Water Pump Impeller – Fits Suzuki 50-85 HP (Replaces 17461-95300, 17461-95301)

Water Pump Impeller – Fits Suzuki 50-85 HP (Replaces 17461-95300, 17461-95301)

This water pump impeller is designed for Suzuki 2-stroke outboard engines, specifically the 50-85 HP DT50, DT75, and DT85 series manufactured between approximately 1978 and 2000. It provides an efficient and reliable cooling solution for your engine.

It serves as a direct replacement for Suzuki part numbers 17461-95300, 17461-95301, 17461-95501, and 17461-95302, as well as aftermarket parts from Sierra (18-3095), Mallory Marine (9-45502), and CEF (500360).

• Direct Fit: Installs using the original press-fit with key connection method.
• Durable Construction: Made from a robust blend of neoprene and hardened nylon for longevity and reliable performance.
• Package Includes: 1 x Water Pump Impeller.

Part Number Cross-Reference

Use this table to confirm equivalent part numbers across OEM and aftermarket brands.

Compatible Engine Models

Confirm your engine model/year in the table below. For Suzuki owners, You can review exploded diagrams here to verify part numbers: Suzuki Parts Diagrams & Catalog.

Technical Specifications

Package Contents

1 x Water Pump Impeller (Replaces 17461-95300/17461-95301/17461-95501/17461-95302)

Explosion Diagram

Installation Guide

1. Safety First: Disconnect the negative battery cable and ensure the engine is off and cool. Shut off the fuel supply.
2. Access the Lower Unit: Remove the mounting bolts securing the lower unit (gearcase) to the outboard's midsection and carefully lower it.
3. Open the Pump Housing: Locate the water pump assembly on top of the lower unit. Remove the bolts holding the pump cover in place.
4. Remove Old Impeller: Carefully slide the old impeller off the driveshaft. Take note of the direction the blades are curved.
5. Clean and Inspect: Clean any debris or corrosion from the inside of the pump housing and wear plate. Inspect them for deep scoring or warping and replace if necessary.
6. Install New Impeller: Lightly lubricate the inside of the housing and the new impeller with marine grease. Slide the new impeller onto the driveshaft, turning it in the direction of engine rotation (usually clockwise) to seat the blades correctly.
7. Reassemble Pump: Reinstall the pump cover and torque the bolts to the manufacturer's specified values.
8. Reattach Lower Unit: Raise the lower unit back into position, ensuring the driveshaft and water tube align correctly. Securely fasten the mounting bolts.
9. Test Operation: Reconnect the battery. Start the engine using a water supply (flushing muffs or in the water) and confirm a strong, steady stream from the telltale outlet.

Troubleshooting & FAQ

Q: How do I confirm this impeller fits my Suzuki engine?
A: Check the "Compatible Engine Models" table. This part is a confirmed fit for Suzuki DT50, DT75, and DT85 models from 1978-2000. For DT60 models, compatibility is based on secondary sources, so we strongly recommend verifying your original part number before ordering.

Q: What are the signs of a failing water pump impeller?
A: Common signs include the engine overheating alarm sounding, a weak or non-existent water stream from the "telltale" outlet, or a noticeable decrease in water pressure at idle.

Q: How often should I replace my outboard's impeller?
A: For preventative maintenance, it is recommended to inspect the impeller annually and replace it every 1-2 years, depending on usage. If you frequently operate in saltwater or sandy/murky conditions, annual replacement is advisable.

Q: OEM vs. Aftermarket?
A: This listing is an aftermarket replacement part (not an OEM component). We build to OEM specifications using comparable-grade materials. Production is done in an ISO9002-certified facility, and each batch is inspected for consistent performance.

Q: How fast do you ship and how much does it cost?
A: We offer fast global shipping—typically 5–15 days worldwide—and standard shipping is free. Expedited options are available at checkout depending on your location.

Q: What is your warranty and return policy?
A: This product includes a 1-year warranty against manufacturing defects under normal use. If something goes wrong, contact our support team with your order details. Returns are accepted within our standard return window (unused & in original condition); please see our policy page or reach out for instructions.

Important Notes

• Verify that the product images and specifications match your original part. If discrepancies exist—even if your model is listed—do not proceed with the purchase.
• This product is an aftermarket replacement part and is not an OEM component.
• Professional installation is recommended to ensure safety and optimal performance.
