Exhaust Mixing Elbow 845261 – Cast Iron – Fits Volvo Penta 30/40

Exhaust Mixing Elbow 845261 – Cast Iron – Fits Volvo Penta 30/40

$228.80
Description

How to Match This Part

This aftermarket exhaust mixing elbow replaces Volvo Penta reference 845261. It mixes raw cooling water with exhaust gas and routes the mixture away from the engine on compatible Volvo Penta 30- and 40-series marine diesels.

Match this part in this order:
1. Original part number on the elbow or parts list (845261; earlier engines may show 843217)
2. Engine model on the engine identification plate
3. Physical form against the product images

Confirm a square mounting flange, a ~90° elbow bend, a water-injection port near the flange, and a dual-wall discharge outlet with an inner pipe and hose bead before ordering. See the product images for flange orientation and outlet detail.

Part Number Cross-Reference

Use this table to confirm equivalent part numbers across OEM and aftermarket brands.

Reference Type Brand Part Number Notes
Primary OEM Reference Volvo Penta 845261 Exhaust pipe elbow
Supersession Volvo Penta 843217 Earlier elbow superseded by 845261 (related hardware may apply on early engines)
Aftermarket Sierra Marine 18-4007 Aftermarket replacement
Aftermarket HGE HGE5261 Aftermarket replacement

Compatible Engine Models

Confirm your engine model in the table below. Match the original part number and the physical shape to the product images. On Volvo Penta inboards, the model and serial identification are typically on the engine block or flywheel housing—not on an outboard transom bracket.

Brand Engine Model
Volvo Penta AD30A, AQAD30A, TAMD30A, TMD30A
Volvo Penta AD40B, AQD40A, AQAD40A, AQAD40B, MD40A, TAMD40A, TAMD40B, TMD40A, TMD40B, TMD40C

Technical Specifications

Specification Value
Product type Exhaust mixing elbow
Material Cast iron
Water inlet 1-1/4" (32 mm)
Exhaust outlet 4" (101 mm)
Bend Approximately 90°
Mounting flange Square flange
Outlet form Dual-wall outlet with inner pipe and hose bead

Installation Guide

1

Allow the engine to cool completely and disconnect the battery before working on the exhaust system.

2

Support the exhaust hose, then remove the old elbow. Protect the manifold mating face from damage.

3

Clean the flange face and compare the new elbow’s flange, water port, and outlet to the removed part and the product images.

4

Install with the gasket and fasteners specified in your Volvo Penta parts list or service manual. Tighten evenly to the manual’s torque values.

5

Reconnect the water and exhaust hoses, secure all clamps, refill cooling water as required, and check for leaks at idle before returning to service.

Note: Follow the Volvo Penta service manual for torque and gasket requirements. Professional installation is recommended.

Troubleshooting & FAQ

Is this an OEM or aftermarket part? +

This is an aftermarket replacement manufactured to match the Volvo Penta 845261 application. It is not a genuine Volvo Penta OEM part.

Does a gasket or hose-barb kit come with this elbow? +

Do not assume a mounting gasket, hose barb, or hardware kit is included. Use the gasket and related parts called out in your Volvo Penta parts list unless your order confirmation states otherwise.

My old number is 843217 — will 845261 fit? +

845261 supersedes the earlier 843217 elbow on the applications listed here. Early engines may also need the additional connector/gasket hardware noted in the Volvo Penta parts catalog—confirm against your serial-number parts list before ordering.

Is this the same as a stainless “kit” elbow sold elsewhere? +

No. This listing is for the cast-iron style elbow shown in the product images. Stainless kit assemblies sold under other brand SKUs are different products and may include extra fittings not shown here.
