Carburetor Assembly – Fits Mercury Mariner 4HP, 5HP & 6HP (4-Stroke)

This aftermarket carburetor assembly is designed for Mercury Mariner 4-stroke outboards, including 4HP, 5HP, and 6HP models. It delivers reliable fuel mixing and engine performance, making it an ideal replacement for worn or damaged OEM carburetors.

Direct Replacement for OEM Part Number: 3R4-03200-1. Also replaces Tohatsu equivalent part number 3R4-03200-1, ensuring broad compatibility across multiple engine configurations.

• Complete carburetor assembly with gasket for easy installation
• Enables performance upgrade: turn your 4HP/5HP engine into 6HP output
• Precision-engineered for optimal fuel delivery and throttle response

Part Number Cross-Reference

Use this table to confirm equivalent part numbers across OEM and aftermarket brands.

Compatible Engine Models

Confirm your engine model/year in the table below. For Mercury owners, here's a guide to help you identify your engine's serial/model: Mercury Serial Number Guide. You can also review exploded diagrams to verify part numbers: Mercury Parts Diagrams & Catalog.

Technical Specifications

Package Contents

• Carburetor Assembly (Complete)
• Gasket (Part No. 27-803508013)

Installation Guide

1. Disconnect the fuel line from the old carburetor and ensure the engine is off and cool.
2. Remove the air intake cover and air filter assembly to access the carburetor mounting.
3. Disconnect the throttle linkage and choke cable from the old carburetor. Take note of their positions for reassembly.
4. Unbolt the old carburetor from the intake manifold using the appropriate socket or wrench.
5. Remove the old gasket and clean the mounting surface thoroughly to ensure a proper seal.
6. Install the new gasket (included) onto the intake manifold, aligning all bolt holes.
7. Position the new carburetor onto the gasket and hand-tighten the mounting bolts.
8. Torque the mounting bolts evenly in a cross pattern to manufacturer specifications to prevent warping.
9. Reconnect the throttle linkage and choke cable to the new carburetor, ensuring smooth operation.
10. Attach the fuel line securely to the carburetor inlet and check for any kinks or damage.
11. Reinstall the air filter assembly and air intake cover, ensuring all clamps are tight.
12. Prime the fuel system and start the engine. Adjust idle speed and mixture settings as needed for optimal performance.
