Dual Octagon Transom Saver Kit – Yellow – Fits 2/3 Ram Systems – Includes 2 Trailering Motor Locks

Product Overview

This Dual Octagon Transom Saver Kit includes two Yellow octagon supports and two Orange trailering motor locks / hydraulic steering stabilizer clips. Use two supports to balance the load on multi-ram (2/3 ram) tilt/trim systems during trailering — helping reduce strain on the transom and hydraulic components while the locks limit steering swing.

Material: marine-grade high-density EPDM rubber with reinforced polymer housing — rust-free vs traditional metal bars; safe for saltwater and freshwater. Aftermarket alternative to QuickMarine / M-Y Wedge style trailering supports for Yamaha, Mercury, Honda, Suzuki, Tohatsu, and Evinrude/Johnson. Not OEM or an authorized QuickMarine dealer part — verify ram count and clearance before ordering. Designed to support typical trailering loads.

What's Included

• 2 × Yellow Octagon Transom Saver supports
• 2 × Orange trailering motor locks / hydraulic steering stabilizer clips
• Contents match the product photo for this color kit

Package: 2 × Yellow octagon supports + 2 × Orange trailering motor locks

Compatibility

Intended for many 2/3 ram outboard trim & tilt systems from Yamaha, Mercury, Honda, Suzuki, Tohatsu, and Evinrude/Johnson.

• Confirm your motor has two or three main tilt/trim rams
• Recommend balancing the load with two supports on multi-ram setups
• Always verify clearance against the product photo and your ram diameter

Fitment is by ram configuration — not by inventing horsepower or year ranges. Contact us with brand/model photos if unsure.

Technical Specs

Installation Notes

1. Trim the outboard to a high trailering position.
2. Identify the main tilt/trim ram (and second ram if using a dual-body kit).
3. Place the support body onto the exposed ram so it seats between the engine and transom bracket area.
4. Slowly lower the motor until the support is lightly compressed and the engine feels stable.
5. Repeat with the second support on the other ram for balanced load.
6. Clip the trailering motor locks onto the hydraulic steering cylinder to limit side-to-side movement (when included).
7. Before launching, raise the motor slightly and remove the support(s) and locks.

Do not force-fit. If the body does not seat cleanly, stop and verify ram style/clearance.

FAQ

Q: Single-ram or multi-ram?
A: Match the kit to your trim/tilt ram count. Single-body kits suit most single-ram motors; dual-body kits are recommended for balanced support on 2/3-ram systems.

Q: What do the trailering motor locks do?
A: The included hydraulic steering stabilizer clips clip onto the steering cylinder to reduce side-to-side engine swing while trailering.

Q: Is this OEM or QuickMarine authentic?
A: No. This is an aftermarket alternative for common QuickMarine / M-Y Wedge style trailering supports — not an OEM or licensed QuickMarine part.

Q: Color / shape for this SKU?
A: This listing is the Yellow dual octagon kit with Orange locks. Use the product photo as the package reference.
