Mercury XR-6 Outboard Motor Parts Diagram & Catalog – Free PDF Download

ACCESSORIES

Below is the parts list for Mercury XR-6 ACCESSORIES:

Part Name	OEM Number	Supersedes
DECK FILL KIT, Oil	15969A3
FLUSHING ATTACHMENT	44357Q2
LINE ASSEMBLY, Fuel (8 Feet) Comment: WITH QUICK DISCONNECT	32-877680Q8
LINE ASSEMBLY, Fuel (12 Feet) Comment: WITH QUICK DISCONNECT	32-877680Q12	32-858620Q12, 32-858620A12, 32-827927A12 WITH QUICK DISCONNECT
LINE ASSEMBLY, Fuel (8 Feet) Comment: WITH QUICK DISCONNECT ENGINE END ONLY	32-877681Q8
LINE ASSEMBLY, Fuel (12 Feet) Comment: WITH QUICK DISCONNECT ENGINE END ONLY	32-877681Q12	32-804792Q12, 32-804792Q, 32-858621Q12, 32-858621A12, 32-17146A12 WITH QUICK DISCONNECT ENGINE END ONLY
LINE ASSEMBLY, Fuel (12 Feet) Comment: NO FIITINGS	32-877683Q12	32-858623Q12, 32-858623A12, 32-822379A12, 32-819380A12, FA599752, FS409752, 32-819380A 3, F216752, FA409752, F289752, FA178752, FA216752, FA284752, FA289752, FS409952 NO FIITINGS
MERCATHODE KIT	88334A2
MERCATHODE MONITOR	86300A5
HOSE EXTENSION KIT	41729A3
SWITCH KIT, Trim (10.00 Feet) Comment: (WITH OR WITHOUT TILLER)	87-18286A18
VISUAL WARNING SYSTEM Comment: (LOW OIL/OVERHEAT)	17334A2
DECK FILL KIT, Oil	15969A3
FLUSHING ATTACHMENT	44357Q2
LINE ASSEMBLY, Fuel (8 Feet) Comment: WITH QUICK DISCONNECT	32-877680Q8
LINE ASSEMBLY, Fuel (12 Feet) Comment: WITH QUICK DISCONNECT	32-877680Q12	32-858620Q12, 32-858620A12, 32-827927A12 WITH QUICK DISCONNECT
LINE ASSEMBLY, Fuel (8 Feet) Comment: WITH QUICK DISCONNECT ENGINE END ONLY	32-877681Q8
LINE ASSEMBLY, Fuel (12 Feet) Comment: WITH QUICK DISCONNECT ENGINE END ONLY	32-877681Q12	32-804792Q12, 32-804792Q, 32-858621Q12, 32-858621A12, 32-17146A12 WITH QUICK DISCONNECT ENGINE END ONLY
LINE ASSEMBLY, Fuel (12 Feet) Comment: NO FIITINGS	32-877683Q12	32-858623Q12, 32-858623A12, 32-822379A12, 32-819380A12, FA599752, FS409752, 32-819380A 3, F216752, FA409752, F289752, FA178752, FA216752, FA284752, FA289752, FS409952 NO FIITINGS
MERCATHODE KIT	88334A2
MERCATHODE MONITOR	86300A5
HOSE EXTENSION KIT	41729A3
SWITCH KIT, Trim (10.00 Feet) Comment: (WITH OR WITHOUT TILLER)	87-18286A18
VISUAL WARNING SYSTEM Comment: (LOW OIL/OVERHEAT)	17334A2

ATTENUATOR PLATE AND THROTTLE LEVERS

Below is the parts list for Mercury XR-6 ATTENUATOR PLATE AND THROTTLE LEVERS:

Position No.	Part Name	OEM Number	Supersedes
1	PLATE ASSEMBLY, Sound Attenuator	817495A1
2	GASKET	27-892211
3	SCREW, (.250-28 x 2.500)	10-884891
4	WASHER, (.281 x .734 x .063)	12-69057
5	CAP	19-815784	22-14685
6	LINKAGE KIT	828277A1
7	NOT SOLD SEPARATE, Throttle Lever	NSS
8	NOT SOLD SEPARATE, Throttle Lever	NSS
9	NOT SOLD SEPARATE, Throttle Link	NSS
10	ROLLER	18178
11	SCREW, (#10-32 x .750)	10-15124
12	WASHER, (.203 x .406 x .040)	12-89302
13	LOCKWASHER, External	10,13-69432
14	DECAL, EPA Label Information Comment: (1999)(135) (135)	37-856985A10	37-856985 10 (1999)(135) (135)
14	DECAL, EPA Label Information Comment: (1999)(150/XR6/MAG. III/175/200) (150/XR6/MAG. III/175/200)	37-856985A11	37-856985 11 (1999)(150/XR6/MAG. III/175/200) (150/XR6/MAG. III/175/200)
15	NOT SOLD SEPARATE, Decal-Caution Airbox	NSS
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
1	PLATE ASSEMBLY, Sound Attenuator	817495A1
2	GASKET	27-892211
3	SCREW, (.250-28 x 2.500)	10-884891
4	WASHER, (.281 x .734 x .063)	12-69057
5	CAP	19-815784	22-14685
6	LINKAGE KIT	828277A1
7	NOT SOLD SEPARATE, Throttle Lever	NSS
8	NOT SOLD SEPARATE, Throttle Lever	NSS
9	NOT SOLD SEPARATE, Throttle Link	NSS
10	ROLLER	18178
11	SCREW, (#10-32 x .750)	10-15124
12	WASHER, (.203 x .406 x .040)	12-89302
13	LOCKWASHER, External	10,13-69432
14	DECAL, EPA Label Information Comment: (1999)(135) (135)	37-856985A10	37-856985 10 (1999)(135) (135)
14	DECAL, EPA Label Information Comment: (1999)(150/XR6/MAG. III/175/200) (150/XR6/MAG. III/175/200)	37-856985A11	37-856985 11 (1999)(150/XR6/MAG. III/175/200) (150/XR6/MAG. III/175/200)
15	NOT SOLD SEPARATE, Decal-Caution Airbox	NSS
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90

Air Compressor Components

Below is the parts list for Mercury XR-6 Air Compressor Components:

Position No.	Part Name	OEM Number	Supersedes
1	COMPRESSOR ASSEMBLY, Air	8M0060053	8M0057463, 8M0050656, 899113A03, 831998A21, 831998A16, 831998A22, 831998A13, 831998T 9, 831998A14
2	END CAP ASSEMBLY	1100-8M0050792	1173-828131A12, 1173-828131A09, 1173-828131A 8
3	NOT SOLD SEPARATE, Retaining Ring	NSS
4	SCREW, (M6 x 20)	10-82130020
5	O-RING	25-89224
6	O-RING, (2.739 x .070)	25-832804
7	CONNECTING ROD ASSEMBLY	653-833146T06	653-833146T04, 653-833146T05, 653-833146T 3
8	PISTON ASSEMBLY	828222A4
9	RING, Lock	53-8348101
10	REED PLATE ASSEMBLY	835088A10	835088A 4
11	O-RING, (3.489 x .070)	25-67207
12	O-RING, (2.739 x .070)	25-832804
13	SEAL	26-828225
14	HEAD ASSEMBLY, Compressor	835087A3
15	FITTING, Straight	22-8307532
16	SCREW, (M8 x 35)	10-81893435
17	FITTING	22-15133
18	FITTING	22-14868
19	FITTING, Straight (.125-27)	22-16604
20	SENSOR ASSEMBLY, Temperature	13536A12
21	RETAINER	137151
22	SCREW, (M8 x 12)	10-81893412
23	O-RING, (.468 x .078)	25-831985	25-885187
24	FITTING	22-856744	22-856744 1
25	PLUG	22-390721
26	NOT SOLD SEPARATE, Decal-Important	NSS
27	GROMMET	25-855349002	25-855349
-	O-RING KIT	25-832804A03	25-832804A 1

Air Handler

Below is the parts list for Mercury XR-6 Air Handler:

Position No.	Part Name	OEM Number	Supersedes
1	COVER ASSEMBLY	827325A7
2	GROMMET	25-8M0153609
3	FILTER	35-853333T	35-853333
4	COVER	853352
5	RIVET	17-855590
6	RETAINER	854633
7	GROMMET	25-857101
8	GROMMET Comment: (150)	25-855613
9	GROMMET Comment: (135)	25-8556131
10	AIR HANDLER ASSEMBLY	855633A15	855633A 4
11	SHIM	15-856139
11	SHIM Comment: (.010 THICK)	15-8561391
12	NOT SOLD SEPARATE, Decal-Caution Start in Gear	NSS
13	BRACKET	855756A1
14	SLEEVE	23-803818
15	SCREW, (M6 x 16)	10-1993716
16	PUMP ASSEMBLY	8M0047624	855843 2
17	CLAMP, (15.7)	54-8M0214911
18	HOSE	32-856778
19	HOSE (18 IN.)	32-85564361
20	INSULATING SLEEVE	23-83312531
21	ELBOW	22-855802A1
22	FITTING	22-880862A1
23	O-RING, (.530 x .082)	25-805062
24	GROMMET	25-856928
25	ENCODER	8285581
26	SCREW, (#10-24 x .620)	10-418051
27	WASHER, (.203 x .500 x .032)	12-8M0204666
28	J CLIP (UPPER STBD.)	54-97224
29	J CLIP (LOWER)	54-8M0024808
30	SCREW, (.250-20 x 1.500) Stainless Steel	10-817504
31	HOSE, (57.00 Inches Bulk) (Cut to 5-3/4 Inches)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
32	FILTER	35-855896T	35-855896
33	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
34	CONNECTOR	22-860273
35	PIN	8215832
36	DECAL, EPA Label Information Comment: (1999)	37-856985A13	37-856985 13 (1999)
37	TIE STRAP, (14.00 Inches)	61990
38	CABLE ASSEMBLY	84-88807A27
39	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
40	WASHER	12-8M0207778
-	POWERHEAD ASSEMBLY Comment: SN# 0G886267 & Up	804545T99	854008T99, 854008T98, 854008A98 SN# 0G886267 & Up
-	POWERHEAD ASSEMBLY Comment: SN# 0G886266 & Below	804545T99	854008T99, 854008T98, 854008A98 SN# 0G886266 & Below

Air Handler Components

Below is the parts list for Mercury XR-6 Air Handler Components:

Position No.	Part Name	OEM Number	Supersedes
-	AIR HANDLER ASSEMBLY	855633A15	855633A 4
1	ADAPTOR PLATE KIT	855420T02
2	GASKET	27-146973
3	GASKET	27-8500581
4	REED BLOCK	855952T2
5	SCREW, (.250-20 x .880)	10-55715
6	PUMP, Oil	855884P1
7	GASKET	27-8565421
8	BRACKET	8552841
9	FITTING	22-855424
10	FITTING	22-8554241
11	FITTING	22-8554246
12	FITTING (STRAIGHT)	22-8554248
13	BUSHING	23-855364
14	GROMMET	25-855362001	25-855362
15	SCREW, (M8 x 40)	10-81893440
16	WASHER, (.344 x 1.00 x .063) Stainless Steel	12-817274	12-817274 1
17	PLENUM KIT, Air	850248A1
18	ELBOW	22-8554242
19	ELBOW Comment: (.236 O.D.)	22-8554249
19	FITTING Comment: (.159 O.D.)	22-15133
20	GASKET	27-8500581
21	SENSOR ASSEMBLY, Temperature	13221T01
22	SCREW, (M4 x 10)	10-4005685
23	LOCKWASHER, Stainless Steel	8,13-26995
24	SCREW, (M4 x 16)	10-4001987
25	THROTTLE BODY KIT	855422A1
26	O-RING	25-855423
27	SCREW, (M6 x 40)	10-82130040
-	POWERHEAD ASSEMBLY Comment: SN# 0G886267 & Up	804545T99	854008T99, 854008T98, 854008A98 SN# 0G886267 & Up
-	POWERHEAD ASSEMBLY Comment: SN# 0G886266 & Below	804545T99	854008T99, 854008T98, 854008A98 SN# 0G886266 & Below

BLEED SYSTEM

Below is the parts list for Mercury XR-6 BLEED SYSTEM:

Position No.	Part Name	OEM Number	Supersedes
1	TUBING, (20.00 Feet Bulk) (9 IN.)	32-892024122	32-99130122
2	TUBING, (20.00 Feet Bulk) (12-1/2 IN.)	32-892024122	32-99130122
3	TUBING, (20.00 Feet Bulk) (14 IN.)	32-892024122	32-99130122
4	TUBING, (20.00 Feet Bulk) (19 IN.)	32-892024122	32-99130122
5	TUBING, (20.00 Feet Bulk) (24 IN.)	32-892024122	32-99130122
6	TUBING, (20.00 Feet Bulk) (26 IN.)	32-892024122	32-99130122
7	CHECK VALVE	21-426982
8	FITTING, Elbow	22-822715
9	FITTING, Barbed	22-56759
10	CHECK VALVE	21-426233
-	POWERHEAD ASSEMBLY Comment: (135)	878365T00	812815T00, 812815T97, 812815A97, 812815A96, 812815A92, 812815A90 (135)
-	POWERHEAD ASSEMBLY Comment: (150/XR6/MAGNUM III)	823434T97	823434A97, 823434A96, 823434A93 (150/XR6/MAGNUM III)
-	POWERHEAD ASSEMBLY Comment: (175)	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (175)
-	POWERHEAD ASSEMBLY Comment: (200)	813043T97	813043A97, 813043A96, 813043A94, 812827A92, 813043A92 (200)
1	TUBING, (20.00 Feet Bulk) (9 IN.)	32-892024122	32-99130122
2	TUBING, (20.00 Feet Bulk) (12-1/2 IN.)	32-892024122	32-99130122
3	TUBING, (20.00 Feet Bulk) (14 IN.)	32-892024122	32-99130122
4	TUBING, (20.00 Feet Bulk) (19 IN.)	32-892024122	32-99130122
5	TUBING, (20.00 Feet Bulk) (24 IN.)	32-892024122	32-99130122
6	TUBING, (20.00 Feet Bulk) (26 IN.)	32-892024122	32-99130122
7	CHECK VALVE	21-426982
8	FITTING, Elbow	22-822715
9	FITTING, Barbed	22-56759
10	CHECK VALVE	21-426233
-	POWERHEAD ASSEMBLY Comment: (135)	878365T00	812815T00, 812815T97, 812815A97, 812815A96, 812815A92, 812815A90 (135)
-	POWERHEAD ASSEMBLY Comment: (150/XR6/MAGNUM III)	823434T97	823434A97, 823434A96, 823434A93 (150/XR6/MAGNUM III)
-	POWERHEAD ASSEMBLY Comment: (175)	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (175)
-	POWERHEAD ASSEMBLY Comment: (200)	813043T97	813043A97, 813043A96, 813043A94, 812827A92, 813043A92 (200)

BOTTOM COWL

Below is the parts list for Mercury XR-6 BOTTOM COWL:

Position No.	Part Name	OEM Number	Supersedes
1	BOTTOM COWL, Black Comment: (BLACK-PORT)	4022-828044A1
2	BOTTOM COWL, Black Comment: (BLACK-STARBOARD)	4022-828045A1
3	SEAL, Cowl (41.00 Inches)	8M0109217	8M0043272, 825318 1
4	CLAMP	54-822024
5	CLAMP	54-822023
6	SCREW, (#10-16 x 1.12)	10-92799
7	SCREW, (M6 x 40)	10-82130040
8	RETAINER	831209
9	PLUG	19-821908
10	WASHER	12-821915
11	CHECK VALVE	8219631
12	O-RING, (.299 x .103)	25-30641
13	FITTING	22-821952
14	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
15	HOSE	32-8M0039077	32-832078 2
16	CLAMP, Worm Gear	54-815504212	54-8M2004076
17	ELBOW, Cylinder Block	22-8320761
18	FITTING, Tell-Tale	22-8M0077650	821904
19	HOSE, (57.00 Inches Bulk) (Cut to 8 Inches)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
20	IDLE EXHAUST BOOT, Exhaust	889847	828216
21	CHECK VALVE ASSEMBLY, Drain	21-817519A1
22	SWITCH ASSEMBLY	87-8M0042301	87-896620, 87-856990, 87-850691, 87-18286A40
23	SCREW, (M6 x 75)	10-824868
24	FRONT HANDLE, Black Comment: (BLACK)	889740A02	821253F 1, 821253F 2, 821253F 4 (BLACK)
25	BUSHING	23-335891
26	O-RING, (.614 x .070)	25-48462
27	PAWL	8219423
28	WASHER, (.281 x .734 x .063)	12-69057
29	NUT, (M6)	11-401366
30	SCREW, (#10-16 x .625)	10-8214281
31	CLIP	54-822873
1	BOTTOM COWL, Black Comment: (BLACK-PORT)	4022-828044A1
2	BOTTOM COWL, Black Comment: (BLACK-STARBOARD)	4022-828045A1
3	SEAL, Cowl (41.00 Inches)	8M0109217	8M0043272, 825318 1
4	CLAMP	54-822024
5	CLAMP	54-822023
6	SCREW, (#10-16 x 1.12)	10-92799
7	SCREW, (M6 x 40)	10-82130040
8	RETAINER	831209
9	PLUG	19-821908
10	WASHER	12-821915
11	CHECK VALVE	8219631
12	O-RING, (.299 x .103)	25-30641
13	FITTING	22-821952
14	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
15	HOSE	32-8M0039077	32-832078 2
16	CLAMP, Worm Gear	54-815504212	54-8M2004076
17	ELBOW, Cylinder Block	22-8320761
18	FITTING, Tell-Tale	22-8M0077650	821904
19	HOSE, (57.00 Inches Bulk) (Cut to 8 Inches)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
20	IDLE EXHAUST BOOT, Exhaust	889847	828216
21	CHECK VALVE ASSEMBLY, Drain	21-817519A1
22	SWITCH ASSEMBLY	87-8M0042301	87-896620, 87-856990, 87-850691, 87-18286A40
23	SCREW, (M6 x 75)	10-824868
24	FRONT HANDLE, Black Comment: (BLACK)	889740A02	821253F 1, 821253F 2, 821253F 4 (BLACK)
25	BUSHING	23-335891
26	O-RING, (.614 x .070)	25-48462
27	PAWL	8219423
28	WASHER, (.281 x .734 x .063)	12-69057
29	NUT, (M6)	11-401366
30	SCREW, (#10-16 x .625)	10-8214281
31	CLIP	54-822873

Bottom Cowl

Below is the parts list for Mercury XR-6 Bottom Cowl:

Position No.	Part Name	OEM Number	Supersedes
1	BOTTOM COWL Comment: (PORT) (BLACK)	100-8M0107321
2	BOTTOM COWL Comment: (STARBOARD) (BLACK)	103-834815A1
3	SEAL, Cowl (41.00 Inches)	8M0109217	8M0043272, 825318 1
4	CLAMP	54-822024
5	CLAMP	54-822023
6	SCREW, (#10-16 x 1.12)	10-92799
7	SCREW, (M6 x 40)	10-82130040
8	RETAINER	831209
9	PLUG	19-821908
10	WASHER	12-821915
11	CHECK VALVE	8219631
12	O-RING, (.299 x .103)	25-30641
13	FITTING	22-821952
14	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
15	HOSE	32-8M0039077	32-832078 2
16	CLAMP, (28.6)	54-850896
17	FITTING	22-8320763
18	FITTING, Tell-Tale	22-8M0077650	821904
19	IDLE EXHAUST BOOT, Exhaust	889847	828216
20	CHECK VALVE ASSEMBLY, Drain	21-817519A1
21	SWITCH ASSEMBLY	87-8M0042301	87-896620, 87-856990, 87-850691, 87-18286A40
22	SCREW, (M6 x 75)	10-824868
23	FRONT HANDLE, Black	889740A02	821253F 1, 821253F 2, 821253F 4
24	BUSHING	23-335891
25	O-RING, (.614 x .070)	25-48462
26	PAWL	8219423
27	WASHER, (.281 x .734 x .063)	12-69057
28	NUT, (M6)	11-401366
29	SCREW, (#10-16 x .625)	10-8214281
30	CLIP	54-822873

CARBURETOR

Below is the parts list for Mercury XR-6 CARBURETOR:

Position No.	Part Name	OEM Number	Supersedes
1	CARBURETOR, Top Comment: 135 - WMV-1A	3326-828272T37	3326-828272A37, 3326-828272A 1 135 - WMV-1A
1	CARBURETOR, Center Comment: 135 - WMV-1A	3326-828272T38	3326-828272A38, 3326-828272A 2 135 - WMV-1A
1	CARBURETOR, Bottom Comment: 135 - WMV-1A	3326-828272T39	3326-828272A39, 3326-828272A 3 135 - WMV-1A
1	CARBURETOR, Top Comment: 150/XR6/MAGNUM III - WMV-3A	3326-828272T43	3326-828272A43, 3326-828272A 7 150/XR6/MAGNUM III - WMV-3A
1	CARBURETOR, Center Comment: 150/XR6/MAGNUM III - WMV-3A	3326-828272T44	3326-828272A44, 3326-828272A 8 150/XR6/MAGNUM III - WMV-3A
1	CARBURETOR, Bottom Comment: 150/XR6/MAGNUM III - WMV-3A	3326-828272A45	3326-828272A 9 150/XR6/MAGNUM III - WMV-3A
1	CARBURETOR, Top Comment: 175 - WMV-4A	3326-828272T46	3326-828272A46, 3326-828272A10 175 - WMV-4A
1	CARBURETOR, Center Comment: 175 - WMV-4A	3326-828272T47	3326-828272A47, 3326-828272A11 175 - WMV-4A
1	CARBURETOR, Bottom Comment: 175 - WMV-4A	3326-828272T48	3326-828272A48, 3326-828272A12 175 - WMV-4A
1	CARBURETOR, Top Comment: 200 - WMV-5A	3326-828272T49	3326-828272A49, 3326-828272A13 200 - WMV-5A
1	CARBURETOR, Center Comment: 200 - WMV-5A	3326-828272T50	3326-828272A50, 3326-828272A14 200 - WMV-5A
1	CARBURETOR, Bottom Comment: 200 - WMV-5A	3326-828272T51	3326-828272A15, 3326-828272A51 200 - WMV-5A
2	COVER	1395-809743
3	GASKET	1395-809758
4	SCREW	1395-8087391
5	GASKET	27-828292
6	JET, (.036) Comment: (TOP/CENTER)(135) PORT	1399-3026
6	JET, .040 Comment: (BOTTOM)(135) PORT	1399-7570
6	JET, Idle Air Vent Comment: (.042-TOP/CENTER)(150/XR6/MAGNUM III) PORT	815633042
6	JET, (.048) Comment: (BOTTOM)(150/XR6/MAGNUM III) PORT	815633048
6	JET, (.030) Comment: (TOP/CENTER)(175) PORT	810741
6	JET, (.038) Comment: (BOTTOM)(175) PORT	815633038
6	JET, (.052) Comment: (TOP)(200) PORT	815633052
6	JET, (.028) Comment: (CENTER)(200) PORT	815633028
6	JET, (.032) Comment: (BOTTOM)(200) PORT	1399-3252
7	JET, (.086) Comment: (135/175)	1395-5815
7	JET, (.082) Comment: (150/XR6/MAGNUM III)	1399-3518
7	JET, Main (.096) Comment: (200)	1399-6249
8	JET, (.036) Comment: (135) STARBOARD	1399-3026
8	JET, (.044) Comment: (150/XR6/MAGNUM III) STARBOARD	810742
8	JET, (.030) Comment: (175) STARBOARD	810741
8	JET, (.052) Comment: (TOP)(200) STARBOARD	815633052
8	JET, (.028) Comment: (CENTER/BOTTOM)(200) STARBOARD	815633028
9	CAP	810779
10	NOT SOLD SEPARATE, Idle Mixture Screw/Spring	NSS
11	LEVER KIT	1395-8113523
12	SPACER	1395-6031
13	NOT SOLD SEPARATE, Spring	NSS
14	NOT SOLD SEPARATE, Gasket-Fuel Bowl	NSS
15	FLOAT ASSEMBLY	810738
16	SHAFT	F10064
17	SCREW, (#6-32 x .187)	1395-5902
18	VALVE SEAT KIT	1395-8116901
19	NOT SOLD SEPARATE, Gasket-Valve Seat	NSS
20	BOWL, Fuel (TOP)	1395-8236231
20	BOWL, Fuel (CENTER/BOTTOM)	1395-8236241
21	SCREW AND WASHER, (#8-32 x .750)	1395-808612	1399-5132
22	PLUG KIT	1395-811694	1395-9596 1
23	SEAL (CONSISTS OF 4 GASKETS)	1395-802731
24	JET, (.072) Comment: (135)	1395-6207
24	JET, (.074) Comment: (150/XR6/MAGNUM III)	1399-3794
24	JET, (.078) Comment: (175)	1395-6680
24	JET, (.080) Comment: (200)	1395-6201
24	JET, (.082) Comment: (200-TOP)	1399-3518
25	TEE FITTING (TOP/CENTER)	1395-7900
26	ELBOW (BOTTOM)	1395-7901
-	GASKET SET, Carburetor	8107493
-	REPAIR KIT, Carburetor	1395-8116913
1	CARBURETOR, Top Comment: 135 - WMV-1A	3326-828272T37	3326-828272A37, 3326-828272A 1 135 - WMV-1A
1	CARBURETOR, Center Comment: 135 - WMV-1A	3326-828272T38	3326-828272A38, 3326-828272A 2 135 - WMV-1A
1	CARBURETOR, Bottom Comment: 135 - WMV-1A	3326-828272T39	3326-828272A39, 3326-828272A 3 135 - WMV-1A
1	CARBURETOR, Top Comment: 150/XR6/MAGNUM III - WMV-3A	3326-828272T43	3326-828272A43, 3326-828272A 7 150/XR6/MAGNUM III - WMV-3A
1	CARBURETOR, Center Comment: 150/XR6/MAGNUM III - WMV-3A	3326-828272T44	3326-828272A44, 3326-828272A 8 150/XR6/MAGNUM III - WMV-3A
1	CARBURETOR, Bottom Comment: 150/XR6/MAGNUM III - WMV-3A	3326-828272A45	3326-828272A 9 150/XR6/MAGNUM III - WMV-3A
1	CARBURETOR, Top Comment: 175 - WMV-4A	3326-828272T46	3326-828272A46, 3326-828272A10 175 - WMV-4A
1	CARBURETOR, Center Comment: 175 - WMV-4A	3326-828272T47	3326-828272A47, 3326-828272A11 175 - WMV-4A
1	CARBURETOR, Bottom Comment: 175 - WMV-4A	3326-828272T48	3326-828272A48, 3326-828272A12 175 - WMV-4A
1	CARBURETOR, Top Comment: 200 - WMV-5A	3326-828272T49	3326-828272A49, 3326-828272A13 200 - WMV-5A
1	CARBURETOR, Center Comment: 200 - WMV-5A	3326-828272T50	3326-828272A50, 3326-828272A14 200 - WMV-5A
1	CARBURETOR, Bottom Comment: 200 - WMV-5A	3326-828272T51	3326-828272A15, 3326-828272A51 200 - WMV-5A
2	COVER	1395-809743
3	GASKET	1395-809758
4	SCREW	1395-8087391
5	GASKET	27-828292
6	JET, (.036) Comment: (TOP/CENTER)(135) PORT	1399-3026
6	JET, .040 Comment: (BOTTOM)(135) PORT	1399-7570
6	JET, Idle Air Vent Comment: (.042-TOP/CENTER)(150/XR6/MAGNUM III) PORT	815633042
6	JET, (.048) Comment: (BOTTOM)(150/XR6/MAGNUM III) PORT	815633048
6	JET, (.030) Comment: (TOP/CENTER)(175) PORT	810741
6	JET, (.038) Comment: (BOTTOM)(175) PORT	815633038
6	JET, (.052) Comment: (TOP)(200) PORT	815633052
6	JET, (.028) Comment: (CENTER)(200) PORT	815633028
6	JET, (.032) Comment: (BOTTOM)(200) PORT	1399-3252
7	JET, (.086) Comment: (135/175)	1395-5815
7	JET, (.082) Comment: (150/XR6/MAGNUM III)	1399-3518
7	JET, Main (.096) Comment: (200)	1399-6249
8	JET, (.036) Comment: (135) STARBOARD	1399-3026
8	JET, (.044) Comment: (150/XR6/MAGNUM III) STARBOARD	810742
8	JET, (.030) Comment: (175) STARBOARD	810741
8	JET, (.052) Comment: (TOP)(200) STARBOARD	815633052
8	JET, (.028) Comment: (CENTER/BOTTOM)(200) STARBOARD	815633028
9	CAP	810779
10	NOT SOLD SEPARATE, Idle Mixture Screw/Spring	NSS
11	LEVER KIT	1395-8113523
12	SPACER	1395-6031
13	NOT SOLD SEPARATE, Spring	NSS
14	NOT SOLD SEPARATE, Gasket-Fuel Bowl	NSS
15	FLOAT ASSEMBLY	810738
16	SHAFT	F10064
17	SCREW, (#6-32 x .187)	1395-5902
18	VALVE SEAT KIT	1395-8116901
19	NOT SOLD SEPARATE, Gasket-Valve Seat	NSS
20	BOWL, Fuel (TOP)	1395-8236231
20	BOWL, Fuel (CENTER/BOTTOM)	1395-8236241
21	SCREW AND WASHER, (#8-32 x .750)	1395-808612	1399-5132
22	PLUG KIT	1395-811694	1395-9596 1
23	SEAL (CONSISTS OF 4 GASKETS)	1395-802731
24	JET, (.072) Comment: (135)	1395-6207
24	JET, (.074) Comment: (150/XR6/MAGNUM III)	1399-3794
24	JET, (.078) Comment: (175)	1395-6680
24	JET, (.080) Comment: (200)	1395-6201
24	JET, (.082) Comment: (200-TOP)	1399-3518
25	TEE FITTING (TOP/CENTER)	1395-7900
26	ELBOW (BOTTOM)	1395-7901
-	GASKET SET, Carburetor	8107493
-	REPAIR KIT, Carburetor	1395-8116913

CRANKSHAFT, PISTONS AND CONNECTING RODS

Below is the parts list for Mercury XR-6 CRANKSHAFT, PISTONS AND CONNECTING RODS:

Position No.	Part Name	OEM Number	Supersedes
1	CRANKSHAFT ASSEMBLY	455-9536T4
2	BEARING, Ball (LOWER)	30-67923T
3	RING	53-67446
4	GEAR SEGMENT KIT, Drive	43-14513A09
5	SCREW, (#6-32 x .630) Socket Button Head	10-854812
6	NUT, Special	6-32,11-854811
7	CARRIER ASSEMBLY	54196A6
8	PACKING	65800
9	RING, Sealing, CRANKSHAFT	39-67377T
10	BEARING KIT	31-16756A6
11	NOT SOLD SEPARATE, Bearing	NSS
12	PISTON Comment: (STARBOARD-STANDARD) 135	765-7441T32
12	PISTON Comment: (STARBOARD-.015 O.S.) 135	765-7443A11
12	PISTON Comment: (STARBOARD-.030 OS.) 135	765-7445T11
12	PISTON Comment: (PORT-STANDARD) 135	765-7442T32
12	PISTON Comment: (PORT-.015 O.S.) 135	765-7444A11
12	PISTON Comment: (PORT-.030 O.S.) 135	765-7446A11
12	PISTON ASSEMBLY, Standard Comment: (STARBOARD-STANDARD) 150/XR6 MAGNUM III 175/200	785-9738T9
12	PISTON ASSEMBLY, .015 Oversize Comment: (STARBOARD-.015 O.S.) 150/XR6 MAGNUM III 175/200	785-9738T10
12	PISTON ASSEMBLY, Standard Comment: (PORT-STANDARD) 150/XR6 MAGNUM III 175/200	785-9737T9
12	PISTON ASSEMBLY, .015 Oversize Comment: (PORT-.015 O.S.) 150/XR6 MAGNUM III 175/200	785-9737A10
13	RING SET, Piston - Standard Comment: (STANDARD) 135	39-93481A12
13	RING SET, Piston - .015 Oversize Comment: (.015 O.S.) 135	39-78918A4
13	RING SET, Piston - .030 Oversize Comment: (.030 O.S.) 135	39-85636A4
13	RING KIT, Piston - Standard Comment: (STD.) 150/XR6 MAGNUM III 175/200	39-822321A12	39-822321A 8, 39-824905A12 (STD.) 150/XR6 MAGNUM III 175/200
13	RING KIT, Piston - .015 Oversize Comment: (.015 O.S.) 150/XR6 MAGNUM III 175/200	39-822321A1
14	RING, Lock	53-857196	40-52035
15	NOT SOLD SEPARATE, Piston Pin	NSS
16	CONNECTING ROD KIT	644-818141A13	644-818141A 2
17	SCREW, (.312-24 x .875)	10-763491
18	WASHER	12-8M0012298	12-812876
19	BEARING KIT	8M0234886
20	BEARING, Needle	29-8M0204691
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	POWERHEAD ASSEMBLY Comment: (135)	878365T00	812815T00, 812815T97, 812815A97, 812815A96, 812815A92, 812815A90 (135)
-	POWERHEAD ASSEMBLY Comment: (150/XR6/MAGNUM III)	823434T97	823434A97, 823434A96, 823434A93 (150/XR6/MAGNUM III)
-	POWERHEAD ASSEMBLY Comment: (175)	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (175)
-	POWERHEAD ASSEMBLY Comment: (200)	813043T97	813043A97, 813043A96, 813043A94, 812827A92, 813043A92 (200)
1	CRANKSHAFT ASSEMBLY	455-9536T4
2	BEARING, Ball (LOWER)	30-67923T
3	RING	53-67446
4	GEAR SEGMENT KIT, Drive	43-14513A09
5	SCREW, (#6-32 x .630) Socket Button Head	10-854812
6	NUT, Special	6-32,11-854811
7	CARRIER ASSEMBLY	54196A6
8	PACKING	65800
9	RING, Sealing, CRANKSHAFT	39-67377T
10	BEARING KIT	31-16756A6
11	NOT SOLD SEPARATE, Bearing	NSS
12	PISTON Comment: (STARBOARD-STANDARD) 135	765-7441T32
12	PISTON Comment: (STARBOARD-.015 O.S.) 135	765-7443A11
12	PISTON Comment: (STARBOARD-.030 OS.) 135	765-7445T11
12	PISTON Comment: (PORT-STANDARD) 135	765-7442T32
12	PISTON Comment: (PORT-.015 O.S.) 135	765-7444A11
12	PISTON Comment: (PORT-.030 O.S.) 135	765-7446A11
12	PISTON ASSEMBLY, Standard Comment: (STARBOARD-STANDARD) 150/XR6 MAGNUM III 175/200	785-9738T9
12	PISTON ASSEMBLY, .015 Oversize Comment: (STARBOARD-.015 O.S.) 150/XR6 MAGNUM III 175/200	785-9738T10
12	PISTON ASSEMBLY, Standard Comment: (PORT-STANDARD) 150/XR6 MAGNUM III 175/200	785-9737T9
12	PISTON ASSEMBLY, .015 Oversize Comment: (PORT-.015 O.S.) 150/XR6 MAGNUM III 175/200	785-9737A10
13	RING SET, Piston - Standard Comment: (STANDARD) 135	39-93481A12
13	RING SET, Piston - .015 Oversize Comment: (.015 O.S.) 135	39-78918A4
13	RING SET, Piston - .030 Oversize Comment: (.030 O.S.) 135	39-85636A4
13	RING KIT, Piston - Standard Comment: (STD.) 150/XR6 MAGNUM III 175/200	39-822321A12	39-822321A 8, 39-824905A12 (STD.) 150/XR6 MAGNUM III 175/200
13	RING KIT, Piston - .015 Oversize Comment: (.015 O.S.) 150/XR6 MAGNUM III 175/200	39-822321A1
14	RING, Lock	53-857196	40-52035
15	NOT SOLD SEPARATE, Piston Pin	NSS
16	CONNECTING ROD KIT	644-818141A13	644-818141A 2
17	SCREW, (.312-24 x .875)	10-763491
18	WASHER	12-8M0012298	12-812876
19	BEARING KIT	8M0234886
20	BEARING, Needle	29-8M0204691
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	POWERHEAD ASSEMBLY Comment: (135)	878365T00	812815T00, 812815T97, 812815A97, 812815A96, 812815A92, 812815A90 (135)
-	POWERHEAD ASSEMBLY Comment: (150/XR6/MAGNUM III)	823434T97	823434A97, 823434A96, 823434A93 (150/XR6/MAGNUM III)
-	POWERHEAD ASSEMBLY Comment: (175)	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (175)
-	POWERHEAD ASSEMBLY Comment: (200)	813043T97	813043A97, 813043A96, 813043A94, 812827A92, 813043A92 (200)

CYLINDER BLOCK AND END CAPS

Below is the parts list for Mercury XR-6 CYLINDER BLOCK AND END CAPS:

Position No.	Part Name	OEM Number	Supersedes
1	CYLINDER BLOCK Comment: (135)	884-859211T2
1	CYLINDER BLOCK Comment: (150/XR6/MAG. III)	884-9763T23
1	CYLINDER BLOCK Comment: (175)	884-9763T17
1	CYLINDER BLOCK Comment: (200)	884-9763T61
2	STUD, Powerhead (1-3/4 IN.)	16-8M0034455	16-818138 4
3	STUD, (.375 x 5.620)	16-670654
3	STUD, (.375 x 6.870) (6-3/4 IN.)	16-8M0034454	16-78438 5
4	PIN, Dowel - Without Hole (.375 x .625)	17-43044
5	PIN (BEARING RACE)	17-8M0036405	17-67296
6	GASKET	27-11338
7	COVER (UPPER)	8M0088723	42249 1
8	SCREW, (.312-18 x 1.500) Hex Flange	10-828213
9	COVER (LOWER)	76867
10	SCREW, (.312-18 x 2.00) Hex Flange	10-828214
11	CHECK VALVE	21-8781051
12	BUSHING	23-99448
13	SCREW, (.375-16 x 3.250)	10-66717
13	SCREW, (.312-18 x 1.250)	10-74824
14	NOT SOLD SEPARATE, Plug	NSS
15	END CAP ASSEMBLY, Upper	1159-858521T1
16	O-RING, (2.800 x .103)	25-54029
17	BEARING KIT	31-16756A4
18	NOT SOLD SEPARATE, Race	NSS
19	SEAL	26-41953
20	SCREW AND LOCKWASHER, (.312-18 x 1.00)	10-30225
21	STUD, (.190-32 x 1.870)	16-15094
22	J CLIP	54-63153
23	NOT SOLD SEPARATE, Plug-Serial Number	NSS
24	SPACER	23-67269
25	WASHER, (.187 x .500 x .062) Neoprene	12-8M0204663
26	WING NUT,	10-32,11-816874	11-73651, 11-816873, 11-90052
27	IDLE SPEED CONTROL	87076A10
28	SCREW, (#10-32 x .875)	10-690201
29	WASHER, (.192 x .375 x .0312) Stainless Steel	12-30164
30	BRACKET	422482
31	SCREW, (.250-20 x .750)	10-49668
32	STUD, (#10-32 x 1.00)	16-8M0034435	16-15093
33	CAP, Nylon	26852
34	SCREW, (.250-20 x 2.125)	10-64022
35	NUT, (.250-20)	11-64015
36	END CAP ASSEMBLY	1156-7809T1
37	O-RING, (3.237 x .103)	25-62700
38	SEAL	26-41953
39	SCREW, (.250-20 x .750)	10-28636
40	LOCKWASHER, (.250) Stainless Steel	13-26992
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	POWERHEAD ASSEMBLY Comment: (135)	878365T00	812815T00, 812815T97, 812815A97, 812815A96, 812815A92, 812815A90 (135)
-	POWERHEAD ASSEMBLY Comment: (150/XR6/MAGNUM III)	823434T97	823434A97, 823434A96, 823434A93 (150/XR6/MAGNUM III)
-	POWERHEAD ASSEMBLY Comment: (175)	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (175)
-	POWERHEAD ASSEMBLY Comment: (200)	813043T97	813043A97, 813043A96, 813043A94, 812827A92, 813043A92 (200)
1	CYLINDER BLOCK Comment: (135)	884-859211T2
1	CYLINDER BLOCK Comment: (150/XR6/MAG. III)	884-9763T23
1	CYLINDER BLOCK Comment: (175)	884-9763T17
1	CYLINDER BLOCK Comment: (200)	884-9763T61
2	STUD, Powerhead (1-3/4 IN.)	16-8M0034455	16-818138 4
3	STUD, (.375 x 5.620)	16-670654
3	STUD, (.375 x 6.870) (6-3/4 IN.)	16-8M0034454	16-78438 5
4	PIN, Dowel - Without Hole (.375 x .625)	17-43044
5	PIN (BEARING RACE)	17-8M0036405	17-67296
6	GASKET	27-11338
7	COVER (UPPER)	8M0088723	42249 1
8	SCREW, (.312-18 x 1.500) Hex Flange	10-828213
9	COVER (LOWER)	76867
10	SCREW, (.312-18 x 2.00) Hex Flange	10-828214
11	CHECK VALVE	21-8781051
12	BUSHING	23-99448
13	SCREW, (.375-16 x 3.250)	10-66717
13	SCREW, (.312-18 x 1.250)	10-74824
14	NOT SOLD SEPARATE, Plug	NSS
15	END CAP ASSEMBLY, Upper	1159-858521T1
16	O-RING, (2.800 x .103)	25-54029
17	BEARING KIT	31-16756A4
18	NOT SOLD SEPARATE, Race	NSS
19	SEAL	26-41953
20	SCREW AND LOCKWASHER, (.312-18 x 1.00)	10-30225
21	STUD, (.190-32 x 1.870)	16-15094
22	J CLIP	54-63153
23	NOT SOLD SEPARATE, Plug-Serial Number	NSS
24	SPACER	23-67269
25	WASHER, (.187 x .500 x .062) Neoprene	12-8M0204663
26	WING NUT,	10-32,11-816874	11-73651, 11-816873, 11-90052
27	IDLE SPEED CONTROL	87076A10
28	SCREW, (#10-32 x .875)	10-690201
29	WASHER, (.192 x .375 x .0312) Stainless Steel	12-30164
30	BRACKET	422482
31	SCREW, (.250-20 x .750)	10-49668
32	STUD, (#10-32 x 1.00)	16-8M0034435	16-15093
33	CAP, Nylon	26852
34	SCREW, (.250-20 x 2.125)	10-64022
35	NUT, (.250-20)	11-64015
36	END CAP ASSEMBLY	1156-7809T1
37	O-RING, (3.237 x .103)	25-62700
38	SEAL	26-41953
39	SCREW, (.250-20 x .750)	10-28636
40	LOCKWASHER, (.250) Stainless Steel	13-26992
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	POWERHEAD ASSEMBLY Comment: (135)	878365T00	812815T00, 812815T97, 812815A97, 812815A96, 812815A92, 812815A90 (135)
-	POWERHEAD ASSEMBLY Comment: (150/XR6/MAGNUM III)	823434T97	823434A97, 823434A96, 823434A93 (150/XR6/MAGNUM III)
-	POWERHEAD ASSEMBLY Comment: (175)	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (175)
-	POWERHEAD ASSEMBLY Comment: (200)	813043T97	813043A97, 813043A96, 813043A94, 812827A92, 813043A92 (200)

Crankshaft, Pistons and Connecting Rods

Below is the parts list for Mercury XR-6 Crankshaft, Pistons and Connecting Rods:

Position No.	Part Name	OEM Number	Supersedes
1	CRANKSHAFT ASSEMBLY	455-850690T2
2	WEAR SLEEVE	78662
3	BEARING, Ball (LOWER)	30-67923T
4	RING	53-67446
5	CARRIER ASSEMBLY	54196A6
6	PACKING	65800
7	RING, Sealing	39-67377T
8	BEARING KIT	31-16756A6
9	NOT SOLD SEPARATE, Race	NSS
10	PISTON Comment: (STARBOARD-STANDARD)	2716-853341T2
10	PISTON Comment: (STARBOARD-.015 O/S)	2716-853341A10
10	PISTON Comment: (PORT-STANDARD)	2716-853340T2
10	PISTON Comment: (PORT-.015 O/S)	2716-853340A10
11	RING SET, Piston Comment: (STANDARD)	39-853306A12
11	RING SET, Piston Comment: (.015 O/S)	39-857120T12
12	RING, Lock	53-857196	40-52035
13	CONNECTING ROD KIT	644-818141A13	644-818141A 2
14	SCREW, (.312-24 x .875)	10-763491
15	WASHER	12-8M0012298	12-812876
16	BEARING KIT	8M0234886
17	BEARING, Needle	29-8M0204691
-	GASKET SET	27-8M0046714	27-814754A00, 27-814754A98
-	POWERHEAD ASSEMBLY Comment: SN# 0G886267 & Up	804545T99	854008T99, 854008T98, 854008A98 SN# 0G886267 & Up
-	POWERHEAD ASSEMBLY Comment: SN# 0G886266 & Below	804545T99	854008T99, 854008T98, 854008A98 SN# 0G886266 & Below

Cylinder Block and End Caps

Below is the parts list for Mercury XR-6 Cylinder Block and End Caps:

Position No.	Part Name	OEM Number	Supersedes
1	CYLINDER BLOCK Comment: SN# 0G886267 & Up	884-828340A14	884-828340T 5 SN# 0G886267 & Up
1	CYLINDER BLOCK Comment: SN# 0G886266 & Below	884-828340A14	884-828340T 5 SN# 0G886266 & Below
2	STUD, Powerhead (1-3/4 IN.)	16-8M0034455	16-818138 4
3	STUD, (.375 x 5.620) Comment: (5-1/2 Inches)	16-670654
3	STUD, (.375 x 6.870) Comment: (6-3/4 Inches)	16-8M0034454	16-78438 5 (6-3/4 Inches)
4	PIN, Dowel - Without Hole (.375 x .625)	17-43044
5	PIN (BEARING RACE)	17-8M0036405	17-67296
6	GASKET	27-11338
7	FITTING (1/2-14)	22-384071
8	CHECK VALVE	21-426233
9	CHECK VALVE	21-426982
10	TUBING, (20.00 Feet Bulk) (Cut to 19 Inches)	32-892024122	32-99130122
11	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
12	CHECK VALVE (Starboard) Comment: SN# 0G886267 & Up	21-858927
12	FITTING (Starboard-Center) Comment: SN# 0G886266 & Below	22-855622
13	CHECK VALVE (Port) Comment: SN# 0G886267 & Up	21-858805
13	ELBOW (Port) Comment: SN# 0G886266 & Below	22-8267611
14	FITTING, Starboard-Top/Bottom Comment: SN# 0G886266 & Below	22-852760
15	TUBING (17-1/2 Inches) Comment: (TOP/BOTTOM)	32-85583464
15	TUBING (20 Inches) Comment: (CENTER)	32-85583464
16	TUBING, (36.00 Inches Bulk) (24-1/2 IN.)	32-8M0054152	32-856060 65
17	CONDUIT, (.750 Inside Diameter x 3.00 Feet Bulk) (Cut to 7 Inches)	32-828547753
18	CHECK VALVE	21-8781051
19	HOSE, (57.00 Inches Bulk) (Cut to 11-1/2 Inches)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
20	CONNECTOR	22-822769
21	TIE STRAP, (4.00 Inches)	56762
22	SCREW, (.375-16 x 3.250)	10-66717
23	SCREW, (.312-18 x 1.250)	10-74824
24	CAP, Nylon	26852
25	SCREW, (.250-20 x 1.750)	10-856832
26	NUT, (.250-20)	11-64015
27	END CAP ASSEMBLY	1159-832760T1
28	O-RING, (2.800 x .103)	25-54029
29	BEARING KIT	31-16756A4
30	NOT SOLD SEPARATE, Bearing Race	NSS
31	SEAL	26-41953
32	SCREW AND LOCKWASHER, (.312-18 x 1.00)	10-30225
33	END CAP ASSEMBLY	1156-7809T1
34	O-RING, (3.237 x .103)	25-62700
35	SEAL	26-41953
36	SCREW, (.250-20 x .750)	10-28636
37	LOCKWASHER, (.250) Stainless Steel	13-26992
38	BRACKET	8538821
39	LEVER, Throttle Position Indicator	8519371
40	SCREW, (M6 x 25)	10-82130025
41	BUSHING	23-8318701
42	GROMMET	25-8M0190980
43	INDICATOR, Throttle Position (Inside)	8M6005165
44	SPACER	850882
45	INDICATOR, Throttle Position (Outside)	8M6005166
46	SCREW (#10-32 X 2-3/4 IN.)	10-850828
47	LINK, Throttle	8M0084738
48	NOT SOLD SEPARATE, Plug-Serial Number	NSS
49	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
-	GASKET SET	27-8M0046714	27-814754A00, 27-814754A98
-	POWERHEAD ASSEMBLY Comment: SN# 0G886267 & Up	804545T99	854008T99, 854008T98, 854008A98 SN# 0G886267 & Up
-	POWERHEAD ASSEMBLY Comment: SN# 0G886266 & Below	804545T99	854008T99, 854008T98, 854008A98 SN# 0G886266 & Below

Cylinder Head

Below is the parts list for Mercury XR-6 Cylinder Head:

Position No.	Part Name	OEM Number	Supersedes
1	CYLINDER HEAD Comment: (PORT)	852380T1
1	CYLINDER HEAD Comment: (STARBOARD)	852381T1
2	GASKET	27-8525203
3	SCREW, (.375-16 x 3.00)	10-832971
4	PIN, Dowel	17-74840
5	GASKET	27-8M0204714
6	COVER	8M0039353	830737 2
7	THERMOSTAT, 62Â° Celsius (143Â° Fahrenheit)	833072003	833072
8	SCREW, (M6 x 25)	10-82130025
9	FITTING, (.250-18) 90 Degree - Brass (Starboard)	22-687271
10	FITTING (Port)	22-68728
11	HOSE, (48.00 Inches Bulk) (Cut to 21-1/2 Inches)	32-77653101
12	HOSE, (48.00 Inches Bulk) (Cut to 11-1/2 Inches)	32-77653101
13	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
14	SENSOR ASSEMBLY, Temperature (Starboard)	13536A14
15	RETAINER	137151
16	SCREW, (M8 x 12)	10-81893412
-	GASKET SET	27-8M0046714	27-814754A00, 27-814754A98
-	POWERHEAD ASSEMBLY Comment: SN# 0G886267 & Up	804545T99	854008T99, 854008T98, 854008A98 SN# 0G886267 & Up
-	POWERHEAD ASSEMBLY Comment: SN# 0G886266 & Below	804545T99	854008T99, 854008T98, 854008A98 SN# 0G886266 & Below

DRIVE SHAFT HOUSING AND EXHAUST TUBE

Below is the parts list for Mercury XR-6 DRIVE SHAFT HOUSING AND EXHAUST TUBE:

Position No.	Part Name	OEM Number	Supersedes
1	HOUSING ASSEMBLY, Driveshaft - Black - Long Comment: (LONG)	1590-8343T10
1	HOUSING, Driveshaft - Black - X-Long Comment: (X-LONG)	3503-813563T1
1	HOUSING ASSEMBLY, Driveshaft Comment: (JET)	1590-8343A13
2	STUD, (.437 x 2.69)	16-56295
3	SCREW, (.500-20 x 6.00)	10-898831	10-63474
4	CABLE ASSEMBLY, Ground	88238A10
5	MOUNT Comment: (135/175 LONG)(JET)	78249
5	MOUNT Comment: (ALL OTHER MODELS)	77327
6	WASHER, (.8125)	12-49339
7	CABLE ASSEMBLY, Ground	88238A10
8	NUT, (.500-20)	11-898832	11-826708 17
9	SCREW, (.250-20 x .500) Stainless Steel	10-41508
10	WASHER, (.453 x .812 x .105) Stainless Steel	12-45176
11	NUT, (.437-20) Stainless Steel	11-8M0204653
12	CLAMP	54-8M0036782	54-67076
13	SCREW, (.312-18 x 1.250)	10-66727
14	COVER, Black	100-8M4500752	8M0001130, 67077T
15	SCREW, (#12-24 x .620)	10-88417
16	NUT	11-35521
17	WASHER	12-48926
18	NUT, (.437-20) Stainless Steel	11-8M0204653
19	WASHER, (.406 x .734 x .063)	12-20553
20	NUT	11-69254
21	BOOT, Idle Exhaust	8M0039081	828212
22	PLUG	19-64649
23	GASKET	27-991734
24	SEAL (LOWER)	66350001
25	TUBE, Exhaust	18276T
26	SEAL (UPPER)	8M0039076	17726 1
27	EXTENSION, Exhaust Comment: (135/150/175/XR6/MAGNUM III)	812834A2
27	EXTENSION, Exhaust Comment: (200) (JET)	879288T71	41942 4 (200) (JET)
28	TUBE, Water Comment: (LONG) (JET)	32-8M0042788	32-859097 1 (LONG) (JET)
28	TUBE Comment: (X-LONG)	32-8M0042790	32-859097 2 (X-LONG)
29	GASKET	27-782461
30	PLATE ASSEMBLY	18233A20
31	SEAL	8M0043165	814701 2
32	BRACKET	68011
33	SCREW, (#10-16 x .500)	10-878608	10-812832
34	PIN, Dowel - Without Hole (.375 x .625)	17-43044
35	SEAL	26-38970
36	SCREW, (.250-20 x .750) Stainless Steel	10-90192
37	GASKET	27-183076
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
1	HOUSING ASSEMBLY, Driveshaft - Black - Long Comment: (LONG)	1590-8343T10
1	HOUSING, Driveshaft - Black - X-Long Comment: (X-LONG)	3503-813563T1
1	HOUSING ASSEMBLY, Driveshaft Comment: (JET)	1590-8343A13
2	STUD, (.437 x 2.69)	16-56295
3	SCREW, (.500-20 x 6.00)	10-898831	10-63474
4	CABLE ASSEMBLY, Ground	88238A10
5	MOUNT Comment: (135/175 LONG)(JET)	78249
5	MOUNT Comment: (ALL OTHER MODELS)	77327
6	WASHER, (.8125)	12-49339
7	CABLE ASSEMBLY, Ground	88238A10
8	NUT, (.500-20)	11-898832	11-826708 17
9	SCREW, (.250-20 x .500) Stainless Steel	10-41508
10	WASHER, (.453 x .812 x .105) Stainless Steel	12-45176
11	NUT, (.437-20) Stainless Steel	11-8M0204653
12	CLAMP	54-8M0036782	54-67076
13	SCREW, (.312-18 x 1.250)	10-66727
14	COVER, Black	100-8M4500752	8M0001130, 67077T
15	SCREW, (#12-24 x .620)	10-88417
16	NUT	11-35521
17	WASHER	12-48926
18	NUT, (.437-20) Stainless Steel	11-8M0204653
19	WASHER, (.406 x .734 x .063)	12-20553
20	NUT	11-69254
21	BOOT, Idle Exhaust	8M0039081	828212
22	PLUG	19-64649
23	GASKET	27-991734
24	SEAL (LOWER)	66350001
25	TUBE, Exhaust	18276T
26	SEAL (UPPER)	8M0039076	17726 1
27	EXTENSION, Exhaust Comment: (135/150/175/XR6/MAGNUM III)	812834A2
27	EXTENSION, Exhaust Comment: (200) (JET)	879288T71	41942 4 (200) (JET)
28	TUBE, Water Comment: (LONG) (JET)	32-8M0042788	32-859097 1 (LONG) (JET)
28	TUBE Comment: (X-LONG)	32-8M0042790	32-859097 2 (X-LONG)
29	GASKET	27-782461
30	PLATE ASSEMBLY	18233A20
31	SEAL	8M0043165	814701 2
32	BRACKET	68011
33	SCREW, (#10-16 x .500)	10-878608	10-812832
34	PIN, Dowel - Without Hole (.375 x .625)	17-43044
35	SEAL	26-38970
36	SCREW, (.250-20 x .750) Stainless Steel	10-90192
37	GASKET	27-183076
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90

Driveshaft Housing and Exhaust Tube

Below is the parts list for Mercury XR-6 Driveshaft Housing and Exhaust Tube:

Position No.	Part Name	OEM Number	Supersedes
1	HOUSING ASSEMBLY, Driveshaft - Black - Long Comment: (LONG) (BLACK)	1590-8343T10
1	HOUSING, Driveshaft - Black - X-Long Comment: (X-LONG) (BLACK)	3503-813563T1
2	STUD, (.437 x 2.69)	16-56295
3	SCREW, (.500-20 x 6.00)	10-898831	10-63474
4	CABLE ASSEMBLY, Ground	88238A10
5	MOUNT	77327
6	WASHER, (.8125)	12-49339
7	CABLE ASSEMBLY, Ground	88238A10
8	NUT, (.500-20)	11-898832	11-826708 17
9	SCREW, (.250-20 x .500) Stainless Steel	10-41508
10	WASHER, (.453 x .812 x .105) Stainless Steel	12-45176
11	NUT, (.437-20) Stainless Steel	11-8M0204653
12	CLAMP	54-8M0036782	54-67076
13	SCREW, (.312-18 x 1.250)	10-66727
14	COVER, Black	100-8M4500752	8M0001130, 67077T
15	SCREW, (#12-24 x .620)	10-88417
16	NUT	11-35521
17	WASHER	12-48926
18	NUT, (.437-20) Stainless Steel	11-8M0204653
19	WASHER, (.406 x .734 x .063)	12-20553
20	NUT	11-69254
21	BOOT, Idle Exhaust	8M0039081	828212
22	PLUG	19-64649
23	GASKET	27-991734
24	SEAL (LOWER)	66350001
25	TUBE, Exhaust	18276T
26	SEAL (UPPER)	8M0039076	17726 1
27	EXTENSION, Exhaust Comment: (150)	812834A2
27	EXTENSION, Exhaust Comment: (135)	879288T71	41942 4 (135)
28	TUBE, Water Comment: (LONG)	32-8M0042788	32-859097 1 (LONG)
28	TUBE Comment: (X-LONG)	32-8M0042790	32-859097 2 (X-LONG)
29	GASKET Comment: (USE WHERE APPLICABLE)	27-782461
30	PLATE ASSEMBLY	18233A20
31	SEAL	8M0043165	814701 2
32	BRACKET	68011
33	SCREW, (#10-16 x .500)	10-878608	10-812832
34	PIN, Dowel - Without Hole (.375 x .625)	17-43044
35	SEAL	26-38970
36	SCREW, (.250-20 x .750) Stainless Steel	10-90192
37	PLUG Comment: (USE WHERE APPLICABLE)	22-390721
38	GASKET	27-183076
-	GASKET SET	27-8M0046714	27-814754A00, 27-814754A98

Dual Engine Tie Bar Kit

Below is the parts list for Mercury XR-6 Dual Engine Tie Bar Kit:

Position No.	Part Name	OEM Number	Supersedes
-	EXTENSION KIT, Dual Engine	92876A9
1	TUBE ASSEMBLY	71565A2
2	O-RING, (.614 x .070)	25-48462
3	MOUNT	41055
4	TAB WASHER	14-42100
5	NUT, (.875-14)	11-8M0041651	11-37984
6	TAB WASHER	88404
7	SCREW, (.250-28 x 1.250)	10-38601
8	BRACKET	17729A1
9	SCREW, (.312-24 x 1.250)	10-62055
10	TAB WASHER	17728
11	SCREW, (.375-24 x 1.38)	10-140001
12	NUT, (.375-24)	11-8M0204726
13	STEERING EYE	8M0026167	8M0005848, 97933 1
14	SLEEVE, (1.625)	23-23651
15	TUBING, (4.00 Inches)	97931
16	COUPLER, (15.00 Inches)	8M0026098	814951 3
17	NUT, (.562-18)	11-42099
18	COUPLING	22-821169
19	WASHER, (.406 x .734 x .063) Stainless Steel	12-34931
20	SCREW, (.375-24 x 1.5)	10-94319
-	EXTENSION KIT, Dual Engine	92876A9
1	TUBE ASSEMBLY	71565A2
2	O-RING, (.614 x .070)	25-48462
3	MOUNT	41055
4	TAB WASHER	14-42100
5	NUT, (.875-14)	11-8M0041651	11-37984
6	TAB WASHER	88404
7	SCREW, (.250-28 x 1.250)	10-38601
8	BRACKET	17729A1
9	SCREW, (.312-24 x 1.250)	10-62055
10	TAB WASHER	17728
11	SCREW, (.375-24 x 1.38)	10-140001
12	NUT, (.375-24)	11-8M0204726
13	STEERING EYE	8M0026167	8M0005848, 97933 1
14	SLEEVE, (1.625)	23-23651
15	TUBING, (4.00 Inches)	97931
16	COUPLER, (15.00 Inches)	8M0026098	814951 3
17	NUT, (.562-18)	11-42099
18	COUPLING	22-821169
19	WASHER, (.406 x .734 x .063) Stainless Steel	12-34931
20	SCREW, (.375-24 x 1.5)	10-94319
-	EXTENSION KIT, Dual Engine	92876A9
1	TUBE ASSEMBLY	71565A2
2	O-RING, (.614 x .070)	25-48462
3	MOUNT	41055
4	TAB WASHER	14-42100
5	NUT, (.875-14)	11-8M0041651	11-37984
6	TAB WASHER	88404
7	SCREW, (.250-28 x 1.250)	10-38601
8	BRACKET	17729A1
9	SCREW, (.312-24 x 1.250)	10-62055
10	TAB WASHER	17728
11	SCREW, (.375-24 x 1.38)	10-140001
12	NUT, (.375-24)	11-8M0204726
13	STEERING EYE	8M0026167	8M0005848, 97933 1
14	SLEEVE, (1.625)	23-23651
15	TUBING, (4.00 Inches)	97931
16	COUPLER, (15.00 Inches)	8M0026098	814951 3
17	NUT, (.562-18)	11-42099
18	COUPLING	22-821169
19	WASHER, (.406 x .734 x .063) Stainless Steel	12-34931
20	SCREW, (.375-24 x 1.5)	10-94319

EXHAUST MANIFOLD AND EXHAUST PLATE

Below is the parts list for Mercury XR-6 EXHAUST MANIFOLD AND EXHAUST PLATE:

Position No.	Part Name	OEM Number	Supersedes
1	GASKET	27-190503
2	DIVIDER PLATE	827323A2
3	SEAL, (12.50 Inches)	26-814754	42838 1, 69668, 88726
4	CLAMP	54-814634
5	SCREW AND WASHER, (.312-18 x 1.500)	10-8263561
6	FITTING, (.500-14)	22-8144301
7	FITTING, (.250-18) (90 DEGREES)	22-920071
8	HOSE, (57.00 Inches Bulk) (23-1/2 IN.)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
9	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
10	COVER	8M0039767	68729 1
11	SCREW, (.312-18 x 1.250)	10-74824
12	GASKET	27-78690002
13	SCREW, (#10-16 x .750)	10-69570
14	WASHER	12-76451
15	DIAPHRAGM	144791
16	DEFLECTOR, Water	16496
17	PLATE	16497A1
18	SPRING	24-64878
19	WASHER	12-85303
20	POPPET	14480
21	GROMMET	25-64872
22	CARRIER	65848
23	GASKET	27-991764
24	PLATE ASSEMBLY, Exhaust	18260T2
25	FITTING, Straight	22-897722
26	PIN, Dowel - Without Hole (.375 x .625)	17-43044
27	SEAL	8M0043164	814701 1
28	BRACKET	680101
29	SCREW, (#10-16 x .500)	10-878608	10-812832
30	WASHER, (.406 x .734 x .063)	12-20553
31	NUT	11-69254
32	BUSHING	23-27132
33	GROMMET	25-8M0179867
34	GROMMET	25-19565002
35	SCREW, (.312-18 x 1.250)	10-66727
36	SCREW, (.312-18 x 2.50)	10-68783
37	SCREW, (.375-16 x 3.50)	10-898833	10-66725
38	BRACKET ASSEMBLY, Front	812905T	812905A 5
39	SCREW, (.3125-18 x .50)	10-8055571
40	WASHER	12-187031
41	GROMMET	25-18778001
42	BRACKET ASSEMBLY, Rear	18578T09
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	POWERHEAD ASSEMBLY Comment: (135)	878365T00	812815T00, 812815T97, 812815A97, 812815A96, 812815A92, 812815A90 (135)
-	POWERHEAD ASSEMBLY Comment: (150/XR6/MAGNUM III)	823434T97	823434A97, 823434A96, 823434A93 (150/XR6/MAGNUM III)
-	POWERHEAD ASSEMBLY Comment: (175)	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (175)
-	POWERHEAD ASSEMBLY Comment: (200)	813043T97	813043A97, 813043A96, 813043A94, 812827A92, 813043A92 (200)
1	GASKET	27-190503
2	DIVIDER PLATE	827323A2
3	SEAL, (12.50 Inches)	26-814754	42838 1, 69668, 88726
4	CLAMP	54-814634
5	SCREW AND WASHER, (.312-18 x 1.500)	10-8263561
6	FITTING, (.500-14)	22-8144301
7	FITTING, (.250-18) (90 DEGREES)	22-920071
8	HOSE, (57.00 Inches Bulk) (23-1/2 IN.)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
9	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
10	COVER	8M0039767	68729 1
11	SCREW, (.312-18 x 1.250)	10-74824
12	GASKET	27-78690002
13	SCREW, (#10-16 x .750)	10-69570
14	WASHER	12-76451
15	DIAPHRAGM	144791
16	DEFLECTOR, Water	16496
17	PLATE	16497A1
18	SPRING	24-64878
19	WASHER	12-85303
20	POPPET	14480
21	GROMMET	25-64872
22	CARRIER	65848
23	GASKET	27-991764
24	PLATE ASSEMBLY, Exhaust	18260T2
25	FITTING, Straight	22-897722
26	PIN, Dowel - Without Hole (.375 x .625)	17-43044
27	SEAL	8M0043164	814701 1
28	BRACKET	680101
29	SCREW, (#10-16 x .500)	10-878608	10-812832
30	WASHER, (.406 x .734 x .063)	12-20553
31	NUT	11-69254
32	BUSHING	23-27132
33	GROMMET	25-8M0179867
34	GROMMET	25-19565002
35	SCREW, (.312-18 x 1.250)	10-66727
36	SCREW, (.312-18 x 2.50)	10-68783
37	SCREW, (.375-16 x 3.50)	10-898833	10-66725
38	BRACKET ASSEMBLY, Front	812905T	812905A 5
39	SCREW, (.3125-18 x .50)	10-8055571
40	WASHER	12-187031
41	GROMMET	25-18778001
42	BRACKET ASSEMBLY, Rear	18578T09
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	POWERHEAD ASSEMBLY Comment: (135)	878365T00	812815T00, 812815T97, 812815A97, 812815A96, 812815A92, 812815A90 (135)
-	POWERHEAD ASSEMBLY Comment: (150/XR6/MAGNUM III)	823434T97	823434A97, 823434A96, 823434A93 (150/XR6/MAGNUM III)
-	POWERHEAD ASSEMBLY Comment: (175)	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (175)
-	POWERHEAD ASSEMBLY Comment: (200)	813043T97	813043A97, 813043A96, 813043A94, 812827A92, 813043A92 (200)

Electrical Components

Below is the parts list for Mercury XR-6 Electrical Components:

Position No.	Part Name	OEM Number	Supersedes
1	PLATE, Electrical Mounting	850675
2	COIL KIT	339-856991A1
3	CABLE ASSEMBLY, Hi Tension	84-881908T	84-821945T74, 84-821945T65
4	SPARK PLUG Comment: (HEAVY DUTY)	33-889597Q	33-889597001, 33-855672 1 (HEAVY DUTY)
4	SPARK PLUG Comment: (MED/LT DUTY-NGK-ZFR5F-11)	33-8557171
4	SPARK PLUG Comment: (MED/LT DUTY-CH#RC12MC4)	33-858409	33-318 (MED/LT DUTY-CH#RC12MC4)
5	SPACER	850676F1
6	SCREW, (.250-20 x 3.250)	10-850898
7	SENSOR, MAP	825762
8	SCREW, (M6 x 14)	10-82129114
9	TUBING, (36.00 Inches Bulk) (31 Inch)	32-9912688
10	SCREW, (.312-18 x 1.250)	10-60411
11	WASHER	12-49436
12	GROMMET	25-833155
13	BUSHING	23-8502341
14	SCREW, (M6 x 14)	10-82129114
15	WASHER, (.281 x .625 x .065) Stainless Steel	12-35044
16	NUT, (.250-20)	11-8267098
17	HARNESS ASSEMBLY, Trim	84-819514A14
18	RELAY ASSEMBLY	8M0207773
19	NOT SOLD SEPARATE, Decal-Trim Relay	NSS
20	BRACKET	828102
21	BUSHING	23-8M0214955
22	GROMMET	25-818967
23	SCREW, (M6 x 25) Comment: (M6 X 25)	10-82129125
23	SCREW, (M6 x 35) Comment: (M6 X 35)	10-82129135
24	BUSHING	23-91912
25	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
26	HARNESS ASSEMBLY, Engine	84-853330A2
27	HARNESS ASSEMBLY (ALTERNATOR)	84-856624A2
28	HARNESS ASSEMBLY (DIRECT INJECTOR)	879346A49	84-858781A 2
29	HARNESS ASSEMBLY (FUEL INJECTOR)	879346A50	84-858780A 2
30	FUSE, Yellow - 20 Ampere	88-812619	88-860608
31	NOT SOLD SEPARATE, Bracket-Fuse Holder	NSS
32	SCREW (M4 X 8)	10-855634
33	ECU, Engine Control Unit Comment: (135)	858891A20	856496R 8, 857127A 3 (135)
33	ECU, Engine Control Unit Comment: (150)	858891A21	856496R 9, 857127A 4 (150)
34	PAD	830897
35	SCREW, (M6 x 25)	10-82130025
36	BUSHING	23-8318701
37	GROMMET	25-8M0190980
38	SCREW, (M6 x 14)	10-82129114
39	CLIP	54-853947
40	CLAMP	8266241
41	SCREW, (#10-16 x .380)	10-878607	10-817626
42	PLATE, Solenoid Mounting	8331371
43	SCREW, (M6 x 12)	10-82130012
44	SCREW, (M6 x 14)	10-82129114
45	SOLENOID ASSEMBLY, (#10-32 / .3125-18 Terminals)	89-817109A2
46	GROMMET	25-822179
47	SCREW, (M6 x 25)	10-82129125
48	CABLE ASSEMBLY, Yellow/Black	84-93388A14
49	BUSHING	23-8M0214955
50	CABLE ASSEMBLY, Battery - Positive	84-88439A25
51	LOCKWASHER, (.312)	13-53166
52	NUT, (.312-18)	11-8M0204668
53	NUT, Brass	10-32,11-45076
54	CABLE ASSEMBLY, (4.00 Inches) Black	84-88807A16
55	CAP NUT,	10-32,11-813938

Exhaust Manifold and Exhaust Plate

Below is the parts list for Mercury XR-6 Exhaust Manifold and Exhaust Plate:

Position No.	Part Name	OEM Number	Supersedes
1	GASKET	27-190503
2	PLATE, Exhaust Divider	828343T3
3	SEAL, (12.50 Inches)	26-814754	42838 1, 69668, 88726
4	SCREW AND WASHER, (.312-18 x 1.500)	10-8263561
5	SCREW, (.312-18 x 1.00)	10-881190	10-855288
6	STRAINER	35-8348082
7	TUBING, (.312) (70.00 Inches Bulk) (Cut to 4-1/2 Inches)	32-8M0108349	32-8M0047448, 32-830757130, 32-830757 80
8	FITTING, (.250-18) 90 Degree - Brass	22-687271
9	HOSE, (48.00 Inches Bulk) (Cut to 21-1/2 Inches)	32-77653101
10	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
11	COVER	8M0039767	68729 1
12	SCREW, (.312-18 x 1.250)	10-74824
13	SCREW, (#10-16 x .750)	10-69570
14	WASHER	12-76451
15	DIAPHRAGM	144791
16	DEFLECTOR, Water	16496
17	PLATE	16497A1
18	GASKET	27-78690002
19	SPRING	24-64878
20	WASHER	12-85303
21	POPPET	14480
22	GROMMET	25-64872
23	CARRIER	65848
24	GASKET	27-991764
25	PLATE ASSEMBLY, Exhaust	850814T1
26	PIN, Dowel - Without Hole (.375 x .625)	17-43044
27	SEAL	8M0043164	814701 1
28	BRACKET	680101
29	SCREW, (#10-16 x .500)	10-878608	10-812832
30	CONNECTOR, (.125-27) (Straight)(Back)	22-89772
31	FITTING, Elbow - 90 Degree (.125-27) (Starboard-Top Hole)	22-629101
32	CONNECTOR, (.125-27) (Straight)(Starboard-Bottom Hole)	22-89772
33	GROMMET	25-8M0179867
34	GROMMET	25-19565002
35	HOSE, (48.00 Inches Bulk) (Cut to 25 Inches)	32-77653101
36	HOSE	32-852759
37	WASHER, (.406 x .734 x .063)	12-20553
38	NUT	11-69254
39	BUSHING	23-27132
40	SCREW, (.312-18 x 1.250)	10-66727
41	SCREW, (.312-18 x 2.50)	10-68783
42	SCREW, (.375-16 x 3.50)	10-898833	10-66725
43	BRACKET ASSEMBLY, Front	812905T	812905A 5
44	SCREW, (.3125-18 x .50)	10-8055571
45	WASHER	12-187031
46	GROMMET	25-18778001
47	BRACKET ASSEMBLY, Rear	18578T09
-	GASKET SET	27-8M0046714	27-814754A00, 27-814754A98
-	POWERHEAD ASSEMBLY Comment: SN# 0G886267 & Up	804545T99	854008T99, 854008T98, 854008A98 SN# 0G886267 & Up
-	POWERHEAD ASSEMBLY Comment: SN# 0G886266 & Below	804545T99	854008T99, 854008T98, 854008A98 SN# 0G886266 & Below

FLYWHEEL/STARTER MOTOR

Below is the parts list for Mercury XR-6 FLYWHEEL/STARTER MOTOR:

Position No.	Part Name	OEM Number	Supersedes
1	COVER KIT	18896A1
2	MARKER	79022
3	SCREW, (.190-32 x .380)	10-37572
4	WASHER, (.203 x .562 x .060) Stainless Steel	12-72761
5	PLUG, Yellow	19-45907
6	NUT, (.625-18)	11-52901
7	WASHER, (.641 x 1.250 x .190)	12-33001
8	FLYWHEEL	271-859238T16	271-859238T 8
9	STATOR	398-9610A19
10	SCREW, (#10-32 x 1.375)	10-90045
11	LOCKWASHER, Stainless Steel	10,13-26996
12	PLATE ASSEMBLY, Trigger	96455A9
13	STARTER MOTOR ASSEMBLY	50-893893	50-79472T 2, 50-79472 2
14	COLLAR	23-8M0034918	23-8M0001391, 56703
15	STOP, Rubber	8M0043376	68042
16	SCREW AND LOCKWASHER, (.250-20 x .625) Stainless Steel	10-69035
17	CABLE ASSEMBLY, (6.00 Inches) Black	84-93388A1
18	CABLE ASSEMBLY (BLACK)	84-93388A14
19	LOCKWASHER, (.250) Stainless Steel	13-26992
20	NUT, (.250-20) Brass	11-94330
21	NOT SOLD SEPARATE, Decal-Timing	NSS
22	NOT SOLD SEPARATE, Decal-In Gear Idle	NSS
23	DECAL, Warning, High Voltage	37-8272822
24	DECAL, Caution, Start In Gear	37-881865	37-825064
1	COVER KIT	18896A1
2	MARKER	79022
3	SCREW, (.190-32 x .380)	10-37572
4	WASHER, (.203 x .562 x .060) Stainless Steel	12-72761
5	PLUG, Yellow	19-45907
6	NUT, (.625-18)	11-52901
7	WASHER, (.641 x 1.250 x .190)	12-33001
8	FLYWHEEL	271-859238T16	271-859238T 8
9	STATOR	398-9610A19
10	SCREW, (#10-32 x 1.375)	10-90045
11	LOCKWASHER, Stainless Steel	10,13-26996
12	PLATE ASSEMBLY, Trigger	96455A9
13	STARTER MOTOR ASSEMBLY	50-893893	50-79472T 2, 50-79472 2
14	COLLAR	23-8M0034918	23-8M0001391, 56703
15	STOP, Rubber	8M0043376	68042
16	SCREW AND LOCKWASHER, (.250-20 x .625) Stainless Steel	10-69035
17	CABLE ASSEMBLY, (6.00 Inches) Black	84-93388A1
18	CABLE ASSEMBLY (BLACK)	84-93388A14
19	LOCKWASHER, (.250) Stainless Steel	13-26992
20	NUT, (.250-20) Brass	11-94330
21	NOT SOLD SEPARATE, Decal-Timing	NSS
22	NOT SOLD SEPARATE, Decal-In Gear Idle	NSS
23	DECAL, Warning, High Voltage	37-8272822
24	DECAL, Caution, Start In Gear	37-881865	37-825064

FUEL LINES

Below is the parts list for Mercury XR-6 FUEL LINES:

Position No.	Part Name	OEM Number	Supersedes
1	TUBING, (15.00 Inches Bulk) (4-1/2 IN.)	32-82381335
2	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
3	CONNECTOR, Tee	22-818993
4	HOSE	32-830760	32-19017
5	CHECK VALVE	22-8189941
6	TUBING, (.312) (70.00 Inches Bulk) (2 IN.)	32-8M0108349	32-8M0047448, 32-830757130, 32-830757 80
7	HOSE	32-830762	32-824001
8	FILTER, Fuel	35-816296Q2
9	HOSE, (57.00 Inches Bulk) (11 IN.)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
10	HOSE, (57.00 Inches Bulk) (4-1/2 IN.)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
11	GASKET	27-828292
12	STUD, (.250-28 x 1.125)	16-270372
13	LOCKWASHER, (.250) Stainless Steel	13-26992
14	NUT, (.250-28)	11-8267089
15	SCREW, (.250-20 x .880)	10-55715
16	TUBING, (20.00 Feet Bulk) (9 IN.)	32-892024122	32-99130122
17	HOSE, (.187) (26.00 Inches Bulk) (4-1/4 IN.)	32-9912878
18	HOSE, (.187) (26.00 Inches Bulk) (26 IN.)	32-9912878
19	VALVE ASSEMBLY, Enrichner	42859A2
20	CLAMP	54-633003
21	SCREW, (.250-20 x .500) Stainless Steel	10-73286
22	TUBING, (36.00 Inches Bulk) (4-1/2 IN.)	32-9912688
23	TUBING, (36.00 Inches Bulk) (3-3/4 IN.)	32-9912688
24	TERMINAL BLOCK	86-45915
25	SCREW, (#10-16 x .600)	10-878609	10-812832 1
25	SCREW, (#10-16 x .380)	10-878607	10-817626
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
1	TUBING, (15.00 Inches Bulk) (4-1/2 IN.)	32-82381335
2	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
3	CONNECTOR, Tee	22-818993
4	HOSE	32-830760	32-19017
5	CHECK VALVE	22-8189941
6	TUBING, (.312) (70.00 Inches Bulk) (2 IN.)	32-8M0108349	32-8M0047448, 32-830757130, 32-830757 80
7	HOSE	32-830762	32-824001
8	FILTER, Fuel	35-816296Q2
9	HOSE, (57.00 Inches Bulk) (11 IN.)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
10	HOSE, (57.00 Inches Bulk) (4-1/2 IN.)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
11	GASKET	27-828292
12	STUD, (.250-28 x 1.125)	16-270372
13	LOCKWASHER, (.250) Stainless Steel	13-26992
14	NUT, (.250-28)	11-8267089
15	SCREW, (.250-20 x .880)	10-55715
16	TUBING, (20.00 Feet Bulk) (9 IN.)	32-892024122	32-99130122
17	HOSE, (.187) (26.00 Inches Bulk) (4-1/4 IN.)	32-9912878
18	HOSE, (.187) (26.00 Inches Bulk) (26 IN.)	32-9912878
19	VALVE ASSEMBLY, Enrichner	42859A2
20	CLAMP	54-633003
21	SCREW, (.250-20 x .500) Stainless Steel	10-73286
22	TUBING, (36.00 Inches Bulk) (4-1/2 IN.)	32-9912688
23	TUBING, (36.00 Inches Bulk) (3-3/4 IN.)	32-9912688
24	TERMINAL BLOCK	86-45915
25	SCREW, (#10-16 x .600)	10-878609	10-812832 1
25	SCREW, (#10-16 x .380)	10-878607	10-817626
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90

FUEL PUMP

Below is the parts list for Mercury XR-6 FUEL PUMP:

Position No.	Part Name	OEM Number	Supersedes
-	PUMP ASSEMBLY, Fuel	14360A78
1	NOT SOLD SEPARATE, Fuel Pump	NSS
2	DIAPHAGM KIT	21-857005A1
3	NOT SOLD SEPARATE, Diaphragm	NSS
4	NOT SOLD SEPARATE, Check Valve-Rubber	NSS
5	NOT SOLD SEPARATE, Retainer	NSS
6	NOT SOLD SEPARATE, Spring	NSS
7	NOT SOLD SEPARATE, Cap	NSS
8	NOT SOLD SEPARATE, Spring	NSS
9	NOT SOLD SEPARATE, Cap	NSS
10	NOT SOLD SEPARATE, Diaphragm	NSS
11	GASKET	27-8M0204705
12	NOT SOLD SEPARATE, Gasket-Boost	NSS
13	NOT SOLD SEPARATE, Gasket-Pulse	NSS
14	PLATE	987752
15	ELBOW	22-996642
16	SCREW, (M6 x 50)	10-82130050
17	SCREW, (M5 x 40)	10-82104540
18	BASE	144303
19	TUBING, (.312) (70.00 Inches Bulk) (6 IN.)	32-8M0108349	32-8M0047448, 32-830757130, 32-830757 80
20	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	POWERHEAD ASSEMBLY Comment: (135)	878365T00	812815T00, 812815T97, 812815A97, 812815A96, 812815A92, 812815A90 (135)
-	POWERHEAD ASSEMBLY Comment: (150/XR6/MAGNUM III)	823434T97	823434A97, 823434A96, 823434A93 (150/XR6/MAGNUM III)
-	POWERHEAD ASSEMBLY Comment: (175)	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (175)
-	POWERHEAD ASSEMBLY Comment: (200)	813043T97	813043A97, 813043A96, 813043A94, 812827A92, 813043A92 (200)
-	PUMP ASSEMBLY, Fuel	14360A78
1	NOT SOLD SEPARATE, Fuel Pump	NSS
2	DIAPHAGM KIT	21-857005A1
3	NOT SOLD SEPARATE, Diaphragm	NSS
4	NOT SOLD SEPARATE, Check Valve-Rubber	NSS
5	NOT SOLD SEPARATE, Retainer	NSS
6	NOT SOLD SEPARATE, Spring	NSS
7	NOT SOLD SEPARATE, Cap	NSS
8	NOT SOLD SEPARATE, Spring	NSS
9	NOT SOLD SEPARATE, Cap	NSS
10	NOT SOLD SEPARATE, Diaphragm	NSS
11	GASKET	27-8M0204705
12	NOT SOLD SEPARATE, Gasket-Boost	NSS
13	NOT SOLD SEPARATE, Gasket-Pulse	NSS
14	PLATE	987752
15	ELBOW	22-996642
16	SCREW, (M6 x 50)	10-82130050
17	SCREW, (M5 x 40)	10-82104540
18	BASE	144303
19	TUBING, (.312) (70.00 Inches Bulk) (6 IN.)	32-8M0108349	32-8M0047448, 32-830757130, 32-830757 80
20	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	POWERHEAD ASSEMBLY Comment: (135)	878365T00	812815T00, 812815T97, 812815A97, 812815A96, 812815A92, 812815A90 (135)
-	POWERHEAD ASSEMBLY Comment: (150/XR6/MAGNUM III)	823434T97	823434A97, 823434A96, 823434A93 (150/XR6/MAGNUM III)
-	POWERHEAD ASSEMBLY Comment: (175)	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (175)
-	POWERHEAD ASSEMBLY Comment: (200)	813043T97	813043A97, 813043A96, 813043A94, 812827A92, 813043A92 (200)

Flywheel/Alternator

Below is the parts list for Mercury XR-6 Flywheel/Alternator:

Position No.	Part Name	OEM Number	Supersedes
1	ALTERNATOR	857006T	834832
2	SCREW, (M10 x 100) Hex Flange - Stainless Steel	10-8M0012503	10-40108100
3	SCREW, (M10 x 120) Hex Flange - Stainless Steel	10-40108120
4	WASHER, (.390 x 1.00 x .06)	12-8M0042641	12-29395
5	MOUNT	23-856975	849639
6	BRACKET	858391T01	858391T, 856972T
7	WASHER, (.406 x 1.250 x .089)	12-845998
8	BRACKET	858393T01	858393T, 856973T
9	NUT, (M10) Brass/Nickel Plated	11-826292
10	SCREW, (M10 x 55)	10-82446155
11	CABLE ASSEMBLY	84-856583T2
12	PIN	8215832
13	BRACKET	857142T	856974T
14	SCREW, (.312-18 x 1.00) Stainless Steel With Nylon Patch	10-812618	10-73169, 10-847568
15	SPRING	24-855798001	24-855798
16	ARM TENSIONER ASSEMBLY	856815T2
17	STUD, (M10 x 85)	16-8M0034457	16-856900
18	NUT, (M10) Brass/Nickel Plated	11-826292
19	BUSHING	23-8568941
20	WASHER	12-4002320
21	PULLEY	8M6005030
22	SCREW, (M10 x 35) Hex Flange - Stainless Steel	10-4010835
23	BELT	57-828507Q4
24	FLYWHEEL	281-834936T6
25	NUT, (.625-18)	11-52901
26	WASHER, (.641 x 1.250 x .190)	12-33001
27	PLUG, Yellow	19-45907

Fuel Pump

Below is the parts list for Mercury XR-6 Fuel Pump:

Position No.	Part Name	OEM Number	Supersedes
1	PUMP ASSEMBLY, Fuel	14360T75
2	DIAPHRAGM KIT	21-857005A1
3	NOT SOLD SEPARATE, Diaphragm	NSS
4	NOT SOLD SEPARATE, Check Valve-Rubber	NSS
5	NOT SOLD SEPARATE, Retainer	NSS
6	NOT SOLD SEPARATE, Spring	NSS
7	NOT SOLD SEPARATE, Cap	NSS
8	NOT SOLD SEPARATE, Spring	NSS
9	NOT SOLD SEPARATE, Cap	NSS
10	NOT SOLD SEPARATE, Diaphragm	NSS
11	GASKET	27-8M0204705
12	NOT SOLD SEPARATE, Gasket-Boost	NSS
13	NOT SOLD SEPARATE, Gasket-Pulse	NSS
14	PLATE	987752
15	ELBOW	22-996642
16	SCREW, (M5 x 40), Fuel Pump	10-82104540
16	SCREW, (M6 x 50), Pump to Crankcase	10-82130050
17	BASE	144303
18	ELBOW (45 DEGREES)	22-782792
19	FITTING	22-291112
20	TUBING, (.312) (70.00 Inches Bulk) (Cut to 6 Inches)	32-8M0108349	32-8M0047448, 32-830757130, 32-830757 80
21	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
22	TUBING (W/INSULATING SLEEVE) (7 IN.)	32-8M0064784	32-897972, 32-856822A 1
23	HOSE AND SLEEVE ASSEMBLY, (18.00 Inches) (W/INSULATING SLEEVE) (18 IN.)	32-8M0043979	32-856822A 2
24	CONNECTOR	22-822769
25	CLAMP, Hose (15.3)	54-8M0214964
-	GASKET SET	27-8M0046714	27-814754A00, 27-814754A98
-	POWERHEAD ASSEMBLY Comment: SN# 0G886267 & Up	804545T99	854008T99, 854008T98, 854008A98 SN# 0G886267 & Up
-	POWERHEAD ASSEMBLY Comment: SN# 0G886266 & Below	804545T99	854008T99, 854008T98, 854008A98 SN# 0G886266 & Below

Fuel Rail Components

Below is the parts list for Mercury XR-6 Fuel Rail Components:

Position No.	Part Name	OEM Number	Supersedes
1	FUEL RAIL, Without Injectors (Starboard)	852379T6
2	FUEL RAIL, Without Injectors (Port)	852378T6
3	SCHRADER VALVE KIT (AIR AND FUEL)	804521
4	FITTING (AIR INLET)	804516
5	FITTING (FUEL INLET)	804515
6	CLAMP (FITTING RETAINER)	804524	54-859153
7	SCREW PACKAGE, (M5 x 8) (2 Per)	10-804525001	804525
8	SCREW PACKAGE, (M5 x 16) (2 Per)	804526
9	COVER (TRACKER VALVE)	804535001	804535
10	SPRING (TRACKER VALVE)	24-804534
11	DIAPHRAGM ASSEMBLY (TRACKER VALVE)	804533
12	O-RING (TRACKER COVER)	25-804536
13	FITTING (AIR/FUEL) STARBOARD	804520
14	FITTING (AIR/FUEL) PORT	804519
15	CLAMP (INJECTOR) DESIGN II	804522
16	RETAINER (INJECTOR) DESIGN I	804523
17	INJECTOR (FUEL)	804527
18	O-RING KIT (LARGE) 6 PER KIT	25-804530
19	O-RING KIT (SMALL) 6 PER KIT	25-804529
20	FITTING	804517
21	O-RING (2 PER KIT)	25-804531
22	O-RING KIT (16 PER KIT)	804532	25-803987

Fuel Rails

Below is the parts list for Mercury XR-6 Fuel Rails:

Position No.	Part Name	OEM Number	Supersedes
1	COMPRESSOR ASSEMBLY, Air	8M0060053	8M0057463, 8M0050656, 899113A03, 831998A21, 831998A16, 831998A22, 831998A13, 831998T 9, 831998A14
2	SCREW, (M6 x 12)	10-85593912
3	PULLEY	8M0175171
4	SCREW, (M10 x 25) Hex Flange - Stainless Steel	10-4010825
5	HOSE	32-8502512
6	SLEEVE, (16.00 Inches)	23-85687631
7	FUEL RAIL (Starboard)	852379T6
8	INJECTOR	8M6001743	8M0065916, 883078A05, 883078A 4
9	CLAMP	54-8M0204696
10	HOSE (16 IN.)	32-85564361
11	STUD, (.312-18/.312-24 x 4.190)	16-858762001	16-8M0020427, 16-858762
12	WASHER, Special	12-854640
13	NUT, (.312-24) Stainless Steel	11-82670911
14	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
15	FUEL RAIL (Port)	852378T6
16	HOSE, (57.00 Inches Bulk) (Cut to 22-1/2 Inches)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
17	CHECK VALVE	21-826810
18	TUBING, (.312) (70.00 Inches Bulk) (Cut to 2-1/2 Inches)	32-8M0108349	32-8M0047448, 32-830757130, 32-830757 80
19	TUBING, (32.00 Inches Bulk) (Cut to 28-1/2 Inches)	32-83476463
20	CLAMP, Hose (15.3)	54-8M0214964
21	TUBING, (36.00 Inches Bulk) (Cut to 28-1/2 Inches)	32-8M0054152	32-856060 65
22	SCREW, (M5 x 10)	10-82104510
23	CLAMP	54-46997
24	STUD, (M10 x 91)	16-8M0063255
25	NUT, (M10) Brass/Nickel Plated	11-826292
26	HOSE (30 IN.) (W/INSULATING SLEEVE)	32-856822A3
27	HOSE (W/INSULATING SLEEVE)	32-855848A1
28	WASHER ASSEMBLY, Cupped	12-828694A1
29	CLAMP, Hose (15.3)	54-8M0214964
30	SLEEVE, (27.00 Inches Bulk) (Cut to 18 Inches)	23-85686953
-	POWERHEAD ASSEMBLY Comment: SN# 0G886267 & Up	804545T99	854008T99, 854008T98, 854008A98 SN# 0G886267 & Up
-	POWERHEAD ASSEMBLY Comment: SN# 0G886266 & Below	804545T99	854008T99, 854008T98, 854008A98 SN# 0G886266 & Below

GEAR HOUSING CHART

Below is the parts list for Mercury XR-6 GEAR HOUSING CHART:

Position No.	Part Name	OEM Number
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (LONG) 2:1 GEAR RATIO STD. ROTATION	1647-9148T81
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (X-LONG) 2:1 GEAR RATIO STD. ROTATION	1647-9148T82
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (LONG) STD. ROTATION 1.87:1 GEAR RATIO	1647-9148T84
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: ( X-LONG) STD. ROTATION 1.87:1 GEAR RATIO	1647-9148T85
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (X-LONG) 2:1 COUNTER ROTATION	1647-9148T83
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (X-LONG) 1.87:1 COUNTER ROTATION	1647-9148T86
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (LONG) 2:1 GEAR RATIO STD. ROTATION	1647-9148T81
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (X-LONG) 2:1 GEAR RATIO STD. ROTATION	1647-9148T82
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (LONG) STD. ROTATION 1.87:1 GEAR RATIO	1647-9148T84
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: ( X-LONG) STD. ROTATION 1.87:1 GEAR RATIO	1647-9148T85
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (X-LONG) 2:1 COUNTER ROTATION	1647-9148T83
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (X-LONG) 1.87:1 COUNTER ROTATION	1647-9148T86

GEAR HOUSING(DRIVESHAFT)(STANDARD/COUNTER ROTATION)

Below is the parts list for Mercury XR-6 GEAR HOUSING(DRIVESHAFT)(STANDARD/COUNTER ROTATION):

Position No.	Part Name	OEM Number	Supersedes
1	GEAR HOUSING ASSEMBLY, Basic	1647-9148T93
2	CONNECTOR ASSEMBLY	22-85822A10
3	PIN, Dowel - Without Hole (.375 x .625)	17-43044
4	STUD, (.437-14/.437-20 x 3.120)	16-786382
4	STUD, (.438 x 3.82 Inches)	16-8M0034464	16-18978 3
5	STUD, (.437-14/.437-20 x 2.060)	16-8M0133358
6	STUD, (.312-18/.324-24 x 3.380)	16-8M0034463	16-56297 2
7	STUD, (.250-20/.250-28 x 3.125)	16-306671
8	FILLER BLOCK	8M0039169	67891
9	BEARING ASSEMBLY, Roller	31-42647A1
10	ANODE	97-826134Q	826134, 826134A 1
11	SCREW, (M6 x 40)	10-4000333
12	NUT, (M6)	11-401386
13	GEAR, Pinion 2:1 - 14 Teeth (Part of 43-828176A2 or 43-828703A1)	43-44101T3
13	NOT SOLD SEPARATE, Pinion Gear (Part of 43-828174A2 or 43-828701A1) Comment: (1.87:1 GEAR RATIO-15TEETH)	NSS
14	WASHER Comment: (Included With Forward Gear Set)	12-92721
15	NUT, (.625-18) Comment: (Included With Forward Gear Set)	11-35921
16	SHIM SET Comment: (Included With Forward Gear Set)	15-42637A1
17	FITTING KIT, Magnetic, Plug Fill/Drain (MAGNETIC)	22-8M0058389	22-67892A06
18	SCREW KIT, (.375-16 x .250)	10-79953Q04
19	WASHER, Fiber	12-191833
20	TIE STRAP, (4.00 Inches)	56762
21	SHIFT SHAFT	789022
22	O-RING, (.862 x .103)	25-25439
23	BUSHING ASSEMBLY	23-77631A2
24	SEAL, Oil	26-8M0204708
25	WASHER	12-77674
26	DRIVESHAFT Comment: (LONG)	45-897624T	45-44000 1 (LONG)
26	DRIVESHAFT Comment: (X-LONG)	45-897625T	45-44209 1 (X-LONG)
27	BEARING, Roller	31-8M0146566
28	NOT SOLD SEPARATE, Cup	NSS
29	RETAINER	8245191
30	BASE ASSEMBLY, Water Pump	46-8M0077147	46-42579A 3
31	GASKET	27-8M0204678
32	O-RING, (2.175 x .175)	25-8M0142854
33	SEAL, Oil	26-89238
34	SEAL, Oil	26-16977
35	GASKET	27-8M0090319	27-85608 1
36	GASKET	27-858524	27-85609 1, 27-85609B 1
37	FACE PLATE	8M0204677
38	BODY ASSEMBLY, Water Pump	46-96148T1
39	INSERT	48752T
40	SEAL	26-38970
41	IMPELLER	47-89984T3
42	KEY	28-8M0214992
43	SCREW, (#14-8 x 2.25)	10-8M0215009
44	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
45	NUT, (.250-28)	11-8267119
46	WASHER	12-36001
47	NUT	11-13436
48	SLEEVE	23-29804T
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	REPAIR KIT, Water Pump	46-96148A8
-	SEAL KIT	26-89238A2
1	GEAR HOUSING ASSEMBLY, Basic	1647-9148T93
2	CONNECTOR ASSEMBLY	22-85822A10
3	PIN, Dowel - Without Hole (.375 x .625)	17-43044
4	STUD, (.437-14/.437-20 x 3.120)	16-786382
4	STUD, (.438 x 3.82 Inches)	16-8M0034464	16-18978 3
5	STUD, (.437-14/.437-20 x 2.060)	16-8M0133358
6	STUD, (.312-18/.324-24 x 3.380)	16-8M0034463	16-56297 2
7	STUD, (.250-20/.250-28 x 3.125)	16-306671
8	FILLER BLOCK	8M0039169	67891
9	BEARING ASSEMBLY, Roller	31-42647A1
10	ANODE	97-826134Q	826134, 826134A 1
11	SCREW, (M6 x 40)	10-4000333
12	NUT, (M6)	11-401386
13	GEAR, Pinion 2:1 - 14 Teeth (Part of 43-828176A2 or 43-828703A1)	43-44101T3
13	NOT SOLD SEPARATE, Pinion Gear (Part of 43-828174A2 or 43-828701A1) Comment: (1.87:1 GEAR RATIO-15TEETH)	NSS
14	WASHER Comment: (Included With Forward Gear Set)	12-92721
15	NUT, (.625-18) Comment: (Included With Forward Gear Set)	11-35921
16	SHIM SET Comment: (Included With Forward Gear Set)	15-42637A1
17	FITTING KIT, Magnetic, Plug Fill/Drain (MAGNETIC)	22-8M0058389	22-67892A06
18	SCREW KIT, (.375-16 x .250)	10-79953Q04
19	WASHER, Fiber	12-191833
20	TIE STRAP, (4.00 Inches)	56762
21	SHIFT SHAFT	789022
22	O-RING, (.862 x .103)	25-25439
23	BUSHING ASSEMBLY	23-77631A2
24	SEAL, Oil	26-8M0204708
25	WASHER	12-77674
26	DRIVESHAFT Comment: (LONG)	45-897624T	45-44000 1 (LONG)
26	DRIVESHAFT Comment: (X-LONG)	45-897625T	45-44209 1 (X-LONG)
27	BEARING, Roller	31-8M0146566
28	NOT SOLD SEPARATE, Cup	NSS
29	RETAINER	8245191
30	BASE ASSEMBLY, Water Pump	46-8M0077147	46-42579A 3
31	GASKET	27-8M0204678
32	O-RING, (2.175 x .175)	25-8M0142854
33	SEAL, Oil	26-89238
34	SEAL, Oil	26-16977
35	GASKET	27-8M0090319	27-85608 1
36	GASKET	27-858524	27-85609 1, 27-85609B 1
37	FACE PLATE	8M0204677
38	BODY ASSEMBLY, Water Pump	46-96148T1
39	INSERT	48752T
40	SEAL	26-38970
41	IMPELLER	47-89984T3
42	KEY	28-8M0214992
43	SCREW, (#14-8 x 2.25)	10-8M0215009
44	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
45	NUT, (.250-28)	11-8267119
46	WASHER	12-36001
47	NUT	11-13436
48	SLEEVE	23-29804T
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	REPAIR KIT, Water Pump	46-96148A8
-	SEAL KIT	26-89238A2

GEAR HOUSING(PROP SHAFT)(COUNTER ROTATION)

Below is the parts list for Mercury XR-6 GEAR HOUSING(PROP SHAFT)(COUNTER ROTATION):

Position No.	Part Name	OEM Number	Supersedes
1	GEAR HOUSING ASSEMBLY, Basic	1647-9148T93
49	FOLLOWER ASSEMBLY	89594A1
50	SHIFT CAM	789562
51	ROD	828287
52	SHIM SET	15-44491A1
53	ADAPTOR ASSEMBLY, Bearing	828830A2
54	BEARING ASSEMBLY, Needle Rollers	31-814653T	31-814653, 31-814653001
55	THRUST WASHER	12-815481
56	BEARING, Thrust	31-815480
57	GEAR ASSEMBLY, Reverse - 14/28 Comment: (135)(2.0:1)	43-828704A2
57	GEAR ASSEMBLY, Reverse - 15/28 Comment: (150/175/200)(1.87:1)	43-828702A2
58	BEARING ASSEMBLY, Roller	31-15844
59	SPRING	24-30893
60	CLUTCH, Sliding	52-859340T	52-854735T, 52-828288
61	PIN, Cross	17-8M0100263	17-8M0084681, 17-8M0020941, 17-30632
62	PIN, Detent	17-828356
63	PROPELLER SHAFT	44-828951
64	GEAR ASSEMBLY, Forward - 14/28 Comment: (135)(2.0:1)	43-828703A1
64	GEAR ASSEMBLY, Forward - 15/28 Comment: (150/175/200)(1.87:1)	43-828701A1
65	SPACER SHIM , (.206)	23-1761514
65	SPACER SHIM , (.208)	23-1761515
65	SPACER SHIM, (.210)	23-1761516
65	SPACER SHIM, (.212)	23-1761517
65	SPACER SHIM, (.214)	23-1761518
65	SPACER SHIM, (.216)	23-1761519
65	SPACER SHIM, (.218)	23-1761520
65	SPACER SHIM, (.220)	23-1761521
65	SPACER SHIM, (.222)	23-1761522
65	SPACER SHIM, (.224)	23-1761523
65	SPACER SHIM, (.226)	23-1761524
65	SPACER SHIM, (.228)	23-1761525
65	SPACER SHIM, (.230)	23-1761526
66	BEARING, Thrust	31-815480
67	THRUST WASHER	12-815481
68	ADAPTOR ASSEMBLY, Bearing	828831A3
69	BEARING ASSEMBLY, Needle Rollers	31-814653T	31-814653, 31-814653001
70	THRUST WASHER	12-18448
71	BEARING, Thrust	31-15842
72	RACE, Thrust	8182911
73	KEEPER	814605
74	O-RING	25-8M0214920
75	CARRIER ASSEMBLY, Bearing	818290A4
76	BEARING, Needle	31-30956T
77	SEAL, Oil (INSIDE)	26-14077
78	SEAL (OUTSIDE)	26-8M0204670
79	TAB WASHER	14-183231
80	KEY	28-30281
81	RETAINER	8M2011027	79448
82	TRIM TAB	31640T07
82	ANODE KIT Comment: (TRACKER/XR6/MAG III/175 /200 LONG)	97-76214Q5
83	SCREW, (.437-14 x 1.750)	10-8M0204686
84	SCREW, (.375-16 x 1.00)	10-65210
85	WASHER, (.453 x .812 x .105) Stainless Steel	12-45176
86	NUT, (.437-20) Stainless Steel	11-8M0204653
-	SEAL KIT	26-89238A2
1	GEAR HOUSING ASSEMBLY, Basic	1647-9148T93
49	FOLLOWER ASSEMBLY	89594A1
50	SHIFT CAM	789562
51	ROD	828287
52	SHIM SET	15-44491A1
53	ADAPTOR ASSEMBLY, Bearing	828830A2
54	BEARING ASSEMBLY, Needle Rollers	31-814653T	31-814653, 31-814653001
55	THRUST WASHER	12-815481
56	BEARING, Thrust	31-815480
57	GEAR ASSEMBLY, Reverse - 14/28 Comment: (135)(2.0:1)	43-828704A2
57	GEAR ASSEMBLY, Reverse - 15/28 Comment: (150/175/200)(1.87:1)	43-828702A2
58	BEARING ASSEMBLY, Roller	31-15844
59	SPRING	24-30893
60	CLUTCH, Sliding	52-859340T	52-854735T, 52-828288
61	PIN, Cross	17-8M0100263	17-8M0084681, 17-8M0020941, 17-30632
62	PIN, Detent	17-828356
63	PROPELLER SHAFT	44-828951
64	GEAR ASSEMBLY, Forward - 14/28 Comment: (135)(2.0:1)	43-828703A1
64	GEAR ASSEMBLY, Forward - 15/28 Comment: (150/175/200)(1.87:1)	43-828701A1
65	SPACER SHIM , (.206)	23-1761514
65	SPACER SHIM , (.208)	23-1761515
65	SPACER SHIM, (.210)	23-1761516
65	SPACER SHIM, (.212)	23-1761517
65	SPACER SHIM, (.214)	23-1761518
65	SPACER SHIM, (.216)	23-1761519
65	SPACER SHIM, (.218)	23-1761520
65	SPACER SHIM, (.220)	23-1761521
65	SPACER SHIM, (.222)	23-1761522
65	SPACER SHIM, (.224)	23-1761523
65	SPACER SHIM, (.226)	23-1761524
65	SPACER SHIM, (.228)	23-1761525
65	SPACER SHIM, (.230)	23-1761526
66	BEARING, Thrust	31-815480
67	THRUST WASHER	12-815481
68	ADAPTOR ASSEMBLY, Bearing	828831A3
69	BEARING ASSEMBLY, Needle Rollers	31-814653T	31-814653, 31-814653001
70	THRUST WASHER	12-18448
71	BEARING, Thrust	31-15842
72	RACE, Thrust	8182911
73	KEEPER	814605
74	O-RING	25-8M0214920
75	CARRIER ASSEMBLY, Bearing	818290A4
76	BEARING, Needle	31-30956T
77	SEAL, Oil (INSIDE)	26-14077
78	SEAL (OUTSIDE)	26-8M0204670
79	TAB WASHER	14-183231
80	KEY	28-30281
81	RETAINER	8M2011027	79448
82	TRIM TAB	31640T07
82	ANODE KIT Comment: (TRACKER/XR6/MAG III/175 /200 LONG)	97-76214Q5
83	SCREW, (.437-14 x 1.750)	10-8M0204686
84	SCREW, (.375-16 x 1.00)	10-65210
85	WASHER, (.453 x .812 x .105) Stainless Steel	12-45176
86	NUT, (.437-20) Stainless Steel	11-8M0204653
-	SEAL KIT	26-89238A2

GEAR HOUSING(PROP SHAFT)(STANDARD ROTATION)

Below is the parts list for Mercury XR-6 GEAR HOUSING(PROP SHAFT)(STANDARD ROTATION):

Position No.	Part Name	OEM Number	Supersedes
1	GEAR HOUSING ASSEMBLY, Basic	1647-9148T93
49	FOLLOWER ASSEMBLY	89594A1
50	SHIFT CAM	789562
51	ROD	828287
52	GEAR SET Comment: (150/XR6/MAG. III/175/200)(1.87:1 - 15/28)	43-878613A2
52	GEAR ASSEMBLY, Forward Comment: (135)(2.0:1 - 14/28)	43-878615A2
53	SHIM SET (.006-7-9-10-20)	15-44491A1
54	BEARING SET, Cup And Cone	31-30894A1
55	BEARING, Needle	31-30895T
56	CLUTCH, Sliding	52-859340T	52-854735T, 52-828288
57	PIN, Cross	17-8M0100263	17-8M0084681, 17-8M0020941, 17-30632
58	PIN, Detent	17-828356
59	SPRING	24-30893
60	PROPELLER SHAFT	44-94148
61	GEAR ASSEMBLY, Reverse - 15/28 Comment: (150/XR6/MAG. III/175/200)(1.87:1)	43-828175A1
61	GEAR ASSEMBLY, Reverse - 14/28 Comment: (135)(2.0:1)	43-828177A1
62	SPACER	23-824108
63	RING, Thrust	681001
64	BEARING ASSEMBLY, Ball	30-88957T
65	O-RING	25-8M0214920
66	CARRIER ASSEMBLY, Bearing	43567T1
67	BEARING, Needle	31-30956T
68	SEAL, Oil (INSIDE)	26-14077
69	SEAL (OUTSIDE)	26-8M0204670
70	KEY	28-30281
71	TAB WASHER	14-79447
72	RETAINER	8M2011027	79448
73	TRIM TAB	31640T07
73	ANODE KIT Comment: (TRACKER/XR6/MAG III/175 /200 LONG)	97-76214Q5
74	SCREW, (.437-14 x 1.750)	10-8M0204686
75	SCREW, (.375-16 x 1.00)	10-65210
76	WASHER, (.453 x .812 x .105) Stainless Steel	12-45176
77	NUT, (.437-20) Stainless Steel	11-8M0204653
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	SEAL KIT	26-89238A2
1	GEAR HOUSING ASSEMBLY, Basic	1647-9148T93
49	FOLLOWER ASSEMBLY	89594A1
50	SHIFT CAM	789562
51	ROD	828287
52	GEAR SET Comment: (150/XR6/MAG. III/175/200)(1.87:1 - 15/28)	43-878613A2
52	GEAR ASSEMBLY, Forward Comment: (135)(2.0:1 - 14/28)	43-878615A2
53	SHIM SET (.006-7-9-10-20)	15-44491A1
54	BEARING SET, Cup And Cone	31-30894A1
55	BEARING, Needle	31-30895T
56	CLUTCH, Sliding	52-859340T	52-854735T, 52-828288
57	PIN, Cross	17-8M0100263	17-8M0084681, 17-8M0020941, 17-30632
58	PIN, Detent	17-828356
59	SPRING	24-30893
60	PROPELLER SHAFT	44-94148
61	GEAR ASSEMBLY, Reverse - 15/28 Comment: (150/XR6/MAG. III/175/200)(1.87:1)	43-828175A1
61	GEAR ASSEMBLY, Reverse - 14/28 Comment: (135)(2.0:1)	43-828177A1
62	SPACER	23-824108
63	RING, Thrust	681001
64	BEARING ASSEMBLY, Ball	30-88957T
65	O-RING	25-8M0214920
66	CARRIER ASSEMBLY, Bearing	43567T1
67	BEARING, Needle	31-30956T
68	SEAL, Oil (INSIDE)	26-14077
69	SEAL (OUTSIDE)	26-8M0204670
70	KEY	28-30281
71	TAB WASHER	14-79447
72	RETAINER	8M2011027	79448
73	TRIM TAB	31640T07
73	ANODE KIT Comment: (TRACKER/XR6/MAG III/175 /200 LONG)	97-76214Q5
74	SCREW, (.437-14 x 1.750)	10-8M0204686
75	SCREW, (.375-16 x 1.00)	10-65210
76	WASHER, (.453 x .812 x .105) Stainless Steel	12-45176
77	NUT, (.437-20) Stainless Steel	11-8M0204653
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	SEAL KIT	26-89238A2

Gear Housing(Driveshaft)(Standard/Counter Rotation)

Below is the parts list for Mercury XR-6 Gear Housing(Driveshaft)(Standard/Counter Rotation):

Position No.	Part Name	OEM Number	Supersedes
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (Long-Standard-1.87:1)	1647-9148T84
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (X-Long-Standard-1.87:1)	1647-9148T85
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (Long-Standard-2:1)	1647-9148T81
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (X-Long-Standard-2:1)	1647-9148T82
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (X-Long-Counter Rotation-1.87:1)	1647-9148T86
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (X-Long-Counter Rotation-2:1)	1647-9148T83
1	GEAR HOUSING ASSEMBLY, Basic	1647-9148T93
2	PIN, Dowel - Without Hole (.375 x .625)	17-43044
3	STUD, (.437-14/.437-20 x 3.120) Comment: (LONG)	16-786382
3	STUD, (.438 x 3.82 Inches) Comment: (X-LONG)	16-8M0034464	16-18978 3 (X-LONG)
4	STUD, (.437-14/.437-20 x 2.060)	16-8M0133358
5	STUD, (.312-18/.324-24 x 3.380)	16-8M0034463	16-56297 2
6	STUD, (.250-20/.250-28 x 3.125)	16-306671
7	FILLER BLOCK	8M0039169	67891
8	BEARING ASSEMBLY, Roller	31-42647A1
9	ANODE	97-826134Q	826134, 826134A 1
10	SCREW, (M6 x 40)	10-4000333
11	NUT, (M6)	11-401386
12	CONNECTOR ASSEMBLY	22-85822A10
13	NOT SOLD SEPARATE, Pinion Gear Comment: (1.87:1 - 15 Teeth)(150)(Part of 43-828174A2 or 43-828701A1)	NSS
13	GEAR, Pinion 2:1 - 14 Teeth Comment: (2:1 - 14 Teeth)(135)(Also part of 43-828176A2 or 43-828703A1)	43-44101T3
14	WASHER	12-92721
15	NUT, (.625-18)	11-35921
16	SHIM SET	15-42637A1
17	SCREW KIT, (.375-16 x .250)	10-79953Q04
18	WASHER, Fiber	12-191833
19	FITTING KIT, Magnetic, Plug Fill/Drain	22-8M0058389	22-67892A06
20	SHIFT SHAFT	789022
21	BUSHING ASSEMBLY	23-77631A2
22	O-RING, (.862 x .103)	25-25439
23	SEAL, Oil	26-8M0204708
24	WASHER	12-77674
25	DRIVESHAFT Comment: (LONG)	45-897624T	45-44000 1 (LONG)
25	DRIVESHAFT Comment: (X-LONG)	45-897625T	45-44209 1 (X-LONG)
26	BEARING, Roller	31-8M0146566
27	NOT SOLD SEPARATE, Cup	NSS
28	RETAINER	8245191
29	BASE ASSEMBLY, Water Pump	46-8M0077147	46-42579A 3
30	NOT SOLD SEPARATE, Retainer	NSS
31	GASKET	27-8M0204678
32	O-RING, (2.175 x .175)	25-8M0142854
33	SEAL, Oil	26-89238
34	SEAL, Oil	26-16977
35	GASKET	27-8M0090319	27-85608 1
36	GASKET	27-858524	27-85609 1, 27-85609B 1
37	FACE PLATE	8M0204677
38	BODY ASSEMBLY, Water Pump	46-96148T1
39	INSERT	48752T
40	SEAL	26-38970
41	IMPELLER	47-89984T3
42	KEY	28-8M0214992
43	SCREW, (#14-8 x 2.25)	10-8M0215009
44	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
45	NUT, (.250-28)	11-8267119
46	WASHER	12-36001
47	NUT	11-13436
48	SLEEVE	23-29804T
-	GASKET SET	27-8M0046714	27-814754A00, 27-814754A98
-	SEAL KIT	26-89238A2
-	REPAIR KIT, Water Pump	46-96148A8

Gear Housing, Propeller Shaft - Counter Rotation

Below is the parts list for Mercury XR-6 Gear Housing, Propeller Shaft - Counter Rotation:

Position No.	Part Name	OEM Number	Supersedes
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (X-LONG - 1.87:1)	1647-9148T86
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (X-LONG - 2:1)	1647-9148T83
1	GEAR HOUSING ASSEMBLY, Basic	1647-9148T93
2	FOLLOWER ASSEMBLY	89594A1
3	SHIFT CAM	789562
4	ROD	828287
5	SHIM SET	15-44491A1
6	ADAPTOR ASSEMBLY, Bearing	828830A2
7	BEARING ASSEMBLY, Needle Rollers	31-814653T	31-814653, 31-814653001
8	THRUST WASHER	12-815481
9	BEARING, Thrust	31-815480
10	GEAR ASSEMBLY, Reverse - 15/28 Comment: (1.87:1 Gear Ratio-150)	43-828702A2
10	GEAR ASSEMBLY, Reverse - 14/28 Comment: (2:1 Gear Ratio-135)	43-828704A2
11	BEARING ASSEMBLY, Roller	31-15844
12	SPRING	24-30893
13	CLUTCH, Sliding	52-859340T	52-854735T, 52-828288
14	PIN, Cross	17-8M0100263	17-8M0084681, 17-8M0020941, 17-30632
15	PIN, Detent	17-828356
16	PROPELLER SHAFT	44-828951
17	GEAR ASSEMBLY, Forward - 15/28 Comment: (1.87:1 Gear Ratio-150)	43-828701A1
17	GEAR ASSEMBLY, Forward - 14/28 Comment: (2:1 Gear Ratio-135)	43-828703A1
18	SPACER SHIM , (.206)	23-1761514
18	SPACER SHIM , (.208)	23-1761515
18	SPACER SHIM, (.210)	23-1761516
18	SPACER SHIM, (.212)	23-1761517
18	SPACER SHIM, (.214)	23-1761518
18	SPACER SHIM, (.216)	23-1761519
18	SPACER SHIM, (.218)	23-1761520
18	SPACER SHIM, (.220)	23-1761521
18	SPACER SHIM, (.222)	23-1761522
18	SPACER SHIM, (.224)	23-1761523
18	SPACER SHIM, (.226)	23-1761524
18	SPACER SHIM, (.228)	23-1761525
18	SPACER SHIM, (.230)	23-1761526
19	BEARING, Thrust	31-815480
20	THRUST WASHER	12-815481
21	ADAPTOR ASSEMBLY, Bearing	828831A3
22	BEARING ASSEMBLY, Needle Rollers	31-814653T	31-814653, 31-814653001
23	THRUST WASHER	12-18448
24	BEARING, Thrust	31-15842
25	RACE, Thrust	8182911
26	KEEPER	814605
27	O-RING	25-8M0214920
28	CARRIER ASSEMBLY, Bearing	818290A4
29	BEARING, Needle	31-30956T
30	SEAL, Oil Comment: (INSIDE)	26-14077
31	SEAL Comment: (OUTSIDE)	26-8M0204670
32	TAB WASHER	14-183231
33	KEY	28-30281
34	RETAINER	8M2011027	79448
35	TRIM TAB	31640T07
36	SCREW, (.437-14 x 1.750)	10-8M0204686
37	SCREW, (.375-16 x 1.00)	10-65210
38	WASHER, (.453 x .812 x .105) Stainless Steel	12-45176
39	NUT, (.437-20) Stainless Steel	11-8M0204653
40	NOT SOLD SEPARATE, Decal-Counter Rotation	NSS
-	SEAL KIT	26-89238A2
-	GASKET SET	27-8M0046714	27-814754A00, 27-814754A98

Gear Housing, Propeller Shaft - Standard Rotation

Below is the parts list for Mercury XR-6 Gear Housing, Propeller Shaft - Standard Rotation:

Position No.	Part Name	OEM Number	Supersedes
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (Long-1.87:1)	1647-9148T84
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (X-Long-1.87:1)	1647-9148T85
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (Long-2:1)	1647-9148T81
-	GEAR HOUSING ASSEMBLY, Complete (4.75 Inch/120.65 mm Torpedo Diameter) Comment: (X-Long-2:1)	1647-9148T82
1	GEAR HOUSING ASSEMBLY, Basic	1647-9148T93
2	FOLLOWER ASSEMBLY	89594A1
3	SHIFT CAM	789562
4	ROD	828287
5	GEAR SET Comment: (1.87:1 - 15/28)(150)	43-878613A2
5	GEAR ASSEMBLY, Forward Comment: (2:1 - 14/28)(135)	43-878615A2
6	SHIM SET	15-44491A1
7	BEARING SET, Cup And Cone	31-30894A1
8	NOT SOLD SEPARATE, Cup	NSS
9	BEARING, Needle	31-30895T
10	RING, Retaining	53-856823
11	CLUTCH, Sliding	52-859340T	52-854735T, 52-828288
12	PIN, Cross	17-8M0100263	17-8M0084681, 17-8M0020941, 17-30632
13	PIN, Detent	17-828356
14	SPRING	24-30893
15	PROPELLER SHAFT	44-94148
16	GEAR ASSEMBLY, Reverse - 15/28 Comment: (150)	43-828175A1
16	GEAR ASSEMBLY, Reverse - 14/28 Comment: (135)	43-828177A1
17	SPACER	23-824108
18	RING, Thrust	681001
19	BEARING ASSEMBLY, Ball	30-88957T
20	O-RING	25-8M0214920
21	CARRIER ASSEMBLY, Bearing	43567T1
22	BEARING, Needle	31-30956T
23	SEAL, Oil (INSIDE)	26-14077
24	SEAL (OUTSIDE)	26-8M0204670
25	KEY	28-30281
26	TAB WASHER	14-79447
27	RETAINER	8M2011027	79448
28	TRIM TAB	31640T07
29	ANODE KIT	97-76214Q5
30	SCREW, (.437-14 x 1.750)	10-8M0204686
31	SCREW, (.375-16 x 1.00)	10-65210
32	WASHER, (.453 x .812 x .105) Stainless Steel	12-45176
33	NUT, (.437-20) Stainless Steel	11-8M0204653
-	SEAL KIT	26-89238A2
-	GASKET SET	27-8M0046714	27-814754A00, 27-814754A98

IGNITION COIL/VOLTAGE REGULATOR

Below is the parts list for Mercury XR-6 IGNITION COIL/VOLTAGE REGULATOR:

Position No.	Part Name	OEM Number	Supersedes
1	MOUNTING PLATE	195872
2	STUD	16-33778
3	BUSHING	23-19661
4	LOCKWASHER, (.250) Stainless Steel	13-26992
5	NUT, (.250-28)	11-8267119
6	CABLE ASSEMBLY	84-88807A35
7	REGULATOR, Voltage	8M0084173	883072T, 854515T 1
8	PLUG, Male	13541
9	HARNESS ASSEMBLY (#2,4 & 6)	84-69738A9
9	HARNESS ASSEMBLY (#1,3 & 5)	84-69739A6
10	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
11	COVER	43542
12	SCREW, (#10-32 x 2.125)	10-90048
13	NUT,	10-32,11-90078
14	CABLE ASSEMBLY	84-88807A13
15	SCREW, (#10-32 x .500) Stainless Steel	10-69022
16	COIL KIT	339-832757A4
17	NUT, Brass	10-32,11-45076
18	CABLE ASSEMBLY, High Tension	84-813715A9
19	BOOT/TERMINAL KIT	85-63709A1
20	SPARK PLUG (NGK #BU8H)	33-13686Q
20	SPARK PLUG (NGK #BUZ8H - CANADA/BELGIUM)	33-896329885
21	CABLE ASSEMBLY (BLACK - 6-1/2 IN.)	84-824912A8
22	HARNESS ASSEMBLY	84-826802A4
23	RELAY ASSEMBLY	8M0207773
24	BRACKET	828102
25	BUSHING	23-8M0214955
26	GROMMET	25-818967
27	NOT SOLD SEPARATE, Decal-Trim Relay	NSS
28	WASHER, (.273 x .437 x .031) Stainless Steel	12-35950
29	NUT/SCREW KIT	11-13855A1
30	SCREW, (.250-20 x 1.250) Stainless Steel	10-F2030	F2046
31	NOT SOLD SEPARATE, Decal-Assembled in Mexico	NSS
1	MOUNTING PLATE	195872
2	STUD	16-33778
3	BUSHING	23-19661
4	LOCKWASHER, (.250) Stainless Steel	13-26992
5	NUT, (.250-28)	11-8267119
6	CABLE ASSEMBLY	84-88807A35
7	REGULATOR, Voltage	8M0084173	883072T, 854515T 1
8	PLUG, Male	13541
9	HARNESS ASSEMBLY (#2,4 & 6)	84-69738A9
9	HARNESS ASSEMBLY (#1,3 & 5)	84-69739A6
10	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
11	COVER	43542
12	SCREW, (#10-32 x 2.125)	10-90048
13	NUT,	10-32,11-90078
14	CABLE ASSEMBLY	84-88807A13
15	SCREW, (#10-32 x .500) Stainless Steel	10-69022
16	COIL KIT	339-832757A4
17	NUT, Brass	10-32,11-45076
18	CABLE ASSEMBLY, High Tension	84-813715A9
19	BOOT/TERMINAL KIT	85-63709A1
20	SPARK PLUG (NGK #BU8H)	33-13686Q
20	SPARK PLUG (NGK #BUZ8H - CANADA/BELGIUM)	33-896329885
21	CABLE ASSEMBLY (BLACK - 6-1/2 IN.)	84-824912A8
22	HARNESS ASSEMBLY	84-826802A4
23	RELAY ASSEMBLY	8M0207773
24	BRACKET	828102
25	BUSHING	23-8M0214955
26	GROMMET	25-818967
27	NOT SOLD SEPARATE, Decal-Trim Relay	NSS
28	WASHER, (.273 x .437 x .031) Stainless Steel	12-35950
29	NUT/SCREW KIT	11-13855A1
30	SCREW, (.250-20 x 1.250) Stainless Steel	10-F2030	F2046
31	NOT SOLD SEPARATE, Decal-Assembled in Mexico	NSS

INSTRUMENTATION

Below is the parts list for Mercury XR-6 INSTRUMENTATION:

Position No.	Part Name	OEM Number	Supersedes
1	SWITCH ASSEMBLY, Lanyard	87-19674A1
2	SCREW, (.190-16 x 1.750) Stainless Steel	10-18303
3	ADAPTER	813679	12051
4	LANYARD ASSEMBLY	15920Q54
5	SCREW, (#10-32 x 2.00) Stainless Steel	10-32866
6	CLAMP, Mounting	18321
7	WASHER, (.200 x .440 x .032)	12-24676
8	NUT, Stainless Steel	10-32,11-68219
9	RETAINER	79146
10	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
11	DIODE ASSEMBLY	812497A2
12	CABLE ASSEMBLY, (6.00 Inches)	84-11149A2
1	SWITCH ASSEMBLY, Lanyard	87-19674A1
2	SCREW, (.190-16 x 1.750) Stainless Steel	10-18303
3	ADAPTER	813679	12051
4	LANYARD ASSEMBLY	15920Q54
5	SCREW, (#10-32 x 2.00) Stainless Steel	10-32866
6	CLAMP, Mounting	18321
7	WASHER, (.200 x .440 x .032)	12-24676
8	NUT, Stainless Steel	10-32,11-68219
9	RETAINER	79146
10	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
11	DIODE ASSEMBLY	812497A2
12	CABLE ASSEMBLY, (6.00 Inches)	84-11149A2

Instrumentation

Below is the parts list for Mercury XR-6 Instrumentation:

Position No.	Part Name	OEM Number	Supersedes
1	SWITCH ASSEMBLY, Lanyard	87-19674A1
2	SCREW, (.190-16 x 1.750) Stainless Steel	10-18303
3	ADAPTER	813679	12051
4	LANYARD ASSEMBLY	15920Q54
5	SCREW, (#10-32 x 2.00) Stainless Steel	10-32866
6	CLAMP, Mounting	18321
7	WASHER, (.200 x .440 x .032)	12-24676
8	NUT, Stainless Steel	10-32,11-68219
9	RETAINER	79146
10	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
11	DIODE ASSEMBLY	812497A2
12	CABLE ASSEMBLY, (6.00 Inches)	84-11149A2
13	WARNING GAUGE KIT	79-859699A1
14	CLAMP	850020
15	LOCKWASHER, Star	8,13-825361
16	NUT, Brass	8-32,11-26419
17	LAMP	88-15163
18	SOCKET, Light Bulb	88-79888
19	CABLE ASSEMBLY, (20.00 Feet)	84-835359A1

JET COMPONENTS

Below is the parts list for Mercury XR-6 JET COMPONENTS:

Position No.	Part Name	OEM Number	Supersedes
1	SCREW, (.190-32 x 1.62)	10-88447
2	WASHER	12-38833
3	SPACER	23-94304
4	PLATE	13381
5	REV LIMITER	821889A30	821889A20
6	HARNESS ASSEMBLY, Adaptor - Rev Limiter	84-823147A5
7	BASE ASSEMBLY, Water Pump	46-8M0077147	46-42579A 3
8	GASKET	27-8M0204678
9	SEAL, Oil	26-89238
10	SEAL, Oil	26-16977
11	GASKET	27-8M0090319	27-85608 1
12	GASKET	27-858524	27-85609 1, 27-85609B 1
13	FACE PLATE	8M0204677
14	BODY ASSEMBLY, Water Pump	46-96148T1
15	INSERT	48752T
16	SEAL	26-38970
17	IMPELLER	47-89984T3
18	KEY	28-8M0214992
19	SCREW, (#14-8 x 2.25)	10-8M0215009
20	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
21	NUT, (.250-28)	11-8267119
22	SCREW, (.312-18 x 2.75)	10-19924275
23	WASHER	12-36001
24	SLEEVE	23-29804T
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	REPAIR KIT, Water Pump	46-96148A8
-	SEAL KIT	26-89238A2
1	SCREW, (.190-32 x 1.62)	10-88447
2	WASHER	12-38833
3	SPACER	23-94304
4	PLATE	13381
5	REV LIMITER	821889A30	821889A20
6	HARNESS ASSEMBLY, Adaptor - Rev Limiter	84-823147A5
7	BASE ASSEMBLY, Water Pump	46-8M0077147	46-42579A 3
8	GASKET	27-8M0204678
9	SEAL, Oil	26-89238
10	SEAL, Oil	26-16977
11	GASKET	27-8M0090319	27-85608 1
12	GASKET	27-858524	27-85609 1, 27-85609B 1
13	FACE PLATE	8M0204677
14	BODY ASSEMBLY, Water Pump	46-96148T1
15	INSERT	48752T
16	SEAL	26-38970
17	IMPELLER	47-89984T3
18	KEY	28-8M0214992
19	SCREW, (#14-8 x 2.25)	10-8M0215009
20	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
21	NUT, (.250-28)	11-8267119
22	SCREW, (.312-18 x 2.75)	10-19924275
23	WASHER	12-36001
24	SLEEVE	23-29804T
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	REPAIR KIT, Water Pump	46-96148A8
-	SEAL KIT	26-89238A2

JET PUMP ASSEMBLY

Below is the parts list for Mercury XR-6 JET PUMP ASSEMBLY:

Position No.	Part Name	OEM Number	Supersedes
-	JET PUMP ASSEMBLY	856143A3
1	HOUSING, Pump	803145T	855767150
2	HOSE, Lube	32-827490
3	SCREW, (.312-18 x 1.00)	10-848497
4	STUD, (.312-18 x 1.81)	16-855840
5	NUT, (.312-18)	11-82670910
6	HOUSING, Intake	85576890
7	LINER	855771
8	SHAFT, Drive	45-8M0084524
9	SLEEVE	23-8271891
10	NUT	11-8271901
11	IMPELLER	47-803985T	47-855708200
12	WASHER	12-36001
13	KEY	28-801405875
14	SHIM, Impeller	15-801404875
15	TAB WASHER	14-801403875
16	SCREW, (.250-20 x .625)	10-19923062
17	SCREW, (.312-18 x 1.250)	10-60411
18	BRACKET, Cable Support	801410
19	NUT, (.312-18)	11-82670910
20	PIN, Dowel	17-801407
21	STUD, (.437-14/.437-20 x 3.120)	16-786382
22	STUD, (.437-14/.437-20 x 2.060)	16-8M0133358
23	NUT, (.437-20) Stainless Steel	11-8M0204653
24	WASHER	12-48926
25	WASHER, (.453 x .812 x .105) Stainless Steel	12-45176
26	STUD, (.250-20/.250-28 x 3.125)	16-306671
27	SCREW, (.375-16 x 3.00) Stainless Steel	10-68299
28	WASHER, (.406 x .750 x .105) Stainless Steel	12-8M0214963
-	JET PUMP ASSEMBLY	856143A3
1	HOUSING, Pump	803145T	855767150
2	HOSE, Lube	32-827490
3	SCREW, (.312-18 x 1.00)	10-848497
4	STUD, (.312-18 x 1.81)	16-855840
5	NUT, (.312-18)	11-82670910
6	HOUSING, Intake	85576890
7	LINER	855771
8	SHAFT, Drive	45-8M0084524
9	SLEEVE	23-8271891
10	NUT	11-8271901
11	IMPELLER	47-803985T	47-855708200
12	WASHER	12-36001
13	KEY	28-801405875
14	SHIM, Impeller	15-801404875
15	TAB WASHER	14-801403875
16	SCREW, (.250-20 x .625)	10-19923062
17	SCREW, (.312-18 x 1.250)	10-60411
18	BRACKET, Cable Support	801410
19	NUT, (.312-18)	11-82670910
20	PIN, Dowel	17-801407
21	STUD, (.437-14/.437-20 x 3.120)	16-786382
22	STUD, (.437-14/.437-20 x 2.060)	16-8M0133358
23	NUT, (.437-20) Stainless Steel	11-8M0204653
24	WASHER	12-48926
25	WASHER, (.453 x .812 x .105) Stainless Steel	12-45176
26	STUD, (.250-20/.250-28 x 3.125)	16-306671
27	SCREW, (.375-16 x 3.00) Stainless Steel	10-68299
28	WASHER, (.406 x .750 x .105) Stainless Steel	12-8M0214963

MISCELLANEOUS INFORMATION

Below is the parts list for Mercury XR-6 MISCELLANEOUS INFORMATION:

Part Name	OEM Number	Supersedes
PARTS MANUAL, 135/150/175/200 XR6/MAGNUM III/140 JET (CARB)	90-803170
OWNERS MANUAL	90-10126980
OWNERS MANUAL Comment: (JET)	90-10140980
SERVICE MANUAL	90-824052R3
DECAL SET Comment: (135 BLACK LONG)	37-813220A00	37-813220A96 (135 BLACK LONG)
DECAL SET Comment: (135 BLACK XL/CXL BLUEWATER)	37-830169A00	37-830169A99, 37-830169A96 (135 BLACK XL/CXL BLUEWATER)
DECAL SET Comment: (150 BLACK XL/CXL BLUEWATER)	37-809687A99	37-809687A96 (150 BLACK XL/CXL BLUEWATER)
DECAL SET Comment: (175 BLACK LONG)	37-824911A00	37-824911A96 (175 BLACK LONG)
DECAL SET Comment: (175 BLACK XL/CXL BLUEWATER)	37-809688A00	37-809688A99, 37-809688A96, 37-855418A99, 37-855418A97 (175 BLACK XL/CXL BLUEWATER)
DECAL SET Comment: (XR6)	37-808552A00	37-808552A96 (XR6)
DECAL SET Comment: (200 BLACK LONG)	37-812563A00	37-808554A96, 37-812563A96 (200 BLACK LONG)
DECAL SET Comment: (200 XL/CXL BLUEWATER)	37-808562A03	37-808562A00, 37-808558A99, 37-808558A96, 37-808562A99, 37-808562A96 (200 XL/CXL BLUEWATER)
DECAL SET Comment: (BLACK140 JET)	37-826333A00	37-826333A96 (BLACK140 JET)
DECAL SET Comment: (GRAY 135 LONG) ALSO ORDER STRIPING DECAL LISTED BELOW	37-813036A97	37-813036A96 (GRAY 135 LONG) ALSO ORDER STRIPING DECAL LISTED BELOW
DECAL SET Comment: (GRAY 135 XL/CXL) ALSO ORDER STRIPING DECAL LISTED BELOW	37-850397A00	37-850397A97, 37-824106A96 (GRAY 135 XL/CXL) ALSO ORDER STRIPING DECAL LISTED BELOW
DECAL SET Comment: (GRAY 150 XL/CXL) ALSO ORDER STRIPING DECAL LISTED BELOW	37-802578A98
DECAL SET Comment: (MAGNUM III) ALSO ORDER STRIPING DECAL LISTED BELOW	37-813034A01	37-804694A00, 37-813034A97, 37-813034A96 (MAGNUM III) ALSO ORDER STRIPING DECAL LISTED BELOW
DECAL SET Comment: (GRAY 175 LONG) ALSO ORDER STRIPING DECAL LISTED BELOW	37-813037A97	37-813037A96 (GRAY 175 LONG) ALSO ORDER STRIPING DECAL LISTED BELOW
DECAL SET Comment: (GRAY 175 XL/CXL) ALSO ORDER STRIPING DECAL LISTED BELOW	37-809705A97	37-809705A96 (GRAY 175 XL/CXL) ALSO ORDER STRIPING DECAL LISTED BELOW
DECAL SET Comment: (GRAY 200 LONG) ALSO ORDER STRIPING DECAL LISTED BELOW	37-808563A03	37-808563A01, 37-808563A00, 37-808563A97, 37-808563A96, 37-815630A97, 37-815630A96 (GRAY 200 LONG) ALSO ORDER STRIPING DECAL LISTED BELOW
DECAL SET Comment: (GRAY 200 XL/CXL) ALSO ORDER STRIPING DECAL LISTED BELOW	37-808563A03	37-808563A01, 37-808563A00, 37-808563A97, 37-808563A96, 37-815630A97, 37-815630A96 (GRAY 200 XL/CXL) ALSO ORDER STRIPING DECAL LISTED BELOW
DECAL SET Comment: (GRAY 140 JET) ALSO ORDER STRIPING DECAL LISTED BELOW	37-826334A97	37-826334A96 (GRAY 140 JET) ALSO ORDER STRIPING DECAL LISTED BELOW
DECAL, Striping (ROLL OF 25 FEET- NEED 6 FEET)	37-824911A25	37-824911
DECAL SET Comment: (XR6 BY MERCURY) TRACKER	37-809846A96
DECAL SET Comment: (200 BY MERCURY) TRACKER	37-808681A01	37-808681A96 (200 BY MERCURY) TRACKER
DECAL SET Comment: (MAGNUM III BY MARINER) TRACKER	37-809850A96
DECAL SET Comment: (200 BY MARINER) TRACKER	37-809852A96
DECAL, EPA Label Information Comment: (135)(1999)	37-856985A10	37-856985 10 (135)(1999)
DECAL, EPA Label Information Comment: (135/XR6/MAG.III/175/200)(1999)	37-856985A11	37-856985 11 (135/XR6/MAG.III/175/200)(1999)
PARTS MANUAL, 135/150/175/200 XR6/MAGNUM III/140 JET (CARB)	90-803170
OWNERS MANUAL	90-10126980
OWNERS MANUAL Comment: (JET)	90-10140980
SERVICE MANUAL	90-824052R3
DECAL SET Comment: (135 BLACK LONG)	37-813220A00	37-813220A96 (135 BLACK LONG)
DECAL SET Comment: (135 BLACK XL/CXL BLUEWATER)	37-830169A00	37-830169A99, 37-830169A96 (135 BLACK XL/CXL BLUEWATER)
DECAL SET Comment: (150 BLACK XL/CXL BLUEWATER)	37-809687A99	37-809687A96 (150 BLACK XL/CXL BLUEWATER)
DECAL SET Comment: (175 BLACK LONG)	37-824911A00	37-824911A96 (175 BLACK LONG)
DECAL SET Comment: (175 BLACK XL/CXL BLUEWATER)	37-809688A00	37-809688A99, 37-809688A96, 37-855418A99, 37-855418A97 (175 BLACK XL/CXL BLUEWATER)
DECAL SET Comment: (XR6)	37-808552A00	37-808552A96 (XR6)
DECAL SET Comment: (200 BLACK LONG)	37-812563A00	37-808554A96, 37-812563A96 (200 BLACK LONG)
DECAL SET Comment: (200 XL/CXL BLUEWATER)	37-808562A03	37-808562A00, 37-808558A99, 37-808558A96, 37-808562A99, 37-808562A96 (200 XL/CXL BLUEWATER)
DECAL SET Comment: (BLACK140 JET)	37-826333A00	37-826333A96 (BLACK140 JET)
DECAL SET Comment: (GRAY 135 LONG) ALSO ORDER STRIPING DECAL LISTED BELOW	37-813036A97	37-813036A96 (GRAY 135 LONG) ALSO ORDER STRIPING DECAL LISTED BELOW
DECAL SET Comment: (GRAY 135 XL/CXL) ALSO ORDER STRIPING DECAL LISTED BELOW	37-850397A00	37-850397A97, 37-824106A96 (GRAY 135 XL/CXL) ALSO ORDER STRIPING DECAL LISTED BELOW
DECAL SET Comment: (GRAY 150 XL/CXL) ALSO ORDER STRIPING DECAL LISTED BELOW	37-802578A98
DECAL SET Comment: (MAGNUM III) ALSO ORDER STRIPING DECAL LISTED BELOW	37-813034A01	37-804694A00, 37-813034A97, 37-813034A96 (MAGNUM III) ALSO ORDER STRIPING DECAL LISTED BELOW
DECAL SET Comment: (GRAY 175 LONG) ALSO ORDER STRIPING DECAL LISTED BELOW	37-813037A97	37-813037A96 (GRAY 175 LONG) ALSO ORDER STRIPING DECAL LISTED BELOW
DECAL SET Comment: (GRAY 175 XL/CXL) ALSO ORDER STRIPING DECAL LISTED BELOW	37-809705A97	37-809705A96 (GRAY 175 XL/CXL) ALSO ORDER STRIPING DECAL LISTED BELOW
DECAL SET Comment: (GRAY 200 LONG) ALSO ORDER STRIPING DECAL LISTED BELOW	37-808563A03	37-808563A01, 37-808563A00, 37-808563A97, 37-808563A96, 37-815630A97, 37-815630A96 (GRAY 200 LONG) ALSO ORDER STRIPING DECAL LISTED BELOW
DECAL SET Comment: (GRAY 200 XL/CXL) ALSO ORDER STRIPING DECAL LISTED BELOW	37-808563A03	37-808563A01, 37-808563A00, 37-808563A97, 37-808563A96, 37-815630A97, 37-815630A96 (GRAY 200 XL/CXL) ALSO ORDER STRIPING DECAL LISTED BELOW
DECAL SET Comment: (GRAY 140 JET) ALSO ORDER STRIPING DECAL LISTED BELOW	37-826334A97	37-826334A96 (GRAY 140 JET) ALSO ORDER STRIPING DECAL LISTED BELOW
DECAL, Striping (ROLL OF 25 FEET- NEED 6 FEET)	37-824911A25	37-824911
DECAL SET Comment: (XR6 BY MERCURY) TRACKER	37-809846A96
DECAL SET Comment: (200 BY MERCURY) TRACKER	37-808681A01	37-808681A96 (200 BY MERCURY) TRACKER
DECAL SET Comment: (MAGNUM III BY MARINER) TRACKER	37-809850A96
DECAL SET Comment: (200 BY MARINER) TRACKER	37-809852A96
DECAL, EPA Label Information Comment: (135)(1999)	37-856985A10	37-856985 10 (135)(1999)
DECAL, EPA Label Information Comment: (135/XR6/MAG.III/175/200)(1999)	37-856985A11	37-856985 11 (135/XR6/MAG.III/175/200)(1999)

OIL INJECTION COMPONENTS

Below is the parts list for Mercury XR-6 OIL INJECTION COMPONENTS:

Position No.	Part Name	OEM Number	Supersedes
1	SENSOR ASSEMBLY	12430A4
2	SCREW, (#10-16 x .600)	10-878609	10-812832 1
3	WARNING MODULE ASSEMBLY	41470A26
4	WASHER, (.192 x .375 x .0312) Stainless Steel	12-30164
5	SCREW, (#10-32 x .875)	10-690201
6	BRACKET KIT	12335A1
7	CORD/HOOK KIT	12323A1
8	TANK	1257-87421
9	CAP ASSEMBLY	36-43298A2
10	O-RING, (2.225 x .210)	25-11332
11	HOUSING ASSEMBLY, Adapter	816190A4
12	O-RING, (2.225 x .210)	25-11332
13	TUBE	32-99802
14	HOSE, (114.00 Inches)	32-99439
15	PUMP, Oil Comment: (135)	815698T	815698, 41032 (135)
15	PUMP ASSEMBLY, Oil Comment: (150/XR6/MAGNUM III/175/200)	815699T	815699, 41033 (150/XR6/MAGNUM III/175/200)
16	BUSHING, Worm	8141032
17	O-RING	25-11379
18	BEARING ASSEMBLY	23-41429A2
19	GEAR, Driven	43-14563
20	SCREW, (#10-32 x .625)	10-32228
22	SCREW, (#10-32 x 1.120)	10-41507
21	LINK ASSEMBLY	193855
22	FITTING	22-8M0207780
23	NOT SOLD SEPARATE, Plug	NSS
24	HOSE, (57.00 Inches Bulk) (6 IN.)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
25	RESERVOIR	994436
26	SCREW, (#10-32 x .875)	10-690201
27	WASHER	12-42118
28	GROMMET	25-42117
29	BUSHING	23-42116
30	TUBING, (25.00 Inches Bulk) (4-3/4 IN.)	32-82381455
31	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
32	CAP ASSEMBLY	36-43300A9
33	FLOAT ASSEMBLY	8M0187298
34	PUSH NUT	11-99265
35	GASKET	27-43307T
36	NOT SOLD SEPARATE, Decal-reservoir Warning	NSS
1	SENSOR ASSEMBLY	12430A4
2	SCREW, (#10-16 x .600)	10-878609	10-812832 1
3	WARNING MODULE ASSEMBLY	41470A26
4	WASHER, (.192 x .375 x .0312) Stainless Steel	12-30164
5	SCREW, (#10-32 x .875)	10-690201
6	BRACKET KIT	12335A1
7	CORD/HOOK KIT	12323A1
8	TANK	1257-87421
9	CAP ASSEMBLY	36-43298A2
10	O-RING, (2.225 x .210)	25-11332
11	HOUSING ASSEMBLY, Adapter	816190A4
12	O-RING, (2.225 x .210)	25-11332
13	TUBE	32-99802
14	HOSE, (114.00 Inches)	32-99439
15	PUMP, Oil Comment: (135)	815698T	815698, 41032 (135)
15	PUMP ASSEMBLY, Oil Comment: (150/XR6/MAGNUM III/175/200)	815699T	815699, 41033 (150/XR6/MAGNUM III/175/200)
16	BUSHING, Worm	8141032
17	O-RING	25-11379
18	BEARING ASSEMBLY	23-41429A2
19	GEAR, Driven	43-14563
20	SCREW, (#10-32 x .625)	10-32228
22	SCREW, (#10-32 x 1.120)	10-41507
21	LINK ASSEMBLY	193855
22	FITTING	22-8M0207780
23	NOT SOLD SEPARATE, Plug	NSS
24	HOSE, (57.00 Inches Bulk) (6 IN.)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
25	RESERVOIR	994436
26	SCREW, (#10-32 x .875)	10-690201
27	WASHER	12-42118
28	GROMMET	25-42117
29	BUSHING	23-42116
30	TUBING, (25.00 Inches Bulk) (4-3/4 IN.)	32-82381455
31	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
32	CAP ASSEMBLY	36-43300A9
33	FLOAT ASSEMBLY	8M0187298
34	PUSH NUT	11-99265
35	GASKET	27-43307T
36	NOT SOLD SEPARATE, Decal-reservoir Warning	NSS

Oil Injection Components

Below is the parts list for Mercury XR-6 Oil Injection Components:

Position No.	Part Name	OEM Number	Supersedes
1	BRACKET KIT	12335A1
2	CORD/HOOK KIT	12323A1
3	TANK	1257-87421
4	CAP ASSEMBLY	36-43298A2
5	NOT SOLD SEPARATE, Insert	NSS
6	O-RING, (2.225 x .210)	25-11332
7	HOUSING ASSEMBLY, Adapter	816190A4
8	O-RING, (2.225 x .210)	25-11332
9	TUBE	32-99802
10	HOSE, (114.00 Inches)	32-99439
11	RESERVOIR ASSEMBLY, Oil	1200-8M0062954	833069T 3
12	NOT SOLD SEPARATE, Decal-Reservoir	NSS
13	GROMMET	25-855362001	25-855362
14	WASHER	12-49436
15	SCREW, (.312-18 x 1.250)	10-60411
16	BUSHING	23-855364
17	SCREW, (.312-18 x 1.750)	10-69267
18	GROMMET	25-833155
19	BUSHING	23-8502341
20	TUBING, (25.00 Inches Bulk) (Cut to 20 Inches)	32-82381455
21	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
22	SWITCH	87-12886A8
23	SCREW, (.164-18 x .375)	10-58376
24	WASHER, (.203 x .562 x .060) Stainless Steel	12-72761
25	SPACER	23-8260841
26	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
27	NOT SOLD SEPARATE, Plug	NSS
28	FITTING	22-8M0207780
29	HOSE, (57.00 Inches Bulk) (Cut to 6 Inches)	32-8M0108355	32-8M0047428, 32-830756109, 32-99127109, 32-877821
30	COOLER ASSEMBLY, Fuel	855785A1
31	CHECK VALVE	21-8557611
32	CLAMP, Hose (15.3)	54-8M0214964
33	TUBING, (17.00 Inches Bulk) (Cut to 3 Inches)	32-85682239
34	HOSE (W/INSULATING SLEEVE) (30 IN.)	32-856822A3

POWER TRIM COMPONENTS

Below is the parts list for Mercury XR-6 POWER TRIM COMPONENTS:

Position No.	Part Name	OEM Number	Supersedes
-	POWER TRIM ASSEMBLY, Complete	855998A11	855998A08, 855998A07, 855998A10, 855998A09, 855998A05, 855998A 3
1	MANIFOLD ASSEMBLY	811604F	811604T
2	PLUG, Pipe (.0625-27)	22-56800
3	CYLINDER ASSEMBLY	880952A03	880952A02, 880952A 1
4	ROD KIT, Trim Piston	823553T	823553, 811609
5	GUIDE KIT	878239A02	878239A 1
6	REPAIR KIT	811607A1
7	CHECK VALVE KIT	811610A1
8	GUIDE ASSEMBLY	1100-8M0021648	878243A 1
9	PISTON/ROD ASSEMBLY, Power Trim Comment: (PORT)	878413A1
9	PISTON/ROD ASSEMBLY, Power Trim Comment: (STBD.)	878414T01	878414A 1 (STBD.)
10	TRIM FILTER ASSEMBLY	35-12184A1
11	MANUAL RELEASE ASSEMBLY	893929A01	813442A 2
12	E RING	53-815949001	53-812844, 53-835104
13	O-RING KIT	811612A3
14	PUMP	811617T1
15	PLUG ASSEMBLY	19-811613
16	SCREW, (M6 x 14)	10-4000327
17	WASHER	12-4002315
18	COVER	811611
19	DRIVE JOINT	828710
20	MOTOR ASSEMBLY Comment: (BREAKDOWN ON POWER TRIM MOTOR)	878265A4
21	SCREW Comment: (LONG)	10-881768A1
21	SCREW Comment: (SHORT)	10-811616
22	SHAFT ASSEMBLY	8M0142997
23	PLUG, Pipe (.0625-27)	22-56800
24	PIN, Groove	17-878267	17-44431
25	PIN, Trilobe	17-821539	17-13794, 17-19603
26	SHAFT	99625002
27	ANODE KIT	97-818298Q1
28	SCREW, (M6 x 25)	10-8M0204707
29	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
30	SCREW, (M10 x 30)	10-4000377
31	WASHER	12-4002319
32	CLAMP	54-26550
33	SCREW, (#10-16 x .600)	10-878609	10-812832 1
34	C WASHER	8M0084613	69205
35	STRIKER PLATE	8M0045383	99630 1
36	LOCKWASHER, (.375)	13-58643
37	NUT, (.375-24)	11-46335
38	NOT SOLD SEPARATE, Decal-Power Trim	NSS
39	CONDUIT, (.350 Inside Diameter x 3.00 Feet Bulk)	32-828547353
40	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
-	POWER TRIM ASSEMBLY, Complete	855998A11	855998A08, 855998A07, 855998A10, 855998A09, 855998A05, 855998A 3
1	MANIFOLD ASSEMBLY	811604F	811604T
2	PLUG, Pipe (.0625-27)	22-56800
3	CYLINDER ASSEMBLY	880952A03	880952A02, 880952A 1
4	ROD KIT, Trim Piston	823553T	823553, 811609
5	GUIDE KIT	878239A02	878239A 1
6	REPAIR KIT	811607A1
7	CHECK VALVE KIT	811610A1
8	GUIDE ASSEMBLY	1100-8M0021648	878243A 1
9	PISTON/ROD ASSEMBLY, Power Trim Comment: (PORT)	878413A1
9	PISTON/ROD ASSEMBLY, Power Trim Comment: (STBD.)	878414T01	878414A 1 (STBD.)
10	TRIM FILTER ASSEMBLY	35-12184A1
11	MANUAL RELEASE ASSEMBLY	893929A01	813442A 2
12	E RING	53-815949001	53-812844, 53-835104
13	O-RING KIT	811612A3
14	PUMP	811617T1
15	PLUG ASSEMBLY	19-811613
16	SCREW, (M6 x 14)	10-4000327
17	WASHER	12-4002315
18	COVER	811611
19	DRIVE JOINT	828710
20	MOTOR ASSEMBLY Comment: (BREAKDOWN ON POWER TRIM MOTOR)	878265A4
21	SCREW Comment: (LONG)	10-881768A1
21	SCREW Comment: (SHORT)	10-811616
22	SHAFT ASSEMBLY	8M0142997
23	PLUG, Pipe (.0625-27)	22-56800
24	PIN, Groove	17-878267	17-44431
25	PIN, Trilobe	17-821539	17-13794, 17-19603
26	SHAFT	99625002
27	ANODE KIT	97-818298Q1
28	SCREW, (M6 x 25)	10-8M0204707
29	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
30	SCREW, (M10 x 30)	10-4000377
31	WASHER	12-4002319
32	CLAMP	54-26550
33	SCREW, (#10-16 x .600)	10-878609	10-812832 1
34	C WASHER	8M0084613	69205
35	STRIKER PLATE	8M0045383	99630 1
36	LOCKWASHER, (.375)	13-58643
37	NUT, (.375-24)	11-46335
38	NOT SOLD SEPARATE, Decal-Power Trim	NSS
39	CONDUIT, (.350 Inside Diameter x 3.00 Feet Bulk)	32-828547353
40	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275

POWER TRIM MOTOR

Below is the parts list for Mercury XR-6 POWER TRIM MOTOR:

Position No.	Part Name	OEM Number
-	MOTOR ASSEMBLY	878265A4
1	BRUSH AND SEAL KIT	828714A1
2	ARMATURE KIT	828713T1
3	END FRAME (COMPLETE)	828715A1
-	MOTOR ASSEMBLY	878265A4
1	BRUSH AND SEAL KIT	828714A1
2	ARMATURE KIT	828713T1
3	END FRAME (COMPLETE)	828715A1

Power Trim Components

Below is the parts list for Mercury XR-6 Power Trim Components:

Position No.	Part Name	OEM Number	Supersedes
-	POWER TRIM ASSEMBLY, Complete	855998A11	855998A08, 855998A07, 855998A10, 855998A09, 855998A05, 855998A 3
1	MANIFOLD ASSEMBLY	811604F	811604T
2	PLUG, Pipe (.0625-27)	22-56800
3	CYLINDER ASSEMBLY	880952A03	880952A02, 880952A 1
4	ROD, Trim Piston	823553T	823553, 811609
5	GUIDE KIT	878239A02	878239A 1
6	REPAIR KIT	811607A1
7	CHECK VALVE KIT	811610A1
8	GUIDE ASSEMBLY	1100-8M0021648	878243A 1
9	PISTON/ROD ASSEMBLY, Power Trim	878413A1
9	PISTON ASSEMBLY, Power Trim (Starboard)	878414T01	878414A 1
10	TRIM FILTER ASSEMBLY	35-12184A1
11	MANUAL RELEASE ASSEMBLY	893929A01	813442A 2
12	E RING	53-815949001	53-812844, 53-835104
13	O-RING KIT	811612A3
14	PUMP	811617T1
15	PLUG ASSEMBLY	19-811613
16	SCREW, (M6 x 14)	10-4000327
17	WASHER	12-4002315
18	COVER	811611
19	DRIVE JOINT	828710
20	MOTOR ASSEMBLY	878265A4
21	SCREW (LONG)	10-881768A1
21	SCREW (SHORT)	10-811616
22	SHAFT ASSEMBLY	8M0142997
23	PLUG, Pipe (.0625-27)	22-56800
24	PIN, Groove	17-878267	17-44431
25	PIN, Trilobe	17-821539	17-13794, 17-19603
26	SHAFT	99625002
27	ANODE KIT	97-818298Q1
28	SCREW, (M6 x 25)	10-8M0204707
29	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
30	SCREW, (M10 x 30)	10-4000377
31	WASHER	12-4002319
32	CLAMP	54-26550
33	SCREW, (#10-16 x .600)	10-878609	10-812832 1
34	C WASHER	8M0084613	69205
35	STRIKER PLATE	8M0045383	99630 1
36	LOCKWASHER, (.375)	13-58643
37	NUT, (.375-24)	11-46335
38	DECAL, Caution-Power Trim	37-435301
39	CONDUIT, (.350 Inside Diameter x 3.00 Feet Bulk)	32-828547353
40	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275

Power Trim Motor

Below is the parts list for Mercury XR-6 Power Trim Motor:

Position No.	Part Name	OEM Number
-	MOTOR ASSEMBLY	878265A4
1	BRUSH AND SEAL KIT	828714A1
2	ARMATURE KIT	828713T1
3	END FRAME (COMPLETE)	828715A1

REED BLOCK AND CYLINDER HEAD

Below is the parts list for Mercury XR-6 REED BLOCK AND CYLINDER HEAD:

Position No.	Part Name	OEM Number	Supersedes
1	CYLINDER HEAD Comment: 135	18787A18
1	CYLINDER HEAD Comment: 150/XR6/ MAGNUM III 175	900-8M0143213
1	CYLINDER HEAD ASSEMBLY Comment: 200	18488F2
2	GASKET Comment: 135	27-18785T
2	GASKET Comment: 150/XR6/ MAGNUM III 175/200	27-822844T05	27-822844T04, 27-822844 1, 27-822844004 150/XR6/ MAGNUM III 175/200
3	SCREW, (.375-16 x 2.30)	10-98534
4	PIN, Dowel (.250 x .625)	17-63779
5	GASKET	27-8M0204714
6	COVER KIT	90390A1
7	THERMOSTAT	75692
8	SCREW, (.312-18 x 1.00)	10-35386
9	FITTING, (.250-18) 90 Degree - Brass	22-687271
10	SENDER, Temperature (STBD.)	97465
11	VALVE, Thermal Air	814612
12	TUBING, (25.00 Inches) (12-3/4 IN.)	32-77653101
13	FITTING	22-68728
14	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
15	TUBING, (25.00 Inches) (11-1/2 IN.)	32-77653101
16	T-FITTING	22-815914
17	SENSOR ASSEMBLY, Temperature (PORT) (2-WIRE)	13536A7
18	RETAINER	137151
19	SCREW, (.312-18 x .500)	10-98257
20	TUBING, (25.00 Inches) (7-1/2 IN.)	32-77653101
21	PLATE ASSEMBLY	43517A9
22	SCREW, (.250-20 x .875) Stainless Steel	10-28668
23	GASKET	27-146972
24	REED BLOCK	855952T3
25	J CLIP	54-8M0024808
26	CLIP	54-23567
27	C WASHER	8M0084613	69205
28	SCREW, (#10-16 x .500)	10-878608	10-812832
29	SCREW, (.250-20 x .880)	10-55715
30	SCREW, (.250-20 x 2.00)	10-96529
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	POWERHEAD ASSEMBLY Comment: (135/150)	878365T00	812815T00, 812815T97, 812815A97, 812815A96, 812815A92, 812815A90 (135/150)
-	POWERHEAD ASSEMBLY Comment: (XR6/MAGNUM III)	823434T97	823434A97, 823434A96, 823434A93 (XR6/MAGNUM III)
-	POWERHEAD ASSEMBLY Comment: (175)	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (175)
-	POWERHEAD ASSEMBLY Comment: (200)	813043T97	813043A97, 813043A96, 813043A94, 812827A92, 813043A92 (200)
1	CYLINDER HEAD Comment: 135	18787A18
1	CYLINDER HEAD Comment: 150/XR6/ MAGNUM III 175	900-8M0143213
1	CYLINDER HEAD ASSEMBLY Comment: 200	18488F2
2	GASKET Comment: 135	27-18785T
2	GASKET Comment: 150/XR6/ MAGNUM III 175/200	27-822844T05	27-822844T04, 27-822844 1, 27-822844004 150/XR6/ MAGNUM III 175/200
3	SCREW, (.375-16 x 2.30)	10-98534
4	PIN, Dowel (.250 x .625)	17-63779
5	GASKET	27-8M0204714
6	COVER KIT	90390A1
7	THERMOSTAT	75692
8	SCREW, (.312-18 x 1.00)	10-35386
9	FITTING, (.250-18) 90 Degree - Brass	22-687271
10	SENDER, Temperature (STBD.)	97465
11	VALVE, Thermal Air	814612
12	TUBING, (25.00 Inches) (12-3/4 IN.)	32-77653101
13	FITTING	22-68728
14	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
15	TUBING, (25.00 Inches) (11-1/2 IN.)	32-77653101
16	T-FITTING	22-815914
17	SENSOR ASSEMBLY, Temperature (PORT) (2-WIRE)	13536A7
18	RETAINER	137151
19	SCREW, (.312-18 x .500)	10-98257
20	TUBING, (25.00 Inches) (7-1/2 IN.)	32-77653101
21	PLATE ASSEMBLY	43517A9
22	SCREW, (.250-20 x .875) Stainless Steel	10-28668
23	GASKET	27-146972
24	REED BLOCK	855952T3
25	J CLIP	54-8M0024808
26	CLIP	54-23567
27	C WASHER	8M0084613	69205
28	SCREW, (#10-16 x .500)	10-878608	10-812832
29	SCREW, (.250-20 x .880)	10-55715
30	SCREW, (.250-20 x 2.00)	10-96529
-	GASKET SET, Engine	27-815791A92	27-815791A90, 27-815809A90, 27-815810A90
-	POWERHEAD ASSEMBLY Comment: (135/150)	878365T00	812815T00, 812815T97, 812815A97, 812815A96, 812815A92, 812815A90 (135/150)
-	POWERHEAD ASSEMBLY Comment: (XR6/MAGNUM III)	823434T97	823434A97, 823434A96, 823434A93 (XR6/MAGNUM III)
-	POWERHEAD ASSEMBLY Comment: (175)	812817T97	812817A97, 812817A96, 812817A92, 821861A92 (175)
-	POWERHEAD ASSEMBLY Comment: (200)	813043T97	813043A97, 813043A96, 813043A94, 812827A92, 813043A92 (200)

STARTER MOTOR

Below is the parts list for Mercury XR-6 STARTER MOTOR:

Position No.	Part Name	OEM Number	Supersedes
-	STARTER MOTOR ASSEMBLY	50-893893	50-79472T 2, 50-79472 2
1	DRIVE KIT	90645
2	PINION ASSEMBLY, Drive	13310T1
3	PLATE	75660
4	THRU BOLT	10-749681
5	NOT SOLD SEPARATE, Washer (AMERICAN BOSCH #WA3122)	NSS
6	ARMATURE	79216
7	BRUSH/SPRING KIT	898265016	75384, 75384 1
8	HOLDER	898265014	61787
9	NOT SOLD SEPARATE, Screw (AMERICAN BOSCH #02441-22-SC-30SM)	NSS
10	END CAP	15386001
-	STARTER MOTOR ASSEMBLY	50-893893	50-79472T 2, 50-79472 2
1	DRIVE KIT	90645
2	PINION ASSEMBLY, Drive	13310T1
3	PLATE	75660
4	THRU BOLT	10-749681
5	NOT SOLD SEPARATE, Washer (AMERICAN BOSCH #WA3122)	NSS
6	ARMATURE	79216
7	BRUSH/SPRING KIT	898265016	75384, 75384 1
8	HOLDER	898265014	61787
9	NOT SOLD SEPARATE, Screw (AMERICAN BOSCH #02441-22-SC-30SM)	NSS
10	END CAP	15386001

SWIVEL BRACKET AND STEERING ARM

Below is the parts list for Mercury XR-6 SWIVEL BRACKET AND STEERING ARM:

Position No.	Part Name	OEM Number	Supersedes
1	SWIVEL BRACKET ASSEMBLY, Black	1499-8M0102865	1499-8710T20
2	SEAL, Oil (LOWER)	26-87735
3	BUSHING	23-818764	23-67669
4	SPACER	23-816039
5	O-RING	25-8M0214926
6	FITTING, Grease	22-8M0169589
7	BUSHING	23-821207	23-99608
8	THRUST WASHER	12-816432
9	SCREW, (.437-20 x 7.50)	10-8M0176309
10	MOUNT Comment: (135/175LONG)(JET)	78687T
10	MOUNT Comment: (ALL OTHER MODELS)	77326
11	WASHER	12-66921
12	WASHER	12-78688
13	NUT, (.437-20) Stainless Steel	11-8M0204653
14	LINK ASSEMBLY, Steering	92876A12
15	SCREW, (.375-24 x 1.25)	10-849838	10-14000
16	NUT, (.375-24)	11-8M0204726
17	WASHER, (.390 x .625 x .062) Stainless Steel	12-37828
18	SWIVEL PIN ASSEMBLY, Steering Arm	17-67706A55
19	YOKE ASSEMBLY, Bottom	86580A1
20	RING, Retaining	53-67684
21	BUMPER	8M0000516	88882 1
22	SCREW, (.250-28 x .500)	10-64014
23	SENDER ASSEMBLY, Trim	8M0074846	821180A 6
24	SCREW, (#10-24 x .750)	10-852368	10-56682
25	LOCKWASHER, Stainless Steel	10,13-26996
26	WASHER, (.203 x .406 x .040)	12-89302
27	NOT SOLD SEPARATE, Decal-Serial Overlaminate	NSS
1	SWIVEL BRACKET ASSEMBLY, Black	1499-8M0102865	1499-8710T20
2	SEAL, Oil (LOWER)	26-87735
3	BUSHING	23-818764	23-67669
4	SPACER	23-816039
5	O-RING	25-8M0214926
6	FITTING, Grease	22-8M0169589
7	BUSHING	23-821207	23-99608
8	THRUST WASHER	12-816432
9	SCREW, (.437-20 x 7.50)	10-8M0176309
10	MOUNT Comment: (135/175LONG)(JET)	78687T
10	MOUNT Comment: (ALL OTHER MODELS)	77326
11	WASHER	12-66921
12	WASHER	12-78688
13	NUT, (.437-20) Stainless Steel	11-8M0204653
14	LINK ASSEMBLY, Steering	92876A12
15	SCREW, (.375-24 x 1.25)	10-849838	10-14000
16	NUT, (.375-24)	11-8M0204726
17	WASHER, (.390 x .625 x .062) Stainless Steel	12-37828
18	SWIVEL PIN ASSEMBLY, Steering Arm	17-67706A55
19	YOKE ASSEMBLY, Bottom	86580A1
20	RING, Retaining	53-67684
21	BUMPER	8M0000516	88882 1
22	SCREW, (.250-28 x .500)	10-64014
23	SENDER ASSEMBLY, Trim	8M0074846	821180A 6
24	SCREW, (#10-24 x .750)	10-852368	10-56682
25	LOCKWASHER, Stainless Steel	10,13-26996
26	WASHER, (.203 x .406 x .040)	12-89302
27	NOT SOLD SEPARATE, Decal-Serial Overlaminate	NSS

Service/Support Material

Below is the parts list for Mercury XR-6 Service/Support Material:

Part Name	OEM Number	Supersedes
DECAL SET Comment: (BLACK 135 LONG)	37-854291A04	37-854291A00, 37-854291A98 (BLACK 135 LONG)
DECAL SET Comment: (BLACK 135 XL/CXL - BLUEWATER)	37-854292A04	37-854292A03, 37-854292A00, 37-854292A99, 37-854292A98 (BLACK 135 XL/CXL - BLUEWATER)
DECAL SET Comment: (BLACK 150 LONG)	37-854294A06	37-854293A04, 37-854293A00, 37-854293A98 (BLACK 150 LONG)
DECAL SET Comment: (BLACK 150 XL/CXL - BLUEWATER)	37-854294A04	37-854294A03, 37-854294A00, 37-854294A99, 37-854294A98 (BLACK 150 XL/CXL - BLUEWATER)
DECAL SET Comment: (GRAY 135 LONG)	37-854295A03	37-854295A01, 37-854295A98, 37-854296A99, 37-854296A98 (GRAY 135 LONG)
DECAL SET Comment: (GRAY 135 XL/CXL)	37-854295A03	37-854295A01, 37-854295A98, 37-854296A99, 37-854296A98 (GRAY 135 XL/CXL)
DECAL SET Comment: (GRAY 150 LONG)	37-854297A03	37-854297A01, 37-854297A98, 37-854298A99, 37-854298A98 (GRAY 150 LONG)
DECAL SET Comment: (GRAY 150 XL/CXL)	37-854297A03	37-854297A01, 37-854297A98, 37-854298A99, 37-854298A98 (GRAY 150 XL/CXL)
DECAL SET Comment: (BLACK TRACKER 135)	37-803988A99
DECAL SET Comment: (BLACK TRACKER 150)	37-802643A98
DECAL SET Comment: (GRAY TRACKER 150)	37-802646A98
DECAL, EPA Label Information Comment: (1999)	37-856985A13	37-856985 13 (1999)
HOSE ASSEMBLY, Fuel	32-858610A31	32-858610A10, 32-16789A18
CLAMP, Worm Gear	54-815504104	54-54428, 54-809952104, 54-8M2001484, 54-F9005, F24772, F24788, F901788
OWNERS MANUAL	90-10199990
SERVICE MANUAL	90-855347R02	90-855347R 1
135/150 DFI (2.5L)	90-803502

Starter Motor

Below is the parts list for Mercury XR-6 Starter Motor:

Position No.	Part Name	OEM Number	Supersedes
1	STARTER MOTOR ASSEMBLY	50-898265008	50-833153 5
2	DRIVE CAP	8236392
3	THRU BOLT	10-8236411
4	DRIVE KIT	823640T	823640
5	PINION	898265015	86177 1
6	ARMATURE	8236381
7	BRUSH/SPRING KIT	898265016	75384, 75384 1
8	HOLDER	898265014	61787
9	CAP, Commutator	8119011
10	SCREW	F15158
11	LOCKWASHER, (.250) Stainless Steel	13-26992
12	NUT, (.250-20) (1/4-20)	11-20890
13	LOCKWASHER, (.250) Stainless Steel	13-26992
14	NUT, (.250-20) Brass	11-94330
15	SCREW (5/16-18 X 1-3/4)	10-853958
16	CABLE ASSEMBLY, Battery - Negative	84-88439A26
17	DECAL, Warning, High Voltage	37-8272822
18	BOOT, Insulator - Red	85-830233

Steering Attaching Kit

Below is the parts list for Mercury XR-6 Steering Attaching Kit:

Position No.	Part Name	OEM Number	Supersedes
-	ATTACHING KIT, Steering (SINGLE)	92876A8
1	BRACKET ASSEMBLY	41055A1
2	TUBE ASSEMBLY	71565A2
3	O-RING, (.614 x .070)	25-48462
4	LOCKWASHER	13-821203
5	NUT, (.875-14)	11-8M0041651	11-37984
6	SCREW, (.250-28 x 1.250)	10-38601
7	LOCKWASHER, Internal (.250)	13-78968
8	COUPLER	850791T	850791, 88319
9	SCREW, (.375-24 x 1.120)	10-73732
10	WASHER, (.390 x .625 x .062) Stainless Steel	12-37828
11	NUT, (.375-24)	11-8M0204726
-	ATTACHING KIT, Steering (SINGLE)	92876A8
1	BRACKET ASSEMBLY	41055A1
2	TUBE ASSEMBLY	71565A2
3	O-RING, (.614 x .070)	25-48462
4	LOCKWASHER	13-821203
5	NUT, (.875-14)	11-8M0041651	11-37984
6	SCREW, (.250-28 x 1.250)	10-38601
7	LOCKWASHER, Internal (.250)	13-78968
8	COUPLER	850791T	850791, 88319
9	SCREW, (.375-24 x 1.120)	10-73732
10	WASHER, (.390 x .625 x .062) Stainless Steel	12-37828
11	NUT, (.375-24)	11-8M0204726

Swivel Bracket and Steering Arm

Below is the parts list for Mercury XR-6 Swivel Bracket and Steering Arm:

Position No.	Part Name	OEM Number	Supersedes
1	SWIVEL BRACKET ASSEMBLY, Black	1499-8M0102865	1499-8710T20
2	O-RING	25-8M0214926
3	BUSHING	23-818764	23-67669
4	SPACER	23-816039
5	SEAL, Oil (LOWER)	26-87735
6	FITTING, Grease	22-8M0169589
7	BUSHING	23-821207	23-99608
8	THRUST WASHER	12-816432
9	YOKE ASSEMBLY, Bottom	86580A1
10	RING, Retaining	53-67684
11	STRIKER PLATE	8M0045383	99630 1
12	LOCKWASHER, (.375)	13-58643
13	NUT, (.375-24)	11-46335
14	SCREW, (.250-28 x .500)	10-64014
15	NOT SOLD SEPARATE, Decal-Serial Overlaminate	NSS
16	SENDER ASSEMBLY, Trim	8M0074846	821180A 6
17	SCREW, (#10-24 x .750)	10-852368	10-56682
18	LOCKWASHER, Stainless Steel	10,13-26996
19	WASHER, (.203 x .406 x .040)	12-89302
20	SWIVEL PIN ASSEMBLY, Steering Arm	17-67706A55
21	SCREW, (.437-20 x 7.50)	10-8M0176309
22	BUMPER	8M0000516	88882 1
23	MOUNT	77326
24	WASHER	12-66921
25	WASHER	12-78688
26	NUT, (.437-20) Stainless Steel	11-8M0204653
27	LINK ROD ASSEMBLY	92876A12
28	SCREW, (.375-24 x 1.25)	10-849838	10-14000
29	NUT, (.375-24)	11-8M0204726
30	WASHER, (.390 x .625 x .062) Stainless Steel	12-37828
31	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275

THROTTLE LEVER AND SHIFT SHAFT

Below is the parts list for Mercury XR-6 THROTTLE LEVER AND SHIFT SHAFT:

Position No.	Part Name	OEM Number	Supersedes
1	LEVER ASSEMBLY	41094A3
2	SCREW, (.250-20 x 2.125)	10-64022
3	NUT, (.250-20)	11-64015
4	CAP, Nylon	26852
5	SCREW, (.190-32 x 1.250)	10-13627
6	NUT, Stainless Steel	10-32,11-68219
7	CAP	48039
8	WASHER, (.390 x 1.50 x .120)	12-46765
9	NUT,	10-32,11-46438
10	ROD	76035
11	NUT, Brass	10-32,11-45076
12	BALL JOINT ASSEMBLY	62459T
13	PIVOT	74897T
14	SPRING	24-823235
15	BUSHING	23-55171
16	LEVER	410952
17	SCREW, (.375-16 x 1.75)	10-818165	10-55337
18	BUSHING	23-55164
19	SCREW, (.250-20 x 2.125)	10-64022
20	NUT, (.250-20)	11-64015
21	CAP, Nylon	26852
22	LATCH	39483
23	SCREW, (.250-28 x .880)	10-69026
24	SPRING	24-20099
25	NUT, (.250-28)	11-826709109	11-33825, 11-35045
26	BARREL	14638
27	ROD	8302391
28	BUSHING	23-8M0215006
29	CAM, Throttle Comment: (135)	8282761
29	CAM Comment: (150 THRU 200)	828276
30	STUD, (.250-28 x 1.750)	16-20353
31	NUT, (.250-28)	11-826709109	11-33825, 11-35045
32	BRACKET ASSEMBLY	814283A2
33	LATCH	98889
34	DRIVE SCREW	10-42975
35	CUP	39519
36	WEAR PLATE	52100
37	LATCH	8M0036768	38279
38	WASHER, (.2656 x .625 x .0625) Stainless Steel	12-35462
39	NUT, (.250-28)	11-826709109	11-33825, 11-35045
40	SCREW, (.312-18 x .880)	10-53167T
41	GUIDE BLOCK	814284
42	SPRING	24-20099
43	LINK ROD ASSEMBLY	67073A1
44	SHIFT SHAFT ASSEMBLY Comment: (LONG)	79932A16
44	SHIFT SHAFT ASSEMBLY Comment: (X-LONG)	79932A17
45	NOT SOLD SEPARATE, Roll Pin	NSS
46	NOT SOLD SEPARATE, Shift Shaft Lever-Upper	NSS
47	BUSHING	23-26856
48	WAVE WASHER	13-29720
49	WASHER, (.2656 x .625 x .0625) Stainless Steel	12-35462
50	NUT, (.250-28)	11-826709109	11-33825, 11-35045
51	IDLE STABILIZING SHIFT KIT Comment: 150/XR6/175 MAGNUM III	87-814281A1
52	SCREW, (#6-32 x .875) Comment: 150/XR6/175 MAGNUM III	10-77478
53	WASHER Comment: 150/XR6/175 MAGNUM III	12-27882
54	RESISTOR MODULE Comment: 150/XR6/175 MAGNUM III	17461A3
1	LEVER ASSEMBLY	41094A3
2	SCREW, (.250-20 x 2.125)	10-64022
3	NUT, (.250-20)	11-64015
4	CAP, Nylon	26852
5	SCREW, (.190-32 x 1.250)	10-13627
6	NUT, Stainless Steel	10-32,11-68219
7	CAP	48039
8	WASHER, (.390 x 1.50 x .120)	12-46765
9	NUT,	10-32,11-46438
10	ROD	76035
11	NUT, Brass	10-32,11-45076
12	BALL JOINT ASSEMBLY	62459T
13	PIVOT	74897T
14	SPRING	24-823235
15	BUSHING	23-55171
16	LEVER	410952
17	SCREW, (.375-16 x 1.75)	10-818165	10-55337
18	BUSHING	23-55164
19	SCREW, (.250-20 x 2.125)	10-64022
20	NUT, (.250-20)	11-64015
21	CAP, Nylon	26852
22	LATCH	39483
23	SCREW, (.250-28 x .880)	10-69026
24	SPRING	24-20099
25	NUT, (.250-28)	11-826709109	11-33825, 11-35045
26	BARREL	14638
27	ROD	8302391
28	BUSHING	23-8M0215006
29	CAM, Throttle Comment: (135)	8282761
29	CAM Comment: (150 THRU 200)	828276
30	STUD, (.250-28 x 1.750)	16-20353
31	NUT, (.250-28)	11-826709109	11-33825, 11-35045
32	BRACKET ASSEMBLY	814283A2
33	LATCH	98889
34	DRIVE SCREW	10-42975
35	CUP	39519
36	WEAR PLATE	52100
37	LATCH	8M0036768	38279
38	WASHER, (.2656 x .625 x .0625) Stainless Steel	12-35462
39	NUT, (.250-28)	11-826709109	11-33825, 11-35045
40	SCREW, (.312-18 x .880)	10-53167T
41	GUIDE BLOCK	814284
42	SPRING	24-20099
43	LINK ROD ASSEMBLY	67073A1
44	SHIFT SHAFT ASSEMBLY Comment: (LONG)	79932A16
44	SHIFT SHAFT ASSEMBLY Comment: (X-LONG)	79932A17
45	NOT SOLD SEPARATE, Roll Pin	NSS
46	NOT SOLD SEPARATE, Shift Shaft Lever-Upper	NSS
47	BUSHING	23-26856
48	WAVE WASHER	13-29720
49	WASHER, (.2656 x .625 x .0625) Stainless Steel	12-35462
50	NUT, (.250-28)	11-826709109	11-33825, 11-35045
51	IDLE STABILIZING SHIFT KIT Comment: 150/XR6/175 MAGNUM III	87-814281A1
52	SCREW, (#6-32 x .875) Comment: 150/XR6/175 MAGNUM III	10-77478
53	WASHER Comment: 150/XR6/175 MAGNUM III	12-27882
54	RESISTOR MODULE Comment: 150/XR6/175 MAGNUM III	17461A3

TOOLS, SPECIAL

Below is the parts list for Mercury XR-6 TOOLS, SPECIAL:

Position No.	Part Name	OEM Number	Supersedes
-	GAUGE TOOL, Carburetor Comment: (CARBRUETOR)	91-36392
-	ISOLATOR KIT, Battery Comment: ELECTRICAL/IGNITION	84-8M0094239	84-815366A 5 ELECTRICAL/IGNITION
-	DIAL INDICATOR TOOL Comment: ELECTRICAL/IGNITION	91-58222A1
-	ADAPTOR Comment: ELECTRICAL/IGNITION	91-890451
-	HOLDER TOOL Comment: ELECTRICAL/IGNITION	91-52344
-	PULLER KIT, Flywheel Comment: ELECTRICAL/IGNITION	91-849154T1
-	MULTI METER Comment: ELECTRICAL/IGNITION	91-99750A1
-	CAP TOOL, Flywheel Puller Comment: ELECTRICAL/IGNITION	91-24161
-	SWITCH ASSEMBLY Comment: ELECTRICAL/IGNITION	91-52024A1
-	SERVICE TACHOMETER Comment: ELECTRICAL/IGNITION	91-59339
-	TESTER, Eight Chamber, EIGHT CHAMBER Comment: ELECTRICAL/IGNITION	91-850439T1
-	GAP TOOL, Single Chamber, SINGLE CHAMBER Comment: ELECTRICAL/IGNITION	91-63998A1
-	SPARK TESTER Comment: ELECTRICAL/IGNITION	91-850439T1
-	HARNESS ASSEMBLY, Test Comment: ELECTRICAL/IGNITION	91-14443A1
-	TIMING LIGHT Comment: ELECTRICAL/IGNITION	91-99379
-	GAUGE TOOL Comment: POWERHEAD	91-29287
-	SLEEVE Comment: POWERHEAD	91-55919
-	HOLDER TOOL Comment: POWERHEAD	91-52344
-	PULLER KIT, Flywheel Comment: POWERHEAD	91-849154T1
-	LIFTING EYE Comment: POWERHEAD	91-904551
-	INSTALLER KIT Comment: POWERHEAD	91-77109A3
-	REMOVAL TOOL, Piston Pin Lock Ring Comment: POWERHEAD	91-52952T1
-	INSTALLER KIT, Piston Pin Comment: POWERHEAD	91-74607A3
-	COMPRESSOR TOOL, Ring (2.0L) Comment: POWERHEAD	91-65494T
-	COMPRESSOR TOOL, Piston Ring (2.5L) Comment: POWERHEAD	91-818773T	91-818773 POWERHEAD
-	EXPANDER TOOL, Piston Ring Comment: POWERHEAD	91-24697
-	STAND TOOL, Powerhead Comment: POWERHEAD	91-30591T1
-	CAP TOOL, Flywheel Puller Comment: POWERHEAD	91-24161
-	TORQUE WRENCH, (0-150 lb-in) Comment: POWERHEAD	91-66274
-	PULLER PLATE Comment: POWERHEAD	91-37241
-	ALIGNMENT TOOL Comment: TRIM/TILT SYSTEM	91-112301
-	MULTI METER Comment: TRIM/TILT SYSTEM	91-99750A1
-	TEST GAUGE KIT Comment: TRIM/TILT SYSTEM	91-52915A6
-	SPANNER WRENCH Comment: TRIM/TILT SYSTEM	91-74951
-	HEAT LAMP Comment: TRIM/TILT SYSTEM	91-63209
-	REMOVER TOOL, Trim Rod Guide Comment: TRIM/TILT SYSTEM	91-44487T1
-	REMOVAL TOOL, Trim Rod Comment: TRIM/TILT SYSTEM	91-44486A1
-	INDICATOR TOOL, Backlash Comment: GEAR HOUSING	91-8M0053505	91-78473 GEAR HOUSING
-	INDICATOR TOOL, Backlash Comment: GEAR HOUSING	91-196601
-	MANDREL, Bearing Driver Cup Comment: GEAR HOUSING	91-31106T
-	DRIVER TOOL, Bearing Cup Comment: GEAR HOUSING	91-87120T
-	PRE LOAD TOOL, Bearing Comment: GEAR HOUSING	91-14311A04
-	INSTALLATION TOOL, Bearing Comment: GEAR HOUSING	91-18601
-	PULLER KIT, Bearing Comment: GEAR HOUSING	91-31229A7
-	MANDREL Comment: GEAR HOUSING	91-15755T
-	DRIVE HEAD TOOL Comment: GEAR HOUSING	91-36569T
-	DRIVER ROD TOOL, Needle Bearings Comment: GEAR HOUSING	91-37323
-	PILOT WASHER Comment: GEAR HOUSING	91-36571T
-	INSTALLATION TOOL, Bearing Comment: GEAR HOUSING	91-38628T
-	NUT, (.625-18) Comment: GEAR HOUSING	11-24156
-	PLATE Comment: GEAR HOUSING	91-29310
-	WASHER Comment: GEAR HOUSING	12-34961
-	WRENCH, Bearing Retainer Comment: GEAR HOUSING	91-43506T
-	INSTALL TOOL, Cross Pin Comment: GEAR HOUSING	91-86642
-	TOOL, Cover Nut Comment: GEAR HOUSING	91-73688
-	DIAL INDICATOR TOOL Comment: GEAR HOUSING	91-58222A1
-	HOLDING TOOL, Dial Indicator Comment: GEAR HOUSING	91-89897
-	FOWARD GEAR INSTALLATION TOOL Comment: GEAR HOUSING	91-815850
-	INSTALLER TOOL, Needle Bearing Comment: GEAR HOUSING	91-86943T
-	WRENCH, Bearing Carrier Retainer Comment: GEAR HOUSING	91-61069T
-	GUIDE PLATE Comment: GEAR HOUSING	91-816243
-	PULLER JAWS Comment: GEAR HOUSING	91-816242
-	WASHER Comment: GEAR HOUSING	12-37429
-	MANDREL Comment: GEAR HOUSING	91-92788T
-	DRIVER TOOL, Oil Seal Comment: GEAR HOUSING	91-31108T
-	LOCATION TOOL, Pinion Comment: GEAR HOUSING	91-12349A05
-	LOCATION TOOL, Pinion Gear Comment: GEAR HOUSING	91-74776T
-	PROPELLER SHAFT Comment: GEAR HOUSING	44-93003
-	INSTALLER TOOL, Bearing Comment: GEAR HOUSING	91-816292
-	PULLER TOOL Comment: GEAR HOUSING	91-85716
-	PULLER JAW ASSEMBLY Comment: GEAR HOUSING	91-46086A1
-	PULLER PLATE Comment: GEAR HOUSING	91-37241
-	INSTALLATION TOOL, Bearing Adaptor Comment: GEAR HOUSING	91-18605A2
-	PULLER ASSEMBLY, Slide Hammer Comment: GEAR HOUSING	91-34569A1
-	REMOVAL/INSTALL TOOL, Shift Shaft Bushing	91-31107T
-	TORQUE WRENCH, (0-150 lb-in)	91-66274
-	GAUGE TOOL, Carburetor Comment: (CARBRUETOR)	91-36392
-	ISOLATOR KIT, Battery Comment: ELECTRICAL/IGNITION	84-8M0094239	84-815366A 5 ELECTRICAL/IGNITION
-	DIAL INDICATOR TOOL Comment: ELECTRICAL/IGNITION	91-58222A1
-	ADAPTOR Comment: ELECTRICAL/IGNITION	91-890451
-	HOLDER TOOL Comment: ELECTRICAL/IGNITION	91-52344
-	PULLER KIT, Flywheel Comment: ELECTRICAL/IGNITION	91-849154T1
-	MULTI METER Comment: ELECTRICAL/IGNITION	91-99750A1
-	CAP TOOL, Flywheel Puller Comment: ELECTRICAL/IGNITION	91-24161
-	SWITCH ASSEMBLY Comment: ELECTRICAL/IGNITION	91-52024A1
-	SERVICE TACHOMETER Comment: ELECTRICAL/IGNITION	91-59339
-	TESTER, Eight Chamber, EIGHT CHAMBER Comment: ELECTRICAL/IGNITION	91-850439T1
-	GAP TOOL, Single Chamber, SINGLE CHAMBER Comment: ELECTRICAL/IGNITION	91-63998A1
-	SPARK TESTER Comment: ELECTRICAL/IGNITION	91-850439T1
-	HARNESS ASSEMBLY, Test Comment: ELECTRICAL/IGNITION	91-14443A1
-	TIMING LIGHT Comment: ELECTRICAL/IGNITION	91-99379
-	GAUGE TOOL Comment: POWERHEAD	91-29287
-	SLEEVE Comment: POWERHEAD	91-55919
-	HOLDER TOOL Comment: POWERHEAD	91-52344
-	PULLER KIT, Flywheel Comment: POWERHEAD	91-849154T1
-	LIFTING EYE Comment: POWERHEAD	91-904551
-	INSTALLER KIT Comment: POWERHEAD	91-77109A3
-	REMOVAL TOOL, Piston Pin Lock Ring Comment: POWERHEAD	91-52952T1
-	INSTALLER KIT, Piston Pin Comment: POWERHEAD	91-74607A3
-	COMPRESSOR TOOL, Ring (2.0L) Comment: POWERHEAD	91-65494T
-	COMPRESSOR TOOL, Piston Ring (2.5L) Comment: POWERHEAD	91-818773T	91-818773 POWERHEAD
-	EXPANDER TOOL, Piston Ring Comment: POWERHEAD	91-24697
-	STAND TOOL, Powerhead Comment: POWERHEAD	91-30591T1
-	CAP TOOL, Flywheel Puller Comment: POWERHEAD	91-24161
-	TORQUE WRENCH, (0-150 lb-in) Comment: POWERHEAD	91-66274
-	PULLER PLATE Comment: POWERHEAD	91-37241
-	ALIGNMENT TOOL Comment: TRIM/TILT SYSTEM	91-112301
-	MULTI METER Comment: TRIM/TILT SYSTEM	91-99750A1
-	TEST GAUGE KIT Comment: TRIM/TILT SYSTEM	91-52915A6
-	SPANNER WRENCH Comment: TRIM/TILT SYSTEM	91-74951
-	HEAT LAMP Comment: TRIM/TILT SYSTEM	91-63209
-	REMOVER TOOL, Trim Rod Guide Comment: TRIM/TILT SYSTEM	91-44487T1
-	REMOVAL TOOL, Trim Rod Comment: TRIM/TILT SYSTEM	91-44486A1
-	INDICATOR TOOL, Backlash Comment: GEAR HOUSING	91-8M0053505	91-78473 GEAR HOUSING
-	INDICATOR TOOL, Backlash Comment: GEAR HOUSING	91-196601
-	MANDREL, Bearing Driver Cup Comment: GEAR HOUSING	91-31106T
-	DRIVER TOOL, Bearing Cup Comment: GEAR HOUSING	91-87120T
-	PRE LOAD TOOL, Bearing Comment: GEAR HOUSING	91-14311A04
-	INSTALLATION TOOL, Bearing Comment: GEAR HOUSING	91-18601
-	PULLER KIT, Bearing Comment: GEAR HOUSING	91-31229A7
-	MANDREL Comment: GEAR HOUSING	91-15755T
-	DRIVE HEAD TOOL Comment: GEAR HOUSING	91-36569T
-	DRIVER ROD TOOL, Needle Bearings Comment: GEAR HOUSING	91-37323
-	PILOT WASHER Comment: GEAR HOUSING	91-36571T
-	INSTALLATION TOOL, Bearing Comment: GEAR HOUSING	91-38628T
-	NUT, (.625-18) Comment: GEAR HOUSING	11-24156
-	PLATE Comment: GEAR HOUSING	91-29310
-	WASHER Comment: GEAR HOUSING	12-34961
-	WRENCH, Bearing Retainer Comment: GEAR HOUSING	91-43506T
-	INSTALL TOOL, Cross Pin Comment: GEAR HOUSING	91-86642
-	TOOL, Cover Nut Comment: GEAR HOUSING	91-73688
-	DIAL INDICATOR TOOL Comment: GEAR HOUSING	91-58222A1
-	HOLDING TOOL, Dial Indicator Comment: GEAR HOUSING	91-89897
-	FOWARD GEAR INSTALLATION TOOL Comment: GEAR HOUSING	91-815850
-	INSTALLER TOOL, Needle Bearing Comment: GEAR HOUSING	91-86943T
-	WRENCH, Bearing Carrier Retainer Comment: GEAR HOUSING	91-61069T
-	GUIDE PLATE Comment: GEAR HOUSING	91-816243
-	PULLER JAWS Comment: GEAR HOUSING	91-816242
-	WASHER Comment: GEAR HOUSING	12-37429
-	MANDREL Comment: GEAR HOUSING	91-92788T
-	DRIVER TOOL, Oil Seal Comment: GEAR HOUSING	91-31108T
-	LOCATION TOOL, Pinion Comment: GEAR HOUSING	91-12349A05
-	LOCATION TOOL, Pinion Gear Comment: GEAR HOUSING	91-74776T
-	PROPELLER SHAFT Comment: GEAR HOUSING	44-93003
-	INSTALLER TOOL, Bearing Comment: GEAR HOUSING	91-816292
-	PULLER TOOL Comment: GEAR HOUSING	91-85716
-	PULLER JAW ASSEMBLY Comment: GEAR HOUSING	91-46086A1
-	PULLER PLATE Comment: GEAR HOUSING	91-37241
-	INSTALLATION TOOL, Bearing Adaptor Comment: GEAR HOUSING	91-18605A2
-	PULLER ASSEMBLY, Slide Hammer Comment: GEAR HOUSING	91-34569A1
-	REMOVAL/INSTALL TOOL, Shift Shaft Bushing	91-31107T
-	TORQUE WRENCH, (0-150 lb-in)	91-66274

TOP COWL

Below is the parts list for Mercury XR-6 TOP COWL:

Position No.	Part Name	OEM Number	Supersedes
1	TOP COWL ASSEMBLY, Black Comment: (BLACK)	4021-827328T7
1	TOP COWL ASSEMBLY, Silver Comment: (SILVER)	4021-827328T8
2	INLET, Air Comment: (BLACK)	821256T03	821256T 1 (BLACK)
2	INLET, Air Comment: (SILVER)	821256T2
3	SCREW, (M6 x 16)	10-82130016
4	SOUND BLANKET KIT	828344A1
5	NOT SOLD SEPARATE, Sound Blanket (TOP)	NSS
6	CAP PLUG	19-823865
7	HANDLE Comment: (BLACK)	831207A16	831207A14, 831207T 3, 831207T10 (BLACK)
7	HANDLE Comment: (SILVER)	831207A15	831207A 4 (SILVER)
8	BUSHING	23-812707	23-71984, 23-F286818, 23-F286828, F480818
9	SPACER	23-831214
10	WASHER, Wave	13-12134
11	CAM, Latch Shaft	8M0001081	889566, F481777, F48177
12	WASHER	12-8M0214930
13	LOCKWASHER, (.250) Stainless Steel	13-26992
14	SCREW, (.250-20 x .620) Stainless Steel	10-28635
15	BRACKET, Front	8M0036792	821249M 2
16	BUMPER, Latch	815477
17	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
18	NUT, (M6)	11-401366
19	RING, Retaining	53-8237951
20	ROLLER	8M0207770
21	PIN, Roll	8155381
22	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
23	NUT, (M6)	11-401366
24	ROPE AND HANDLE KIT, Manual Starting	47341A11
25	NOT SOLD SEPARATE, Decal-Starting Procedure	NSS
1	TOP COWL ASSEMBLY, Black Comment: (BLACK)	4021-827328T7
1	TOP COWL ASSEMBLY, Silver Comment: (SILVER)	4021-827328T8
2	INLET, Air Comment: (BLACK)	821256T03	821256T 1 (BLACK)
2	INLET, Air Comment: (SILVER)	821256T2
3	SCREW, (M6 x 16)	10-82130016
4	SOUND BLANKET KIT	828344A1
5	NOT SOLD SEPARATE, Sound Blanket (TOP)	NSS
6	CAP PLUG	19-823865
7	HANDLE Comment: (BLACK)	831207A16	831207A14, 831207T 3, 831207T10 (BLACK)
7	HANDLE Comment: (SILVER)	831207A15	831207A 4 (SILVER)
8	BUSHING	23-812707	23-71984, 23-F286818, 23-F286828, F480818
9	SPACER	23-831214
10	WASHER, Wave	13-12134
11	CAM, Latch Shaft	8M0001081	889566, F481777, F48177
12	WASHER	12-8M0214930
13	LOCKWASHER, (.250) Stainless Steel	13-26992
14	SCREW, (.250-20 x .620) Stainless Steel	10-28635
15	BRACKET, Front	8M0036792	821249M 2
16	BUMPER, Latch	815477
17	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
18	NUT, (M6)	11-401366
19	RING, Retaining	53-8237951
20	ROLLER	8M0207770
21	PIN, Roll	8155381
22	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
23	NUT, (M6)	11-401366
24	ROPE AND HANDLE KIT, Manual Starting	47341A11
25	NOT SOLD SEPARATE, Decal-Starting Procedure	NSS

Throttle Lever and Shift Shaft

Below is the parts list for Mercury XR-6 Throttle Lever and Shift Shaft:

Position No.	Part Name	OEM Number	Supersedes
1	LEVER	8M0040990	850389 1
2	SCREW, (.375-16 x 1.75)	10-818165	10-55337
3	BUSHING	23-55164
4	WASHER, (.391 x .880 x .125) Stainless Steel	12-74759
5	WASHER, (.390 x .625 x .062) Stainless Steel	12-37828
6	SCREW, (.250-20 x 2.125)	10-64022
7	NUT, (.250-20)	11-64015
8	CAP, Nylon	26852
9	INSERT	42927
10	WASHER	12-35459
11	NUT, (M6)	11-401386
12	CAM	856221A1
13	BUSHING	23-852970
14	SCREW, (M6 x 40)	10-82130040
15	BUSHING	23-8M0215006
16	BALL, Threaded	8235694
17	LINK	8508152
18	ROLLER	67748
19	ROLLER, Throttle	8502861
20	SCREW, (M5 x 16)	10-40056107
21	WASHER, (.203 x .406 x .040)	12-89302
22	LOCKWASHER, External	10,13-69432
23	BRACKET, Anchor	814283T6
24	LATCH	98889
25	DRIVE SCREW	10-42975
26	CUP	39519
27	WEAR PLATE	52100
28	LATCH	8M0036768	38279
29	WASHER, (.2656 x .625 x .0625) Stainless Steel	12-35462
30	NUT, (.250-28)	11-826709109	11-33825, 11-35045
31	SCREW, (.312-18 x .880) Stainless Steel	10-28782
32	GUIDE BLOCK	814284
33	SPRING	24-20099
34	LINK ROD ASSEMBLY	67073A1
35	SHIFT SHAFT ASSEMBLY Comment: (LONG)	79932A16
35	SHIFT SHAFT ASSEMBLY Comment: (X-LONG)	79932A17
36	NOT SOLD SEPARATE, Roll Pin	NSS
37	NOT SOLD SEPARATE, Shift Shaft Lever-Upper	NSS
38	BUSHING	23-26856
39	WAVE WASHER	13-29720
40	WASHER, (.2656 x .625 x .0625) Stainless Steel	12-35462
41	NUT, (.250-28)	11-826709109	11-33825, 11-35045
42	SWITCH	87-8M0052931	87-814281A 2
43	SCREW, (#6-32 x .875)	10-77478
44	WASHER	12-27882

Tools, Special

Below is the parts list for Mercury XR-6 Tools, Special:

Position No.	Part Name	OEM Number	Supersedes
-	INDICATOR TOOL, Backlash Comment: GEAR HOUSING	91-8M0053505	91-78473 GEAR HOUSING
-	INDICATOR TOOL, Backlash Comment: GEAR HOUSING	91-196601
-	MANDREL, Bearing Driver Cup Comment: GEAR HOUSING	91-31106T
-	DRIVER TOOL, Bearing Cup Comment: GEAR HOUSING	91-87120T
-	INSTALLATION TOOL, Bearing Comment: GEAR HOUSING	91-18601
-	PRE LOAD TOOL, Bearing Comment: GEAR HOUSING	91-14311A04
-	PULLER KIT, Bearing Comment: GEAR HOUSING	91-31229A7
-	MANDREL Comment: GEAR HOUSING	91-15755T
-	DRIVE HEAD TOOL Comment: GEAR HOUSING	91-36569T
-	DRIVER ROD TOOL, Needle Bearings Comment: GEAR HOUSING	91-37323
-	PILOT WASHER Comment: GEAR HOUSING	91-36571T
-	INSTALLATION TOOL, Bearing Comment: GEAR HOUSING	91-38628T
-	NUT, (.625-18) Comment: GEAR HOUSING	11-24156
-	PLATE Comment: GEAR HOUSING	91-29310
-	WASHER Comment: GEAR HOUSING	12-34961
-	RETAINING TOOL, Bearing Comment: GEAR HOUSING	91-43506T
-	TOOL, Cover Nut Comment: GEAR HOUSING	91-73688
-	INSTALL TOOL, Cross Pin Comment: GEAR HOUSING	91-86642
-	DIAL INDICATOR TOOL Comment: GEAR HOUSING	91-58222A1
-	HOLDING TOOL, Dial Indicator Comment: GEAR HOUSING	91-89897
-	FOWARD GEAR INSTALLATION TOOL Comment: GEAR HOUSING	91-815850
-	INSTALLER TOOL, Needle Bearing - Forward Gear Comment: GEAR HOUSING	91-86943T
-	NUT TOOL, Gear Housing Cover Comment: GEAR HOUSING	91-61069T
-	GUIDE PLATE Comment: GEAR HOUSING	91-816243
-	PULLER JAWS Comment: GEAR HOUSING	91-816242
-	WASHER Comment: GEAR HOUSING	12-37429
-	MANDREL Comment: GEAR HOUSING	91-92788T
-	DRIVER TOOL, Oil Seal Comment: GEAR HOUSING	91-31108T
-	LOCATION TOOL, Pinion Comment: GEAR HOUSING	91-12349A05
-	LOCATION TOOL, Pinion Gear Comment: GEAR HOUSING	91-74776T
-	PROPELLER SHAFT Comment: GEAR HOUSING	44-93003
-	INSTALLER TOOL, Bearing Comment: GEAR HOUSING	91-816292
-	PULLER TOOL Comment: GEAR HOUSING	91-85716
-	PULLER JAW ASSEMBLY Comment: GEAR HOUSING	91-46086A1
-	PULLER PLATE Comment: GEAR HOUSING	91-37241
-	INSTALLATION TOOL, Bearing Adaptor Comment: GEAR HOUSING	91-18605A2
-	PULLER ASSEMBLY, Slide Hammer Comment: GEAR HOUSING	91-34569A1
-	REMOVAL/INSTALL TOOL, Shift Shaft Bushing Comment: GEAR HOUSING	91-31107T
-	TORQUE WRENCH, (0-150 lb-in) Comment: GEAR HOUSING	91-66274
-	ISOLATOR KIT, Battery Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	84-8M0094239	84-815366A 5 ELECTRICAL/IGNITION TRIM/TILT SYSTEM
-	CARTRIDGE Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	91-8226086
-	HARNESS ASSEMBLY, DDT Adaptor Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	84-822560A5
-	HOLDER TOOL Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	91-52344
-	PULLER KIT, Flywheel Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	91-849154T1
-	CABLE ASSEMBLY, DDT Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	84-825003A1
-	DIGITAL DIAGNOSTIC TESTER Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	91-823686A2
-	MULTI METER Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	91-99750A1
-	SWITCH ASSEMBLY Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	91-52024A1
-	SERVICE TACHOMETER Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	91-59339
-	TESTER, Eight Chamber, EIGHT CHAMBER Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	91-850439T1
-	GAP TOOL, Single Chamber, SINGLE CHAMBER Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	91-63998A1
-	TESTER Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	91-850439T1
-	TACH INTERFACE MODULE Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	91-825824A2
-	TIMING LIGHT Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	91-99379
-	ALIGNMENT TOOL Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	91-112301
-	MULTI METER Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	91-99750A1
-	TEST GAUGE KIT Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	91-52915A6
-	SPANNER WRENCH Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	91-74951
-	HEAT LAMP Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	91-63209
-	REMOVER TOOL, Trim Rod Guide Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	91-44487T1
-	REMOVAL TOOL, Trim Rod Comment: ELECTRICAL/IGNITION TRIM/TILT SYSTEM	91-44486A1
-	GAUGE TOOL Comment: POWERHEAD	91-29287
-	SLEEVE Comment: POWERHEAD	91-55919
-	HOLDER TOOL Comment: POWERHEAD	91-52344
-	PULLER KIT, Flywheel Comment: POWERHEAD	91-849154T1
-	LIFTING EYE Comment: POWERHEAD	91-904551
-	INSTALLER KIT Comment: POWERHEAD	91-77109A3
-	REMOVAL TOOL, Piston Pin Lock Ring Comment: POWERHEAD	91-52952T1
-	EXPANDER TOOL, Piston Ring Comment: POWERHEAD	91-24697
-	INSTALLER KIT, Piston Pin Comment: POWERHEAD	91-74607A3
-	STAND TOOL Comment: POWERHEAD	91-30591T1
-	CAP TOOL, Flywheel Puller Comment: POWERHEAD	91-24161
-	COMPRESSOR TOOL, Ring Comment: POWERHEAD	91-823237T	91-823237 POWERHEAD
-	COMPRESSOR TOOL, Ring (2.0L) Comment: POWERHEAD	91-65494T
-	COMPRESSOR TOOL (2.5L) Comment: POWERHEAD	91-818773T	91-818773 POWERHEAD
-	TORQUE WRENCH, (0-150 lb-in) Comment: POWERHEAD	91-66274
-	PULLER PLATE Comment: POWERHEAD	91-37241
-	PRESSURE GAUGE Comment: DFI	91-881834A1
-	SCREW, (M5 x 25) Comment: DFI	10-4007325
-	INSTALLATION TOOL, Seal/Teflon Ring Comment: DFI	91-8519803
-	SIZING TOOL, Seal/Teflon Ring Comment: DFI	91-8519802
-	GAUGE KIT Comment: DFI	91-881833A03	91-881833A 2 DFI
-	MULTI METER Comment: DFI	91-99750A1

Top Cowl

Below is the parts list for Mercury XR-6 Top Cowl:

Position No.	Part Name	OEM Number	Supersedes
1	TOP COWL ASSEMBLY Comment: (BLACK)	4021-852552T3
1	TOP COWL ASSEMBLY Comment: (SILVER)	4021-852552T4
2	INLET, Air - Black Comment: (BLACK)	821256T03	821256T 1 (BLACK)
2	INLET, Air Comment: (SILVER)	821256T2
3	SCREW, (M6 x 16)	10-82130016
4	SOUND BLANKET KIT	854607A1
5	NOT SOLD SEPARATE, Sound Blanket-Top Back	NSS
6	NOT SOLD SEPARATE, Sound Blanket-Port	NSS
7	NOT SOLD SEPARATE, Sound Blanket-Starboard	NSS
8	NOT SOLD SEPARATE, Sound Blanket-Front	NSS
9	NOT SOLD SEPARATE, Sound Blanket-Back	NSS
10	CAP PLUG	19-823865
11	HANDLE ASSEMBLY, Black Comment: (BLACK)	831207A16	831207A14, 831207T 3, 831207T10 (BLACK)
11	HANDLE Comment: (SILVER)	831207A15	831207A 4 (SILVER)
12	BUSHING	23-812707	23-71984, 23-F286818, 23-F286828, F480818
13	SPACER	23-831214
14	WASHER, Wave	13-12134
15	CAM, Latch Shaft	8M0001081	889566, F481777, F48177
16	WASHER	12-8M0214930
17	LOCKWASHER, (.250) Stainless Steel	13-26992
18	SCREW, (.250-20 x .620) Stainless Steel	10-28635
19	BRACKET, Front	8M0036792	821249M 2
20	BUMPER, Latch	815477
21	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
22	NUT, (M6)	11-401366
23	RING, Retaining	53-8237951
24	ROLLER	8M0207770
25	PIN, Roll	8155381
26	WASHER, (.281 x .500 x .060) Stainless Steel	12-8M0204649
27	NOT SOLD SEPARATE, Decal-Counter Rotation	NSS
28	NOT SOLD SEPARATE, Decal-Break In	NSS

Transom Brackets

Below is the parts list for Mercury XR-6 Transom Brackets:

Position No.	Part Name	OEM Number	Supersedes
1	BRACKET ASSEMBLY, Transom-Starboard	3426-828334T03
2	BRACKET ASSEMBLY, Transom-Port	3425-828333T08
3	FITTING, Grease Comment: (PORT)	22-8M0169588
4	TILT TUBE	826125A1
5	NUT, (1.00-14) Brass/Nickel Plate	11-826135
6	O-RING, (.612 x .103)	25-45711
7	WASHER	13-88750
8	NUT, (.875-14)	11-826164
9	SCREW, (.500-20 x 4.500)	10-8M0149747
10	WASHER, (1.5 x 3.05 x 0.13) Stainless Steel	12-8M0204648
11	NUT, (.500-20)	11-91962
12	LEVER ASSEMBLY	8M0115104	8M0115103, 99629T 2
13	SPRING, Tension	24-830899
14	NYLINER	23-65830
15	SPRING, Compression	24-830900
16	KNOB	99633
17	PIN, Groove	17-99615
18	PIN	17-893709	17-99617
1	BRACKET ASSEMBLY, Transom-Starboard	3426-828334T03
2	BRACKET ASSEMBLY, Transom-Port	3425-828333T08
3	FITTING, Grease Comment: (PORT)	22-8M0169588
4	TILT TUBE	826125A1
5	NUT, (1.00-14) Brass/Nickel Plate	11-826135
6	O-RING, (.612 x .103)	25-45711
7	WASHER	13-88750
8	NUT, (.875-14)	11-826164
9	SCREW, (.500-20 x 4.500)	10-8M0149747
10	WASHER, (1.5 x 3.05 x 0.13) Stainless Steel	12-8M0204648
11	NUT, (.500-20)	11-91962
12	LEVER ASSEMBLY	8M0115104	8M0115103, 99629T 2
13	SPRING, Tension	24-830899
14	NYLINER	23-65830
15	SPRING, Compression	24-830900
16	KNOB	99633
17	PIN, Groove	17-99615
18	PIN	17-893709	17-99617
1	BRACKET ASSEMBLY, Transom-Starboard	3426-828334T03
2	BRACKET ASSEMBLY, Transom-Port	3425-828333T08
3	FITTING, Grease Comment: (PORT)	22-8M0169588
4	TILT TUBE	826125A1
5	NUT, (1.00-14) Brass/Nickel Plate	11-826135
6	O-RING, (.612 x .103)	25-45711
7	WASHER	13-88750
8	NUT, (.875-14)	11-826164
9	SCREW, (.500-20 x 4.500)	10-8M0149747
10	WASHER, (1.5 x 3.05 x 0.13) Stainless Steel	12-8M0204648
11	NUT, (.500-20)	11-91962
12	LEVER ASSEMBLY	8M0115104	8M0115103, 99629T 2
13	SPRING, Tension	24-830899
14	NYLINER	23-65830
15	SPRING, Compression	24-830900
16	KNOB	99633
17	PIN, Groove	17-99615
18	PIN	17-893709	17-99617

Vapor Separator Components

Below is the parts list for Mercury XR-6 Vapor Separator Components:

Position No.	Part Name	OEM Number	Supersedes
1	COVER KIT	855432A1
2	FITTING, Straight, STRAIGHT	22-8568431
3	FITTING, (90 Degree)	22-196881
4	SEAL	26-803878
5	FITTING KIT, Pump Outlet	22-855437A2
6	NOT SOLD SEPARATE, O Ring	NSS
7	SCREW AND WASHER, (#8-32 x .750)	1395-808612	1399-5132
8	GASKET	27-855528
9	FLOAT KIT	8M6004920
10	SHAFT	F10064
11	VALVE, Needle	8M6004917
12	SCREW, (#6-32 x .187)	1395-5902
13	PUMP KIT	855427A1
14	SLEEVE	8M6000589	23-855428
15	BOWL KIT	855434A1
16	SEAL	26-8554331
17	PLUG KIT	19-855435A1
18	ELBOW	22-8554245
19	FILTER KIT	35-18458Q4
20	PROBE	8M0204710

WIRING HARNESS/STARTER SOLENOID

Below is the parts list for Mercury XR-6 WIRING HARNESS/STARTER SOLENOID:

Position No.	Part Name	OEM Number	Supersedes
1	HARNESS ASSEMBLY, Engine Wiring	84-826730A4
2	FUSE, 20 Ampere	88-8M0207796
3	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
4	TERMINAL BLOCK	86-194372
5	SCREW, (.190-32 x .620)	10-38055
6	WASHER, (.203 x .406 x .040)	12-89302
7	NUT, Brass	10-32,11-45076
8	CLAMP	54-814634
9	IGNITION PLATE	434292
10	SWITCHBOX ASSEMBLY	332-7778A12
11	SCREW, (#12-24 x 2.00)	10-13669
12	BUSHING	23-94453
13	CABLE ASSEMBLY	84-62310A2
14	NUT, Brass	10-32,11-45076
15	CABLE ASSEMBLY (3 IN. - WHITE/BLACK)	84-91865A1
15	CABLE ASSEMBLY (6 IN. - RED/WHITE)	84-88528A2
16	WIRE ASSEMBLY	84-60871A10
17	SCREW, (#10-16 x .380)	10-878607	10-817626
18	CABLE ASSEMBLY, Black	84-65999A3
19	SCREW, (#10-32 x .500)	10-87926
20	SCREW, (.312-18 x 1.250)	10-60411
21	LOCKWASHER, (.312)	13-8M0204647
22	WASHER	12-36042
23	WASHER, (Rubber)	12-67264
24	BUSHING	23-67268
25	CABLE ASSEMBLY, Positive - Battery	84-88439A34
25	CABLE ASSEMBLY, Negative - Battery	84-88439A24
26	SCREW, (.250-20 x 1.120)	10-455611
27	LOCKWASHER, (.250) Stainless Steel	13-26992
28	CABLE ASSEMBLY, Black	84-65999A2
29	INSULATOR	85-78866
30	NUT, Brass	10-32,11-45076
31	SOLENOID ASSEMBLY, (#10-32 / .3125-18 Terminals)	89-817109A2
32	GROMMET	25-822179
33	BUSHING	23-8M0214955
34	NUT, Brass	10-32,11-45076
35	LOCKWASHER, (.312)	13-53166
36	NUT, (.312-18)	11-8M0204668
1	HARNESS ASSEMBLY, Engine Wiring	84-826730A4
2	FUSE, 20 Ampere	88-8M0207796
3	TIE STRAP, (8.00 Inches)	54-816311T	54-816311, 54-90077, 54-826785, F1877, F717046-1, F717046, MAF03001, 833188E, 54-F9301, 54-816311100, 54-898101111, 54-898101275
4	TERMINAL BLOCK	86-194372
5	SCREW, (.190-32 x .620)	10-38055
6	WASHER, (.203 x .406 x .040)	12-89302
7	NUT, Brass	10-32,11-45076
8	CLAMP	54-814634
9	IGNITION PLATE	434292
10	SWITCHBOX ASSEMBLY	332-7778A12
11	SCREW, (#12-24 x 2.00)	10-13669
12	BUSHING	23-94453
13	CABLE ASSEMBLY	84-62310A2
14	NUT, Brass	10-32,11-45076
15	CABLE ASSEMBLY (3 IN. - WHITE/BLACK)	84-91865A1
15	CABLE ASSEMBLY (6 IN. - RED/WHITE)	84-88528A2
16	WIRE ASSEMBLY	84-60871A10
17	SCREW, (#10-16 x .380)	10-878607	10-817626
18	CABLE ASSEMBLY, Black	84-65999A3
19	SCREW, (#10-32 x .500)	10-87926
20	SCREW, (.312-18 x 1.250)	10-60411
21	LOCKWASHER, (.312)	13-8M0204647
22	WASHER	12-36042
23	WASHER, (Rubber)	12-67264
24	BUSHING	23-67268
25	CABLE ASSEMBLY, Positive - Battery	84-88439A34
25	CABLE ASSEMBLY, Negative - Battery	84-88439A24
26	SCREW, (.250-20 x 1.120)	10-455611
27	LOCKWASHER, (.250) Stainless Steel	13-26992
28	CABLE ASSEMBLY, Black	84-65999A2
29	INSULATOR	85-78866
30	NUT, Brass	10-32,11-45076
31	SOLENOID ASSEMBLY, (#10-32 / .3125-18 Terminals)	89-817109A2
32	GROMMET	25-822179
33	BUSHING	23-8M0214955
34	NUT, Brass	10-32,11-45076
35	LOCKWASHER, (.312)	13-53166
36	NUT, (.312-18)	11-8M0204668

Download this page as PDF: Click here

For Mercury Owners:

To assist you in maintaining and repairing your marine engines, we hope the following resources may be of use:

Mercury / Mercruiser / Mariner Parts from JLM Marine

About JLM Marine

Founded in 2002, JLM Marine has established itself as a dedicated manufacturer of high-quality marine parts, based in China. Our commitment to excellence in manufacturing has earned us the trust of top marine brands globally.

As a direct supplier, we bypass intermediaries, which allows us to offer competitive prices without compromising on quality. This approach not only supports cost-efficiency but also ensures that our customers receive the best value directly from the source.

We are excited to expand our reach through retail channels, bringing our expertise and commitment to quality directly to boat owners and enthusiasts worldwide.
