Water Pump Impeller – Fits Yamaha 6HP & 8HP Outboard Motors (Replaces 6G1-44352-00-00)

$17.50

Water Pump Impeller – Fits Yamaha 6HP & 8HP Outboard Motors (Replaces 6G1-44352-00-00)

$17.50

Water Pump Impeller – Fits Yamaha 6HP & 8HP Outboard Motors (Replaces 6G1-44352-00-00)

This water pump impeller is designed for a precise fit on a range of Yamaha and Mercury/Mariner 2-stroke outboard motors. It is compatible with Yamaha 6HP and 8HP models from 1984 to 2009, as well as Mercury/Mariner 6HP (6C, 6D) and 8HP (8C) series engines.

Engineered as a direct replacement for the original component, this impeller ensures reliable performance for your cooling system. It is cross-compatible with multiple OEM and aftermarket part numbers, facilitating a straightforward replacement process.

  • Material: High-strength Neoprene (CR) rubber for durability and longevity.
  • Included Component: Contains one water pump impeller.
  • Installation: Requires disassembly of the water pump housing.

Part Number Cross-Reference

Use this table to confirm equivalent part numbers across OEM and aftermarket brands.

Brand Part Number
Yamaha 6G1-44352-00-00 / 6G1-44352-00
Sierra 18-3066
Mercury 47-11590M
Mallory 9-45610
CEF 500302
GLM 89870

Compatible Engine Models

Confirm your engine model/year in the table below. For Yamaha owners, here’s a guide to help you identify your engine’s serial/model: Yamaha Serial Number Guide. You can also review exploded diagrams to verify part numbers: Yamaha Parts Diagrams & Catalog.

For Mercury owners, here’s a guide to help you identify your engine’s serial/model: Mercury Serial Number Guide. You can also review exploded diagrams to verify part numbers: Mercury Parts Diagrams & Catalog.

Yamaha 2-Stroke Outboard

Model Rated HP Stroke Years OEM Part No. Notes
6HP 6SJ 6 2-Stroke 1986 6G1-44352-00-00
6HP 6LJ 6 2-Stroke 1986 6G1-44352-00-00
6HP 6SH 6 2-Stroke 1987 6G1-44352-00-00
6HP 6LH 6 2-Stroke 1987 6G1-44352-00-00
6HP 6SG 6 2-Stroke 1988 6G1-44352-00-00
6HP 6LG 6 2-Stroke 1988 6G1-44352-00-00
6HP 6SF 6 2-Stroke 1989 6G1-44352-00-00
6HP 6LF 6 2-Stroke 1989 6G1-44352-00-00
6HP 6SD 6 2-Stroke 1990 6G1-44352-00-00
6HP 6LD 6 2-Stroke 1990 6G1-44352-00-00
6HP 6MSHP 6 2-Stroke 1991 6G1-44352-00-00
6HP 6MLHP 6 2-Stroke 1991 6G1-44352-00-00
6HP 6MSHQ 6 2-Stroke 1992 6G1-44352-00-00
6HP 6MLHQ 6 2-Stroke 1992 6G1-44352-00-00
6HP 6MSHR 6 2-Stroke 1993 6G1-44352-00-00
6HP 6MLHR 6 2-Stroke 1993 6G1-44352-00-00
6HP 6MSHS 6 2-Stroke 1994 6G1-44352-00-00
6HP 6MLHS 6 2-Stroke 1994 6G1-44352-00-00
6HP 6MSHT 6 2-Stroke 1995 6G1-44352-00-00
6HP 6MLHT 6 2-Stroke 1995 6G1-44352-00-00
6HP 6MSHU 6 2-Stroke 1996 6G1-44352-00-00
6HP 6MLHU 6 2-Stroke 1996 6G1-44352-00-00
6HP 6MSHV 6 2-Stroke 1997 6G1-44352-00-00
6HP 6MLHV 6 2-Stroke 1997 6G1-44352-00-00
6HP 6MSHW 6 2-Stroke 1998 6G1-44352-00-00
6HP 6MLHW 6 2-Stroke 1998 6G1-44352-00-00
6HP 6MSHX 6 2-Stroke 1999 6G1-44352-00-00
6HP 6MLHX 6 2-Stroke 1999 6G1-44352-00-00
6HP 6MSHY 6 2-Stroke 2000 6G1-44352-00-00
6HP 6MLHY 6 2-Stroke 2000 6G1-44352-00-00
8HP 8LN 8 2-Stroke 1984 6G1-44352-00-00
8HP 8SN 8 2-Stroke 1984 6G1-44352-00-00
8HP 8LK 8 2-Stroke 1985 6G1-44352-00-00
8HP 8SK 8 2-Stroke 1985 6G1-44352-00-00
8HP 8LJ 8 2-Stroke 1986 6G1-44352-00-00
8HP 8SJ 8 2-Stroke 1986 6G1-44352-00-00
8HP 8LH 8 2-Stroke 1987 6G1-44352-00-00
8HP 8SH 8 2-Stroke 1987 6G1-44352-00-00
8HP 8LG 8 2-Stroke 1988 6G1-44352-00-00
8HP 8SG 8 2-Stroke 1988 6G1-44352-00-00
8HP 8LF 8 2-Stroke 1989 6G1-44352-00-00
8HP 8SF 8 2-Stroke 1989 6G1-44352-00-00
8HP 8LD 8 2-Stroke 1990 6G1-44352-00-00
8HP 8SD 8 2-Stroke 1990 6G1-44352-00-00
8HP 8MSHP 8 2-Stroke 1991 6G1-44352-00-00
8HP 8MLHP 8 2-Stroke 1991 6G1-44352-00-00
8HP 8MSHQ 8 2-Stroke 1992 6G1-44352-00-00
8HP 8MLHQ 8 2-Stroke 1992 6G1-44352-00-00
8HP 8MSHR 8 2-Stroke 1993 6G1-44352-00-00
8HP 8MLHR 8 2-Stroke 1993 6G1-44352-00-00
8HP 8MSHS 8 2-Stroke 1994 6G1-44352-00-00
8HP 8MLHS 8 2-Stroke 1994 6G1-44352-00-00
8HP 8MSHT 8 2-Stroke 1995 6G1-44352-00-00
8HP 8MLHT 8 2-Stroke 1995 6G1-44352-00-00
8HP 8MSHU 8 2-Stroke 1996 6G1-44352-00-00
8HP 8MLHU 8 2-Stroke 1996 6G1-44352-00-00
8HP 8MSHV 8 2-Stroke 1997 6G1-44352-00-00
8HP 8MLHV 8 2-Stroke 1997 6G1-44352-00-00
8HP 8MSHW 8 2-Stroke 1998 6G1-44352-00-00
8HP 8MLHW 8 2-Stroke 1998 6G1-44352-00-00
8HP 8MSHX 8 2-Stroke 1999 6G1-44352-00-00
8HP 8MLHX 8 2-Stroke 1999 6G1-44352-00-00
8HP 8MSHY 8 2-Stroke 2000 6G1-44352-00-00
8HP 8MLHY 8 2-Stroke 2000 6G1-44352-00-00
8HP 8MSHZ 8 2-Stroke 2001 6G1-44352-00-00
8HP 8MSHA 8 2-Stroke 2002 6G1-44352-00-00
8HP 8MSHB 8 2-Stroke 2003 6G1-44352-00-00
8HP 8MSHC 8 2-Stroke 2004 6G1-44352-00-00
8HP 8MSHD 8 2-Stroke 2005 6G1-44352-00-00
8HP 8MSH 8 2-Stroke 2005–2009 6G1-44352-00-00 Years 2005-2009 models

Mercury/Mariner Outboard

Model Rated HP Stroke OEM Part No. Notes
6C 6 2-Stroke 47-11590M Serial # begins with 6H8
6D 6 2-Stroke 47-11590M Serial # begins with 6H6
8C 8 2-Stroke 47-11590M Serial # begins with 6G1

Technical Specifications

Specification Value
Product Type Water Pump Impeller
Material Neoprene Rubber / CR (Chloroprene Rubber)
Number of Blades 6
Impeller Height 17.85mm (0.70 inch) / 18.0mm (0.71 inch)
Overall Diameter 39.56mm (1.57 inch) / 40.0mm (1.57 inch)
Hub Shaft Diameter 11.80mm (0.46 inch) / 11.9mm (0.47 inch)
Weight 10g (0.35 oz)
Installation Direct replacement; requires water pump housing disassembly

Package Contents

  • 1 x Water Pump Impeller (Replaces OEM 6G1-44352-00-00)

Explosion Diagram

Explosion Diagram

Installation Guide

  1. Safety First: Disconnect the engine's battery and remove the spark plug wires to prevent accidental starting.
  2. Access the Lower Unit: Remove the bolts securing the gearcase (lower unit) to the engine's midsection and carefully lower it.
  3. Open Water Pump Housing: Locate the water pump assembly on top of the gearcase. Unscrew the bolts to remove the housing cover.
  4. Remove Old Impeller: Take note of the blade orientation. Pull the old impeller straight off the driveshaft. A key or pin may also need to be removed.
  5. Clean and Inspect: Thoroughly clean the inside of the housing and the wear plate. Check for scoring, warping, or corrosion and replace if necessary.
  6. Install New Impeller: Slide the new impeller onto the driveshaft. While pushing down, turn the driveshaft clockwise to help bend the blades in the correct direction.
  7. Reassemble Housing: Apply a light coat of marine grease to the inside of the housing and reinstall the cover, tightening the bolts to the manufacturer's specified torque.
  8. Reattach Lower Unit: Carefully guide the lower unit back into place, ensuring the driveshaft, shift shaft, and water tube align correctly. Secure with bolts.
  9. Test Operation: Reconnect the battery and spark plugs. Start the engine in a test tank or with a water flusher to confirm the cooling system is pumping water.

Troubleshooting & FAQ

Q: How do I confirm this fits my engine?
A: The best method is to compare your existing part's specifications and appearance with the images and data provided here. Check the compatible model tables and cross-reference your part number. When in doubt, use the linked guides to find your engine's model or serial number to be certain.

Q: What are the signs of a failing water pump impeller?
A: A weak or no water stream from the "tell-tale" port is the most common sign. Other indicators include engine overheating alarms, a hot-to-the-touch engine exterior, or reduced engine performance.

Q: How often should I replace the impeller?
A: For preventative maintenance, it is recommended to inspect the impeller annually and replace it every 1-2 years, depending on usage (hours) and operating conditions (saltwater vs. freshwater). An impeller can fail from age and disuse, not just from high hours.

Q: Is it necessary to buy a full water pump repair kit?
A: While this listing is for the impeller only, a full kit (which includes the housing, gaskets, and wear plate) is recommended if the existing housing shows signs of warping, scoring, or corrosion, as this can cause premature failure of a new impeller.

Q: OEM vs. Aftermarket?
A: This listing is an aftermarket replacement part (not an OEM component). We build to OEM specifications using comparable-grade materials. Production is done in an ISO9002-certified facility, and each batch is inspected for consistent performance.

Q: How fast do you ship and how much does it cost?
A: We offer fast global shipping—typically 5–15 days worldwide—and standard shipping is free. Expedited options are available at checkout depending on your location.

Q: What is your warranty and return policy?
A: This product includes a 1-year warranty against manufacturing defects under normal use. If something goes wrong, contact our support team with your order details. Returns are accepted within our standard return window (unused & in original condition); please see our policy page or reach out for instructions.

Important Notes

  • Verify that the product images and specifications match your original part. If discrepancies exist—even if your model is listed—do not proceed with the purchase.
  • This product is an aftermarket replacement part and is not an OEM component.
  • Professional installation is recommended to ensure safety and optimal performance.
