
1	Battery Cable Assy, Starter Motor (L:4 00)	33810-93J01-0000
24-1	Clamp, (L:145)	09407-14407-0000
25-1	Suzuki Clamp (ID:20), (ID:20)	09408-00008-0000
2	Nut	08316-10087-0000
24-2	Clamp, (L:145)	09407-14407-0000
25-2	Suzuki Clamp (ID:20), (ID:20)	09408-00008-0000
3-1	Engine Harness Assy, Wiring	36610-98J82-0000
3-2	Engine Harness Assy, Wiring	36610-98J82-0000
3-3	Engine Harness Assy, Wiring	36610-98JA0-0000
4	Suzuki Fuse (10A), (10A)	09481-10504-0000
5	SPC Selector Connector, Select Terminal	36612-98J10-0000
6	Upper Cover O-Ring, UPR Cover	36721-98L10-0000
7	Puller, Fuse	36737-98L00-0000
8	Cover, Fuse Case UPR	36738-98L00-0000
9	Suzuki Cushion (8.5X20X8), (8.5X20X8)	09320-08510-0000
10	Suzuki Relay Assy	38860-76F01-0000
11	Suzuki Relay Assy	38860-76F01-0000
12	Suzuki Fuse (15A), (15A)	09481-15504-0000
13	Fuse (30A), (30A)	09481-30504-0000
14	Fuse (40A), (40A)	09481-40403-0000
15	Fuse (60A), (60A)	09481-60403-0000
16	Terminal Cap, Terminal	36612-96J01-0000
17	Nut	08310-00067-0000
18	Washer, Lock	08321-01067-0000
19	Bracket, Harness	36617-93J00-0000
20	Harness Bracket, Harness	36617-93J10-0000
21	Bracket, Harness	36617-98J00-0000
22	Suzuki Bolt, (6X12)	01550-0612C-0000
23	Clamp	09403-20308-0000
26	Clamp	09408-00184-0000
27	Clip (ID:11.5), (ID:11.5)	09408-00012-0000
28	Clip (ID:23), (ID:23)	09408-00024-0000
29	Suzuki Bolt	01550-06127-0000

Intake Manifold

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Intake Manifold:

Position No.	Part Name	OEM Number
1	Manifold, Intake	13110-98J10-0000
2	Intake Manifold Gasket, Intake Manifold	13119-98J00-0000
3	Stud Bolt, Stud	09108-08282-0000
4	Bolt (8X65), (8X65)	09103-08437-0000
5	Nut, (N8)	09159-08136-0000
6	Washer (8.2X23X3.2)	09160-08161-0000

Key Less Start (020:(E01,E03),021:E11)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Key Less Start (020:(E01,E03),021:E11):

Position No.	Part Name	OEM Number
1	Cushion, Lead Wire	32851-93J00-0000
2	Holder, CDI Unit	32980-38F00-0000
3	Harness Assy, KLS Controller	36623-96L02-0000
4	Terminal	36615-96300-0000
5	Harness Assy, KLS Can (L:6500+ 10)	36662-96L01-0000
6	Decal, KLS	37117-96L00-0000
7-1	Controller Assy, KLS (433MHZ)	37171-96L02-0000
7-2	Controller Assy, KLS (315MHZ)	37171-96L12-0000
8-1	Remocon Assy, KLS (433MHZ)	37172-96L01-0000
8-2	Remocon Assy, KLS (315MHZ)	37172-96L10-0000
9	Holder, KLS Parts	37173-96L10-0000
10	Warning Buzzer, Warning	38500-93J90-0000
11	Relay Assy, KLS	38860-96L01-0000
12	Clamp, (L:145)	09407-14407-0000

Key Less Start (022:E11)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Key Less Start (022:E11):

Position No.	Part Name	OEM Number
1	Cushion, Lead Wire	32851-93J00-0000
2	Holder, CDI Unit	32980-38F00-0000
3	Harness Assy, KLS Cont	36623-98LA0-0000
4	Decal, KLS	37117-96L00-0000
5-1	Controller Assy, KLS 433 (433M Z)	37171-98L00-0000
5-2	Controller Assy, KLS 315 (315M Z)	37171-98L10-0000
6-1	Remocon Assy, KLS 433	37172-96L02-0000
6-2	Keyless Start Replacement Key, KLS 315	37172-96L11-0000
7	Holder, KLS Parts	37173-96L10-0000
8	Relay Assy, KLS	38860-96L01-0000
9	Clamp, (L:145)	09407-14407-0000

Magneto

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Magneto:

Position No.	Part Name	OEM Number
1-2	Flywheel, Magneto	32102-98J11-0000
1-4	Battery Charging Coil, Battery Charging	32120-93J00-0000
1-6	Suzuki Bolt, (6X16)	01550-06167-0000
1-11	Suzuki Bolt, (6X16)	01550-06167-0000
14-1	Suzuki Bolt	01550-06127-0000
2	Bolt (12X26), (12X26)	09103-12125-0000
14-2	Suzuki Bolt, (6X12)	01550-0612C-0000
3	Suzuki Pin (6X12), (6X12)	09202-06031-0000
4-2	Battery Charging Coil, Battery Charging	32120-93J01-0000
5	Holder, Stator Connector	32131-93J00-0000
6-2	Suzuki Bolt, (6X16)	01550-0616C-0000
7	Ignition Timing Coil (CKP Sensor), IGN Timing	32160-88L00-0000
8	Bolt (5X10), (5X10)	09106-05030-0000
9	CMP Sensor Assy, CMP	33220-69J00-0000
10	O Ring	33221-42F00-0000
11-2	Suzuki Bolt, (6X16)	01550-0616C-0000
12	Suzuki Bolt (6X35), (6X35)	09103-06231-0000
13	Clamp	09403-13414-0000

OPT: Gasket Set (E01,E03,E11)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ OPT: Gasket Set (E01,E03,E11):

Position No.	Part Name	OEM Number
1	Suzuki Gasket Set	11410-98830-0000
2	Cylinder Head Gasket (STBD), Cylinder Head STBD	11141-98J10-0000
3	Cylinder Head Gasket (PORT), Cylinder Head Port	11142-98J10-0000
4	Cylinder Head Cover Gasket (STBD), Head Cover STBD	11179-93J00-0000
5	Cylinder Head Cover Gasket (PORT), Head Cover Port	11189-93J00-0000
6	Water Jacket Cover Gasket, Crankcase WTR JKT Cov R	11332-93J00-0000
7	Intake Manifold Gasket, Intake Manifold	13119-98J00-0000
8	Exhaust Cover Gasket- STBD, Exh Cover STBD	14151-93J00-0000
9	Exhaust Cover Gasket- Port, Exh Cover Port	14152-93J00-0000
10	Pump Case Panel Gasket, Pump Case Panel	17472-98J00-0000
11	Cylinder Block Gasket, Cylinder Block Plate	11272-93J00-0000
12	Gasket, Oil Pan	11489-93J00-0000
13	Exhaust Tube Gasket, Exhaust Tube	14212-93J00-0000
14	Motor Mount Cover Gasket, Mount Oil Seal Cover	51123-93J00-0000
15	Engine Holder Gasket, Engine Holder Cover	51142-93J00-0000
16	Engine Base Gasket, Engine Cover	51211-93J00-0000

OPT: Harness (1) (020,021)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ OPT: Harness (1) (020,021):

Position No.	Part Name	OEM Number
1-10	Boat Control Module (BCM), Boat Electric	36770-98J13-0000
24-1	SPC Selector Connector - Counter Rotating, Counter Select	36612-98J20-0000
2	Battery Isolator Charge Lead	33830-98J11-0000
24-2	SPC Selector Connector - Counter Rotating, Counter Select	36612-98J20-0000
3	Suzuki Clamp, (L:100)	09407-10404-0000
4	Fuse (40A)	09481-40401-0000
5	BCM Connector Cap, Rubber	33911-88BL0-0000
6	BCM Cushion, Engine Control Unit	33925-93J00-0000
7	SPC 1.0 Terminal Resistor, Terminal	33926-98J00-0000
8	SPC 1.0 BCM Harness Assy, BCM No.1 For SNG	36623-98J21-0000
9	Terminal	36615-96300-0000
10-2	Boat Control Module (BCM), Boat Electric	36770-98J22-0000
11	BCM Holder (Left)	36775-98J00-0000
12	BCM Holder (Right)	36776-98J00-0000
13	SPC 1.0 Dual Station Harness, Dual Station, MAI	36622-98J00-0000
14	Fuse (10A)	09481-10501-0000
15	SPC 1.0 Second Station BCM Harness, BCM No.2 For SNG	36624-98J02-0000
16	Terminal	36615-96300-0000
17	SPC 1.0 Dual Engine Harness, Dual Engine	36621-98J00-0000
18	SPC 1.0 Triple Engine BCM Harness Assy, No.1 For MUL	36623-98J30-0000
19	Terminal	36615-96300-0000
20	SPC 1.0 Second Station Engine BCM Harness, BCM No.2 For MUL	36624-98J11-0000
21	Terminal	36615-96300-0000
22	SPC 1.0 Triple Engine Harness, Triple Engine	36621-98J10-0000
23	Suzuki Clamp (ID:13)	09403-13402-0000
25	Terminal Set & Sleeve Set	36990-87D00-0000
26	SMG4 Extension Wire, Gauge EXT	36667-96L20-0000

OPT: Harness (1) (022)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ OPT: Harness (1) (022):

Position No.	Part Name	OEM Number
1	21FT SPC 2.0 Main Wiring Harness, Remote Control (L:6 00)	36620-98L00-0000
2	Battery Isolator Charge Lead, Battery Isolator Lead	33830-98J11-0000
3	Suzuki Clamp, (L:100)	09407-10404-0000
4	Fuse (40A)	09481-40401-0000
5	BCM Cushion, Engine Control Unit	33925-98L00-0000
6	SPC 2.0 Terminal Resistor, Terminal	33926-98L00-0000
7	SPC 2.0 Single Engine BCM Harness Assy, BCM No.1 SNGL	36623-98L00-0000
9	BCM Holder (F), BCM	36775-98L00-0000
10	BCM Holder (R), BCM	36776-98L00-0000
11	SPC 2.0 Dual Station Wiring Harness, Dual Station MAI	36622-98L00-0000
12	SPC 2.0 Second Station BCM Harness, BCM No.2 SNGL	36624-98L00-0000
13	SPC 2.0 Dual Engine Harness, Dual Engine	36621-98L00-0000
14	SPC 2.0 BCM Harness Assy, BCM No.1 For MUL	36623-98L10-0000
15	SPC 2.0 Second Station BCM Harness, BCM No.2 Multi	36624-98L10-0000
16	SPC 2.0 Second Station BCM Harness, BCM No.2 QDRPL	36624-98L20-0000
17	SPC Selector Connector - Counter Rotating, Counter Select	36612-98J20-0000
18	SMG4 2.0 2FT Gauge Extension Cable, Gauge EXT	36667-96L60-0000
19	Terminal Set & Sleeve Set	36990-87D00-0000
20	Suzuki Clamp (ID:13)	09403-13402-0000
21	Relay Assy	38860-96L10-0000
22	Signal Con Unit, Signal Converter	37140-98L00-0000

OPT: Harness (2) (020,021)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ OPT: Harness (2) (020,021):

Position No.	Part Name	OEM Number
1	Battery Sub-Lead Harness, Battery (L:2250)	36625-98J10-0000
2	Suzuki Fuse (30A), (30A)	09481-30501-0000
3	SPC 1.0 Quad Engine BCM Harness Assy, BCM For Quadropl	36623-98J40-0000
4	Terminal	36615-96300-0000
5	Harness Comp, R/Con Extension	36627-98J00-0000
6	Flush Connector, Flush Water	17917-87L00-0000

OPT: Harness (2) (022)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ OPT: Harness (2) (022):

Position No.	Part Name	OEM Number
1-1	Battery Sub-Lead Harness, Battery (L:2250)	36625-98J10-0000
1-2	Battery Sub-Lead Harness, Battery (L:6100)	36625-98J20-0000
2	Suzuki Fuse (30A)	09481-30501-0000
3	SPC 2.0 Quad Engine BCM Harness Assy, No.1 For QDRPL	36623-98L40-0000
4	SPC 2.0 R/C Extension Harness, R/Con EXT	36627-98L00-0000
5	EM Switch EXT Harness, EM Switch EXT	36627-98L10-0000
6	Flush Connector, Water	17917-87L00-0000

OPT: Key Less Start ((020,021):(E01,E03,E11))

Below is the parts list for Suzuki 2022 DF 250AP-240001~ OPT: Key Less Start ((020,021):(E01,E03,E11)):

Position No.	Part Name	OEM Number
1-3	Ignition Key (931)	37141-99E00-0000
21-1	Controller Set, KLS (315MHZ)	37170-96L15-0000
23-1	Controller Assy, KLS (433MHZ)	37171-96L02-0000
24-1	Remocon Assy, KLS (433MHZ)	37172-96L01-0000
2	Switch Assy, Main	37110-96L00-0000
21-2	Controller Set, KLS (433MHZ)	37170-96L05-0000
23-2	Controller Assy, KLS (315MHZ)	37171-96L12-0000
24-2	Remocon Assy, KLS (315MHZ)	37172-96L10-0000
3-2	Ignition Key (932)	37141-99E10-0000
3-3	Ignition Key (933)	37141-99E20-0000
3-4	Ignition Key (934)	37141-99E30-0000
3-5	Ignition Key (935)	37141-99E40-0000
3-6	Ignition Key (936)	37141-99E50-0000
4	Knob, Main Switch	37143-96L00-0000
5	Sheet, Main SW Panel	37114-98J00-0000
6	Panel, Main Switch	37139-96L30-0000
7	Kill Switch Assy, Emergency	37820-93J11-0000
8	Emergency Stop Switch Lanyard, Emergency SW Loc	37823-92E01-0000
9	Nut	37826-92J10-0000
10	Screw	03122-05169-0000
11	Harness Set, KLS Controller	37105-96L04-0000
12	Holder, CDI Unit	32980-38F00-0000
13	Harness Assy, KLS Controller	36623-96L02-0000
14	Terminal	36615-96300-0000
15	Harness Assy, KLS Can (L:6500 110)	36662-96L01-0000
16	Holder, KLS Parts	37173-96L10-0000
17	Warning Buzzer, Warning	38500-93J90-0000
18	Relay Assy, KLS	38860-96L01-0000
19	Cushion, Lead Wire	32851-93J00-0000
20	Clamp, (L:145)	09407-14407-0000
22	Decal, KLS	37117-96L00-0000
25	Wire, KLS Can EXT	36663-96L00-0000
26	Harness Assy, KLS Can (L:810+1 0)	36664-96L00-0000
27	Holder, KLS Parts	37173-96L00-0000

OPT: Key Less Start (022)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ OPT: Key Less Start (022):

Position No.	Part Name	OEM Number
1	SPC 2.0 Modular Push Button Ignition, Eng Start SW	37290-98L00-0000
14-1	KIT, KLS	37105-98L00-0000
19-1	Controller Assy, KLS 433 (433 HZ)	37171-98L00-0000
20-1	Remocon Assy, KLS 433	37172-96L02-0000
2	Cover, Eng Start Panel	37292-98L00-0000
14-2	Keyless Start System, KLS	37105-98L10-0000
19-2	Controller Assy, KLS 315 (315 HZ)	37171-98L10-0000
20-2	Keyless Start Replacement Key, KLS 315	37172-96L11-0000
3	Screw	03141-0516A-0000
4	SPC 2.0 Vertical Push Button Panel, Eng Start SW Vert	37290-98L10-0000
5	Cover, Eng Start Panel Vert	37292-98L10-0000
6	SPC 2.0 Kill Switch Assy, Emergency	37820-98L00-0000
7	Emergency Stop Switch Lanyard, Emergency SW Loc	37823-98L01-0000
8	Screw	03141-0516A-0000
9	SPC 2.0 Horizontal Push Button Panel, Eng Start SW Horiz	37290-98L20-0000
10	Cover, Eng Start Panel Horiz	37292-98L20-0000
11	SPC 2.0 Kill Switch Assy, Emergency	37820-98L00-0000
12	Emergency Stop Switch Lanyard, Emergency SW Lock	37823-98L01-0000
13	Screw	03141-0516A-0000
15	Cushion, Lead Wire	32851-93J00-0000
16	Holder, CD Unit	32980-38F00-0000
17	Harness Assy, KLS Cont	36623-98LA0-0000
18	Decal, KLS	37117-96L00-0000
21	Holder, KLS Parts	37173-96L10-0000
22	Relay Assy, KLS	38860-96L01-0000
23	Clamp, (L:145)	09407-14407-0000
24	CAN Extension Harness (SPC 2.0), Can Ext	36627-98L20-0000

OPT: Multi Function Gauge (1) (020,021)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ OPT: Multi Function Gauge (1) (020,021):

Position No.	Part Name	OEM Number
1	SPC 1.0 SMG4 Gauge Display Kit, Single Gauge Electric	34000-96L63-0000
3	Gauge Nut, Gauge	34112-96L00-0000
4	SMG4 Gauge Bezel, Gauge	34193-96L00-0000
5	SMG4 Gauge Cover, Gauge	34211-96L00-0000
6	Gauge Packing, Gauge	34825-96L00-0000
7	SMG4 Gauge Harness- SPC 1.0, Gauge	36661-96L20-0000
8	Terminal	36615-96300-0000
9	Kit, Dual Gauge Electric	34000-96L76-0000
11	Gauge Nut, Gauge	34112-96L00-0000
12	SMG4 Gauge Bezel, Gauge	34193-96L00-0000
13	SMG4 Gauge Cover, Gauge	34211-96L00-0000
14	Gauge Packing, Gauge	34825-96L00-0000
15	SMG4 Gauge Harness- SPC 1.0, Gauge	36661-96L20-0000
16	Terminal	36615-96300-0000
17	Wire, 2 Extension	36662-88L10-0000
18	Harness Assy, Network Power	36663-88L00-0000
19	Connector, Branch	36664-88L00-0000
20	Unit, Resistor Female	36665-88L00-0000
22	SMG4 SPC 1.0 Dual Gauge Adapter, Gauge Adapter (L:100+10 )	36667-96L00-0000
23	SMG4 Second Gauge Adapter, Gauge Adapter	36667-96L11-0000
24	SMG4 Gauge Adapter Tanks 3-4, Gauge Adapter	36667-96L30-0000

OPT: Multi Function Gauge (1) (022)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ OPT: Multi Function Gauge (1) (022):

Position No.	Part Name	OEM Number
2	Gauge Nut, Gauge	34112-96L00-0000
3	SMG4 Gauge Bezel, Gauge	34193-96L00-0000
4	SMG4 Gauge Cover, Gauge	34211-96L00-0000
5	Gauge Packing, Gauge	34825-96L00-0000
6	Gauge Set, Multi	34011-96L50-0000
7	Gauge Nut, Gauge	34112-96L00-0000
8	SMG4 Gauge Bezel, Gauge	34193-96L00-0000
9	SMG4 Gauge Cover, Gauge	34211-96L00-0000
10	Gauge Packing, Gauge	34825-96L00-0000
11	Wire, 2 Extension	36662-88L10-0000
12	Harness Assy, Network Power	36663-88L00-0000
13	Connector, Branch	36664-88L00-0000
14	Unit, Resistor Female	36665-88L00-0000
16	SMG4 2.0 Dual Gauge Adapter, Dual Gauge Adapter	36667-96L40-0000
17	SMG4 2.0 Dual Gauge Adapter, Dual Gauge Adapter	36667-96L50-0000

OPT: Multi Function Gauge (2) (020,021)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ OPT: Multi Function Gauge (2) (020,021):

Position No.	Part Name	OEM Number
1	Kit, Dual Station	34002-96L16-0000
3	Gauge Nut, Gauge	34112-96L00-0000
4	SMG4 Gauge Bezel, Gauge	34193-96L00-0000
5	SMG4 Gauge Cover, Gauge	34211-96L00-0000
6	Gauge Packing, Gauge	34825-96L00-0000
7	Wire, 2 Extension	36662-88L10-0000
8	Connector, Branch	36664-88L00-0000
9	Dual Station Adapter, Dual Station	36665-96L00-0000
10	Gauge Power Adapter (Dual Station), Gauge Power	36666-96L00-0000
11	Extension Wire, Trim Meter Ext (L:6500)	36682-92E00-0000
13	Gauge Nut, Gauge	34112-96L00-0000
14	SMG4 Gauge Bezel, Gauge	34193-96L00-0000
15	SMG4 Gauge Cover, Gauge	34211-96L00-0000
16	Gauge Packing, Gauge	34825-96L00-0000
18	Wire, 2 Extension	36662-88L10-0000
19	Harness Assy, Network Power	36663-88L00-0000
20	Connector, Branch	36664-88L00-0000
21	Unit, Resistor Female	36665-88L00-0000
24	Wire, 6 Extension	36662-88L20-0000
25	Wire, 15 Extension	36662-88L30-0000
26	Module Assy, GPS Reciever	39950-88L02-0000
27	Wire, 25 Extension	36662-88L00-0000
28	Harness Assy, Network Power	36663-88L00-0000
29	Unit, Resistor Female	36665-88L00-0000
31	Wire, 2 Extension	36662-88L10-0000
32	Connector, Branch	36664-88L00-0000

OPT: Multi Function Gauge (2) (022)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ OPT: Multi Function Gauge (2) (022):

Position No.	Part Name	OEM Number
2	Gauge Nut, Gauge	34112-96L00-0000
3	SMG4 Gauge Bezel, Gauge	34193-96L00-0000
4	SMG4 Gauge Cover, Gauge	34211-96L00-0000
5	Gauge Packing, Gauge	34825-96L00-0000
6	Gauge Set, Multi	34011-96L50-0000
7	Gauge Nut, Gauge	34112-96L00-0000
8	SMG4 Gauge Bezel, Gauge	34193-96L00-0000
9	SMG4 Gauge Cover, Gauge	34211-96L00-0000
10	Gauge Packing, Gauge	34825-96L00-0000
11	Set, Wire	36001-88L00-0000
12	Wire, 2 Extension	36662-88L10-0000
13	Harness Assy, Network Power	36663-88L00-0000
14	Connector, Branch	36664-88L00-0000
15	Unit, Resistor Female	36665-88L00-0000
18	Wire, 6 Extension	36662-88L20-0000
19	Wire, 15 Extension	36662-88L30-0000
20	Module Assy, GPS Receiver	39950-88L02-0000
21	Wire, 25 Extension	36662-88L00-0000
22	Harness Assy, Network Power	36663-88L00-0000
23	Unit, Resistor Femal	36665-88L00-0000
25	Wire, 2 Extension	36662-88L10-0000
26	Connector, Branch	36664-88L00-0000

OPT: Remote Control Assy Dual (020,021)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ OPT: Remote Control Assy Dual (020,021):

Position No.	Part Name	OEM Number
1	Remote Control Assy, Multiple	67200-98J16-0000
1-1	21FT SPC 1.0 Main Wiring Harness, Remote Control (L:6 00)	36620-98J31-0000
1-2	31FT SPC 1.0 Main Wiring Harness, Remote Control (L:9 00)	36620-98J41-0000
2	Housing	67211-98J20-0000
3	Lever, Handle	67251-98J00-0000
4	Shaft, Drive Remocon	67246-98J10-0000
5	NO.1 Grip, No.1	67261-98J00-0000
6	Grip, No.2	67261-98J10-0000
7	Cover, Lever	67263-98J00-0000
8	Dual Control Box Cover, Remocon Upper	67212-98J30-0000
9	Cover, Remocon Bottom	67271-98J40-0000
10	Panel Assy, Back	67222-98J10-0000
11	Rooler, Detent	67236-98J10-0000
12	Guide, Detent Roller	67235-98J10-0000
13	Spring, Detent	67237-98J40-0000
14	Holder, Detnet Spring	67233-98J10-0000
15	Suzuki Nut, (M5)	67287-92E00-0000
16	Screw, Detent Adjustment (5X1 )	67239-98J00-0000
17	Pad, Brake	67223-98J00-0000
18	Screw (5X18)	67296-98J50-0000
19	Screw, (4X10)	67296-98JA0-0000
20	Grommet, Remocon Cover	67272-98J10-0000
21	Bush, Drive Shaft	67252-98J10-0000
22	Washer	67288-98J20-0000
23	C-Ring	67292-98J00-0000
24	Suzuki Potentiometer	15980-98J00-0000
25	Lever, Potentiometer No.2	67227-98J10-0000
26	SPC Trim Switch Assy, PTT	37850-98J02-0000
27	Clamp, Lead	67269-98J01-0000
28	Packing	67273-98J20-0000
29	Screw (8X30)	67296-98J60-0000
30	Screw (5X70)	67296-98J30-0000
31	Screw (5X14)	67296-98JG0-0000
32	Screw (5X12)	67296-98J00-0000
33	Screw (4X10)	67296-94300-0000
34	Washer, Bottom Cover	67288-98J40-0000
35	Washer, Potentiometer	67288-98J00-0000
36	Suzuki Washer	67288-92E20-0000
37	Suzuki Bolt (5X50)	67226-98J00-0000
38	Washer (5.5X16X1.5)	09160-05024-0000
39	Suzuki Nut, (M5)	67287-92E00-0000
40	Screw, (8X30)	67296-98J90-0000
41	Lever, Potentiometerr No.1	67227-98J00-0000
42	Suzuki Mark (F-N-R)	67284-98J10-0000
43	Mark, Lever	67257-98J00-0000
44	Band	67269-98J30-0000
45	Washer, Spring	67288-98J10-0000
46	Washer, Lever Cover	67288-98J30-0000
47	Washer, Wave	67228-98J50-0000
48	Housing, Remocon	67211-98J30-0000
49	Panel Assy, Back	67222-98J20-0000
50	Shaft, Drive Remocon	67246-98J20-0000
51	Packing (Front)	67273-98J10-0000
52	Packing (Rear)	67273-98J30-0000
53	Grommet, Remocon Bottom Cover	67277-98J00-0000
54	Bolt (5X14), Upper Cover	67296-98JF0-0000
55	Nut, Upper Cover Bolt	67297-98J00-0000
56	Spring, Detent	67237-98J50-0000
57	Harness, Condenser Adapter	36890-98J00-0000

OPT: Remote Control Assy Dual (022)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ OPT: Remote Control Assy Dual (022):

Position No.	Part Name	OEM Number
1	Multiple Engine Control Box- SPC 2.0, Multiple Top Mount	67200-98L10-0000
26-1	21FT SPC 2.0 Main Wiring Harness, Remote Control (L:6 00)	36620-98L00-0000
2	Switch Assy, Boat Control	37130-98L10-0000
26-2	31FT SPC 2.0 Main Wiring Harness, Remote Control (L:9 00)	36620-98L10-0000
3	Power Trim and Tilt Switch, PTT	37850-98L00-0000
26-3	6.5FT SPC 2.0 Wiring Harness Extension, Remote Control Ext L:2000)	36620-98L20-0000
4	Cover, R/Con Upper	67212-98L10-0000
5	Mark, Handle Lever	67284-98L00-0000
6	Mark, Handle Lever	67284-98L10-0000
7	Emblem, Mark	68111-88L00-0000
8	Suzuki Bolt (5X50), (5X50)	67226-98J00-0000
9	Grip, R/Con No.1	67261-98L00-0000
10	Grip, R/Con No.2	67261-98L10-0000
11	Grip, R/Con No.3	67261-98L20-0000
12	Clamp, Lead	67269-98L00-0000
13	Dual Control Bottom Cover, R/Con Bottom	67271-98L10-0000
14	Grommet, R/Con Cover	67272-98L10-0000
15	Packing, R/Con	67273-98L10-0000
16	Grommet, R/Con Grip	67277-98L10-0000
17	Grommet, R/Con Bottom Cover	67277-98L20-0000
18	Suzuki Nut, (M5)	67287-92E00-0000
19	Washer, Bottom Cover	67288-98J40-0000
20	Screw (5X18)	67296-98J50-0000
21	Screw	67296-98L00-0000
22	Bolt, Upper Cover	67296-98L10-0000
23	Nut, Upper Cover Bolt	67297-98J00-0000
24	Washer (5.5X16X1.5)	09160-05024-0000
25	Screw	67296-88D00-0000
27	Warning Buzzer, Warning	38500-93J90-0000
28	Warning Buzzer Clamp	09407-14403-0000

OPT: Remote Control Assy Single (020,021)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ OPT: Remote Control Assy Single (020,021):

Position No.	Part Name	OEM Number
1-1	21FT SPC 1.0 Main Wiring Harness, Remote Control (L:6 00)	36620-98J31-0000
1-2	31FT SPC 1.0 Main Wiring Harness, Remote Control (L:9 00)	36620-98J41-0000
2	Housing	67211-98J20-0000
3	Lever, Handle	67251-98J00-0000
4	Shaft, Drive Remocon	67246-98J10-0000
5	NO.1 Grip, No.1	67261-98J00-0000
6	Cover, Lever	67263-98J00-0000
7	Cover, Remocon Upper	67212-98J20-0000
8	Cover, Remocon Bottom	67271-98J30-0000
9	Panel Assy, Back	67222-98J10-0000
10	Rooler, Detent	67236-98J10-0000
11	Guide, Detent Rollor	67235-98J10-0000
12	Spring, Detent	67237-98J30-0000
13	Holder, Detent Spring	67233-98J10-0000
14	Suzuki Nut, (M5)	67287-92E00-0000
15	Screw, Detent Adjustment (5X1 )	67239-98J00-0000
16	Pad, Brake	67223-98J00-0000
17	Screw (5X18)	67296-98J50-0000
18	Screw, (4X10)	67296-98JA0-0000
19	Grommet, Remocon Cover	67272-98J10-0000
20	Bush, Drive Shaft	67252-98J10-0000
21	Washer	67288-98J20-0000
22	C-Ring	67292-98J00-0000
23	Suzuki Potentiometer	15980-98J00-0000
24	Lever, Potentiometer No.1	67227-98J10-0000
25	SPC Trim Switch Assy, PTT	37850-98J02-0000
26	Clamp, Lead	67269-98J01-0000
27	Packing	67273-98J00-0000
28	Screw (8X30)	67296-98J60-0000
29	Flange, Base	67274-98J00-0000
30	Suzuki Washer	67288-92E20-0000
31	Screw, (8X30)	67296-98J90-0000
32	Screw (5X14)	67296-98JG0-0000
33	Screw (4X10)	67296-94300-0000
34	Washer, Potentiometer	67288-98J00-0000
35	Screw (5X50)	67296-98J20-0000
36	Suzuki Bolt (5X50)	67226-98J00-0000
37	Washer (5.5X16X1.5)	09160-05024-0000
38	Suzuki Nut, (M5)	67287-92E00-0000
39	Screw (5X12)	67296-98J00-0000
40	Washer, Bottom Cover	67288-98J40-0000
41	Screw (5X35)	67296-98J10-0000
42	Suzuki Mark (F-N-R)	67284-98J10-0000
43	Mark, Lever	67257-98J00-0000
44	Band	67269-98J30-0000
45	Washer, Spring	67288-98J10-0000
46	Washer, Lever Cover	67288-98J30-0000
47	Washer, Wave	67228-98J50-0000
48	Packing (Front)	67273-98J10-0000
49	Packing (Rear)	67273-98J30-0000
50	Grommet, Remocon Bottom Cover	67277-98J00-0000
51	Bolt (5X14), Upper Cover	67296-98JF0-0000
52	Nut, Upper Cover Bolt	67297-98J00-0000
53	Harness, Condenser Adapter	36890-98J00-0000

OPT: Remote Control Assy Single (022)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ OPT: Remote Control Assy Single (022):

Position No.	Part Name	OEM Number
1	Single Engine Control Box- SPC 2.0, Single Top Mount	67200-98L00-0000
23-1	21FT SPC 2.0 Main Wiring Harness, Remote Control (L:6 00)	36620-98L00-0000
2	Switch Assy, Boat Control	37130-98L00-0000
23-2	31FT SPC 2.0 Main Wiring Harness, Remote Control (L:9 00)	36620-98L10-0000
3	Power Trim and Tilt Switch, PTT	37850-98L00-0000
23-3	6.5FT SPC 2.0 Wiring Harness Extension, Remote Control Ext L:2000)	36620-98L20-0000
4	Cover, R/Con Upper	67212-98L00-0000
5	Mark, Handle Lever	67284-98L00-0000
6	Emblem, Mark	68111-88L00-0000
7	Suzuki Bolt (5X50)	67226-98J00-0000
8	Grip, R/Con No.1	67261-98L00-0000
9	Grip, R/Con No.2	67261-98L10-0000
10	Clamp, Lead	67269-98L00-0000
11	Cover, R/Con Bottom	67271-98L00-0000
12	Grommet, R/Con Cover	67272-98L00-0000
13	Packing, R/Con	67273-98L00-0000
14	Grommet, R/Con Bottom Cover	67277-98L00-0000
15	Grommet, R/Con Grip	67277-98L10-0000
16	Suzuki Nut, (M5)	67287-92E00-0000
17	Washer, Bottom Cover	67288-98J40-0000
18	Screw (5X18)	67296-98J50-0000
19	Screw	67296-98L00-0000
20	Bolt, Upper Cover	67296-98L10-0000
21	Nut, Upper Cover Bolt	67297-98J00-0000
22	Screw	67296-88D00-0000

OPT: Switch (020,021)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ OPT: Switch (020,021):

Position No.	Part Name	OEM Number
1	SPC 1.0 Key Switch Panel Assy, Main Switch	37100-98J05-0000
2	Switch Assy, Main	37110-98J02-0000
3-1	Ignition Key (941)	37141-99EA0-0000
3-2	Ignition Key (942)	37141-99EB0-0000
3-3	Ignition Key (931)	37141-99E00-0000
3-4	Ignition Key (932)	37141-99E10-0000
3-5	Ignition Key (933)	37141-99E20-0000
3-6	Ignition Key (934)	37141-99E30-0000
3-7	Ignition Key (935)	37141-99E40-0000
3-8	Ignition Key (936)	37141-99E50-0000
3-9	Ignition Key (937)	37141-99E60-0000
3-10	Ignition Key (938)	37141-99E70-0000
3-11	Ignition Key (939)	37141-99E80-0000
3-12	Ignition Key (940)	37141-99E90-0000
4	Ignition Key Cap, Key	37143-99E00-0000
5	Ignition Switch Panel, Main SW	37139-98J10-0000
6	Kill Switch Assy, Emergency	37820-93J11-0000
7	Emergency Stop Switch Lanyard, Emergency SW Loc	37823-92E01-0000
8	Nut	37826-92J10-0000
9	Screw	03122-05169-0000
10	Sheet, Main SW Panel	37114-98J00-0000
11	Single Engine Control Panel	37100-98J11-0000
12	Nut	37112-98J00-0000
13	Warning Buzzer, Warning	38500-93J90-0000
14	Warning Buzzer Clamp	09407-14403-0000
15	Panel Assy, Emergency SW	37803-93J04-0000
16	Panel, Emergency Stop SW	37825-99E10-0000
17	Kill Switch Assy, Emergency	37820-93J11-0000
18	Emergency Stop Switch Lanyard, Emergency SW Loc	37823-92E01-0000
19	Nut	37826-92J10-0000
20	Screw	03122-05169-0000
21	Dual Engine Control Panel	37100-98J21-0000
22	Nut	37112-98J10-0000
23	Triple Engine Control Panel	37100-98J31-0000
24	Nut	37112-98J10-0000
25	Troll Mode Switch, Trolling Control S	37860-87L00-0000
26	Panel	37862-87L00-0000
27	Screw, (5X16)	09131-05004-0000

OPT: Switch (022)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ OPT: Switch (022):

Position No.	Part Name	OEM Number
1	Key Switch Panel Assy, Main Switch	37100-98L00-0000
1-1	Ignition Key (931)	37141-98L00-0000
1-1	Ignition Key (931)	37141-99E00-0000
1-5	Ignition Key (935)	37141-99E40-0000
1-5	Ignition Key (935)	37141-98L40-0000
1-6	Ignition Key (936)	37141-99E50-0000
1-6	Ignition Key (936)	37141-98L50-0000
1-7	Ignition Key (937)	37141-99E60-0000
1-7	Ignition Key (937)	37141-98L60-0000
1-8	Ignition Key (938)	37141-98L70-0000
1-8	Ignition Key (938)	37141-99E70-0000
1-9	Ignition Key (939)	37141-99E80-0000
1-9	Ignition Key (939)	37141-98L80-0000
1-10	Ignition Key (940)	37141-99E90-0000
1-10	Ignition Key (940)	37141-98L90-0000
1-11	Ignition Key (941)	37141-98LA0-0000
1-11	Ignition Key (941)	37141-99EA0-0000
1-12	Ignition Key (942)	37141-99EB0-0000
1-12	Ignition Key (942)	37141-98LB0-0000
15-1	Ignition Key (931)	37141-98L00-0000
16-1	Ignition Key (931)	37141-99E00-0000
24-1	Ignition Key (931)	37141-98L00-0000
25-1	Ignition Key (931)	37141-99E00-0000
2-1	Ignition Key (932)	37141-98L10-0000
2-1	Ignition Key (932)	37141-99E10-0000
2-3	Ignition Key (932)	37141-98L10-0000
2-4	Ignition Key (932)	37141-99E10-0000
15-2	Ignition Key (932)	37141-98L10-0000
16-2	Ignition Key (932)	37141-99E10-0000
24-2	Ignition Key (932)	37141-98L10-0000
25-2	Ignition Key (932)	37141-99E10-0000
3-1	Ignition Key (933)	37141-98L20-0000
3-1	Ignition Key (931)	37141-98L00-0000
3-1	Ignition Key (933)	37141-99E20-0000
3-3	Ignition Key (933)	37141-98L20-0000
3-4	Ignition Key (933)	37141-99E20-0000
3-5	Ignition Key (935)	37141-98L40-0000
3-6	Ignition Key (936)	37141-98L50-0000
3-7	Ignition Key (937)	37141-98L60-0000
3-8	Ignition Key (938)	37141-98L70-0000
3-9	Ignition Key (939)	37141-98L80-0000
3-10	Ignition Key (940)	37141-98L90-0000
3-11	Ignition Key (941)	37141-98LA0-0000
3-12	Ignition Key (942)	37141-98LB0-0000
15-3	Ignition Key (933)	37141-98L20-0000
16-3	Ignition Key (933)	37141-99E20-0000
24-3	Ignition Key (933)	37141-98L20-0000
25-3	Ignition Key (933)	37141-99E20-0000
4-1	Ignition Key (934)	37141-98L30-0000
4-1	Ignition Key (931)	37141-99E00-0000
4-1	Ignition Key (934)	37141-99E30-0000
4-3	Ignition Key (934)	37141-98L30-0000
4-4	Ignition Key (934)	37141-99E30-0000
4-5	Ignition Key (935)	37141-99E40-0000
4-6	Ignition Key (936)	37141-99E50-0000
4-7	Ignition Key (937)	37141-99E60-0000
4-8	Ignition Key (938)	37141-99E70-0000
4-9	Ignition Key (939)	37141-99E80-0000
4-10	Ignition Key (940)	37141-99E90-0000
4-11	Ignition Key (941)	37141-99EA0-0000
4-12	Ignition Key (942)	37141-99EB0-0000
15-4	Ignition Key (934)	37141-98L30-0000
16-4	Ignition Key (934)	37141-99E30-0000
24-4	Ignition Key (934)	37141-98L30-0000
25-4	Ignition Key (934)	37141-99E30-0000
5	Cover, Main SW Panel	37138-98L00-0000
15-5	Ignition Key (935)	37141-98L40-0000
16-5	Ignition Key (935)	37141-99E40-0000
24-5	Ignition Key (935)	37141-98L40-0000
25-5	Ignition Key (935)	37141-99E40-0000
6	Warning Buzzer, Warning	38500-93J90-0000
15-6	Ignition Key (936)	37141-98L50-0000
16-6	Ignition Key (936)	37141-99E50-0000
24-6	Ignition Key (936)	37141-98L50-0000
25-6	Ignition Key (936)	37141-99E50-0000
7	Screw	03141-0516A-0000
15-7	Ignition Key (937)	37141-98L60-0000
16-7	Ignition Key (937)	37141-99E60-0000
24-7	Ignition Key (937)	37141-98L60-0000
25-7	Ignition Key (937)	37141-99E60-0000
8	SPC 2.0 Emergency Stop Switch Assembly, Emergency SW	37803-98L00-0000
15-8	Ignition Key (938)	37141-98L70-0000
16-8	Ignition Key (938)	37141-99E70-0000
24-8	Ignition Key (938)	37141-98L70-0000
25-8	Ignition Key (938)	37141-99E70-0000
9	SPC 2.0 Kill Switch Assy, Emergency	37820-98L00-0000
15-9	Ignition Key (939)	37141-98L80-0000
16-9	Ignition Key (939)	37141-99E80-0000
24-9	Ignition Key (939)	37141-98L80-0000
25-9	Ignition Key (939)	37141-99E80-0000
10	Emergency Stop Switch Lanyard, Emergency SW Lock	37823-98L01-0000
15-10	Ignition Key (940)	37141-98L90-0000
16-10	Ignition Key (940)	37141-99E90-0000
24-10	Ignition Key (940)	37141-98L90-0000
25-10	Ignition Key (940)	37141-99E90-0000
11	Cover, Emergency SW Panel	37832-98L00-0000
15-11	Ignition Key (941)	37141-98LA0-0000
16-11	Ignition Key (941)	37141-99EA0-0000
24-11	Ignition Key (941)	37141-98LA0-0000
25-11	Ignition Key (941)	37141-99EA0-0000
12	Screw	03141-0516A-0000
15-12	Ignition Key (942)	37141-98LB0-0000
16-12	Ignition Key (942)	37141-99EB0-0000
24-12	Ignition Key (942)	37141-98LB0-0000
25-12	Ignition Key (942)	37141-99EB0-0000
13	Vertical Ignition Switch Assy, Main Switch	37100-98L10-0000
17	Vertical Key Switch Cover, Main SW Panel Vert	37138-98L10-0000
18	SPC 2.0 Kill Switch Assy, Emergency	37820-98L00-0000
19	Emergency Stop Switch Lanyard, Emergency SW Lock	37823-98L01-0000
20	Warning Buzzer, Warning	38500-93J90-0000
21	Screw	03141-0516A-0000
22	Horizontal Ignition Switch Assy, Main Switch Horiz	37100-98L20-0000
26	Cover, Main SW Panel Horiz	37138-98L20-0000
27	SPC 2.0 Kill Switch Assy, Emergency	37820-98L00-0000
28	Emergency Stop Switch Lanyard, Emergency SW Lock	37823-98L01-0000
29	Warning Buzzer, Warning	38500-93J90-0000
30	Screw	03141-0516A-0000
31	Dual Engine Ignition Panel Assy, Main Switch Multi	37100-98L30-0000
35	Cover, Main SW Panel Multiple	37138-98L30-0000
36	SPC 2.0 Kill Switch Assy, Emergency	37820-98L00-0000
37	Emergency Stop Switch Lanyard, Emergency SW Lock	37823-98L01-0000
38	Warning Buzzer, Warning	38500-93J90-0000
39	Screw	03141-0516A-0000
40	Troll Mode Switch, Trolling Control S	37860-98L00-0000
41	Cover, Trolling Control SW	37865-98L00-0000
42	Screw	03141-0516A-0000
43	SPC 2.0 Dual Engine Control Panel	37120-98L00-0000
44	Nut	37112-98J10-0000
45	SPC 2.0 Triple Engine Control Panel, Triple	37120-98L10-0000
46	Nut	37112-98J10-0000
47	SPC 2.0 Quad Engine Control Panel (PORT), QDRPL Port	37120-98L20-0000
48	Nut	37112-98J10-0000
49	SPC 2.0 Quad Engine Control Panel (STBD), QDRP STBD	37120-98L30-0000
50	Nut	37112-98J10-0000
51	SPC 2.0 Quintuple Engine Control Panel, Quintuple	37120-98L40-0000
52	Nut	37112-98J10-0000
53	SPC 2.0 Sextuple Engine Control Panel (PORT), Sextuple Port	37120-98L50-0000
54	Nut	37112-98J10-0000
55	SPC 2.0 Sextuple Engine Control Panel (STBD), Sextuple STBD	37120-98L60-0000
56	Nut	37112-98J10-0000
57	Warning Buzzer, Warning	38500-93J90-0000
58	Warning Buzzer Clamp	09407-14403-0000

OPT:Flush Mount Remocon (020,021)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ OPT:Flush Mount Remocon (020,021):

Position No.	Part Name	OEM Number
1	Single Engine Flush Mount Control Box, Flash MT	67200-98J22-0000
2	Cover, Bottom Base	67271-98J20-0000
3	Cover, Top Base	67264-98J00-0000
4	Cover, Lever	67263-98J20-0000
5	Grip, A	67261-98J20-0000
6	Grip, B	67261-98J30-0000
7	Button, Neutral Lock	67265-98J00-0000
8	Link, Neutral Lock No.1	67255-98J00-0000
9	Plate, Joint	67258-98J00-0000
10	Block, Neutral Lock	67256-98J00-0000
11	Spring	67259-98J00-0000
12	Lever, Handle	67251-98J20-0000
13	Spacer	67294-98J00-0000
14	Link, Neutral Lock No.2	67254-98J00-0000
15	Slider, Neutral Button	67233-98J00-0000
16	Screw, (4X10)	67296-98JA0-0000
17	Plate, Lever	67234-98J00-0000
18	Housing	67211-98J20-0000
19	Clamp, Lead	67269-98J20-0000
20	Screw (4X30)	67296-98JB0-0000
21	Screw, (4X35)	67227-98J20-0000
22	Screw, (4X20)	67227-98J30-0000
23	Washer, Plane	67288-98J50-0000
24	Screw (6X40)	67296-98JC0-0000
25	Nut	67287-98J00-0000
26	Bolt (6X50)	67226-98J10-0000
27	Washer, Innternal Tooth (M4)	67288-98J60-0000
28	Screw (5X40)	67296-98JD0-0000
29	Pin	67238-98J00-0000
30	Washer, Plane	67288-98J70-0000
31	Shaft, Drive	67246-98J00-0000
32	Panel Assy, Back	67222-98J00-0000
33	Roller, Detent	67236-98J00-0000
34	Guide, Detent Rooler	67235-98J00-0000
35	Spring, Detent	67237-98J00-0000
36	Pad, Brake	67223-98J00-0000
37	Screw, (5X35)	67296-98JE0-0000
38	Bush, Drive Shaft	67252-98J00-0000
39	Washer, Washer	67288-98J20-0000
40	C-Ring	67292-98J00-0000
41	Suzuki Potentiometer	15980-98J00-0000
42	Lever, Potentiometer No.2	67227-98J10-0000
43	Screw (4X10)	67296-94300-0000
44	Washer, Potentiometer	67288-98J00-0000
45	Screw (5X35)	67296-98J10-0000
46	Washer, Spring	67288-98J10-0000
47	Washer, Wave	67228-98J50-0000
48	Screw (8X30)	67296-98J60-0000
49	Washer (6.5X24X2)	09160-06104-0000
50	Screw (5X18)	67296-98J50-0000
51	Grommet, Cover	67272-98J00-0000
52	SPC Trim Switch Assy, PTT	37850-98J02-0000
53	Band	67269-98J10-0000
54	Mark, Lever	67257-98J00-0000
55	Harness, Condenser Adapter	36890-98J00-0000

OPT:Flush Mount Remocon (022)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ OPT:Flush Mount Remocon (022):

Position No.	Part Name	OEM Number
1	Single Engine Flush Mount Control Box- SPC 2.0, Flash Mount	67200-98L20-0000
2	Grommet, R/Con Cover	67272-98L20-0000
3	Cover, Top Base	67264-98L00-0000
4	Mark, Handle Lever	67284-98L20-0000
5	Cover, Lever	67263-98J20-0000
6	Grip, A	67261-98J20-0000
7	Grip, B	67261-98J30-0000
8	Button, Neutral Lock	67265-98J00-0000
9	Link, Neutral Lock No.1	67255-98J00-0000
10	Plate, Joint	67258-98J00-0000
11	Block, Neutral Lock	67256-98L00-0000
12	Spring	67259-98J00-0000
13	Lever, Handle	67251-98J20-0000
14	Spacer	67294-98J00-0000
15	Link, Neutral Lock No.2	67254-98J00-0000
16	Screw, (4X10)	67296-98JA0-0000
17	Plate, Lever	67234-98J00-0000
18	Housing	67211-98J20-0000
19	Screw (4X30)	67296-98JB0-0000
20	Screw, (4X35)	67227-98J20-0000
21	Washer, Plane	67288-98J50-0000
22	Nut	67287-98J00-0000
23	Bolt (6X50)	67226-98J10-0000
24	Washer, Innternal Tooth (M4)	67288-98J60-0000
25	Pin	67238-98J00-0000
26	Washer, Potentiometer	67288-98J00-0000
27	Screw (8X30)	67296-98J60-0000
28	Washer (6.5X24X2)	09160-06104-0000
29	SPC Trim Switch Assy, PTT	37850-98J02-0000
30	Mark, Lever	67257-98J00-0000
31	SPC 2.0 Kill Switch Assy, Emergency	37820-98L00-0000
32	Emergency Stop Switch Lanyard, Emergency SW Lock	37823-98L01-0000
33	Switch, Boat Control	37130-98L20-0000
34	Screw	67227-98L00-0000

Oil Pan

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Oil Pan:

Position No.	Part Name	OEM Number
1	Cover, Protection Anode	11261-93J10-0000
29-1	Suzuki Bolt	01550-06127-0000
2-1	Internal Protection Anode, Protection	55321-87J01-0000
2-2	Magnesium Anode, (MAGNESIUM)	55321-87J11-0000
2-7	Oil Pan, Oil (White)	11501-93J02-Y5S
2-9	Exhaust Pipe, Exhaust (White)	11541-93J00-0EP
29-2	Suzuki Bolt, (6X12)	01550-0612C-0000
3	Suzuki Bolt, (8X25)	29103-93J30-0000
4	Suzuki Anode Bolt (6x14), (6X14)	09103-06281-0000
5	Internal Anode O-Ring, (D:1.9,ID:21.8)	09280-22019-0000
6	Gasket, Oil Pan	11489-93J00-0000
7-1	Oil Pan, Oil (Black)	11501-93J03-YAY
7-3	Oil Pan, Oil (White)	11501-93J03-QTN
7-4	Oil Pan, Oil (Black)	11501-93J03-YAY
8	Oil Pan Union, Oil Pan	11591-93J10-0000
9-1	Exhaust Pipe, Exhaust (Black)	11541-93J00-YAY
9-3	Exhaust Pipe, Exhasut (White)	11541-93J00-QTN
9-4	Exhaust Pipe, Exhaust (Black)	11541-93J00-YAY
10	Exhaust Tube Seal, Exhaust Tube	14154-93J01-0000
11	Tube, Exhaust	14211-98J00-0000
12	Exhaust Tube Gasket, Exhaust Tube	14212-93J00-0000
13	Suzuki Bolt, (6X20)	29116-93J00-0000
14	Exhaust Release Pipe, Exhaust Release	11435-93J01-0000
15	Engine Oil Drain Plug Gasket, (12.5X20X2.5)	09168-12012-0000
16	Engine Oil Drain Plug, (12X18.65)	09248-12009-0000
17	Suzuki Pin, (8X12)	09202-08006-0000
18	Suzuki Pin, (8X12)	09202-08006-0000
19	Bolt	01550-1050A-0000
20	Oil Pan Bolt (8X40), 8X40 (8X40)	09116-08128-0000
21	Suzuki Bolt (10X50)	09116-10175-0000
22	Suzuki Bolt (10X195)	09116-10146-0000
23	Bolt (10X200), (10X200)	09116-10184-0000
24	Suzuki Bolt, (6X12)	29103-93J00-0000
26	Oil Level Gauge, Oil Level	16910-93J00-0000
27	Guide, Oil Level Gauge	16930-93J00-0000
28	O-Ring, (D:2.1,ID:8.8)	09280-09008-0000

Oil Pump

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Oil Pump:

Position No.	Part Name	OEM Number
1	Sprocket, Oil Pump Drive (NT:3 )	12632-93J11-0000
2	Sprocket, Oil Pump Driven (NT:18)	16113-93J10-0000
3	Oil Pump Assy, Oil	16400-93J03-0000
4	Strainer, Oil Pump	16520-93J00-0000
5	Oil Pump Drive Chain, Oil Pump Drive	16760-93J00-0000
6	Oil Pump Chain Tensioner, Oil Pump Chain	16781-93J00-0000
7	Oil Pump Tensioner Spring, Oil Pump Tensioner	16782-93J00-0000
8	Bolt, Oil Pump Tensioner	16783-93J01-0000
9	Shim (12X20X0.5), (12X20X0.5)	09181-12158-0000
10	O Ring (D:2.4,ID:21.8), (D:2.4,ID:21.8)	09280-22020-0000
11	Bolt, (6X16)	01550-0616A-0000
12	Bolt	01550-0845A-0000
13	Bolt	01550-0865A-0000
14	Bolt	01550-0885A-0000
15	Suzuki Bearing (15X32X9)	08110-60020-0000

PTT Motor (L-Transom)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ PTT Motor (L-Transom):

Position No.	Part Name	OEM Number
1	PTT Motor Assy, PTT	38100-93L01-0000
2	Screw	31111-94900-0000
3	Holder Assy, Brush	31173-94920-0000
4	PTT O-Ring	31123-94910-0000
5	PTT Motor Brush Set	31133-90J00-0000
6	PTT Motor Brush (+)	31133-94910-0000
7	PTT Motor Spring	31135-94900-0000
8	PTT Motor Brush and Breaker	31136-90J20-0000
9	Oil Seal, Oil	33799-97E00-0000
10	Armature	31311-94900-0000

PTT Motor (X-Transom,XX-Transom)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ PTT Motor (X-Transom,XX-Transom):

Position No.	Part Name	OEM Number
1	PTT Motor Assy, PTT	38100-93J04-0000
2	Screw	31111-94900-0000
3	Holder Assy, Brush	31173-94920-0000
4	PTT O-Ring	31123-94910-0000
5	PTT Motor Brush Set	31133-90J00-0000
6	PTT Motor Brush (+)	31133-94910-0000
7	PTT Motor Spring	31135-94900-0000
8	PTT Motor Brush and Breaker	31136-90J20-0000
9	Oil Seal, Oil	33799-97E00-0000
10	Suzuki Armature- DISCONTINUED	31311-93J00-0000

PTT Switch/Engine Control Unit (DF250A)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ PTT Switch/Engine Control Unit (DF250A):

Position No.	Part Name	OEM Number
1	Shift Position Sensor Assy, Shift Position	13580-98J02-0000
15-1	Suzuki Bolt	01550-06127-0000
23-1	Engine Control Unit (ECU), Engine Control	33930-98JD0-0000
28-1	Suzuki Bolt, (6X16)	01550-06167-0000
2	O-Ring	13575-40F00-0000
15-2	Suzuki Bolt, (6X12)	01550-0612C-0000
23-2	Engine Control Unit (ECU), Engine Control	33930-98JG0-0000
28-2	Suzuki Bolt, (6X16)	01550-0616C-0000
3	Lever, Shift Sensor	37729-98J00-0000
4	Suzuki Washer (5.5X12X0.8), (5.5X12X0.8)	09160-05029-0000
5	Bolt	07130-05167-0000
6	Lock Washer, Lock	08321-0105A-0000
7	Neutral Safety Switch, Neutral	37721-93J00-0000
8	Suzuki Screw (4X16), (4X16)	09137-04004-0000
9	Suzuki Clamp, (L:100)	09407-10404-0000
10	Switch Assembly Cover, Switch Assy	37725-93J11-0000
11	Power Trim and Tilt Switch, PTT	37850-92J00-0000
12	Tape, PTT Switch	37856-92J00-0000
13	PTT Switch Bushing, PTT Switch	37857-92J01-0000
14	Clamp	09403-11328-0000
16	Tilt Limit Switch, Tilt Limit	37722-93J12-0000
17	Clamp	09403-09330-0000
18	Screw, (6X12)	29125-93J00-0000
19	Power Trim and Tilt Relay, PTT	38410-93J12-0000
20	PTT Relay Holder, PTT Relay	38415-93J00-0000
21	Suzuki Bolt	01550-06127-0000
22	Clamp, (L:300)	09407-30401-0000
24	Cushion, Engine Control Unit	33925-98J00-0000
25	SPC Shift Actuator, Shift	38890-98J11-0000
26	Shift Actuator Damper, Shift Actuator	38892-98J01-0000
27	Shift Actuator Bracket, Shift Actuator	38895-98J00-0000
29	Bolt, (6X35)	01550-06357-0000
30	Suzuki Relay Assy	38860-76F01-0000
31	Relay Holder, Relay	38915-90J00-0000

Rectifier/Ignition Coil

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Rectifier/Ignition Coil:

Position No.	Part Name	OEM Number
1	Rectifier & Regulator	32800-98J01-0000
2	Rectifier & Regulator O-Ring, Rect & Regulator	32805-93J00-0000
3	Electric Parts Holder, Electric Parts	32890-98J01-0000
4	Washer (6.5X24X1.6), (6.5X24X1.6)	09160-06134-0000
5	Washer, (6.3X17X1.6)	09169-06062-0000
6	Suzuki Cushion, (9X18X9.5)	09320-09016-0000
7	VST Bolt (6X25), (6X25)	09116-06202-0000
8	Suzuki Cushion	09320-12095-0000
9-1	Suzuki Bolt	01550-06127-0000
9-2	Suzuki Bolt, (6X12)	01550-0612C-0000
10-1	Suzuki Bolt, (6X25)	01550-06257-0000
10-2	Bolt, (6X25)	01550-0625C-0000
11	Ignition Coil Assy, Ignition	33410-93J00-0000
12-1	Suzuki Bolt, (6X20)	01550-06207-0000
12-2	Suzuki Bolt, (6X20)	01550-0620C-0000
13	Clip (ID:16), (ID:16)	09408-00021-0000

Ring Gear Cover

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Ring Gear Cover:

Position No.	Part Name	OEM Number
1	Cover, Ring Gear	11510-98J03-0000
14-1	Suzuki Bolt, (6X20)	01550-06207-0000
15-1	Suzuki Bolt, (6X20)	01550-06207-0000
16-1	Suzuki Bolt, (6X40)	01550-06407-0000
17-1	Suzuki Bolt	01550-08357-0000
2	Hose, Breather	11174-98J01-0000
14-2	Suzuki Bolt, (6X20)	01550-0620C-0000
15-2	Suzuki Bolt, (6X20)	01550-0620C-0000
16-2	Bolt	01550-0640C-0000
17-2	Bolt	01550-0835C-0000
3	Union, Breather	11176-98J00-0000
4	Ring Gear Cover Plate, Ring Gear Cover	11514-98J00-0000
5	Arrester, Flame	13710-98J00-0000
6	Silencer, Upper Cover	13811-98J00-0000
7	Suzuki Clip	09401-18410-0000
8	Suzuki Bolt, Purge Valve Bracket	01550-06127-0000
9	Suzuki Bolt, (6X20)	01550-06207-0000
10	Suzuki Screw	11517-98J00-0000
11	Brace, Ring Gear Cover	11515-93J00-0000
12	Air Duct Guard (STBD), Air Duct STBD	13841-98J10-0000
13	Guard, Air Duct Port	13851-98J10-0000
18	Label (S.I.G.P)	69711-93E11-0000
19	Label, Oil & Clearance	61494-93J01-0000

Sensor (L-Transom)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Sensor (L-Transom):

Position No.	Part Name	OEM Number
1	Sensor, Inlet Air Temp	13650-52G00-0000
2	Air Temp Sensor Grommet, Inlet Air Temp SNSR	13655-87J01-0000
3	Suzuki Bolt, (6X12)	29103-93J00-0000
4	Exhaust Temp Sensor Assembly, Temp	34830-87J20-0000
5	Exhaust Temp Sensor Assembly, Temp	34830-87J20-0000
6	Trim Sensor Assembly, Trim	34840-98J11-0000
7	Oil Pressure Sensor, Oil Pressure	37820-98J00-0000
8	Suzuki Bolt, (6X12)	29103-93J00-0000
9	Clamp	09403-19412-0000
10	Suzuki Clamp, (L:80)	29404-93J21-0000
11	Clamp, (L:145)	09407-14407-0000
12	Trim Sensor Lever, Trim Sensor	34841-96J00-0000
13	Trim Sensor Bracket, Trim Sensor	34845-96J00-0000
14	Suzuki Screw (5X16)	09136-05041-0000
15	Suzuki Washer (5.5X12X0.8), (5.5X12X0.8)	09160-05029-0000
16	Suzuki Bolt (6X20), (6X20)	09103-06093-0000
17	O2 Sensor, Oxygen	18213-98J30-0000
18	Clamp	09403-07340-0000
19	Holder, Temp Sensor	11218-98J02-0000
20	Holder, Oil Sensor	11219-98J00-0000
21	Oil Temp Sensor Assembly, Oil Temp	34830-98J00-0000
22	Protector, Lead Wire	34813-93J00-0000
23	Trim Sensor Wire, Trim Sensor	36611-96J01-0000
24	Cam, Trim Sender	43117-96J00-0000
25	Suzuki Bolt, (5X12)	09116-05010-0000
26	Suzuki Bolt, Trim Sender Calm	09116-05010-0000

Sensor (X-Transom,XX-Transom)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Sensor (X-Transom,XX-Transom):

Position No.	Part Name	OEM Number
1	Sensor, Inlet Air Temp	13650-52G00-0000
2	Air Temp Sensor Grommet, Inlet Air Temp Sensor	13655-87J01-0000
3	Suzuki Bolt, (6X12)	29103-93J00-0000
4	Exhaust Temp Sensor Assembly, Temp	34830-87J20-0000
5	Exhaust Temp Sensor Assembly, Temp	34830-87J20-0000
6	Trim Sensor Assembly, Trim & Tilt	34840-98J03-0000
7	Oil Pressure Sensor, Oil Pressure	37820-98J00-0000
8	Suzuki Screw (6X10)	09125-06063-0000
9	Clamp	09403-19412-0000
11	Clamp, (L:145)	09407-14407-0000
12	Trim Sensor Lever, Trim Sensor	34841-88L01-0000
13	Trim Sensor Bracket, Trim Sensor	34845-88L02-0000
14	Nut, (M5)	09140-05005-0000
15	Suzuki Screw (5X16)	09136-05041-0000
16	Suzuki Washer (5.5X12X0.8), (5.5X12X0.8)	09160-05029-0000
17	Suzuki Bolt (6X20), (6X20)	09103-06093-0000
18	O2 Sensor, Oxygen	18213-98J30-0000
19	Clamp	09403-07340-0000
20	Holder, Temp Sensor	11218-98J02-0000
21	Holder, Oil Sensor	11219-98J00-0000
22	Oil Temp Sensor Assembly, Oil Temp	34830-98J00-0000

Side Cover (L-Transom)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Side Cover (L-Transom):

Position No.	Part Name	OEM Number
1-1	STBD Oil Pan Cover (L-20"), Oil Pan STBD (Black)	61131-93J20-YAY
1-1	Clamp, (L:250)	09407-25402-0000
1-1	Hook Front Lever, Hook Front (Black)	61645-98J00-YAY
1-1	Rigging Hose Adapter Pin, (RIGGING)	09208-06009-0000
1-1	STBD Rear Hook Lever, Hook Rear STBD (Black)	61633-98J10-YAY
1-1	R/Con Cable Grommet, R/CON Cable	61124-98J20-0000
1-1	Lever, Hook Rear Port (Black)	61634-98J10-YAY
1-2	Clamp	09407-25402-0000
1-2	Port Oil Pan Cover (L-20"), Oil Pan Port (Black)	61141-93J20-YAY
1-2	Rigging Hose Adapter Pin	09208-06011-0000
1-2	STBD Rear Hook Lever, Hook Rear STBD (White)	61633-98J10-Y5S
1-2	Hook Front Lever, Hook Front (White)	61645-98J00-Y5S
1-2	R/Con Cable Grommet, R/CON Cable	61124-98J30-0000
1-2	Lever, Hook Rear Port (White)	61634-98J10-Y5S
1-3	STBD Rear Hook Lever, Hook Rear STBD (White)	61633-98J10-QTN
1-3	STBD Oil Pan Cover (L-20"), Oil Pan STBD (White)	61131-93J20-QTN
1-3	Hook Front Lever, Hook Front (White)	61645-98J00-QTN
1-3	Lever, Hook Rear Port (White)	61634-98J10-QTN
1-4	STBD Rear Hook Lever, Hook Rear STBD (Black)	61633-98J10-YAY
1-4	Lever, Hook Rear Port (Black)	61634-98J10-YAY
1-4	STBD Oil Pan Cover (L-20"), Oil Pan STBD (Black)	61131-93J20-YAY
1-4	Hook Front Lever, Hook Front (Black)	61645-98J00-YAY
1-6	STBD Side Cover, Side STBD (Black)	61811-98J20-YAY
1-7	Cover, Side Port (Black)	61821-98J10-YAY
18-1	Panel, Front (Black)	61831-98J02-YAY
2-1	STBD Oil Pan Cover (L-20"), Oil Pan STBD (White)	61131-93J20-Y5S
2-2	Port Oil Pan Cover (L-20"), Oil Pan Port (White)	61141-93J20-Y5S
2-3	Port Oil Pan Cover (L-20"), Oil Pan Port (White)	61141-93J20-QTN
2-4	Port Oil Pan Cover (L-20"), Oil Pan Port (Black)	61141-93J20-YAY
2-6	STBD Side Cover, Side STBD (White)	61811-98J20-Y5S
2-7	Cover, Side Port (White)	61821-98J10-Y5S
18-2	Panel, FR (White)	61831-98J02-Y5S
3	Cushion, Oil Pan Cover Upper	61137-93J00-0000
18-3	Panel, Front (White)	61831-98J02-QTN
4	Suzuki Screw (6X17), (6X17)	09136-06161-0000
18-4	Panel, Front (Black)	61831-98J02-YAY
5	Suzuki Cover Screw (6x35), (6X35)	09139-06249-0000
6-3	STBD Side Cover, Side STBD (White)	61811-98J20-QTN
6-4	STBD Side Cover, Side STBD (Black)	61811-98J20-YAY
7-3	Cover, Side Port (White)	61821-98J10-QTN
7-4	Cover, Side Port (Black)	61821-98J10-YAY
8	Side Cover Seal, Side Cover	61134-93J20-0000
9	Side Cover Pin, (Black)	09409-05302-5PK
10	Side Cover Plug, Side Cover	61817-93J01-0000
11	Suzuki Cover Screw (6x35), (6X35)	09139-06249-0000
12	Holder, Side Cover	61827-93J02-0000
13	Side Cover Cushion	09321-10030-0000
14	Bolt	01550-08167-0000
15	Seal, Front Panel	61832-98J00-0000
16	Seal, Side Cover	61812-98J00-0000
17	Protector, Side Cover	61814-98J00-0000
19	Trim Tab Bolt, (8X38)	09116-08163-0000
20	Washer, (ID:8.5)	09169-08050-0000
21	Front Panel Cushion	09320-11013-0000
22	Side Cover Cushion	09321-10030-0000
23	SUZUKI FLUSH PLUG AND GASKET KIT, Water	150-350-FLUSHPLUG
24	Suzuki Flush Plug Gasket, Water Plug	17914-93J00-0000
25	Engine Cover Gasket, Side Cover	61112-98J00-0000
26	Shaft, Cover Hook	61630-98J00-0000
27	Shaft, Engine Cover Hook	63632-98J20-0000
28	Shaft, Engine Cover Hook	63632-98J30-0000
29	Bush	09306-17002-0000
30	Washer (17X30X3), (17X30X3)	09160-17052-0000
31	Bush	61636-98J00-0000
35	Bolt, (8X45)	29103-93J20-0000
36	Suzuki Bolt, (8X25)	29103-93J30-0000
37	Suzuki Washer (8.5X28X1.5), (8.5X28X1.5)	09160-08152-0000
38	Washer (8.5X16X1.2), (8.5X16X1.2)	09160-08082-0000
39	Spacer	61635-98J00-0000
40	Bush	61643-98J00-0000
41	Spring, Hook Shaft	61658-98J00-0000
42	Cushion, (14X20X9)	09329-14003-0000
45	Engine Cover Label, Engine Cover	61458-90J01-0000
46	Rigging Hose Adapter, Hose	67361-90J10-0000
48	Suzuki E Ring	09383-04002-0000

Squeeze Pump (E03,E11,E40)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Squeeze Pump (E03,E11,E40):

Position No.	Part Name	OEM Number
1-1	Primer Bulb, Squeeze	65770-93J13-0000
2-1	Suzuki Primer Bulb, Squeeze	65770-93J04-0000

Starting Motor

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Starting Motor:

Position No.	Part Name	OEM Number
1	Starting Motor, Starting	31100-98L10-0000
19-1	Bolt	01550-08307-0000
2	Case, Gear	31150-98L00-0000
19-2	Bolt	01550-0835C-0000
3	Housing, Rear	31170-92J00-0000
4	Brush Holder Assy, Brush	31173-98L00-0000
5	Lever Assy	31191-63J00-0000
6	Suzuki Switch Assembly	31220-98L10-0000
7	Armature	31311-63J00-0000
8	Screw Set	31192-92J00-0000
9	Bolt	31261-75F10-0000
10	Clutch Set, Starting Motor	31340-98L00-0000
11	Stopper Set	31313-86030-0000
12	Pinion	31320-98L00-0000
13	Shaft, Pinion	31341-98L00-0000
14	Internal Gear Assy	31343-63J00-0000
15	Gear Assy	31344-63J00-0000
16	Band, Starting Motor	31912-98J00-0000
17	Damper, Lower	31918-92J01-0000
18	Bolt	01550-08207-0000
20	Starter Motor Lead Wire, Starter Motor	36645-93J00-0000

Swivel Bracket (L-Transom)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Swivel Bracket (L-Transom):

Position No.	Part Name	OEM Number
1	Grease Nipple (Zerk Fitting), Grease	22511-99011-0000
2	Clamp To Swivel Lead, (L:165)	36894-87D00-0000
3-1	Swivel Bracket, Swivel (Black)	43111-96J20-YAY
3-2	Swivel Bracket, Swivel (White)	43111-96J20-Y5S
3-3	Swivel Bracket, Swivel (White)	43111-96J20-QTN
3-4	Swivel Bracket, Swivel (Black)	43111-96J20-YAY
3-6	Bracket, Steering (White)	43750-96J03-QTN
4	Clamp Shaft Swivel Bushing, Clamp Shaft Swivel	43211-93J11-0000
5	Steering Bushing, Steering	43711-97E11-0000
6-1	Bracket, Steering (Black)	43750-96J03-YAY
6-2	Bracket, Steering (White)	43750-96J03-Y5S
6-4	Bracket, Steering (Black)	43750-96J03-YAY
7	Suzuki Screw (6X10)	09125-06063-0000
8	Suzuki Washer (39.5X64X1), (39.5X64X1.0)	09160-39001-0000
9	Suzuki Shim (39.5X64X0.3), (39.5X64X0.30)	09181-39001-0000
10	Suzuki Circlip	09380-38003-0000
11	Washer, (26.2X52.0X1.0)	09169-28003-0000
12	Oil Seal (39X51X5), (39X51X5)	09282-39001-0000
13	Swivel Lead (L:310), (L:310)	36895-87D10-0000
14	Suzuki Screw (6X10)	09125-06063-0000
15	Tilt Lock Lever, Tilt Lock	41220-96J10-0000
16	Tilt Lock Lever (PORT), Tilt Lock Port	41234-96J10-0000
17	Tilt Stop Rod Bushing, Tilt Stopper Rod	41224-95E01-0000
18	Tilt Lock Link, Tilt Lock Lever	41230-96J00-0000
19	Bracket, Tilt Lock Spring	41233-95E10-0000
20	Suzuki Screw (6X10)	09125-06063-0000
21	Suzuki Nut, (M10)	09140-10032-0000
22	Washer (6.5X13X1.0), (6.5X13X1.0)	09160-06082-0000
23	Cotter Pin	09204-01006-0000
24	Suzuki Spring	09440-19028-0000
25	Spring	09443-10043-0000
26	Suzuki Screw (6X10)	09125-06063-0000

Swivel Bracket (X-Transom,XX-Transom)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Swivel Bracket (X-Transom,XX-Transom):

Position No.	Part Name	OEM Number
1	Grease Nipple (Zerk Fitting), Grease	22511-99011-0000
2	Clamp To Swivel Lead, (L:165)	36894-87D00-0000
3-1	Swivel Bracket, Swivel (Black)	43111-93J24-YAY
3-2	Swivel Bracket, Swivel (White)	43111-93J24-Y5S
3-3	Swivel Bracket, Swivel (White)	43111-93J24-QTN
3-4	Swivel Bracket, Swivel (Black)	43111-93J24-YAY
3-7	Steering Bracket (X), Steering (White)	43750-93J03-QTN
4	Washer, Swivel to Clamp BRKT	43114-93J00-0000
5	Clamp Shaft Swivel Bushing, Clamp Shaft Swivel	43211-93J11-0000
6	Steering Bushing, Steering	43711-97E11-0000
7-1	Steering Bracket (X), Steering (Black)	43750-93J03-YAY
7-2	Steering Bracket (X), Steering (White)	43750-93J03-Y5S
7-4	Steering Bracket (X), Steering (Black)	43750-93J03-YAY
8	Suzuki Screw (6X10)	09125-06063-0000
9	Suzuki Washer (39.5X64X1), (39.5X64X1.0)	09160-39001-0000
10	Suzuki Shim (39.5X64X0.3), (39.5X64X0.30)	09181-39001-0000
11	Oil Seal (39X51X5), (39X51X5)	09282-39001-0000
12	Suzuki Circlip	09380-38003-0000
13	Tilt Lock Lever, Tilt Lock	41220-93J11-0000
14	Tilt Lock Lever (PORT), Tilt Lock Port	41234-93J11-0000
15	Tilt Stop Rod Bushing, Tilt Stopper Rod	41224-95E01-0000
16	Tilt Lock Link, Tilt Lock Lever	41230-96J00-0000
17	Bracket, Tilt Lock Spring	41233-95E10-0000
18	Suzuki Screw (6X10)	09125-06063-0000
19	Suzuki Nut, (M10)	09140-10032-0000
20	Washer (6.5X13X1.0), (6.5X13X1.0)	09160-06082-0000
21	Cotter Pin	09204-01006-0000
22	Suzuki Spring	09440-19028-0000
23	Spring	09443-10043-0000

Thermostat

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Thermostat:

Position No.	Part Name	OEM Number
1	Water Return Hose, Water Return STBD	11196-93J00-0000
1-1	Suzuki Bolt, (6X25)	01550-06257-0000
1-1	Suzuki Bolt, (6X20)	01550-06207-0000
1-1	Suzuki Bolt, (6X20)	01550-06207-0000
1-1	Suzuki Bolt	01550-06127-0000
1-2	Bolt, (6X25)	01550-0625C-0000
1-2	Suzuki Bolt, (6X20)	01550-0620C-0000
1-2	Suzuki Bolt, (6X20)	01550-0620C-0000
1-2	Suzuki Bolt	01550-0612C-0000
25-1	Bolt	01550-08127-0000
2	Water Return Hose, Water Return Port	11197-93J00-0000
25-2	Bolt	01550-0812C-0000
3	Plate, Cyl Block Wtr Jkt	11270-93J00-0000
4	Cylinder Block Gasket, Cyl Block Plate	11272-93J00-0000
5	Water Outlet Pipe, Water Outlet	17581-93J00-0000
6	Water Outlet Pipe Gasket, Water Outlet Pipe	17582-93J00-0000
8	Water Pressure Valve, Water Pressure	17660-99E01-0000
9-1	Thermostat (50C), Water (50C)	17670-90J20-0000
10	Thermostat Cover, Thermostat	17681-93J00-0000
11	3 Way, Water Hose	17711-90J00-0000
12	Hose, Water	17712-93J01-0000
13	Suzuki Bolt, (6X25)	09116-06121-0000
14	Suzuki O-Ring, (D:3.1,ID:26.4)	09280-26006-0000
15	Suzuki Cushion	09320-12093-0000
16	Suzuki Hose (5X9X600)	09352-50006-600
17	Suzuki Hose (5X9X600)	09352-50006-600
18	Suzuki Hose (5X9X600)	09352-50006-600
19	Suzuki Hose (5X9X600)	09352-50006-600
20	Suzuki Hose (5X9X600)	09352-50006-600
21	Suzuki Hose (5X9X600)	09352-50006-600
22	Suzuki Hose (5X9X600)	09352-50006-600
23	Suzuki Hose (5X9X2000)	09352-50903-00B
24	Suzuki Hose (5X9X2000)	09352-50903-00B
26	Suzuki 3 Way Joint	09367-06002-0000
27	Suzuki Clip	09401-08413-0000
28	Suzuki Clip	09401-14409-0000
29	Suzuki Clip	09401-25406-0000
30	Clamp	09403-25304-0000
31	Suzuki Clamp (ID:20), (ID:20)	09408-00008-0000
32	Clip, (D1:12,D2:8)	09408-00056-0000
36	Holder, Water Hose	17713-98J01-0000
37	Suzuki Clip	09401-15414-0000
38	Water Flush Hose, Water Flush	17915-98J01-0000
39	Clip (ID:23), (ID:23)	09408-00024-0000
40	Clip (ID:16), (ID:16)	09408-00021-0000
41	Harness Bracket, Harness	36617-93J10-0000

Throttle Body

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Throttle Body:

Position No.	Part Name	OEM Number
1	Hose, PCV	11193-98J01-0000
1-1	Nut	08316-10087-0000
1-2	Nut	08316-1008C-0000
28-1	Bolt	01550-08167-0000
29-1	Suzuki Bolt	01550-08357-0000
30-1	Suzuki Bolt	01550-08607-0000
2	PCV Valve Seal, PCV Valve	11198-98L00-0000
28-2	Bolt	01550-0816C-0000
29-2	Bolt	01550-0835C-0000
30-2	Bolt	01550-0860C-0000
3-1	Collector Assy	13100-98J11-0000
3-2	Collector Assy	13100-98J20-0000
4	Spacer, Collector	13137-98J00-0000
5	Cover, Collector	13140-98J10-0000
6	Collector Cover Gasket, Collector Cover	13147-98J00-0000
7	Funnel, Air Collector	13180-98J01-0000
8	Pressure Sensor (MAP), Pressure	18590-68H00-0000
9	Oil Release O-Ring, (D:1.3,ID:9.8)	09280-10009-0000
10	Bolt	01550-08167-0000
11	Suzuki Bolt	01550-08357-0000
12-1	Screw	02162-05207-0000
12-2	Bolt, Pressure Sensor (5X20)	09103-05028-0000
13	Pin, (11X12)	04211-11129-0000
14	Bracket, Collector	13134-98J00-0000
15	Collector Gasket, Collector	13139-98J00-0000
16	Body Assy, Throttle	13310-98J01-0000
17	Throttle Gasket, Throttle Body	13343-98J10-0000
18	Damper, Throttle Body	13315-98J01-0000
19	Throttle Gasket, Throttle Body	13421-98J00-0000
20	Throttle Body Grommet, Throttle Body	13813-98J00-0000
21	Clip
22	Valve, PCV	18118-93J00-0000
23	Bolt (8X250), (8X250)	09103-08370-0000
24	Cable Holder Cushion	09320-08076-0000
25	Clamp	09403-13310-0000
26	Clamp	09408-00155-0000
27	Bolt, Stud	01421-08357-0000
31	Pin, (11X12)	04211-11129-0000
32	Nut, (M8)	09159-08136-0000
34	Washer (8.2X23X3.2)	09160-08161-0000

Timing Chain

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Timing Chain:

Position No.	Part Name	OEM Number
1	Driven Gear, Driven (NT:40)	12730-98J02-0000
2	Suzuki Bearing (40x80x18), (40X80X18)	09262-40012-0000
3	Bearing (40X80X18), (40X80X18)	09262-40017-0000
4	Oil Seal (32X47X6), (32X47X6)	09283-32044-0000
5	Driven Gear Holder, Driven Gear	12734-93J00-0000
6	Engine Holder O-Ring, (D:5.7,ID:69.6)	09280-70012-0000
7	Bolt	01550-0855A-0000
8	Timing Chain, Timing 1st	12761-93J00-0000
9	2nd Timing Chain, Timing 2nd	12762-93J00-0000
10	Timing Chain Guide Base, Timing Chain Guide No. 1	12770-93J00-0000
11	Timing Chain Gasket, Timing Chain Guide Bas	12778-93J00-0000
12	Pin, (13X14)	04211-13149-0000
13	Bolt, (8X30)	01550-0830A-0000
14	Timing Chain Shoe, Timing Chain Upper	12771-93J00-0000
15	Shoe, (32X47X6)	12775-93J00-0000
16	Timing Chain Guide, Timing Chain No. 2	12772-93J00-0000
17	Bolt, (8X30)	01550-0830A-0000
18	Timing Chain Tensioner Assy, Timing Chain	12810-93J00-0000
19	Timing Chain Tensioner Pad, Timing Chain Tensioner	12813-73G00-0000
20	Timing Chain Spacer, Timing Chain Tensioner	12812-90J00-0000
21	Bolt, (8X30)	01550-0830A-0000
22	Tensioner Adjuster Assy, Tensioner No.1	12831-93J01-0000
23	STBD Tensioner Assy, STBD	12832-93J00-0000
24	Tensioner Assy, Port, Port	12833-93J00-0000
25	Bolt	01550-0620A-0000
26	Bolt	01550-0620A-0000

Transmission (020,021)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Transmission (020,021):

Position No.	Part Name	OEM Number
1-1	Shaft, Drive	57110-93L02-0000
1-2	Shaft, Drive	57110-93L12-0000
1-3	Drive Shaft (XX), Drive	57110-93L22-0000
1-7	Shim (T:0.45), (60X66X0.45)	09181-60004-0000
1-11	Shim, (32X37X0.5)	09181-32035-0000
14-1	Shim, Rear Gear (T:0.50)	09181-93101-0000
15-1	Shim, Front Gear (T:3.50)	59171-93L00-0000
2	Drive Shaft Collar, Drive Shaft	57133-93L00-0000
14-2	Shim, Rear Gear (T:0.55)	09181-93102-0000
15-2	Shim, Front Gear (T:3.55)	59171-93L10-0000
3	Drive Shaft Bearing Spacer, Drive SFT BRG	57134-93J00-0000
14-3	Shim, Rear Gear (T:0.60)	09181-93103-0000
15-3	Shim, Front Gear (T:3.60)	59171-93L20-0000
4	Drive Shaft Bearing Nut, (M28)	09159-28003-0000
14-4	Shim, Rear Gear (T:0.65)	09181-93104-0000
15-4	Shim, Front Gear (T:3.65)	59171-93L30-0000
5	Suzuki Bearing (32X66X49), (32X66X49)	09269-32002-0000
14-5	Shim, Rear Gear (T:0.70)	09181-93105-0000
15-5	Shim, Front Gear (T:3.70)	59171-93L40-0000
6	Gear Set, (32X66X49)	57300-93L20-0000
14-6	Shim, Rear Gear (T:0.75)	09181-93106-0000
15-6	Shim, Front Gear (T:3.75)	59171-93L50-0000
7-2	Shim (T:0.50), (60X66X0.5)	09181-60005-0000
7-3	Shim (T:0.55), (60X66X0.55)	09181-60006-0000
7-4	Shim (T:0.60), (60X66X0.6)	09181-60007-0000
7-5	Shim (T:0.65), (60X66X0.65)	09181-60008-0000
7-6	Shim (T:0.70), (60X66X0.7)	09181-60009-0000
7-7	Shim (T:0.75), (60X66X0.75)	09181-60010-0000
7-8	Shim (T:0.80), (60X66X0.8)	09181-60011-0000
7-9	Shim (T:0.85), (60X66X0.85)	09181-60012-0000
7-10	Drive Shaft Shim (T:0.90), (60X66X0.9)	09181-60013-0000
7-11	Shim, (32X37X0.8)	09181-32041-0000
14-7	Shim, Rea Gear (T:0.80)	09181-93107-0000
15-7	Shim, Front Gear (T:3.80)	59171-93L60-0000
8	Nut	09140-16026-0000
14-8	Shim, Rear Gear (T:0.85)	09181-93108-0000
15-8	Shim, Front Gear (T:3.85)	59171-93L70-0000
9	Washer	08221-16256-0000
14-9	Shim, Rear Gear (T:0.90)	09181-93109-0000
15-9	Shim, Front Gear (T:3.90)	59171-93L80-0000
10	Spacer (32.4X40X3), (32.4X40X3)	09180-32006-0000
14-10	Shim, Rear Gear (T:0.95)	09181-93110-0000
15-10	Shim, Front Gear (T:3.95)	59171-93L90-0000
11-2	Shim, (32X37X0.55)	09181-32036-0000
11-3	Shim, (32X37X0.6)	09181-32037-0000
11-4	Shim, (32X37X0.65)	09181-32038-0000
11-5	Shim, (32X37X0.7)	09181-32039-0000
11-6	Shim, (32X37X0.75)	09181-32040-0000
11-8	Shim, (32X37X0.85)	09181-32042-0000
11-9	Shim, (32X37X0.9)	09181-32043-0000
11-10	Shim, (32X37X0.95)	09181-32044-0000
14-11	Shim, Rear Gear (T:1.00)	09181-93111-0000
15-11	Shim, Front Gear (T:4.00)	59171-93LA0-0000
12	Washer (60X72X3), (60X72X3)	09160-60012-0000
14-12	Shim, Rear Gear (T:1.05)	09181-93112-0000
15-12	Shim, Front Gear (T:4.05)	59171-93LB0-0000
13	Suzuki Bearing (80X105X4), (80X105X4)	09263-80002-0000
14-13	Shim, Rear Gear (T:1.10)	09181-93113-0000
15-13	Shim, Front Gear (T:4.10)	59171-93LC0-0000
16	Suzuki Bearing (30X72X28.75), (30X72X28.75)	09265-30033-0000
17	Propeller Shaft, Propeller	57610-93L10-0000
18	Shifter, Clutch Dog	57621-93L00-0000
19	Pin (8X55), (8X55)	09202-08013-0000
20	Connector Pin, Connector	57631-93L01-0000
21	Suzuki Spring	09440-58001-0000
22	Detent Spring, Detent	57617-93L00-0000
23	Suzuki Ball	06111-07004-0000
24	Suzuki Ball	06111-11004-0000
26	Suzuki Bearing (30X40X25), (30X40X25)	09263-30023-0000
27	Bearing, (32X58X17)	09265-32003-0000
28	Suzuki O-Ring, (D:3,ID:109)	09280-00047-0000
29	Oil Seal, (30X45X6)	09282-30006-0000
30	Suzuki Circlip	09381-40003-0000
31	Prop Shaft Bearing Spacer, Prop SFT BRG HSG	56147-93L00-0000
32	Drive Shaft Housing, Drive Shaft BRG	56130-93J02-0000
33	Suzuki O-Ring, (D:3.1,ID:65.4)	09280-66004-0000
34	Suzuki Oil Seal, (24X40X7)	09282-24004-0000
35	Suzuki Circlip	09381-40003-0000
36	Spacer, Forward Thrust	57622-93L00-0000
37	Wave Washer, Wave	09164-50002-0000
38	Circlip	09381-72003-0000
39	Nut (M48,T:6.0)	09140-48001-0000
40	Prop Shaft Stopper, Prop SFT BRG HSG	56122-93L00-0000
41	Prop Shaft BRG Washer, Prop SFT BRG HSG No. 1	56126-93L10-0000
42	Prop Shaft Washer, Prop SFT BRG HSG No. 2	56127-93L00-0000
43	Prop Shaft B Seal, Prop SFT BRG HSG	56128-93L00-0000
44	Stopper Bush, Stopper	56129-93L00-0000
45	Suzuki O-Ring, (D:1.8,ID:117.6)	09280-00030-0000
46	Inner Bearing Spacer, Bearing Inner	57527-93L00-0000
47	Spacer, Bearing Outer	57541-93L00-0000
48	Suzuki Bearing (50X80X20)	09265-50004-0000
49	Suzuki Bearing (55X100X22.75)	09265-55001-0000

Transmission (022)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Transmission (022):

Position No.	Part Name	OEM Number
1-1	Shaft, Drive	57110-93L02-0000
1-2	Shaft, Drive	57110-93L12-0000
1-3	Drive Shaft (XX), Drive	57110-93L22-0000
1-7	Shim (T:0.45), (60X66X0.45)	09181-60004-0000
1-11	Shim, (32X37X0.5)	09181-32035-0000
14-1	Shim, Rear Gear (T:0.50)	09181-93101-0000
15-1	Shim, Front Gear (T:3.50)	59171-93L00-0000
2	Drive Shaft Collar, Drive Shaft	57133-93L00-0000
14-2	Shim, Rear Gear (T:0.55)	09181-93102-0000
15-2	Shim, Front Gear (T:3.55)	59171-93L10-0000
3	Drive Shaft Bearing Spacer, Drive SFT BRG	57134-93J00-0000
14-3	Shim, Rear Gear (T:0.60)	09181-93103-0000
15-3	Shim, Front Gear (T:3.60)	59171-93L20-0000
4	Drive Shaft Bearing Nut, (M28)	09159-28003-0000
14-4	Shim, Rear Gear (T:0.65)	09181-93104-0000
15-4	Shim, Front Gear (T:3.65)	59171-93L30-0000
5	Suzuki Bearing (32X66X49), (32X66X49)	09269-32002-0000
14-5	Shim, Rear Gear (T:0.70)	09181-93105-0000
15-5	Shim, Front Gear (T:3.70)	59171-93L40-0000
6	Gear Set, Gear	57300-93L20-0000
14-6	Shim, Rear Gear (T:0.75)	09181-93106-0000
15-6	Shim, Front Gear (T:3.75)	59171-93L50-0000
7-2	Shim (T:0.50), (60X66X0.5)	09181-60005-0000
7-3	Shim (T:0.55), (60X66X0.55)	09181-60006-0000
7-4	Shim (T:0.60), (60X66X0.6)	09181-60007-0000
7-5	Shim (T:0.65), (60X66X0.65)	09181-60008-0000
7-6	Shim (T:0.70), (60X66X0.7)	09181-60009-0000
7-7	Shim (T:0.75), (60X66X0.75)	09181-60010-0000
7-8	Shim (T:0.80), (60X66X0.8)	09181-60011-0000
7-9	Shim (T:0.85), (60X66X0.85)	09181-60012-0000
7-10	Drive Shaft Shim (T:0.90), (60X66X0.9)	09181-60013-0000
7-11	Shim, (32X37X0.8)	09181-32041-0000
14-7	Shim, Rea Gear (T:0.80)	09181-93107-0000
15-7	Shim, Front Gear (T:3.80)	59171-93L60-0000
8	Nut	09140-16026-0000
14-8	Shim, Rear Gear (T:0.85)	09181-93108-0000
15-8	Shim, Front Gear (T:3.85)	59171-93L70-0000
9	Washer	08221-16256-0000
14-9	Shim, Rear Gear (T:0.90)	09181-93109-0000
15-9	Shim, Front Gear (T:3.90)	59171-93L80-0000
10	Spacer (32.4X40X3), (32.4X40X3)	09180-32006-0000
14-10	Shim, Rear Gear (T:0.95)	09181-93110-0000
15-10	Shim, Front Gear (T:3.95)	59171-93L90-0000
11-2	Shim, (32X37X0.55)	09181-32036-0000
11-3	Shim, (32X37X0.6)	09181-32037-0000
11-4	Shim, (32X37X0.65)	09181-32038-0000
11-5	Shim, (32X37X0.7)	09181-32039-0000
11-6	Shim, (32X37X0.75)	09181-32040-0000
11-8	Shim, (32X37X0.85)	09181-32042-0000
11-9	Shim, (32X37X0.9)	09181-32043-0000
11-10	Shim, (32X37X0.95)	09181-32044-0000
14-11	Shim, Rear Gear (T:1.00)	09181-93111-0000
15-11	Shim, Front Gear (T:4.00)	59171-93LA0-0000
12	Washer (60X72X3), (60X72X3)	09160-60012-0000
14-12	Shim, Rear Gear (T:1.05)	09181-93112-0000
15-12	Shim, Front Gear (T:4.05)	59171-93LB0-0000
13	Suzuki Bearing (80X105X4), (80X105X4)	09263-80002-0000
14-13	Shim, Rear Gear (T:1.10)	09181-93113-0000
15-13	Shim, Front Gear (T:4.10)	59171-93LC0-0000
16	Suzuki Bearing (30X72X28.75), (30X72X28.75)	09265-30033-0000
17	Propeller Shaft, Propeller	57610-93L10-0000
18	Shifter, Clutch Dog	57621-93L00-0000
19	Pin (8X55), (8X55)	09202-08013-0000
20	Connector Pin, Connector	57631-93L01-0000
21	Suzuki Spring	09440-58001-0000
22	Detent Spring, Detent	57617-93L00-0000
23	Suzuki Ball	06111-07004-0000
24	Suzuki Ball	06111-11004-0000
25	Prop Shaft Housing, Prop Shaft BRG	56120-93L30-0000
26	Suzuki Bearing (30X40X25), (30X40X25)	09263-30023-0000
27	Bearing, (32X58X17)	09265-32003-0000
28	Suzuki O-Ring, (D:3,ID:109)	09280-00047-0000
29	O-Ring, (D:2.4,ID:79.8)	09280-80001-0000
30	Oil Seal, (30X45X6)	09282-30006-0000
31	Suzuki Circlip	09381-40003-0000
32	Prop Shaft Bearing Spacer, Prop SFT BRG HSG	56147-93L00-0000
33	Drive Shaft Housing, Drive Shaft BRG	56130-93J02-0000
34	Suzuki O-Ring, (D:3.1,ID:65.4)	09280-66004-0000
35	Suzuki Oil Seal, (24X40X7)	09282-24004-0000
36	Suzuki Circlip	09381-40003-0000
37	Spacer, Forward Thrust	57622-93L00-0000
38	Wave Washer, Wave	09164-50002-0000
39	Circlip	09381-72003-0000
40	Nut (M48,T:6.0)	09140-48001-0000
41	Prop Shaft Stopper, Prop Shaft BRG Housing	56122-93L00-0000
42	Prop Shaft BRG Washer, Prop SFT BRG HSG No. 1	56126-93L10-0000
43	Prop Shaft Washer, Prop SFT BRG HSG No. 2	56127-93L00-0000
44	Prop Shaft B Seal, Prop SFT BRG Housing	56128-93L00-0000
45	Stopper Bush, Stopper	56129-93L00-0000
46	Suzuki O-Ring, (D:1.8,ID:117.6)	09280-00030-0000
47	Inner Bearing Spacer, Bearing Inner	57527-93L00-0000
48	Spacer, Bearing Outer	57541-93L00-0000
49	Suzuki Bearing (50X80X20)	09265-50004-0000
50	Suzuki Bearing (55X100X22.75)	09265-55001-0000

Trim Cylinder (L-Transom)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Trim Cylinder (L-Transom):

Position No.	Part Name	OEM Number
1	Trim PTT Assy, Power With Tilt	48000-93L03-0000
2	Clamp, (L:45)	29404-93J01-0000
3	Bolt, Through	31281-92J10-0000
4	PTT Motor Assy, PTT	38100-93L01-0000
5	PTT Pump Assy, PTT	48502-96J05-0000
6	PTT Filter	48582-95E01-0000
7	Valve Set, Manual	48864-96J10-0000
9	Piston Sub Assembly	48401-93L00-0000
10	Piston	48601-93L00-0000
11	O Ring Set	48627-95E00-0000
12	Trim Rod Cap, Trim Cylinder	48630-96J00-0000
13	Trim Cylinder O-Ring Set, Head (2PCS)	48633-94900-0000
14	Manifold, PTT	48641-93L01-0000
15	Suzuki Free Piston, Free	48650-94900-0000
16	O-Ring Set	48405-93J00-0000
17	Piston Ring Set, Piston	48615-97E00-0000
18	Suzuki Reservoir Assy	48570-95E01-0000
19	Trim Reservoir Cap	48572-95E00-0000
20	Joint, Drive	48583-95E00-0000
21	PTT O-Ring	48585-95E00-0000
22	Suzuki O-Ring Set, (6PCS)	48588-94900-0000
23	Bolt, Reservoir	48861-92J01-0000
24	Bolt, Pump No.1	48862-92J20-0000
25	Pump No.2 Bolt, Pump No.2	48862-92J30-0000
26	Tilt Cylinder Shaft, Tilt Cylinder LWR	48121-93L00-0000
27	Washer	09160-10161-0000
28	Trim Cylinder Ram Pad, Trim Cylinder RAM	48311-96J20-0000
29	Shaft, Tilt CYL Upper	48321-87D03-0000
30	Bush, Tilt CYL Lower	48326-95E00-0000
31	Suzuki Bolt (10X35), (10X35)	09116-10183-0000
32	Suzuki Nut, (M10)	09140-10031-0000
33	Lock Washer, Lock (10.2X18.4X2.5)	09162-10005-0000
34	Bush	09306-17001-0000
35	Trim Cylinder Circlip	09380-17009-0000
36	Clamp To Swivel Lead, (L:165)	36894-87D00-0000
37	Suzuki Screw (6X10)	09125-06063-0000
38	Screw, (5X8)	29125-93J10-0000
39	Swivel Lead (L:310), (L:310)	36895-87D10-0000

Trim Cylinder (X-Transom,XX-Transom)(See Note 1)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Trim Cylinder (X-Transom,XX-Transom)(See Note 1):

Position No.	Part Name	OEM Number
1	Trim PTT Assy, Power With Tilt	48000-98J09-0000
2	Bolt, Through	31281-92J10-0000
3	PTT Motor Assy, PTT	38100-93J04-0000
4	Manifold Assy	48500-98J14-0000
5	Manual Valve	48864-98L00-0000
6	Valve Set, Up Blow	48320-93J00-0000
7	PTT Filter	48582-95E01-0000
8	O-Ring Set	48605-93J00-0000
9	Buck Up Ring, Back Up	48615-87D00-0000
10	Piston Ram	48610-93J01-0000
11	Trim Rod Cap	48630-98L00-0000
12	Trim Cylinder O-Ring	48633-93J00-0000
13	Check Valve	48691-93J00-0000
14	Tilt Cylinder Assy	48400-98J03-0000
15	O-Ring Set	48405-93J00-0000
16	Suzuki Free Piston, Free	48650-93J00-0000
17	O-Ring Set	48627-93J00-0000
18	Piston O-Ring, Piston	48427-87D00-0000
19	Trim Reservoir Cap	48572-87J10-0000
20	PTT O-Ring	48585-95E00-0000
21	O-Ring	48585-98L00-0000
22	Bolt, Reservoir	48862-87J20-0000
23	Joint, Drive	48583-95E00-0000
24	Trim Cylinder Shaft	48121-93J13-0000
25	Suzuki O-Ring Set	48125-93J10-0000
26	Back Up Ring	48451-93J00-0000
27	O-Ring	48452-93J00-0000
28	O-Ring	48452-93J10-0000
29	Nylon Washer, Tilt CYL To Manifold	48126-93J00-0000
30	Cover	48573-93J00-0000
31	Suzuki Bolt	48128-93J11-0000
32	Reservoir Tank	48571-93J00-0000
33	Pad, Trim Cyl Ram	48311-96J10-0000
34	Shaft, Tilt CYL Upper	48321-93J00-0000
35	Suzuki Nut, (M10)	09140-10031-0000
36	Lock Washer, Lock (10.2X18.4X2.5)	09162-10005-0000
37	Tilt Cylinder Upper Bushing	09306-24001-0000
38	Suzuki Circlip	09380-21002-0000
39	Suzuki Bolt (10X50)	09116-10175-0000
40	Clamp To Swivel Lead, (L:165)	36894-87D00-0000
41	Lead, (L:230)	36895-87D01-0000
42	Lead, (L:230)	36895-87D01-0000
43	Suzuki Screw (6X10)	09125-06063-0000
44	Suzuki Screw (6X10)	09125-06063-0000
45	Suzuki Screw (6X10)	09125-06063-0000

Trim Cylinder (X-Transom,XX-Transom)(See Note)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Trim Cylinder (X-Transom,XX-Transom)(See Note):

Position No.	Part Name	OEM Number
1	Trim PTT Assy, Power With Tilt	48000-98J09-0000
2	Bolt, Through	31281-92J10-0000
3	PTT Motor Assy, PTT	38100-93J04-0000
4	Manifold Assy	48500-98J14-0000
5	Manual Valve	48864-98L00-0000
6	Valve Set, Up Blow	48320-93J00-0000
7	PTT Filter	48582-95E01-0000
8	O-Ring Set	48605-93J00-0000
9	Buck Up Ring, Back Up	48615-87D00-0000
10	Piston Ram	48610-93J01-0000
11	Trim Rod Cap	48630-98L00-0000
12	Trim Cylinder O-Ring	48633-93J00-0000
13	Check Valve	48691-93J00-0000
14	Tilt Cylinder Assy	48400-98J03-0000
15	O-Ring Set	48405-93J00-0000
16	Suzuki Free Piston, Free	48650-93J00-0000
17	O-Ring Set	48627-93J00-0000
18	Piston O-Ring, Piston	48427-87D00-0000
19	Trim Reservoir Cap	48572-87J10-0000
20	PTT O-Ring	48585-95E00-0000
21	Bolt, Reservoir	48862-87J20-0000
22	Joint, Drive	48583-95E00-0000
23	Trim Cylinder Shaft	48121-93J13-0000
24	Suzuki O-Ring Set	48125-93J10-0000
25	Back Up Ring	48451-93J00-0000
26	O-Ring	48452-93J00-0000
27	O-Ring	48452-93J10-0000
28	Nylon Washer, Tilt CYL To Manifold	48126-93J00-0000
29	Suzuki Bolt	48128-93J11-0000
30	Cover	48573-93J00-0000
31	Reservoir Tank	48571-93J00-0000
32	Pad, Trim Cyl Ram	48311-96J10-0000
32	Shaft, Tilt CYL Upper	48321-93J00-0000
34	Suzuki Nut, (M10)	09140-10031-0000
35	Lock Washer, (10.2X18.4X2.5)	09162-10005-0000
36	Tilt Cylinder Upper Bushing	09306-24001-0000
37	Suzuki Circlip	09380-21002-0000
38	Suzuki Bolt (10X50)	09116-10175-0000
39	Clamp To Swivel Lead, (L:165)	36894-87D00-0000
40	Lead, (L:230)	36895-87D01-0000
41	Lead, (L:230)	36895-87D01-0000
42	Suzuki Screw (6X10)	09125-06063-0000
43	Suzuki Screw (6X10)	09125-06063-0000
44	Suzuki Screw (6X10)	09125-06063-0000

Water Pump (E01,E03,E11)

Below is the parts list for Suzuki 2022 DF 250AP-240001~ Water Pump (E01,E03,E11):

Position No.	Part Name	OEM Number
1	Water Pump Case, Water Pump	17410-93J01-0000
2	Water Pump Case Sleeve, Water Pump Case	17413-93J02-0000
3	Water Pump Case Seal, Water Pump Case	17416-93J00-0000
4	Water Pump Impeller, Water Pump	17461-93J00-0000
5	Water Pump Case Panel, Pump Case Under	17471-98J01-0000
6	Pump Case Panel Gasket, Pump Case Panel	17472-98J00-0000
7	Panel, Pump Case Panel	17473-98J00-0000
8-1	Water Tube (X), Water	17561-93J03-0000
8-2	Water Tube (XX), Water	17561-93J13-0000
8-3	Water Tube (L), Water	17561-93J21-0000
8-4	Water Tube (X), Water	17561-93J03-0000
8-5	Water Tube (XX), Water	17561-93J13-0000
8-6	Water Tube (L), Water	17561-93J21-0000
8-7	Water Tube (X), Water	17561-93J03-0000
8-8	Water Tube (XX), Water	17561-93J13-0000
9	Water Tube Upper Bushing, Water Tube Upper	17562-93J00-0000
10	Lower Water Tube Bushing, Water Tube Lower	17563-93J00-0000
11	Water Pump Housing Bushing, Water Pump Case	17564-93J00-0000
12	Water Tube Spacer, Water Tube	17612-93J00-0000
13	Water Filter Screen (PORT), Water Port Side	17631-93L10-0000
14	Water Filter Screen (STBD), Water Stbd Side	17632-93L10-0000
15	Suzuki Bolt, (6X20)	29116-93J00-0000
16	Gearcase Bolt (8X45), (8X45)	09116-08131-0000
17	Suzuki Screw, (4X18)	09132-04034-0000
18	Suzuki Pin (6X12), (6X12)	09202-06031-0000
19	Impeller Key	09420-05009-0000
20	Water Pump Gasket (20X27X2)	09168-20002-0000
21	Water Filter Cover, Water Filter	17633-93L00-0000
22	Water Pump Kit, Water Pump Repair	17400-98J01-0000
23	Water Pump Case Seal, Water Pump Case	17416-93J00-0000
24	Water Pump Impeller, Water Pump	17461-93J00-0000
25	Water Pump Case Panel, Pump Case Under	17471-98J01-0000
26	Pump Case Panel Gasket, Pump Case Panel	17472-98J00-0000
27	Panel, Water Pump No. 2	17473-98J00-0000
28	Impeller Key	09420-05009-0000
29	Water Pump Case Sleeve	17413-93J02-0000

For Suzuki Outboard Owners:

About JLM Marine

Founded in 2002, JLM Marine has established itself as a dedicated manufacturer of high-quality marine parts, based in China. Our commitment to excellence in manufacturing has earned us the trust of top marine brands globally.

As a direct supplier, we bypass intermediaries, which allows us to offer competitive prices without compromising on quality. This approach not only supports cost-efficiency but also ensures that our customers receive the best value directly from the source.

We are excited to expand our reach through retail channels, bringing our expertise and commitment to quality directly to boat owners and enthusiasts worldwide.

Suzuki Parts on Sale

photo of jlm marine fuel pump assembly 15100-94l00 for suzuki df25a df30a models, silver circular housing with curved indentation, two black connectors on top, mounted on black bracket with side cutouts

photo fuel pump assembly suzuki df25a df30a 15100-94l01 black rectangular with two barb fittings central circular metal disc and mounting holes

Fuel Pump Assembly – Fits Suzuki DF25A/DF30A 25HP/30HP 4-Stroke (Replaces 15100-94L00, 15100-94L01)

Fuel Pump Assembly – Fits Suzuki DF25A/DF30A 25HP/30HP 4-Stroke (Replaces 15100-94L00, 15100-94L01) This fuel pump assembly is designed to fit Suzuki four-stroke outboard engines, specifically the DF25A (25HP) and DF30A (30HP) models. It serves as a direct, OEM-compatible replacement for Suzuki part numbers 15100-94L00...

$37.40; $37.40
Unit price: per

photo of a JLM Marine thermostat, 60°c, 17670-94402, with silver dome, black seal, and brass fitting, showing copper wax pellet interior

photo of JLM Marine thermostat 17670-94402 for Suzuki 9.9-70hp, metal housing with rubber seal, internal spring and brass thermal element, golden threaded shaft

Thermostat (60°C/140°F) – Fits Suzuki Marine Outboard Engines 9.9-70HP (Replaces 17670-94402, 17670-94400, 17670-94404)

Thermostat (60°C/140°F) – Fits Suzuki Marine Outboard Engines 9.9-70HP This thermostat is designed for Suzuki outboard engines, covering 4-stroke models from 9.9 HP to 70 HP (1999–2009) and select 40 HP 2-stroke models (1984–1998). As a crucial component for temperature regulation, it ensures your...

$27.49; $27.49
Unit price: per

photo of jlm marine fuel pump for suzuki df4 df5 df6 15100-91j03 black plastic top with silver screws and knob silver metal base with nipple

photo of jlm marine fuel pump for suzuki df4 df5 df6 2003 models 15100-91j03 with black plastic top silver metal plunger and metal casing with nipple outlet and accessories

Fuel Pump for Suzuki DF4, DF5, DF6 2003+ Models (15100-91J03, 15100-91J00, 15100-91J01, 15100-91J02)

OEM Part Numbers 15100-91J03, 15100-91J00, 15100-91J01, 15100-91J02 Compatible Models Suzuki Four-Stroke Engines: DF4 (2003+) DF5 (2003+) DF6 (2003+) Explosion Diagram Technical Specifications Weight: 199 g Package Dimensions: 10 x 9 x 6 cm Package Contents Hose clamp 90467-09M09-00 (9 x 1 mm) O-ring 93210-27ME3-00...

$38.90; ~~$45.00~~; $38.90
Unit price: per

close-up of jlm marine thermostat 17670-91j00-91j01-91j02 for suzuki outboard engines df 2.5-20hp with copper cylinder silver metal housing and black rubber gasket

photo of thermostat for suzuki outboard engines df 2.5-20hp, 17670-91j00, 91j01, 91j02, metal valve with rubber seal, open and close at specific temperatures

Thermostat – Fits Suzuki Outboard DF 2.5-20 HP (Replaces 17670-91J00, 17670-91J01, 17670-91J02)

Thermostat – Fits Suzuki Outboard DF 2.5-20 HP This replacement thermostat is designed for a range of Suzuki 4-Stroke outboard engines, including DF2.5 (2006), DF4/DF5/DF6 (2002 and newer), and DF9.9B/DF15A/DF20A (2013 and newer). It also fits select Johnson/Evinrude models that use part number 5033385....

$28.00; $28.00
Unit price: per

Low Pressure Fuel Pump – Fits Suzuki 40-140HP 4-Stroke Outboards (Replaces 15100-90J00)

Low Pressure Fuel Pump – Fits Suzuki 40-140HP & Johnson/Evinrude 90-140HP 4-Stroke Outboards This is a direct aftermarket replacement for the low-pressure electric fuel pump used on a wide range of Suzuki 4-stroke outboard motors (40-140HP) from 2001-2016 and select Johnson/Evinrude 4-stroke models (90-140HP)...

$43.90; $43.90
Unit price: per

Ignition Key Switch – Fits Suzuki 8-225 HP Outboard Engines (Replaces 37110-99E02)

Ignition Key Switch – Fits Suzuki 8-225 HP Outboard Engines (Replaces 37110-99E02) This is a main ignition key switch assembly for Suzuki outboard engines, designed for reliability and seamless operation. It features a 3-position switch (Off-Run-Start) and includes a convenient push-to-choke function integrated into...

$35.99; $35.99
Unit price: per

Thermostat (71°C/160°F) – Fits Suzuki Outboard DF90-DF300 (Replaces 17670-90J10)

Thermostat (71°C/160°F) – Fits Suzuki Outboard DF90-DF300 (Replaces 17670-90J10) This thermostat is designed for Suzuki 4-Stroke outboard motors from 90 to 300 HP, manufactured between 2001 and 2016. It fits a wide range of models, including the DF90, DF100, DF115, DF140, DF150, DF175, DF200,...

$25.50; $25.50
Unit price: per

photo of jlm marine water pump impeller kit for suzuki df250 df300, includes black rubber impeller with four vanes, silver metal housing, silver base gasket with punched holes, black figure-eight gasket, black rubber seal, and silver metal bracket

photo of JLM Marine water pump impeller kit for Suzuki df250 df300 with black plastic impeller and five rubber vanes

Water Pump Impeller Kit – Fits Suzuki DF250/DF300 Outboards (Replaces 17400-98J00/17400-98J01/17400-98J02/17400-98J03/17400-98J04)

Water Pump Impeller Kit – Fits Suzuki DF250/DF300 Outboards (Replaces 17400-98J00/17400-98J01/17400-98J02/17400-98J03/17400-98J04) This water pump impeller kit is designed for a range of Suzuki 4-Stroke outboard motors, including the DF250SS (2008–Current), DF250AP (2013–Current), DF300 (2007–2011), and DF300AP (2012–Current) models. It provides a reliable solution for...

$55.00; $55.00
Unit price: per

Water Pump Impeller Kit – Fits Suzuki DT4/DT5 4-5 HP (Replaces 17400-98650, 17400-98652)

Water Pump Impeller Kit – Fits Suzuki DT4/DT5 4-5 HP (Replaces 17400-98650, 17400-98652) This water pump impeller service kit is designed for Suzuki 2-stroke outboard motors, including the DT4 and DT5 models (4–5 HP) manufactured between 1984 and 2002. It also serves as a...

$22.99; ~~$23.00~~; $22.99
Unit price: per

Thermostat (60°C) – Fits Suzuki Outboard DF8A, DF9.9, DF15, DF20, DF25, DF30A (Replaces 17670-94J00, 17670-94J01, 17670-94J02)

Thermostat (60°C) – Fits Suzuki Outboard DF8A, DF9.9, DF15, DF20, DF25, DF30A This is an aftermarket replacement thermostat for Suzuki Outboard 4-stroke engines from 8 HP to 30 HP, covering 2005–2012 models including the DF8A, DF9.9, DF15, DF20, DF25, and DF30A series. It is...

$27.99; $27.99
Unit price: per

Thermostat, 50°C (122°F) – Fits Suzuki DF40-70/DT9.9-65/PU55 (Replaces 17670-93961, 17670-93962)

Thermostat, 50°C (122°F) – Fits Suzuki DF40-70/DT9.9-65/PU55 This thermostat opens at 50°C (122°F) to regulate cooling system operation in Suzuki outboard engines. It is engineered for a precise fit and reliable performance, ensuring your engine maintains its optimal temperature. This part is a direct...

$33.50; $33.50
Unit price: per

Water Pump Repair Kit – Fits Suzuki 8-20 HP (Replaces 17400-99J01)

Water Pump Repair Kit – Fits Suzuki 8-20 HP (Replaces 17400-99J01) This water pump repair kit is designed for Suzuki 4-stroke outboard models, including the DF8A, DF9.9A, DF9.9B, DF15A, and DF20A engines. It provides a reliable solution for maintaining your engine’s cooling system for...

$28.60; $28.60
Unit price: per

Water Pump Impeller Kit – Fits Suzuki DF40A/DF50A/DF60A 4-Stroke Outboard (Replaces 17400-88L00, 17400-88L01)

Water Pump Impeller Kit – Fits Suzuki DF40A/DF50A/DF60A 4-Stroke Outboard (Replaces 17400-88L00, 17400-88L01) This water pump impeller repair kit is designed for Suzuki 4-Stroke 40–60 HP outboard engines (DF40A, DF50A, DF60A models) from 2010 and newer. It serves as a direct replacement, ensuring your...

$31.30; $31.30
Unit price: per

Water Pump Impeller Kit – Fits Suzuki DF100A/DF115/DF115A/DF140A/DF150AP/DF175AP (Replaces 17400-92J21, 17400-92J22, 17400-92J23)

Water Pump Impeller Kit – Fits Suzuki DF100A/DF115/DF115A/DF140A/DF150AP/DF175AP This water pump impeller kit is designed for a range of Suzuki 4-stroke outboard motors from 90 HP to 175 HP (2009 and newer). It serves as a direct replacement part, manufactured to meet or exceed...

$35.00; $35.00
Unit price: per

Water Pump Impeller – Fits Suzuki DT9.9/DT15/DF8/DF9.9/DF15 & Johnson/Evinrude 9.9/15 HP (Replaces 17461-93903)

Water Pump Impeller – Fits Suzuki DT9.9/DT15/DF8/DF9.9/DF15 & Johnson/Evinrude 9.9/15 HP (Replaces 17461-93903) This water pump impeller is designed for a wide range of Suzuki and Johnson/Evinrude outboard motors. It serves as a direct replacement part, ensuring proper fit and function for maintaining your...

$12.00; $12.00
Unit price: per

photo of JLM Marine fuel pump for Suzuki 8-65 hp, silver and black rectangular body with black rubber diaphragm, two black side nozzles, IN and OUT markings

JLM Marine fuel pump for Suzuki 8-65 HP, silver-grey rectangular casing with IN OUT ports, black barb fittings, rubber diaphragm, includes gasket and hose clamps

Fuel Pump Assembly for Suzuki DT9.9, DT20-DT65 Models (15100-94300)

OEM Part Numbers 15100-94300, 15100-94312, 15100-94301, 15100-94302, 15100-94303, 15100-94310, 15100-94311 Compatible Models Suzuki Two-Stroke Engines DT9.9 (1988-1997) DT20 (1986-1988) DT25 (1983-2000) DT30 (1983-2000) DT35 (1980-1989) DT40 (1980-1998) DT50 (1977-1984) DT55 (1985-1997) DT60 (1983-1984) DT65 (1978-1997) Explosion Diagram Technical Specifications Weight: 181g Package Dimensions: 10*9*6...

$28.90; $28.90
Unit price: per

Water Pump Impeller Kit – Fits Suzuki 20-50 HP Outboard Motors (Replaces 17400-96350, 17400-96353)

Water Pump Impeller Kit – Fits Suzuki 20-50 HP Outboard Motors This water pump impeller service kit provides a reliable solution for maintaining the cooling system on a wide range of Suzuki outboards. It is designed to fit various 2-stroke and 4-stroke models, ensuring...

$25.99; ~~$31.00~~; $25.99
Unit price: per

photo of jlm marine water flush plug kit 17913-99e12 for suzuki 4-stroke df 25-140 hp compatible with three ribbed cylindrical plugs and three black o-rings

photo of jlm marine water flush plug kit 17913-99e12, three black plastic screw caps with ribbed shafts and circular indentations, and two black rubber o-rings, on white background

Water Flush Plug Kit – Fits Suzuki 4-Stroke DF 25-140 HP (Replaces 17913-99E12)

Water Flush Plug Kit – Fits Suzuki 4-Stroke DF 25-140 HP (Replaces 17913-99E12) This aftermarket water flush plug kit is designed for a range of Suzuki 4-Stroke outboards, including DF models from 25 to 140 HP (non-A/B versions) manufactured between 2001 and 2011. It...

$17.00; $17.00
Unit price: per

jlm marine timing belt 12761-93el0 black toothed serpentine loop

photo of JLM Marine timing belt 12761-93el0 for Suzuki DF9.9 DF15 DF20, black with trapezoidal teeth, curved U-shape

Timing Belt for Suzuki DF9.9, DF15, DF20 (2004+) (12761-93EL0)

Timing Belt – Fits Suzuki DF9.9/DF15/DF20 & Johnson/Evinrude 9.9/15 HP Outboards This high-quality timing belt is a direct replacement for specific Suzuki and Johnson/Evinrude 4-stroke outboard engines. It is engineered with a reinforced construction to meet or exceed OEM specifications, ensuring reliable engine timing...

$35.70; $35.70
Unit price: per

photo of jlm marine fuel pump for suzuki marine 20hp-90hp models 15100-94300, silver metal housing with black rubber, two barbed fittings, includes mounting plates and spring clips

photo of jlm marine fuel pump assembly 15100-94300 for suzuki marine 20hp-90hp models, silver octagonal pump with black rubber base and attached black hose

Fuel Pump Assembly for Yamaha 20HP-90HP 2-Stroke Outboards (692-24410-01-00)

Fuel Pump Assembly – Fits Yamaha 2-Stroke 20-90HP This fuel pump assembly is designed as a direct-fit replacement for a wide range of Yamaha 2-stroke outboard engines from 20 to 90 HP, including various C, E, and P-series models manufactured between 1984 and 2009....

Popular Products

Categories

Recent Post

Suzuki DF 90 2024 DF 90AWQH-440001~ Outboard Motor Parts Diagram & Catalog

Suzuki DF 90 2024 DF 90ATH-440001~ Outboard Motor Parts Diagram & Catalog

Suzuki DF 90 2024 DF 90AT-440001~ Outboard Motor Parts Diagram & Catalog

Featured Products

Shop by Motor

Live Help

Suzuki DF 250 2022 DF 250AP-240001~ Outboard Motor Parts Diagram & Catalog

Camshaft (DF250A:(020,021))

Camshaft (DF250A:022)

Clamp Bracket (L-Transom)

Clamp Bracket (X-Transom,XX-Transom)

Clutch Rod (020,021)

Clutch Rod (022)

Clutch Shaft

Cylinder Block

Cylinder Head

Drive Shaft Housing (L-Transom)

Drive Shaft Housing (X-Transom)

Drive Shaft Housing (XX-Transom)

Engine Cover ((021,022):DF250A)

Engine Cover (020:DF250A)

Engine Holder

Exhaust Cover

Fuel Hose (E01,E11)

Fuel Injector (E01,E03,E11)

Fuel Pump/Fuel Vapor Separator ((020,021):(E01,E03,E11))

Fuel Pump/Fuel Vapor Separator (022:(E01,E03,E11))

Gear Case (E01,E40)

Gear Case (E03,E11)

Harness

Intake Manifold

Key Less Start (020:(E01,E03),021:E11)

Key Less Start (022:E11)

Magneto

OPT: Gasket Set (E01,E03,E11)

OPT: Harness (1) (020,021)

OPT: Harness (1) (022)

OPT: Harness (2) (020,021)

OPT: Harness (2) (022)

OPT: Key Less Start ((020,021):(E01,E03,E11))

OPT: Key Less Start (022)

OPT: Multi Function Gauge (1) (020,021)

OPT: Multi Function Gauge (1) (022)

OPT: Multi Function Gauge (2) (020,021)

OPT: Multi Function Gauge (2) (022)

OPT: Remote Control Assy Dual (020,021)

OPT: Remote Control Assy Dual (022)

OPT: Remote Control Assy Single (020,021)

OPT: Remote Control Assy Single (022)

OPT: Switch (020,021)

OPT: Switch (022)

OPT:Flush Mount Remocon (020,021)

OPT:Flush Mount Remocon (022)

Oil Pan

Oil Pump

PTT Motor (L-Transom)

PTT Motor (X-Transom,XX-Transom)

PTT Switch/Engine Control Unit (DF250A)

Rectifier/Ignition Coil

Ring Gear Cover

Sensor (L-Transom)

Sensor (X-Transom,XX-Transom)

Side Cover (L-Transom)

Squeeze Pump (E03,E11,E40)

Starting Motor

Swivel Bracket (L-Transom)

Swivel Bracket (X-Transom,XX-Transom)

Thermostat

Throttle Body

Timing Chain

Transmission (020,021)

Transmission (022)

Trim Cylinder (L-Transom)

Trim Cylinder (X-Transom,XX-Transom)(See Note 1)

Trim Cylinder (X-Transom,XX-Transom)(See Note)

Water Pump (E01,E03,E11)

For Suzuki Outboard Owners:
