Water Pump Impeller – Fits Yamaha 9.9-15 HP Outboards (Replaces 63V-44352-01-00, 6E5-44352-01-00)

Water Pump Impeller – Fits Yamaha 9.9-15 HP Outboards (Replaces 63V-44352-01-00, 6E5-44352-01-00)

This water pump impeller fits a wide range of Yamaha 9.9 HP and 15 HP, 2-Stroke and 4-Stroke outboard motors from 1984 to present. As a critical component of the engine's cooling system, regular replacement prevents overheating and ensures reliable performance.

This part is a direct replacement for Yamaha OEM part numbers 63V-44352-01-00 and 6E5-44352-01-00, Quicksilver 8M6010335, Sierra 18-3040, and older aftermarket number 682-W0078-00.

• Installation Location: Mounts inside the lower unit water pump housing.
• Durable Construction: Made from high-quality, corrosion-resistant rubber with a 6-blade design to ensure proper water flow.
• Package Contents: Includes the impeller only. Note: Hardware and gaskets are sold separately.

Part Number Cross-Reference

Use this table to confirm equivalent part numbers across OEM and aftermarket brands.

Compatible Engine Models

Confirm your engine model/year in the table below. For Yamaha owners, here’s a guide to help you identify your engine’s serial/model: Yamaha Serial Number Guide. You can also review exploded diagrams to verify part numbers: Yamaha Parts Diagrams & Catalog.

Technical Specifications

Package Contents

• 1 x Water Pump Impeller (Replaces 63V-44352-01-00)
• Note: Gaskets, wear plates, and other hardware are not included.

Installation Guide

Professional installation is recommended. The following are general guidelines and not a substitute for an official service manual.

1. Disconnect the battery and shift the outboard into the neutral position.
2. Place a drain pan under the lower unit and remove the gearcase oil drain screw to empty the oil.
3. Remove the bolts that secure the lower unit to the upper engine casing.
4. Carefully separate the lower unit from the rest of the outboard.
5. Locate the water pump housing on the lower unit and remove its mounting bolts.
6. Lift the housing to expose the old impeller. Take note of the blade direction.
7. Slide the old impeller off the driveshaft. Clean the interior of the pump housing and the wear plate.
8. Slide the new impeller onto the driveshaft. Turn the driveshaft clockwise while pushing down to help seat the blades in the correct orientation.
9. Reinstall the water pump housing, using new gaskets if necessary.
10. Reattach the lower unit, ensuring the driveshaft, water tube, and shift shaft are correctly aligned.
11. Secure the lower unit bolts to the manufacturer's specified torque.
12. Refill the gearcase with new marine gear lubricant before operating.

Troubleshooting & FAQ

How do I confirm this fits my engine?

This impeller is designed for Yamaha 9.9 HP and 15 HP (2-stroke and 4-stroke) models. The best way to ensure fitment is to match your engine's model and year against the "Compatible Engine Models" chart and verify your existing part number with our "Part Number Cross-Reference" table.

How often should I replace the water pump impeller?

For preventative maintenance, it is recommended to replace the impeller every 2-3 years or after 200-300 hours of use. If you notice a weak water stream from the tell-tale outlet or receive an engine overheating alarm, the impeller should be inspected and replaced immediately.

What is the difference between the 63V and 682 series part numbers?

The 63V-44352-01-00 part number generally corresponds to newer 4-stroke Yamaha 9.9/15 HP models, while the 682-W0078 series fits older 2-stroke models (typically 1984-1995). Our aftermarket impeller is engineered to replace both versions, providing broad compatibility.

OEM vs. Aftermarket?

This listing is an aftermarket replacement part (not an OEM component). We build to OEM specifications using comparable-grade materials. Production is done in an ISO9002-certified facility, and each batch is inspected for consistent performance.

How fast do you ship and how much does it cost?

We offer fast global shipping—typically 5–15 days worldwide—and standard shipping is free. Expedited options are available at checkout depending on your location.

What is your warranty and return policy?

This product includes a 1-year warranty against manufacturing defects under normal use. If something goes wrong, contact our support team with your order details. Returns are accepted within our standard return window (unused & in original condition); please see our policy page or reach out for instructions.

Important Notes

• Verify that the product images and specifications match your original part. If discrepancies exist—even if your model is listed—do not proceed with the purchase.
• This product is an aftermarket replacement part and is not an OEM component.
• Professional installation is recommended to ensure safety and optimal performance.
