Fuel Line Connector – Fits Johnson/Evinrude Outboards (Replaces 174508, 176745, 775640)

Fuel Line Connector – Fits Johnson/Evinrude Outboards

For Johnson/Evinrude outboard motors. This female fuel connector is designed for 5/16" fuel lines, ensuring a reliable, leak-free connection. It is compatible with a wide range of Johnson/Evinrude outboards that utilize this common fitting size.

This part is a direct replacement for Sierra 18-8056, EMP 22-00819, Mallory Marine 9-38014, Moeller Marine 033410-10, and Evinrude/Johnson 174508, 176745, 775640.

• Designed for 5/16" marine fuel lines.
• Features a quick-connect female fitting for easy installation.
• Compatible with marine gasoline and ethanol-blended fuels.

Part Number Cross-Reference

Use this table to confirm equivalent part numbers across OEM and aftermarket brands.

Compatible Engine Models

Confirm your engine model/year in the table below. For Johnson/Evinrude owners, here’s a guide to help you identify your engine’s serial/model: Johnson/Evinrude Serial Number Guide.

Technical Specifications

Package Contents

• 1 x Fuel Line Connector (Replaces 174508 / 176745 / 775640)

Installation Guide

1. Safety First: Ensure the engine is off, cool, and in a well-ventilated area. Disconnect the battery.
2. Locate Old Connector: Identify the existing female fuel line connector on the 5/16" fuel line.
3. Disconnect Old Part: Release the old connector from the engine-side male fitting and release any hose clamps securing it to the fuel line.
4. Remove from Hose: Carefully pull the old connector off the fuel hose. Be prepared for minor fuel spillage; have rags ready.
5. Install New Connector: Slide the new fuel line connector onto the end of the 5/16" fuel hose and secure it firmly with the hose clamp.
6. Connect to Engine: Push the new female connector onto the male fitting on the engine until it clicks securely into place, ensuring the O-ring creates a proper seal.
7. Check for Leaks: Prime the fuel system using the primer bulb. Carefully inspect the new connection for any signs of fuel leaks.
8. Final Test: Reconnect the battery, start the engine, and monitor the connection for any leaks.

Troubleshooting & FAQ

Q: How do I know if this connector will fit my Johnson/Evinrude engine?

A: This connector is designed for Johnson/Evinrude outboards that use a 5/16" fuel line. Please verify your fuel line size and compare your existing connector to the images and cross-referenced part numbers (174508, 176745, 775640) to ensure a match.

Q: What causes a fuel line connector to fail?

A: Failure is often due to a degraded or cracked internal O-ring, which leads to air leaks and fuel delivery problems. Physical damage from impact or material fatigue from age and ethanol exposure can also cause the housing to crack or fail.

Q: Is this a male or female connector?

A: This is a female quick-disconnect connector that attaches to the fuel line. It mates with the male connector on the engine or fuel tank side (such as part 18-8063).

Q: OEM vs. Aftermarket?

A: This listing is an aftermarket replacement part (not an OEM component). We build to OEM specifications using comparable-grade materials. Production is done in an ISO9002-certified facility, and each batch is inspected for consistent performance.

Q: How fast do you ship and how much does it cost?

A: We offer fast global shipping—typically 5–15 days worldwide—and standard shipping is free. Expedited options are available at checkout depending on your location.

Q: What is your warranty and return policy?

A: This product includes a 1-year warranty against manufacturing defects under normal use. If something goes wrong, contact our support team with your order details. Returns are accepted within our standard return window (unused & in original condition); please see our policy page or reach out for instructions.

Important Notes

• Verify that the product images and specifications match your original part. If discrepancies exist—even if your model is listed—do not proceed with the purchase.
• This product is an aftermarket replacement part and is not an OEM component.
• Professional installation is recommended to ensure safety and optimal performance.
