17461-98501 Outboard Impeller for Suzuki DT4 DT5 DT6 DT8 DF4 DF6 | JLM Marine

17461-98501 Outboard Impeller for Suzuki DT4 DT5 DT6 DT8 DF4 DF6

This high-quality aftermarket water pump impeller is designed to fit a wide range of Suzuki outboard engines, including both 2-stroke and 4-stroke models from 4 HP to 8 HP. It ensures reliable cooling system performance for DT4, DT5, DT6, DT8, DF4, and DF6 engines spanning production years from the early 1980s through 2003 and later.

This impeller directly replaces OEM part numbers 17461-98501, 17461-98502, and 17461-98503, providing a cost-effective solution for routine maintenance or emergency repairs.

• Complete impeller ready for installation
• Compatible with both 2-stroke and 4-stroke Suzuki outboards
• Essential for maintaining proper engine cooling

Part Number Cross-Reference

Use this table to confirm equivalent part numbers across OEM and aftermarket brands.

Compatible Engine Models

Confirm your engine model/year in the table below. For Suzuki owners, you can review exploded diagrams here to verify part numbers: Suzuki Parts Diagrams & Catalog.

Package Contents

• 1 × Outboard Impeller

Installation Guide

1. Disconnect the fuel line and remove the lower unit from the outboard motor following your engine's service manual.
2. Locate and remove the water pump housing cover, typically secured by several bolts.
3. Carefully extract the old impeller from the pump housing, noting the direction of the vanes.
4. Inspect the pump housing and wear plate for damage or excessive wear; replace if necessary.
5. Lubricate the new impeller with glycerin, soapy water, or water pump grease to ease installation.
6. Insert the new impeller into the housing, ensuring the vanes face the correct direction (same as the original).
7. Align the impeller drive pin or key with the driveshaft slot during installation.
8. Reinstall the water pump housing cover and torque bolts to the manufacturer's specifications.
9. Reattach the lower unit to the outboard, ensuring all seals and O-rings are properly seated.
10. Reconnect the fuel line and refill the lower unit gear oil if drained.
11. Test the cooling system by running the engine in a test tank or on muffs, checking for proper water flow from the tell-tale outlet.

Troubleshooting & FAQ

Q: How do I confirm this impeller fits my Suzuki outboard?
A: Cross-reference your engine model and year with the compatibility table above. You can also verify the OEM part number (17461-98501, 17461-98502, or 17461-98503) using the Suzuki parts diagrams linked in the compatibility section.

Q: How often should I replace my water pump impeller?
A: Most manufacturers recommend replacing the impeller every 2-3 years or 200-300 hours of operation, whichever comes first. If you notice overheating, reduced water flow from the tell-tale, or visible cracking/wear on the vanes, replace it immediately.

Q: What are the signs of a failing impeller?
A: Common symptoms include engine overheating, weak or no water discharge from the tell-tale (pilot hole), steam from the engine, or an audible temperature alarm. Inspect the impeller if any of these occur.

Q: Can I use this impeller on both 2-stroke and 4-stroke Suzuki engines?
A: Yes, this impeller is compatible with both 2-stroke models (DT4, DT5, DT6, DT8) and 4-stroke models (DF4, DF6) as listed in the compatibility table.

Q: Is this an OEM part or aftermarket?
A: This listing is an aftermarket replacement part (not an OEM component). We build to OEM specifications using comparable-grade materials. Production is done in an ISO9002-certified facility, and each batch is inspected for consistent performance.

Q: How fast do you ship and how much does it cost?
A: We offer fast global shipping—typically 5–15 days worldwide—and standard shipping is free. Expedited options are available at checkout depending on your location.

Q: What is your warranty and return policy?
A: This product includes a 1-year warranty against manufacturing defects under normal use. If something goes wrong, contact our support team with your order details. Returns are accepted within our standard return window (unused & in original condition); please see our policy page or reach out for instructions.

Important Notes

• Verify that the product images and specifications match your original part. If discrepancies exist—even if your model is listed—do not proceed with the purchase.
• This product is an aftermarket replacement part and is not an OEM component.
• Professional installation is recommended to ensure safety and optimal performance.
